Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

APPENDIX

Specifications and Cables

This appendix provides system, port, and cabling specifications for the Cisco 827 routers.

System Specifications

Table A-1 outlines the system specifications for the routers.

Table A-1 System Specifications

Description Design Specification

Physical Dimensions

Dimensions (H x W x D) 2.0 x 9.7 x 8.5 in. (5.1 x 24.6 x 21.6 cm)

Weight (does not include desktop power supply) •Cisco 827-4V router: 1.5 lb. (0.68 kg)

•Cisco 827H router: 1.48 lb. (0.67 kg)

•Cisco 827 router: 1.48 lb. (0.67 kg)

Environmental Operating Ranges

Nonoperating temperature –4 to 149°F (–20 to 65°C)

Nonoperating humidity 5 to 95%, relative humidity

Nonoperating altitude 0 to 15,000 ft (4570 m)

Operating temperature 32 to 104°F (0 to 40°C)

Operating humidity 10 to 85% relative humidity

Operating altitude 0 to 10,000 ft (3000 m)

Router Power (Cisco 827, 827-4V, and SOHO 77)

AC input voltage 100 to 250 VAC

Frequency 50 to 60 Hz

Power consumption 29W

Router Power (Cisco 827H and SOHO 77H)

AC input voltage 100 to 240 VAC

Frequency 50 to 60 Hz

Power consumption 15W

A-2

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Appendix A Specifications and Cables

Port Connector Pinouts

For information on regulatory compliance, refer to the Regulatory Compliance and Safety Information

for Cisco 827 Routers document that shipped with your router.

Warning

Ultimate disposal of this product should be handled according to all national laws and regulations.

Port Connector Pinouts

This section provides pinouts for the following connectors:

•Ethernet—See Table A-2.

•Console (for connecting a terminal or PC)—See Table A-3.

•Telephone—See Table A-4.

•ADSL—See Table A-5

•Power—See Table A-6 and Ta ble A-7.

Table A-2 shows the Ethernet connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H,

SOHO 77, and SOHO 77H routers.

Table A-3 shows the Ethernet connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H,

SOHO 77, and SOHO 77H routers.

Telephone Port Power (Cisco 827-4V)

Voltage -24V and -71V

Table A-1 System Specifications (continued)

Description Design Specification

Table A-2 Ethernet Connector Pinouts (RJ-45)

Function

(TO HUB/TO PC Button –

IN Position)

Function

(TO HUB/TO PC Button –

OUT Position)

1TX+ RX+

2TX– RX–

3RX+ TX+

4 Unused Unused

5 Unused Unused

6RX– TX–

7 Unused Unused

8 Unused Unused

A-3

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Appendix A Specifications and Cables

Port Connector Pinouts

Table A-3 Console Connector Pinouts (RJ-45)

Pin Function

1RTS

2DTR

3TXD

4GND

5GND

6RXD

7DSR

8CTS

A-4

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Appendix A Specifications and Cables

Port Connector Pinouts

The console port is configured as a data communications equipment (DCE) device. The default

parameters for the console port are as follows:

•9600 baud

•Eight data bits

•No parity

•One stop bit

Table A-4 shows telephone connector pinouts for the Cisco 827-4V router.

Table A-5 shows ADSL connector pinouts for the Cisco 827-4V, Cisco 827, Cisco 827H, SOHO 77, and

SOHO 77H routers.

Table A-4 Cisco 827-4V Router Telephone Connector Pinouts (RJ-11)

Pin Function

1Unused

2Tip

3Ring

4Unused

Table A-5 ADSL Connector Pinouts (RJ-11)

Pin Function

1 Loopback to pin 6

2Unused

3Tip

4Ring

5Unused

6 Loopback to pin 1

A-5

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Appendix A Specifications and Cables

Cabling Specifications

Table A-6 shows the power connector pinouts for the Cisco 827, Cisco 827-4V, and SOHO 77 routers.

Table A-7 shows the power connector pinouts for the Cisco 827H and SOHO 77H routers.

Cabling Specifications

This section provides specifications for the following Ethernet cables, which you might need to provide:

•Straight-through cables

•Crossover cables

This section also provides information on Ethernet and telephone cable distance limitations. (Telephone

cable connects a device to a telephone port.)

Ethernet Cable Specifications

Table A-8 lists the specifications for straight-through and crossover Ethernet cables.

Table A-6 Cisco 827, Cisco 827-4V, and SOHO 77 Power Connector Pinouts

Pin Function

1ROF

2RTN

3+12

4 –12

5+5

6RTN

7 –71

8 –24

Table A-7 Cisco 827H and SOHO 77H Power Connector Pinouts

Pin Function

1ROF

2RTN

3AC_Lost

4Unused

5+5VF

6RTN

7Unused

8Unused

A-6

Cisco 827 and SOHO 77 Routers Hardware Installation Guide

78-6854-03

Appendix A Specifications and Cables

Cabling Specifications

Maximum Cable Distances

Table A-9 provides the maximum distances of Ethernet and telephone cables that you can use to connect

equipment to the router.

Table A-8 Ethernet Cable Specifications

Type Category Shielding

10BASE-T Category 3 or 5 Shielded twisted-pair (STP)

10BASE-T – Unshielded twisted-pair (UTP)

Table A-9 Maximum Cable Distances

Cable Maximum Distance

Ethernet cables 328 ft (100 m)

Telephone cable 500 ft (152 m)
