Cisco Catalyst 8300 Series Manuel

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

First Published: 2023-09-05

Americas Headquarters

Cisco Systems, Inc.

170 West Tasman Drive

San Jose, CA 95134-1706

USA

http://www.cisco.com

Tel: 408 526-4000

800 553-NETS (6387)

Fax: 408 527-0883

CONTENTS

Overview of Cisco Catalyst 8300 Series Edge uCPE 1

CHAPTER 1

Cisco Catalyst 8300 Series Edge uCPE Chassis 1

Location of Labels on Cisco Catalyst 8300 Series Edge uCPE 3

Hardware Features 4

Status Indicators and LEDs for Gigabit Ethernet Ports 4

Fans, Ventilation, and Airflow 7

Prepare for Installation 9

CHAPTER 2

Safety Recommendations and Warnings 9

Safety with Electricity 10

Site Requirements 11

Mounting Requirements 11

Power Guidelines and Requirements 12

Network Cabling Specification 12

Required Tools and Equipment 13

Install the Cisco Catalyst 8300 Series Edge uCPE 15

CHAPTER 3

Unpacking the Device 15

Installing the Cisco Catalyst 8300 Series Edge uCPE 15

Grounding the Chassis 25

Initial Server Setup 26

Install and Upgrade Field Replaceable Units 29

CHAPTER 4

Installing a Dual In-line Memory Module (DIMM) 30

Removing a DIMM 31

Installing the M.2 Storage Module 31

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

iii

Installing and Removing a Network Interface Module (NIM) 33

Installing Pluggable Interface Module 34

Installing Drive Bays 35

Replace (Remove and Install) Fan Tray 37

Remove Small Form Pluggable Modules 38

Laser Safety Guidelines 41

CHAPTER 5

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

Contents

CHAPTER 1

Overview of Cisco Catalyst 8300 Series Edge

uCPE

The Cisco Catalyst ™8300 Series Edge Universal Customer Premises Equipment (uCPE) is a purpose-built

x86 platform that is designed for branch virtualization. It enables device consolidation across network and

security functions, improves operational flexibility and service agility, simplifies network operations, and

results in reduced deployment times and fewer truck rolls for delivery of add-on services.

•Cisco Catalyst 8300 Series Edge uCPE Chassis, on page 1

•Location of Labels on Cisco Catalyst 8300 Series Edge uCPE, on page 3

•Hardware Features, on page 4

•Status Indicators and LEDs for Gigabit Ethernet Ports, on page 4

•Fans, Ventilation, and Airflow, on page 7

Cisco Catalyst 8300 Series Edge uCPE Chassis

Chassis- Front Panel

Physical Interface Module

(PIM) slot for CAT 7 LTE

or 5G cellular

connectivity (for future

use)

2Status LEDs1

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

E1.S disk slot

(For future use)

4Network Interface Module

(NIM) slot for additional

L2/L3 MACsec, Power

over Ethernet (PoE) ports

(for future use)

RFID6U.2 2.5-inch disk slots x

M.2 disk slot (75 GB USB M.2, 600 GB or 2 TB NVMe disk)7

Chassis- Bezel Side

GND Lug or Ground

Point

2PSU Slot1

Chassis On/off Switch4Fan Tray

Visible through chassis.

PSU Slot5

Chassis- Internal

Fan Tray2DIMM slots x 41

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

Overview of Cisco Catalyst 8300 Series Edge uCPE

Cisco Catalyst 8300 Series Edge uCPE Chassis

Location of Labels on Cisco Catalyst 8300 Series Edge uCPE

The figure below shows the location of the labels on the Cisco Catalyst 8300 Series Edge uCPE. Labels are

located at the same location on all the Cisco Catalyst 8300 Series Edge uCPE.

Product labels location1

Compliance label location1

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

Overview of Cisco Catalyst 8300 Series Edge uCPE

Location of Labels on Cisco Catalyst 8300 Series Edge uCPE

Hardware Features

•USB-A 3.0 and Micro-USB Console port:You can use this port to connect a mouse, keyboard, or any

other USB device. Using a USB hub, you can connect more than one USB device to this port. Because

this port is backward compatible, you can also use an older version of USB devices on this port.

•Front panel Gigabit Ethernet ports: There are 4 SFP ports and 4 Copper ports (GE0 supports 802.3bt

POE standard and UPOE+ PD if compliant with 802.3bt).

•M.2 storage module: This is a high capacity storage component. The OS is installable in this module.

The storage capacity of this module is upgradeable. The storage capacity is 75GB USB M.2 or 600GB

NVME M.2 or 2TB NVME M.2.

•CPU: Ice Lake 20-core HCC with all core turbo frequency of 2.5 GHz, D2796NFT base frequency is 2

GHz and max turbo frequency of 3.1 GHz.

•Dual In-Line Memory Modules (DIMMs): Stores the running configuration and routing tables and is

used for packet buffering by the network interfaces.

• Supports maximum of 128 GB of main memory with 4 x 32 GB DDR4

DIMMs.

• Four DIMM slots, numbered from 0 to 3 with a frequency of 3200 MHz .

• Uses DDR4 DIMMs for the main memory.

• Memory DIMM combinations allowed: 1 x 32GB, 2 x 16GB, 2 x 32GB, 4

x 16GB, 4 x 32GB.

Note

•Network Interface Module (NIM): The device supports one NIM when you need additional ports. See,

data sheet for supported NIMs.

•Pluggable Interface Module (PIM): The device supports one PIM for cellular connectivity. See data

sheet for supported PIMs.

For proper thermal functioning of the system, all module slots or optional

components (PIM, NIM, E1.S, M.2 and U.2) that do not have a functional module

installed must be provisioned with a blank filler.

Note

Status Indicators and LEDs for Gigabit Ethernet Ports

The front panel Gigabit Ethernet ports has eight ports: four RJ45 ports and four SFP ports.

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

Overview of Cisco Catalyst 8300 Series Edge uCPE

Hardware Features

LED indicator for device

status

2LED indicator for power

supply

LED indicator for blue

beacon

4LED indicator for

environmental status

Link6CPU Activity5

Link for GEO/0~0/28Activity for 0/0 - 0/2

copper ports

Link/LOS for SFP

0/3~0/6

Hazard Fault symbol2E1.S Activity1

SSD Activity for U.2 slot3

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

Overview of Cisco Catalyst 8300 Series Edge uCPE

Status Indicators and LEDs for Gigabit Ethernet Ports

DescriptionColorLED Definition

Ethernetport0/1/2 ActivityLED

Off: No Activity Blinking Green :

Ethernet Activity Detected

GGE0-2 RJ45 Activity LED

Ethernet port 0/1/2 Link LED

Off: No link Green: Ethernet cable

present and link established with

other side

GGE0-2 RJ45 Link LED

SFP+ port 0/1/2/3 Link LED Off:

Not present or not configured

Yellow : Loss of Signal Green:

Green: Link established

G/YSFP+ 0-3 Link LED

BMC Management Ethernet

Activity LED Off: No Activity

Blinking Green : Activity

GBMC Management port Activity

LED

BMC Management Ethernet

Link LED Off: No link Green:

Ethernet cable present and link

established with other side

GBMC Management port Link LED

DescriptionColorLED Definition

Power supply status LED Off:

The system is powered off Amber

(Green + Red) : A PSU in system

is not functioning correctly Green:

All installed PSUs are operating

correctly

R/Y LED1PWR (1 LED)

Status LED GREEN - x86 booted

fine AMBER - x86 in rommon

mode (setup menu) RED blinking

— x86 Secure boot failure RED -

x86 is UP but BIOS is not fully UP

yet (bios post cmplt not set) OFF -

x86 in power-off state

R/G/Y LED2STATUS (1 LED)

Cisco Catalyst 8300 Series Edge uCPE Hardware Installation Guide

Overview of Cisco Catalyst 8300 Series Edge uCPE

Status Indicators and LEDs for Gigabit Ethernet Ports
