Cisco NCS 560-4 Manuel

Cisco NCS 560-4 Router Hardware Installation Guide

First Published: 2019-05-24

Last Modified: 2020-08-01

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

Cisco NCS 560-4 Router Overview 1

CHAPTER 1

Cisco NCS 560-4 Router Features 1

System Specifications 3

Fan Trays 3

Interface Modules 6

Digital Optical Monitoring 6

RSP Modules (N560-4-RSP4 and N560-4-RSP4E) 7

GNSS Module (A900-CM-GNSS) 8

Power Supply 9

Network Timing Interfaces 12

Online Insertion and Removal (OIR) 12

Regulatory Compliance 13

Preparing for Installation 15

CHAPTER 2

Safety Guidelines 15

Standard Warning Statements 15

Safety Guidelines for Personal Safety and Equipment Protection 17

Safety With Electricity 17

Power Supply Considerations 21

Preventing ESD Damage 21

Site Planning 22

General Precautions 22

Site Planning Checklist 22

Site Selection Guidelines 23

Environmental Requirements 23

Physical Characteristics 23

Cisco NCS 560-4 Router Hardware Installation Guide

iii

Assembly Guidelines 23

Air Flow Guidelines 23

Air Flow Guidelines for Enclosed Rack Installation 25

Floor Loading Considerations 25

Site Power Guidelines 25

Electrical Circuit Requirements 26

Site Cabling Guidelines 27

Asynchronous Terminal Connections 27

Interference Considerations 28

Rack-Mounting Guidelines 28

Precautions for Rack-Mounting 28

Rack Selection Guidelines 29

Cabinet Selection Guidelines 30

Equipment Rack Guidelines 31

Rack Compatibility 32

Rack Types 32

Installation Checklist 34

Creating a Site Log 34

Receiving the Cisco NCS 560-4 Router 35

Chassis-Lifting Guidelines 36

Tools and Equipment 36

Unpack and Verify Shipped Contents 37

Installing the Cisco NCS 560-4 Router 39

CHAPTER 3

Prerequisites 39

Installing the Router in a Rack 39

Assembling the Plenum (N560-4-F2B-AIR-U=) 42

Installing the Plenum on the Rack When Router is Not Installed on the Rack 45

Installing the Plenum on the Rack When Router is Installed on the Rack 52

Installing the Cisco NCS 560 Router Vertically 55

Attaching the Cable Management Brackets 62

Installing the Chassis Ground Connection 63

Installing the Power Supply 65

Preventing Power Loss 66

Cisco NCS 560-4 Router Hardware Installation Guide

Contents

Power Connection Guidelines 67

Guidelines for DC-Powered Systems 67

Guidelines for AC-Powered Systems 67

Installing the N560-PWR1200-D-E DC Power Supply Module 68

Installing the A900-PWR1200-D DC Power Supply Module 70

Activating the DC Power Supply 72

Removing and Replacing the DC Power Supply 72

Installing the AC Power Supply Module for A900-PWR1200-A (1200 W) 74

Recommended Power Cables 75

Activating the AC Power Supply 75

Removing and Replacing the AC Power Supply 76

Installing the Fan Trays 77

Removing and Replacing the Dust Filter 79

Dust Filter Maintenance 80

Removing and Replacing the Fan Trays 80

RSP Installation 82

Installing an RSP Module 82

Removing an RSP Module 84

Removing the IM Center Brackets 85

Interface Module Installation 86

Installing an Interface Module 87

Removing an Interface Module 88

Hot-Swapping an RSP or Interface Module 88

Installing Dust Caps 89

Securing the Cables Around the Cable Management Brackets 89

Connecting the Router to the Network 92

Connecting Console Cables 92

Connecting to the Serial Port using Microsoft Windows 93

Connecting to the Console Port using Mac OS X 94

Connecting to the Console Port using Linux 95

Installing the Cisco Microsoft Windows USB Device Driver 95

Installing the Cisco Microsoft Windows XP USB Driver 96

Installing the Cisco Microsoft Windows 2000 USB Driver 96

Installing the Cisco Microsoft Windows XP USB Driver 96

Cisco NCS 560-4 Router Hardware Installation Guide

Contents

Uninstalling the Cisco Microsoft Windows USB Driver 97

Uninstalling the Cisco Microsoft Windows XP and 2000 USB Driver Using the Setup.exe

Program 97

Uninstalling the Cisco Microsoft Windows XP and 2000 USB Driver Using the Add Remove

Programs Utility 97

Uninstalling the Cisco Microsoft Windows Vista USB Driver 98

Connecting to the Auxiliary Port 98

Connecting a Management Ethernet Cable 99

Installing and Removing SFP Modules 100

Connecting a USB Flash Device 100

Removing a USB Flash Device 100

Connecting Timing Cables 101

Connecting Cables to the BITS Interface 101

Connecting Cables to the Input 10Mhz or 1PPS Interface 101

Connecting Cables to the Output 10Mhz or 1PPS Interface 102

Connecting Cables to the ToD Interface 102

Connecting Cables to a GNSS Interface 102

Connecting a Cable to the GNSS Antenna Interface 103

Connecting Ethernet Cables 103

Connecting Cables to SFP Modules 104

Installing and Removing SFP Modules 104

Cisco Router Initial Configuration 105

CHAPTER 4

Pinout and LED Details 107

APPENDIX A

Pinouts 107

BITS Port Pinout 107

GPS Port Pinout 108

Time of Day Pinout 108

Alarm Port Pinout 109

Console/Aux RJ45 RS232 Serial Port Pinout 109

Management Ethernet Port Pinout 110

USB Console Port Pinout 111

USB Flash/MEM Port Pinout 111

Cisco NCS 560-4 Router Hardware Installation Guide

Contents

Fiber-Optic Specifications 112

Alarm Conditions 112

LED Summary 112

RSP LEDs 113

Interface Module LEDs 114

Fan Tray LEDs 116

Power Supply LEDs 117

Site Logs and Manufacturers 119

APPENDIX B

Manufacturers 119

Cisco NCS 560-4 Router Hardware Installation Guide

vii

Contents

Cisco NCS 560-4 Router Hardware Installation Guide

viii

Contents

CHAPTER 1

Cisco NCS 560-4 Router Overview

The Cisco NCS 560-4 (4RU) router, is a full-featured, modular and programmable aggregation router. It is

designed for the cost-effective delivery of converged mobile (IP RAN, Mobile xHaul), residential, and business

services (MEF CE 3.0, layer 2/layer 3 and EVPN). The Cisco NCS 560-4 router provides redundancy, shallow

depth, low power consumption, high Ethernet interface density, and high services scale, is optimized for

aggregation and remote Point-Of-Presence (POP) applications

•Cisco NCS 560-4 Router Features, on page 1

•System Specifications, on page 3

•Fan Trays, on page 3

•Interface Modules, on page 6

•Digital Optical Monitoring , on page 6

•RSP Modules (N560-4-RSP4 and N560-4-RSP4E), on page 7

•GNSS Module (A900-CM-GNSS), on page 8

•Power Supply, on page 9

•Network Timing Interfaces, on page 12

•Online Insertion and Removal (OIR), on page 12

•Regulatory Compliance, on page 13

Cisco NCS 560-4 Router Features

• Fully redundant and centralized forwarding

• Six Interface Module (IM) slots

• Aggregate backplane capacity of 1.8Tbps

• Support for 1:1 and 2:1 power supply redundancy configurations, capable of delivering approximately

1.5KW to the router

• Three fan trays working in pull-mode and drawing air from right to left

The image below illustrates the Cisco NCS 560-4 Router chassis design.

Cisco NCS 560-4 Router Hardware Installation Guide

Figure 1: Cisco NCS 560-4 Router Front Panel

Interface module slot2Interface module

slot

Route Switch Processor

(N560-4-RSP4E or N560-4-RSP4)

4Interface module

slot

Power Supplies (three)6System LEDs5

Management Port8RJ-45 Console7

Time of day timing (ToD) port10USB memory port9

USB console12Auxiliary console11

BITS timing port14GNSS module13

10 MHz In1610 MHz Out15

1PPS In181PPS Out17

Slave fan tray20Master fan tray19

——Fan Filters21

The cabling for all interfaces (power, data and control) are on the front side of the chassis. The chassis grounding

point is located on the rear side of the chassis.

The following image illustrates the slot numbering scheme for the FRUs in Cisco NCS 560-4 router in case

of single width IMs.

Cisco NCS 560-4 Router Hardware Installation Guide

Cisco NCS 560-4 Router Overview

Cisco NCS 560-4 Router Features
