Installing the Cisco AS5300

This chapter guides you through the installation of the Cisco AS5300 universal access server and

includes the following sections:

•Required Tools and Equipment

•Setting Up the Chassis

•Connecting to the Network

•Connecting the Console Terminal and Modem

•Connecting to the Alarm Port

•Supplying Power

•Where to Go Next

Warning

Only trained and qualified personnel should be allowed to install or replace this equipment.

Warning

This equipment is intended to be grounded. Ensure that the host is connected to earth ground

during normal use.

Warning

Incorrect connection of this or connected equipment to the general purpose outlet could result in

a hazardous situation.

Required Tools and Equipment

The following items are included with the access server:

• 19- and 24-inch rack-mount brackets

• Rubber feet for desktop installation

• RJ-45-to-DB-9 female DTE adapter (labeled TERMINAL)

• RJ-45-to-DB-25 female DTE adapter (labeled TERMINAL)

• RJ-45-to-DB-25 male DCE adapter (labeled MODEM)

• RJ-45-to-RJ-45 rollover console cable

• ESD-preventive wrist strap

• Nylon cable tie

• Cable tie holder

• Grounding lug

You might need the following equipment, which is not included:

• Four screws for installing the access server in a rack

• Straight-through RJ-45-to-RJ-45 cable for an Ethernet connection

• Ethernet hub or PC with a network interface card for Ethernet LAN connections

• Up to four straight-through RJ-45-to-RJ-45 cables for T1 connections

• Up to four E1 cables for E1 connections

• PC running terminal emulation software for local administrative access

• Modem for remote administrative access

Setting Up the Chassis

You can set the chassis on a desktop or install it in a rack. Use the procedure in this section that

best meets the needs of your network:

•Setting the Chassis on a Desktop

•Rack-Mounting the Chassis

Warning

When installing the unit, the ground connection must always be made first and disconnected last.

Warning

This unit is intended for installation in restricted access areas. A restricted access area is where

access can only be gained by service personnel through the use of a special tool, lock and key, or

other means of security, and is controlled by the authority responsible for the location.

Setting the Chassis on a Desktop

The location of the chassis is extremely important for proper operation. Equipment placed too

close together, inadequate ventilation, and inaccessible panels can cause malfunctions and

shutdowns, and can make maintenance difficult. The following information will help you to plan

the location of the chassis:

• Plan for access to both front and rear panels of the chassis.

• Ensure that the room where the chassis operates has adequate ventilation. Remember that

electrical equipment generates heat. Ambient air temperature may not cool equipment to

acceptable operating temperatures without adequate ventilation.

Attach the rubber feet as shown in . Rubber feet are included in the accessory kit that shipped

with your access server.

Figure 3-1 Attaching the Rubber Feet

Rack-Mounting the Chassis

This section describes how to rack-mount the chassis. The access server arrives with 19-inch

rack-mount brackets and larger brackets for use with a 23- or 24-inch rack. (See .) You can also

order telco rack-mount brackets (see ). The part number for telco brackets is AS52/3RM-

TELCO-19"=.

The following information will help you plan your equipment rack configuration:

• Enclosed racks must have adequate ventilation. Ensure that the rack is not congested,

because each unit generates heat. An enclosed rack should have louvered sides and a fan to

provide cooling air. Heat generated by equipment near the bottom of the rack can be drawn

upward into the intake ports of the equipment above.

• When mounting a chassis in an open rack, ensure that the rack frame does not block the

intake or exhaust ports. If the chassis is installed on slides, check the position of the chassis when

it is seated in the rack.

• Baffles can isolate exhaust air from intake air, which also helps to draw cooling air through

the chassis. The best placement of the baffles depends on the airflow patterns in the rack, which

can be found by experimenting with different configurations.

• When equipment installed in a rack (particularly in an enclosed rack) fails, try operating the

equipment by itself, if possible. Power OFF other equipment in the rack (and in adjacent racks)

to allow the unit under test a maximum of cooling air and clean power.

• Install the chassis and external devices to which it will connect in a contiguous stack.

Warning

Before working on a chassis or working near power supplies, unplug the power

cord on AC units; disconnect the power at the circuit breaker on DC units.

Required Tools and Equipment

You need the following tools and equipment to rack-mount the chassis:

• Number 2 Phillips screwdriver (not included)

• Screws for attaching the chassis to the rack (not included)

• Rack-mount brackets

Figure 3-2 Standard Rack-Mount Brackets

Figure 3-3 Telco Rack-Mount Bracket

Attaching the Brackets

To install the chassis in a rack, attach the brackets in one of the following ways:

• With the standard brackets on the side panels of the access server with the front panel

forward or rear panel forward, as shown in and .

• With the telco brackets on the side panels of the access server with the rear panel forward, as

shown in .

Note Although the installations show the 19-inch brackets, the procedure is the same for the

larger brackets.

Figure 3-4 Standard Bracket Installation—Front Panel Forward

Figure 3-5 Standard Bracket Installation—Rear Panel Forward

Figure 3-6 Optional Telco Bracket Installation—Rear Panel Forward

Installing in a Rack

After the brackets are secured to the chassis, you can rack-mount the access server. Using the

screws that you provide, attach the chassis to the rack as shown in .

Figure 3-7 Attaching the Chassis to the 19-Inch Rack—Rear Panel Forward

Connecting to the Network

This section describes how to connect the access server to your network. The cables required to

connect the access server to a network are not provided. For ordering information, contact

customer service (see the section "Cisco Connection Online" in the "Preface") or see the

appendix "" for cable and port pinouts.

Warning

To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-

network voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV

circuits. Some LAN and WAN ports use both RJ-45 connectors. Use caution when connecting

cables.

Note Connect the alarm port only to a safety extra-low voltage (SELV) source using 22 AWG,

or thicker, copper wire. SELV ratings are maximum 30 Volts AC (RMS), maximum 60 Volts

DC, and maximum 50 VA power. The alarm port is rated for 2.0 Amps maximum current.

Warning

Do not work on the system or connect or disconnect cables during periods of lightning activity.

Caution

If the access server is configured with fewer than three feature cards, make sure that a blank slot

cover is installed over each open slot to ensure proper airflow.

Note The access server arrives with all cards already installed, unless you order a card

separately as a spare. Refer to the Cisco AS5300 Universal Access Server Module Installation

Guide for card installation instructions.

Connecting to an Ethernet Network

You can connect the access server to an Ethernet network by using a straight-through RJ-45-to-

RJ-45 Ethernet cable to connect the Ethernet 10BaseT or 10/100BaseT port to an Ethernet hub.

(See .)

Figure 3-8 Connecting to an Ethernet Hub (10BaseT Shown)

Connecting to a WAN

You can connect the access server to a WAN in the following ways:

• Use a straight-through RJ-45-to-RJ-45 cable to connect each T1/PRI port to an RJ-45 jack.

(See .)
