Cisco Linksys WUSB600N Manuel utilisateur

USER GUIDE

Wireless-N USB Network Adapter

with Dual-Band

Model: WUSB600N

About This Guide

Wireless-N USB Network Adapter with Dual-Band

About This Guide

Icon Descriptions

While reading through the User Guide you may see

various icons that call attention to specific items. Below is

a description of these icons:

NOTE: This check mark indicates that there is

a note of interest and is something that you

should pay special attention to while using the

product.

WARNING: This exclamation point indicates

that there is a caution or warning and it is

something that could damage your property or

product.

WEB: This globe icon indicates a noteworthy

website address or e-mail address.

Online Resources

Website addresses in this document are listed without

http:// in front of the address because most current web

browsers do not require it. If you use an older web browser,

you may have to add http:// in front of the web address.

Resource Website

Linksys www.linksysbycicso.com

Linksys International www.linksysbycisco.com/international

Glossary www.linksysbycisco.com/glossary

Network Security www.linksysbycisco.com/security

Linksys, Cisco, and the Cisco Logo are

registered trademarks or trademarks

of Cisco Systems, Inc. and/or its

affiliates in the U.S. and certain other

countries. Other brands and product

names are trademarks or registered

trademarks of their respective

Table of Contents

Wireless-N USB Network Adapter with Dual-Band

Chapter 1: Product Overview 1

Storing the Cap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

USB Extension Base . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Chapter 2: Wireless Security Checklist 2

General Network Security Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Additional Security Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Chapter 3: Conguration 3

How to Access the Wireless Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

How to Use the Wireless Manager . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Saved Networks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Appendix A: Troubleshooting 9

Appendix B: Windows Vista Conguration 10

Windows Vista Conguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

New Wireless Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10

Appendix C: Windows XP Wireless Zero Conguration 13

Windows XP Wireless Zero Conguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13

Appendix D: Specications 15

Appendix E: Warranty Information 16

Limited Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Appendix F: Regulatory Information 18

FCC Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

FCC Radiation Exposure Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Safety Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Industry Canada Statement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Restrictions in the 5 GHz Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18

Avis d’Industrie Canada. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Restrictions dans la bande 5 GHz. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Wireless Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19

Avis de non-responsabilité concernant les appareils sans l . . . . . . . . . . . . . . . . . .19

User Information for Consumer Products Covered by EU Directive 2002/96/EC on Waste

Electric and Electronic Equipment (WEEE) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20

Appendix G: Software End User License Agreement 24

Cisco Products . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Software Licenses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24

Chapter 1 Product Overview

Wireless-N USB Network Adapter with Dual-Band

Chapter 1:

Product Overview

Thank you for choosing the Linksys by Cisco Wireless-N

USB Network Adapter with Dual-Band. Using the latest

wireless networking technology, the Adapter adds

or upgrades wireless connectivity on your notebook

computer. To help protect your data and privacy, you can

use industrial-strength WPA2 encryption to protect your

wireless connection.

LED

Link (Blue) The LED flashes when there is

wireless network activity.

Storing the Cap

When the Adapter is plugged into the USB Extension Base

or your computer’s USB port, the cap may be stored on

the top of the Adapter.

To store the cap, push it onto the top of the adapter until

it fits snugly.

USB Extension Base

A USB Extension Base is provided for easy access to the

USB port. To use the USB Extension Base, connect the

Adapter to the Base, then connect the USB Extension Base

to the USB port on your PC or laptop.

Chapter 2 Wireless Security Checklist

Wireless-N USB Network Adapter with Dual-Band

Chapter 2:

Wireless Security Checklist

Wireless networks are convenient and easy to install, so

homes with high-speed Internet access are adopting them

at a rapid pace. Because wireless networking operates by

sending information over radio waves, it can be more

vulnerable to intruders than a traditional wired network.

Like signals from your cellular or cordless phones, signals

from your wireless network can also be intercepted. Since

you cannot physically prevent someone from connecting

to your wireless network, you need to take some additional

steps to keep your network secure.

1. Change the default wireless

network name or SSID

Wireless devices have a default wireless network name

or Service Set Identifier (SSID) set by the factory. This

is the name of your wireless network, and can be up

to 32 characters in length. Linksys wireless products

use linksys as the default wireless network name. You

should change the wireless network name to something

unique to distinguish your wireless network from other

wireless networks that may exist around you, but do not

use personal information (such as your Social Security

number) because this information may be available for

anyone to see when browsing for wireless networks.

2. Change the default password

For wireless products such as access points and routers,

you will be asked for a password when you want to change

their settings. These devices have a default password set

by the factory. The Linksys default password is admin.

Hackers know these defaults and may try to use them

to access your wireless device and change your network

settings. To thwart any unauthorized changes, customize

the device’s password so it will be hard to guess.

3. Enable MAC address filtering

Linksys routers give you the ability to enable Media Access

Control (MAC) address filtering. The MAC address is a

unique series of numbers and letters assigned to every

networking device. With MAC address filtering enabled,

wireless network access is provided solely for wireless

devices with specific MAC addresses. For example, you can

specify the MAC address of each computer in your home

so that only those computers can access your wireless

network.

4. Enable encryption

Encryption protects data transmitted over a wireless

network. Wi-Fi Protected Access (WPA/WPA2) and Wired

Equivalent Privacy (WEP) offer different levels of security

for wireless communication.

A network encrypted with WPA/WPA2 is more secure

than a network encrypted with WEP, because WPA/WPA2

uses dynamic key encryption. To protect the information

as it passes over the airwaves, you should enable the

highest level of encryption supported by your network

equipment.

WEP is an older encryption standard and may be the

only option available on some older devices that do not

support WPA.

General Network Security Guidelines

Wireless network security is useless if the underlying

network is not secure.

•Password protect all computers on the network and

individually password protect sensitive files.

•Change passwords on a regular basis.

•Install anti-virus software and personal firewall

software.

•Disable file sharing (peer-to-peer). Some applications

may open file sharing without your consent and/or

knowledge.

Additional Security Tips

•Keep wireless routers, access points, or gateways away

from exterior walls and windows.

•Turn wireless routers, access points, or gateways

off when they are not being used (at night, during

vacations).

•Usestrongpassphrasesthatareatleasteightcharacters

in length. Combine letters and numbers to avoid using

standard words that can be found in the dictionary.

WEB:Formoreinformationonwirelesssecurity,

visit www.linksysbycisco.com/security

Chapter 3 Advanced Configuration

Wireless-N USB Network Adapter with Dual-Band

Chapter 3:

Configuration

The Linksys Wireless Manager is used to configure the

Adapter.TheWireless Manager lets you search for available

wireless networks, establish or terminate a connection

with a wireless network, and save a wireless network’s

settings.

How to Access the Wireless Manager

After you have installed the Adapter, the Linksys Wireless

Manager icon appears in the system trayof your computer.

If the Adapter is connected to a wireless network, the icon

will have green bars (the exact number of green bars

varies depending on the network’s signal strength). If the

Adapter is not connected to a wireless network, the icon

will have gray bars with a red X.

Linksys Wireless Manager Icon—

Connected to a Wireless Network

Linksys Wireless Manager Icon—

Not Connected to a Wireless Network

To open the Wireless Manager, click the icon, and then

select View Wireless Networks... from the pop-up menu.

(To skip the pop-up menu, double-click the icon instead.)

To close the Wireless Manager, click the icon, and then

select Close from the pop-up menu.

Wireless Manager Icon Pop-up Menu

How to Use the Wireless Manager

The Wireless Manager opens with the Connect to a

Wireless Network screen.This screen allows you to connect

to a wireless network, or to disconnect from a wireless

network.

When the Connect to a Wireless Network screen first

appears, it displays a message indicating that the Wireless

Manager is searching for wireless networks within range.

When the search is complete, the screen displays the

available wireless networks within range.

Connect to a Wireless Network—Searching for Wireless Networks

Connect to a Wireless Network—Available Wireless Networks

The list of available wireless networks provides the

following information about each network:

•Network name The network’s unique name or SSID.

•Connection status The word Connected appears if

the Adapter is connected to the network.

•Wi-Fi Protected Setup support The icon

appears

the network supports Wi-Fi Protected Setup.

NOTE: The Adapter supports Wi-Fi Protected

Setup, a feature that makes it easy to set up

a wireless network. For information on this

feature, go to How to Connect Using Wi-Fi

Protected Setup, page 6.

•Security The icon appears if the network uses

wireless security. The security type (WPA2, WPA, WEP) is

listed below the network name.

•Network signal strength The green bars in the

icon indicate the network’s signal strength; is the

strongest level and is the weakest level.

Chapter 3 Advanced Configuration

Wireless-N USB Network Adapter with Dual-Band

To connect to a wireless network, go to How to Connect to

aWireless Network, page 4.To disconnect from a wireless

network, select the network, and click Disconnect. To

refresh the list of available networks, click Search Again.

How to Connect to a Wireless Network

Follow these instructions to connect to a wireless network

that has not been saved. (To connect to a saved network,

go to How to Connect to a Saved Network, page 8.)

1. On the Connect to a Wireless Network screen, locate

the name of your wireless network in the list. If your

wireless network is not in the list, go to How to

Connect to a Hidden Wireless Network, page 5.

2. If your wireless network supports Wi-Fi Protected

Setup (the icon appears next to the network’s

name), go to How to Connect Using Wi-Fi Protected

Setup, page 6.

3. Select your network, and then click Connect.

Select a Wireless Network

4. If the wireless network uses wireless security, enter the

security key. Click Next.

Enter Wireless Network’s Security Key

5. The Checking Connection screen appears while the

Wireless Manager establishes the wireless connection.

When it is finished, click Next.

Checking Connection

6. The Connected to Your Network screen appears. To

save your network’s settings, select Remember this

network. (Saving a network’s settings will make it

easier to reconnect

to the network.)

Click Finish to exit

the Wireless Manager.

Connected to Your Network

Congratulations! The Adapter is connected to

the network.

Chapter 3 Advanced Configuration

Wireless-N USB Network Adapter with Dual-Band

How to Connect to a Hidden Wireless Network

NOTE: By default, a wireless network’s router

broadcasts the network name (SSID).

A“hidden”

wireless network is a network whose router has

been configured not to broadcast the network

name (SSID).

Follow these instructions to connect to a wireless network

that is not listed on the Connect to a Wireless Network

screen.

1. On the Connect to a Wireless Network screen, select My

network is not in this list. Click Next.

Select My Network is Not in This List

2. The next screen asks if you want to connect to a hidden

network. If your network is hidden, select Connect to

hidden network. Click Next.

Confirm Connection to Hidden Network

NOTE: If your wireless network is NOT hidden,

select My network is not hidden, and then

click Next. Follow the instructions on the next

screen—verify that your network router is

powered on and is within range of the Adapter,

and then click Retry to search for wireless

networks again. Then go to How to Connect to

a Wireless Network, page 4 to continue.

3. Enter your wireless network’s name (SSID). Click Next.

Enter Wireless Network’s Name (SSID)

4. If your wireless network uses wireless security,

enter the security key. Click Next.

If your wireless network does not use wireless security,

leave the security key field blank, and click Next.

Enter Wireless Network’s Security Key

Chapter 3 Advanced Configuration

Wireless-N USB Network Adapter with Dual-Band

5. The Checking Connection screen appears.

Checking Connection

6. The Connected to Your Network screen appears. To

save your network’s settings, select Remember this

network. (Saving a network’s settings will make it

easier to reconnect

to the network.)

Click Finish to exit

the Wireless Manager.

Connected to Your Network

Congratulations! The Adapter is connected to

the network.

How to Connect Using Wi-Fi Protected Setup

On the Connect to a Wireless Network screen, the Wi-Fi

Protected Setup icon ( ) indicates a network that supports

Wi-Fi Protected Setup. Follow these instructions to connect

to a wireless network using Wi-Fi Protected Setup.

NOTE: Before you begin, make sure the router

and the computer with the Adapter are in the

same room

1. On the Connect to a Wireless Network screen, select

your network, and then click Connect.

Select the Wireless Network

2. The Quickly Connect Using Push Button screen appears.

Quick Connect Using Push Button

3. Press the router’s Wi-Fi Protected Setup button

until an LED lights up. If your router does not have this

button, click Skip and go to Enter the Adapter’s PIN

Number, page 7.

4. Within two minutes, click Connect on the Quickly

Connect Using Push Button screen.

Chapter 3 Advanced Configuration

Wireless-N USB Network Adapter with Dual-Band

5. The Adapter connects to the network.

Connecting to the Network via Wi-Fi Protected Setup

NOTE: If the connection cannot be set up, the

message, “Registration failed” appears. If this

happens, use one of two options:

•Push Button Press the router’s Wi-Fi

Protected Setup button until an LED

lights up. Then click Connect to try again.

•PIN Click Skip,and then go to Enter the

Adapter’s PIN Number, page 7.

6. The Connected to Your Network screen appears. To

save your network’s settings, select Remember this

network. (Saving a network’s settings will make it

easier to reconnect

to the network.)

Click Finish to

exit the Wireless Manager.

Connected to Your Network

Congratulations! The Adapter is connected to

the network.

Enter the Adapter’s PIN Number

Enter the PIN Number

1. Access the web-based utility of the router. (Refer to the

router’s documentation for instructions.)

2. On the router’s Wi-Fi Protected Setup screen, enter

the Adapter’s PIN number in the appropriate field.

Then perform the appropriate action to save the PIN

number; for example, click Register. (Refer to the

router’s documentation for instructions.)

NOTE: Enter the Adapter’s PIN number without

the hyphen.

3. The Adapter connects to the network, and the

Connected to Your Network screen appears. To save

your network’s settings, select Remember this

network. (Saving a network’s settings will make it

easier to reconnect

to the network.)

Click Finish to exit

the Wireless Manager.

Connected to Your Network

Congratulations! The Adapter is connected to

the network.

Autres manuels pour Linksys WUSB600N

Table des matières

Autres manuels Cisco Carte réseau

Cisco

Cisco PA-T3 Instructions d'utilisation et d'entretien

Cisco

Cisco Linksys PLS300 Manuel utilisateur

Cisco

Cisco uBR10-SRP-OC12SML Manuel utilisateur

Cisco

Cisco uBR-MC28U Manuel utilisateur

Cisco

Cisco CE-100T-8 Mode d’emploi

Cisco

Cisco VWIC-2MFT-T1 - Multiflex Trunk Voice/WAN Interface Card Expansion... Manuel utilisateur

Cisco

Cisco HWIC-1FE - WAN Interface Card Expansion... Mode d’emploi

Cisco

Cisco ASR 9000 Series Manuel utilisateur

Cisco

Cisco CTX2500 Manuel utilisateur

Cisco

Cisco Modular Gigabit Ethernet Line Card I Instructions d'utilisation et d'entretien

Cisco

Cisco WAN Interface Card WIC-1DSU-56K4 Manuel utilisateur

Cisco

Cisco WAN Interface Cards Cable WIC-1B-U Manuel utilisateur

Cisco

Cisco 12000 - Series Chassis Modular Expansion... Instructions d'utilisation et d'entretien

Cisco

Cisco DFC3A Manuel d'installation et d'exploitation

Cisco

Cisco Gateway Controllers Instructions originales

Cisco

Cisco One-Port Serial WAN Interface Card Cable... Manuel utilisateur

Cisco

Cisco 6500 - Catalyst Series 10 Gigabit EN Interface Module... Manuel d'installation et d'exploitation

Cisco

Cisco Aironet 340 Series Manuel utilisateur

Cisco

Cisco 7300-6T3 Manuel de l'opérateur

Cisco

Cisco Catalyst 4500 Series Manuel

Cisco

Cisco WAE-674-K9 - Wide Area Application Engine... Manuel utilisateur

Cisco

Cisco Media Gateway Controller Node Manager Manuel utilisateur

Cisco

Cisco Valet Connector AM10 Manuel utilisateur

Cisco

Cisco Catalyst 4500 Series Comment utiliser

Manuels Carte réseau populaires d'autres marques

FirstComm

FirstComm OBiWiFi5G Manuel utilisateur

Sun Microsystems

Sun Microsystems Interface Adapter Manuel utilisateur

TRENDnet

TRENDnet TU2-ETG Manuel utilisateur

YASKAWA

YASKAWA SI-EN3 Manuel utilisateur

Paradyne

Paradyne BitStorm 2600 IP DSLAM Manuel utilisateur

Belkin

Belkin F5D7050 Manuel utilisateur

3Com

3Com EtherLink 3C509B Manuel utilisateur

TRENDnet

TRENDnet TEG-PCITX Manuel utilisateur

Delta Electronics

Delta Electronics Braking Modules VFDB Series Manuel utilisateur

TwinMOS

TwinMOS Booming Manuel utilisateur

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Manuel utilisateur

Buffalo

Buffalo AirStation WLI-PCM-L11GP Manuel utilisateur

National Instruments

National Instruments NI 9234 Manuel utilisateur

Hama

Hama 49276 Manuel utilisateur

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Manuel d'utilisation

Compaq

Compaq Wireless LAN 100 Manuel utilisateur

Bose

Bose PowerMatch Dante Manuel utilisateur

TRENDnet

TRENDnet TEG-PCITXR Manuel utilisateur
