Cisco Catalyst 9200 Series Manuel

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

First Published: 2018-11-19

Last Modified: 2022-07-19

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

Product Overview 1

CHAPTER 1

Switch Models 1

Front Panel Components 3

10/100/1000 Ports 4

PoE and PoE+ Ports 4

Multigigabit Ethernet Ports 5

Management Ports 5

USB Type A Port 6

SD Card Slot 6

Uplink Ports 7

Internal Power Supply 9

Rear Panel 9

RFID Tag 10

StackWise Ports 10

Auxiliary Power Adapter 11

Power Supply Modules 11

Fan Modules 13

Ethernet Management Port 14

RJ-45 Console Port 14

Network Configurations 15

Preparing for Installation 17

CHAPTER 2

Safety Warnings 17

Installation Guidelines 19

Site Requirements 20

Temperature 21

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

iii

Air Flow 21

Humidity 22

Altitude 22

Dust and Particles 23

Air Quality 23

Corrosion 23

EMI and Radio Frequency Interference 24

Shock and Vibration 25

Power Source Interruptions 25

System Grounding 26

Maintaining Safety with Electricity 28

Preventing ESD Damage 29

Tools and Equipment 29

Verifying Switch Operation 30

Installing the Switch 31

CHAPTER 3

Shipping Box Contents 31

Planning a Switch Data Stack 32

Switch Stacking Guidelines 32

Data Stack Cabling Configurations 34

Data Stack Bandwidth and Partitioning Examples 35

Power-On Sequence for Switch Stacks 37

Mounting the Switch 38

Rack-Mounting 38

Attaching the Rack-Mount Brackets 40

Mounting the Switch in a Rack 41

Installing the Switch on a Table or Shelf 42

After Switch Installation 43

Connecting to the StackWise Ports 43

Connecting Devices to the Ethernet Ports 46

10/100/1000/Multigigabit Ethernet Port Connections 46

Auto-MDIX Connections 46

PoE and POE+ Port Connections 46

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Contents

Installing a Compact Switch 49

CHAPTER 4

Shipping Box Contents 49

Mounting the Switch 51

Mounting on a Desk or Shelf Without Mounting Screws 51

Mounting using the Mounting Tray and Screws 52

Mounting using the Mounting Tray and Magnet 55

Mounting Under a Desk or a Shelf 58

Mounting the Switch Using Rack Mount Brackets 62

Mounting the Switch on a DIN Rail 63

Connecting the System Ground 65

Attaching the Adapter Bracket to the Switch (Optional) 66

Installing the Power Cord Retainer (Optional) 69

Installing the Cable Guard (Optional) 71

Installing an SFP or SFP+ Module 73

10/100/1000 PoE and PoE+Port Connections 74

10/100/1000/Multigigabit Ethernet Port Connections 75

Auto-MDIX Connections 76

Installing a Network Module 77

CHAPTER 5

Installing a Network Module in the Switch 77

Safety Warnings 77

Installing a Network Module 78

Removing a Network Module 81

Finding the Network Module Serial Number 82

Installing and Removing Pluggable Transceiver Modules 83

Installing a Cisco Pluggable Transceiver Module 83

Removing a Cisco Pluggable Transceiver Module 85

Installing a Power Supply Unit 87

CHAPTER 6

Power Supply Modules Overview 87

Finding the Power Supply Module Serial Number 90

Installation Guidelines 91

Installing or Replacing an AC Power Supply Module 92

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Contents

Installing a Fan Module 95

CHAPTER 7

Fan Modules Overview 95

Installation Guidelines 96

Installing a Fan Module 97

Finding the Fan Module Serial Number 97

Configuring the Switch 99

CHAPTER 8

Configuring the Switch Using the Web User Interface 99

Configuring the Switch Using the CLI 99

Accessing the CLI Through the Console Port 99

Connecting the RJ45 Console Port 99

Connecting the USB Console Port 100

Installing the Microsoft Windows USB Device Driver 101

Installing the Cisco Microsoft Windows USB Driver 101

Installing the Silicon Labs Windows USB Device Driver 102

Uninstalling the Cisco Microsoft Windows USB Driver 102

Technical Specifications 103

APPENDIX A

Environmental and Physical Specifications 103

Specifications for the Power Supplies and Fans 107

Switch LEDs 109

APPENDIX B

LEDs 109

Console LED 110

System LED 110

ACTIVE LED 110

STACK LED 111

PoE LED 112

Port LEDs and Modes 112

Beacon LED 115

RJ-45 Console Port LED 115

Fan LED 116

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Contents

Uplink Port LEDs 116

Introduction ?

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

vii

Contents

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

viii

Contents

CHAPTER 1

Product Overview

•Switch Models, on page 1

•Front Panel Components, on page 3

•Rear Panel, on page 9

•Network Configurations, on page 15

Switch Models

The Cisco Catalyst 9200 Series switches have four modular (C9200) and eight fixed (C9200L) switch models.

The following tables describe all the available Cisco Catalyst 9200 Series switches and the features supported.

Table 1: C9200L Switch Models and Descriptions

DescriptionSwitch Model

Stackable 24x1G PoE+ ports; 4x1G SFP fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-24P-4G

Stackable 24x1G PoE+ ports; 4x10G SFP+ fixed uplink ports; 2

power supply slots; 2 fixed fans; supports StackWise-80.

C9200L-24P-4X

Stackable 24x1G ports; 4x1G SFP fixed uplink ports; 2 power supply

slots; 2 fixed fans; supports StackWise-80.

C9200L-24T-4G

Stackable 24x1G ports; 4x10G SFP+ fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-24T-4X

Stackable 48x1G PoE+ ports; 4x1G SFP fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-48P-4G

Stackable 48x1G PoE+ ports; 4x10G SFP+ fixed uplink ports; 2

power supply slots; 2 fixed fans; supports StackWise-80.

C9200L-48P-4X

Stackable 48x1G ports; 4x1G SFP fixed uplink ports; 2 power supply

slots; 2 fixed fans; supports StackWise-80.

C9200L-48T-4G

Stackable 48x1G ports; 4x10G SFP+ fixed uplink ports; 2 power

supply slots; 2 fixed fans; supports StackWise-80.

C9200L-48T-4X

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

DescriptionSwitch Model

Stackable 8xMultigigabit Ethernet PoE+ ports and 16x1G PoE+

ports; 4x10G SFP+ fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-24PXG-4X

Stackable 8xMultigigabit Ethernet PoE+ ports and 16x1G PoE+

ports; 2x25G SFP28 fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-24PXG-2Y

Stackable 12xMultigigabit Ethernet PoE+ ports and 36x1G PoE+

ports; 4x10G SFP+ fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-48PXG-4X

Stackable 8xMultigigabit Ethernet PoE+ ports and 40x1G PoE+

ports; 2x25G SFP28 fixed uplink ports; 2 power supply slots; 2 fixed

fans; supports StackWise-80.

C9200L-48PXG-2Y

Stackable 48x1G PoE+ ports with partial PoE support; 4x1G SFP

fixed uplink ports; 2 power supply slots; 2 fixed fans; supports

StackWise-80.

C9200L-48PL-4G

Stackable 48x1G PoE+ ports with partial PoE support; 4x10G SFP

fixed uplink ports; 2 power supply slots; 2 fixed fans; supports

StackWise-80.

C9200L-48PL-4X

Table 2: C9200 Switch Models and Descriptions

DescriptionSwitch Model

Stackable 24x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-24P

Stackable 24x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-24PB

Stackable 24x1G ports; 4x1G and 4x10G network modules for uplink

ports; 2 power supply slots; 2 field-replaceable fans; supports

StackWise-160.

C9200-24T

Stackable 48x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-48P

Stackable 48x1G PoE+ ports; 4x1G and 4x10G network modules

for uplink ports; 2 power supply slots; 2 field-replaceable fans;

supports StackWise-160.

C9200-48PB

Stackable 48x1G ports; 4x1G and 4x10G network modules for uplink

ports; 2 power supply slots; 2 field-replaceable fans; supports

StackWise-160.

C9200-48T

Cisco Catalyst 9200 Series Switches Hardware Installation Guide

Product Overview

Switch Models
