CHAPTER

5-1

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Operating the Cisco ICS 7750

This chapter explains how to operate the Cisco Integrated Communications

System 7750 (Cisco ICS 7750) after initial configuration is complete. The chapter

is organized as follows:

•Accessing the System, page 5-1

•Backing Up System Data, page 5-23

•Setting Security Privileges, page 5-30

•Shutting Down the System, page 5-31

Accessing the System

This section tells how to access the Cisco ICS 7750 and gives guidelines for best

practices when accessing the system:

•Accessing the System During Initial Configuration, page 5-2

•Accessing the System After Initial Configuration, page 5-2

•Accessing ICSConfig, page 5-4

•Accessing ICS System Manager, page 5-4

•Navigating in ICS System Manager, page 5-5

•Using ICS System Manager, page 5-6

•Accessing Cisco CallManager, page 5-8

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

5-2

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

•Accessing SPE310s, page 5-8

•Best Practices for Using Microsoft SQL Server, page 5-14

•Best Practices for Configuring DHCP, page 5-15

•Best Practices for Using the Cisco IOS CLI, page 5-16

•Using Peripherals with SPE310s, page 5-19

Accessing the System During Initial Configuration

When configuring the system for the first time, you can use a web browser to

perform most tasks. See Chapter 4, “Completing the Cisco ICS 7750 Installation,”

for system installation and configuration instructions.

Accessing the System After Initial Configuration

After system installation and configuration, you have many ways to access the

system:

•Cisco browser-based software interfaces:

–

ICSConfig—The Cisco ICS System Manager initial configuration

program (ICSConfig) enables you to specify key system parameters

during initial configuration and to change those parameters at any time

after initial configuration. For additional information, see the “Accessing

ICSConfig” section on page 5-4.

–

ICS System Manager—ICS System Manager is preinstalled on the

Cisco System Processing Engine 310 (SPE310) running System

Manager, in chassis slot 6. You can use ICS System Manager to access,

configure, monitor, and manage the chassis, its cards, and the

interconnected Catalyst switches. For additional information, see the

“Accessing ICS System Manager” section on page 5-4.

–

Cisco CallManager—You can install Cisco CallManager on SPE310s

and use the software to configure call admission control, route plans,

voice gateways (typically multiservice route processors [MRPs] or

analog station interfaces [ASIs]), Cisco IP Phones, and other features

5-3

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

associated with transmitting voice traffic over an IP network. For

additional information, see the “Accessing Cisco CallManager” section

on page 5-8.

•Cisco IOS software command-line interface (CLI)—You can use Cisco IOS

software to configure ASIs, MRPs, and SSPs. For additional information, see

the “Accessing the Cisco IOS CLI on ASIs, MRPs, and the SSP Through

Telnet” section on page 5-11.

•Microsoft Windows software interfaces:

–

Terminal Services Client—You can use Terminal Services Client to

access the SPE310 desktop and perform standard Windows file

management operations on the SPE310. For additional information, see

the “Accessing SPE310s” section on page 5-8.

Terminal Services Client is packaged with Windows 2000. Terminal

Services Client is also available for downloading and installing on to

other Windows operating systems. See the “Installing Microsoft

Terminal Services Client” section on page 2-19 for installation

instructions.

–

Terminal emulation interfaces—You can use native tools such as Telnet

and HyperTerminal to configure system cards. You can also connect

directly to the system alarm processor (SAP) through a console or

modem connection and troubleshoot system cards. For additional

information, see the “Accessing Processor Cards Through the SAP”

section on page 5-12.

•Simple Network Management Protocol (SNMP)–based Management

Information Base (MIB)—You can use the SNMP MIB to manage the

Cisco ICS 7750 with software such as CiscoWorks2000 and HP OpenView.

(For additional information, see the “Using Network Management Solutions

with the Cisco ICS 7750” section on page 6-146.)

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

5-4

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Accessing ICSConfig

Follow these steps to access ICSConfig.

Note This section describes ICSConfig functionality after initial configuration is

complete. For a description of ICSConfig functionality during initial

configuration, see Chapter 4, “Completing the Cisco ICS 7750 Installation.”

Step 1 On a PC, open Netscape Communicator or Microsoft Internet Explorer.

Step 2 In the Location or Address field, enter the following URL, replacing IP address

with the IP address of the SPE310 running System Manager:

http://IP address/icsconfig

Step 3 Log in as an administrator (user ID administrator), and enter your password (the

default is changeme).

Step 4 Click OK.

The system discovers the cards that are currently installed in the chassis. After the

discovery process is complete, the ICS 7700 System Configuration page displays.

Step 5 Click ICS 7700 System Setup.

Step 6 Make any desired changes to the system parameters, and submit your changes.

It will take up to 20 minutes for the system to process your changes. When the

STATUS LEDs on the SPE310s change to solid green, the submit process is

complete.

Accessing ICS System Manager

You can use ICS System Manager to access, configure, monitor, and manage the

chassis and its cards.

5-5

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

When you have installed and configured your system as described in Chapter 4,

“Completing the Cisco ICS 7750 Installation,” follow these steps to access

ICS System Manager:

Step 1 On a PC, open Netscape Communicator or Microsoft Internet Explorer.

Step 2 In the Location or Address field, enter the following URL, replacing IP address

with the IP address of the SPE310 running System Manager:

http://IP address/ics

Note If you do not know the IP address of the SPE310, see the “Determining

the IP Address of an SPE310” section on page 5-22.

Step 3 Log in as the super administrator (user ID is admin), and enter your password

(the default is admin).

Step 4 Click Login.

Navigating in ICS System Manager

To navigate in ICS System Manager, click the tabs that are visible at the top of

every ICS System Manager page:

•Home—Displays a page in which you can toggle between a short summary

(Summary View) and a detailed list (Detailed View) of information about

system cards.

•Configure—Displays a page in which you can choose any of the following

utilities:

–

SSP Manager—Enables you to configure the system switch processor

(SSP) and to perform LAN management tasks, such as administering

workgroup changes and using link statistics to troubleshoot problems.

–

System Setup—Enables you to view system parameters and provides

instructions for changing the parameters.

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

5-6

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

–

Fan Manager—Enables you to view and update information related to the

planned replacement of the fan tray.

–

COM Port Manager—Enables you to view and change system port

assignments (other than the SAP console port).

–

Applications—Provides one or more links to applications such as Cisco

CallManager.

•Monitor—Displays a page that shows current data about your system, such as

the number of bytes transferred over an Ethernet port or the amount of disk

space used on an SPE310.

•Event Manager—Displays a page in which you can set preferences for

logging and event notifications, define rules for the reporting of system

events, set up event reports, and view system events.

•Software Upgrade—Displays a page from which you can upload and install

Cisco IOS software images for ASIs, MRPs, and SSPs, and firmware for the

SAP. For additional information, see the Cisco ICS 7750 Release Notes for

the release to which you are upgrading.

•Security—Displays a page for assigning users to groups with different

security levels.

•System Maintenance—Displays a page for scheduling and running backups

of system software data and viewing instructions on restoring system

software data.

Using ICS System Manager

This section tells how to use ICS System Manager to perform the following

routine tasks:

•Determining the ICS System Manager Version

•Determining the Cisco IOS Software Release Running on the SSP

Note For additional information about how to use ICS System Manager, refer to the

ICS System Manager online help.

5-7

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

Determining the ICS System Manager Version

The ICS System Manager bundle version number is displayed on the System

Manager home page, in a box just under the graphic representation of the system

chassis.

For example:

Software Bundle:

V<version number>

Running since:

The ICS System Manager home page also lists the cards currently running in the

system chassis, as well as their assigned IP addresses and the software running on

each. You can switch between a summary view and a detailed view of the

hardware and software installed on the cards in the system.

Determining the Cisco IOS Software Release Running on the SSP

You can use ICS System Manager to determine the Cisco IOS software release

that is running on the SSP, as well as other information about the SSP, as follows:

Step 1 Click the Configure tab on the ICS System Manager home page.

Step 2 Click SSP Manager.

Step 3 If prompted, log in as an administrator (user ID administrator), and enter your

password (the default is changeme).

Step 4 Click show tech-support.

The system invokes the show version command on the SSP. The following is

sample output from this command:

Cisco Internetwork Operating System Software

IOS (tm) C2900XL Software (C2900XL-C3H2S-M), Version 12.0(5.2)XU,

MAINTENANCE INTERIM SOFTWARE

Additional output lines from the show version command include information

such as the processor revision numbers and the amount of available memory.

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

5-8

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Accessing Cisco CallManager

You can install Cisco CallManager on SPE310s and use the software to configure

call admission control, route plans, voice gateways (such as MRPs or ASIs with

installed voice interface cards [VICs] or voice WAN interface cards [VWICs]),

Cisco IP Phones, and other features associated with transmitting voice traffic over

an IP network.

To access Cisco CallManager on the Cisco ICS 7750, follow these steps:

Step 1 Click the Configure tab on the ICS System Manager home page.

Step 2 Click Applications.

The page refreshes, displaying a table that contains information about the

SPE310s and the applications that are running on them.

Step 3 Click the desired CallManager Administration: IP address/CCMAdmin link

(where IP address is the IP address of the target SPE310 running

Cisco CallManager).

Step 4 Log in to CallManager as an administrator.

Note You can also access Cisco CallManager on the Cisco ICS 7750 by entering the

following URL, replacing IP address with the IP address of an SPE310 running

Cisco CallManager: http://IP address/CCMAdmin.

Accessing SPE310s

You can use Terminal Services Client to access the SPE310 desktop, as described

in the following topics:

•Accessing the SPE310 Windows Interface Through Terminal Services Client,

page 5-9

•Accessing the SPE310 Windows Interface Through Directly Connected

Peripherals, page 5-9

•Accessing SPE310s Through Telnet, page 5-11

5-9

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

•Accessing the Cisco IOS CLI on ASIs, MRPs, and the SSP Through Telnet,

page 5-11

•Accessing Processor Cards Through the SAP, page 5-12

Accessing the SPE310 Windows Interface Through Terminal Services Client

To access the SPE310 Windows interface through Terminal Services Client,

follow these steps:

Step 1 On the PC that you use to administer the Cisco ICS 7750, choose Start >

Programs > Terminal Services Client > Client Connection Manager.

Step 2 Use the Client Connection Manager to open a Terminal Services connection with

the target SPE310:

•If you already have a Terminal Services Client connection defined for the

target SPE310, choose it, and choose File > Connect.

•If you do not have a Terminal Services Client connection defined for the

target SPE310, choose File > New Connection. Follow the instructions in

the wizard. Then choose File > Connect.

The Terminal Services Client window opens. You can use Terminal Services

Client to access standard Windows utilities on the SPE310, such as Windows

Explorer and the Control Panel.

Accessing the SPE310 Windows Interface Through Directly Connected

Peripherals

You can connect a monitor, keyboard, and mouse directly to the SPE310 to access

the Windows user interface, as follows.

Note For a summary of the issues related to the connection of peripherals to SPE310s,

as well as best practices for using peripherals with SPE310s, see the “Using

Peripherals with SPE310s” section on page 5-19.

Chapter 5 Operating the Cisco ICS 7750

Accessing the System

5-10

Cisco ICS 7750 Installation and Configuration Guide

78-14165-03

Note For a list of USB peripherals that have been tested on the Cisco ICS 7750, see the

“Using Peripherals with SPE310s” section on page 5-19.

Step 1 Connect the monitor cable to the video port on the SPE310, and power on the

monitor.

Step 2 Do one of the following, based on the type of peripherals that you are using:

•USB—Connect a USB keyboard to one SPE310 USB port, and connect a

USB mouse to the other SPE310 USB port.

•PS/2—Connect the “Y” splitter cable for your keyboard and mouse to the

keyboard/mouse port on the target SPE310. Then connect your keyboard and

mouse to the available ends of the “Y” splitter cable.

Note If you are using the “Y” splitter cable to connect a PS/2 mouse and a

keyboard to the SPE310, the keyboard and mouse must be connected

at or before the time that the SPE310 is rebooted in order to be

recognized by the operating system. A USB keyboard and mouse are

usually recognized without rebooting the operating system.

Step 3 Use the keyboard, mouse, and monitor to access standard Windows utilities on

the SPE310, such as Windows Explorer and the Control Panel.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Cisco Système de conférence

Cisco

Cisco Webex Room Kit Plus Precision 60 Manuel utilisateur

Cisco

Cisco TelePresence SX10 Manuel utilisateur

Cisco

Cisco UNIFIED COMMUNICATIONS UC320W Mode d’emploi

Cisco

Cisco TelePresence DX70 Manuel utilisateur

Cisco

Cisco 7937G - Unified IP Conference Station VoIP... Mode d’emploi

Cisco

Cisco TelePresence System C20 Plus Manuel utilisateur

Cisco

Cisco Spark Room Kit Plus Manuel utilisateur

Cisco

Cisco TelePresence SX20 Manuel de service

Cisco

Cisco TelePresence SX10 Manuel de service

Cisco

Cisco TelePresence Touch 10 Manuel utilisateur

Cisco

Cisco TelePresence DX70 Manuel de service

Cisco

Cisco EX60 Manuel utilisateur

Cisco

Cisco Webex Codec Pro Manuel utilisateur

Cisco

Cisco TelePresence System Codec C90: Profile 65" Manuel de service

Cisco

Cisco EX60 Manuel utilisateur

Cisco

Cisco Quick Set C20 Manuel utilisateur

Cisco

Cisco 7935 - IP Conference Station VoIP Phone Mode d’emploi

Cisco

Cisco TelePresence SX20 Manuel utilisateur

Cisco

Cisco MX Series Manuel utilisateur

Cisco

Cisco TelePresence MX700 Manuel utilisateur

Cisco

Cisco Webex Room Panorama Manuel utilisateur

Cisco

Cisco 7937G - Unified IP Conference Station VoIP... Manuel utilisateur

Cisco

Cisco TelePresence SX10 Manuel utilisateur

Cisco

Cisco TelePresence System Codec C90 Manuel utilisateur

Manuels Système de conférence populaires d'autres marques

Kramer

Kramer VIA GO Manuel utilisateur

AVT

AVT MAGIC AC1 Go Manuel utilisateur

ProSoft Technology

ProSoft Technology AN-X4-AB-DHRIO Manuel utilisateur

Sony

Sony PCS-I150 Manuel utilisateur

Middle Atlantic Products

Middle Atlantic Products VTC Series Manuel utilisateur

Prentke Romich Company

Prentke Romich Company Vanguard Plus Mode d’emploi

Speakerbus

Speakerbus iD 712 Manuel utilisateur

Trelleborg

Trelleborg SafePilot CAT PRO Manuel utilisateur

Sennheiser

Sennheiser ADN Manuel utilisateur

ADTRAN

ADTRAN NetVanta 7100 Manuel utilisateur

AINA

AINA PTT Voice Responder Manuel utilisateur

Yamaha

Yamaha ProjectPhone PJP-100H Manuel utilisateur

vissonic

vissonic VLI Series Manuel utilisateur

Panasonic

Panasonic KX-VC500 Manuel utilisateur

Poly

Poly Trio 8300 Manuel utilisateur

Crestron

Crestron Mercury CCS-UCA-SMK Dessin dimensionnel

Inmarsat

Inmarsat mini M Manuel utilisateur

Tenveo

Tenveo ALL-IN-ONE Manuel utilisateur
