CIS VISION:analog VCC-G20X30T1 Guide de démarrage rapide

VCC-G20X30T1 Rev. 900-557-32-00

29mm Cubic XGA

Analog B/W Camera

VCC-G20X30T1

Product Specification

& Operational Manual

CIS Corporation

VCC-G20X30T1 Rev. 900-557-32-00

Table of Contents

1. Scope of Application..................................................................................................................... 3

2. Handling Precautions.................................................................................................................... 3

3. Product Outline............................................................................................................................ 4

4. Specification ................................................................................................................................ 5

4.1. General Specification .............................................................................................................. 5

4.2. Durability............................................................................................................................... 7

4.3. Safety/Quality Standards......................................................................................................... 7

4.4. CCD Spectral Response (Representative Value)......................................................................... 8

4.5. Optical Black Layout ............................................................................................................... 8

5. External Connector Pin Assignment................................................................................................ 9

5.1. 12pins Circular Connector HR10-10R-12PA (HIROSE)................................................................ 9

5.2. Switch Settings....................................................................................................................... 9

6. Function.....................................................................................................................................11

7. Dimensions.................................................................................................................................13

8. Timing Chart...............................................................................................................................14

8.1. Horizontal synchronous timing................................................................................................14

8.2. Vertical synchronous timing of Progressive scan.......................................................................14

8.3. Vertical synchronous timing of Binning scan ............................................................................15

8.4. Vertical synchronous timing of Partial scan..............................................................................15

8.5. Long time exposure mode timing (Restart Reset operation)......................................................16

8.6. External trigger operation timing by pulse width setup (SYNC Reset type) .................................16

8.7. External trigger operation timing by pulse width setup (SYNC Non-Reset type)........................17

9. Cases for Indemnity (Limited Warranty).......................................................................................18

10. CCD Pixel Defect .......................................................................................................................18

11. Product Support ........................................................................................................................18

VCC-G20X30T1 Rev. 900-557-32-00

1. Scope of Application

This is to describe VCC-G20X30T1, XGA B/W CCD camera. All specifications contained herein are

subject to change without prior notice. Reproduction in whole or in part is prohibited.

2. Handling Precautions

The camera must not be used for any nuclear equipments or aerospace equipments with which

mechanical failure or malfunction could result in serious bodily injury or loss of human life. Our

warranty does not apply to damages or defects caused by irregular and/or abnormal use of the

product.

Please observe all warnings and cautions stated below.

Our warranty does not apply to damages or malfunctions caused by neglecting these precautions.

zDo not use or store the camera in the following extreme conditions:

¾Extremely dusty or humid places.

¾Extremely hot or cold places (operating temperature –5℃ to +45℃)

¾Close to generators of powerful electromagnetic radiation such as radio or TV transmitters.

¾Places subject to fluorescent light reflections.

¾Places subject to unstable (flickering, etc.) lighting conditions.

¾Places subject to strong vibration.

zRemove dust or dirt on the surface of the lens with a blower.

zDo not apply excessive force or static electricity that could damage the camera.

zDo not shoot direct images that are extremely bright (e.g., light source, sun, etc.), and when

camera is not in use, put the lens cap on.

zFollow the instructions in Chapter 6, “External connector pin assignment” for connecting the

camera. Improper connection may cause damages not only to the camera but also to the

connected devices.

zConfirm the mutual ground potential carefully and then connect the camera to monitors or

computers. AC leaks from the connected devices may cause damages or destroy the camera.

zDo not apply excessive voltage. (Use only the specified voltage.) Unstable or improper power

supply voltage may cause damages or malfunction of the camera.

zMake sure that the camera and peripheral equipments are properly connected before turning the

camera on. Especially in INT/EXT sync signal settings, improper connection may cause

damages to the camera and the connected devices.

zAt least 5 seconds shall be waited to reboot the camera.

In case of abnormal operation, contact the distributor from whom you purchased the product.

VCC-G20X30T1 Rev. 900-557-32-00

3. Product Outline

VCC-G20X30T1 is a high-resolution industrial B/W camera module utilizing a 1/3-inch PS IT CCD.

800K pixels CCD image sensor with on-chip micro-lenses realizes high sensitivity and high resolution.

Key Features

□ Sync. System

HD/VD External sync. input

Internal sync. output

□ Electronic shutter

Electronic shutter speed switchable by rear panel switch

1/30s ～1/10,000s : 8 steps

Electronic shutter switchable by trigger pulse width

1/4s ～1/100,000s

□ High frame rates

The followings are effective at trigger shutter operation.

29.68 fps: Full Frame Scan Mode

59.35 fps: Vertical Binning Mode

89.14 fps: 1/3 Partial Scan Mode

118.7 fps: 1/4 Partial Scan Mode

□ 29mm Cubic in size

Its small size, 29mm cubic, and light weight, 44g, makes it a best match for use in

embedded systems for image calibration and microscopic applications.

VCC-G20X30T1 Rev. 900-557-32-00

4. Specification

4.1. General Specification

Item Specification Remarks

Power consumption 2.0 W (with rated supply)

Power requirements DC +12V±10%

Pick up device

1/3” Interline Transfer B/W CCD ICX204AL

(Sony)

Total pixel number 1034(H) ×779(V)

Effective pixel number 1024(H) ×768(V)

Unit cell size 4.65μm(H) ×4.65μm(V) Square pixel

Spectral response Refer to 4.4. CCD Spectral response (representative value).

Synchronization

System

Internal Sync. HD/VD External Sync.

Input signal level: 2～5Vp-p, TTL Input

Automatically switched by HD recognition.

Frequency allowance: 28～31MHz

Jitter: under 20ns

Jumper

resistance of

75Ωterminal

is HR70,

29.5MHz.

Scanning system

Non-interlace scan

1/30sec Full Frame Scan (Standard operation)(External sync.)

1270 PCLK

796 HD

Horizontal frequency 23.622 KHz (23.228 KHz)

Vertical frequency 29.676 Hz (29.18 Hz)

Pixelclock 30.0 MHz (29.5 MHz)

1/60sec Binning Scan

1270 PCLK

398 HD

Horizontal frequency 23.622 KHz

Vertical frequency 59.35 Hz

Pixel clock 30.0 MHz

1/90sec Partial Scan

1270 PCLK

265 HD

Horizontal frequency 23.622 KHz

Vertical frequency 89.14 Hz

Pixel clock 30.0 MHz

1/120sec Partial Scan

1270 PCLK

199 HD

Horizontal frequency 23.622 KHz

Vertical frequency 118.7 Hz

Pixel clock 30.0 MHz

Video output signal

Analog output 1.0V(p-p)

Sync. negative, 75Ωunbalanced, DC connect

White clip level 820 ±50mVp-p

Setup level 25 ±15mVp-p

Synclevel 290 ±30mVp-p

DClevel 500 ±100mV

VCC-G20X30T1 Rev. 900-557-32-00

Item Specification Remarks

Trigger input

Input signal Trigger Positive, Rising edge.

Input signal level Low 0.5Vmax , High 4Vmin

Input trigger width 4μs ～250ms

Normal shutter

operation

Setting by the rear switch.

OFF, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000s

External trigger

shutter operation

Setting by the rear switch.

1/30, 1/125, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000s

Setting by trigger pulse width.

10us ～250ms (1/100,000s ～1/4s)

Sensitivity F5.6 400 lx (Exposure time 1/30sec, Gain 0dB, 3200°K)

Minimum illumination F1.4 2 lx (Exposure time 1/30sec, Gain Max, VS 50IRE)

S/N ratio 52 dB (Gain 0dB)

Horizontal resolution 768 TV line

Gain Fix 0dB

Manual 0 ～+12 dB

γGamma 1.0 fixed

Dimension Refer to overall dimension drawing (Clause 7)

29mm(H) x 29mm(W) x 29mm(D) (excluding protruding part)

Mass 44g

Lens Mount C Mount

Flange Back Flange focal length fixed

Optical axis accuracy Within φ0.4 from the center

VCC-G20X30T1 Rev. 900-557-32-00

4.2. Durability

Item Specification Remarks

Operation

temperature

Specifications guaranteed: -0℃～+ 40℃with RH 20～80%

Operation guaranteed: -5℃～+ 45℃with RH 20～80%

With no condensation

Storage

temperature

-25℃～+ 60℃with RH 20～90%

With no condensation

Vibration resistance

Acceleration 98m/S2 (10G)

Vibration frequency 20～200Hz

Direction X Y Z 3 directions

Testing time 120min for each direction

No malfunction shall occur after testing the above.

Shock resistance Acceleration 490m/S2 (50G)

Direction 6directions

Grounded

mechanical

chassis/Insulation

Mechanical chassis of VCC-G20X30T1 is grounded, therefore, use an

insulated tripod adaptor when the camera shall be isolated.

4.3. Safety/Quality Standards

・ UL Standard

Conform to UL standard including materials and others.

・ CE Standard

Conform to EN55022:2006 Class B

Conform to EN61000-6-2: 2005

・ RoHS

Conform to RoHS.

・ FCC Compliance Conform to FCC Class A Digital Device

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two

conditions: (1) this device may not cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired operation.

VCC-G20X30T1 Rev. 900-557-32-00

4.4. CCD Spectral Response (Representative Value)

4.5. Optical Black Layout

Optical

Black

Effective Image

Area

Signal Output

Top View

H:1034 , V:779



PinNo.1

PinNo.9

VCC-G20X30T1 Rev. 900-557-32-00

5. External Connector Pin Assignment

5.1. 12pins Circular Connector HR10-10R-12PA (HIROSE)

Partial input can be done via rear switch No.9. It can be effective

either turning switch No.9 on, or make the connector No.9 GND

externally. (10KΩpulls up partial input.)

5.2. Switch Settings

Rear panel switch function 10bit DIP-Switch

1 E2 ◇Electronic Shutter Speed 3bit, 8step

2 E1 OFF ～1/10000sec

3 E0

4 BINNING ◇Binning SCAN ON/OFF

5 MODE2 ◇Function 3bit

6 MODE1 NormalMode/Restart-ResetMode

7 MODE0 Trigger Shutter Mode

8 GAIN ◇Fix 0dB / Manual Gain 0～12dB

9 PARTIAL ◇Partial Scan ON/OFF

10 IN/OUT ◇HD/VD Input, Output ON: Input

OFF

●indicates initial setting position.

Pin No.

1 GND

2 Power IN +12V

3 GND

4 Video Out

5 GND

6 HD In/Out

7 VD In/Out

8 GND

9 Partial

10 WEN Out

11 Trigger In

12 GND

●

VCC-G20X30T1 Rev. 900-557-32-00

Rear Fixed Electronic Shutter Switch SW1, SW2, SW3

E2 E1 E0 ShutterValue ActualTimeatNormalOperation ActualTimeatTriggerOperation

1 2 3

OFF OFF OFF OFF 33.3 ms 17.0 ms

OFF OFF ON 1/125 sec 8.0 ms 8.0 ms

OFF ON OFF 1/250 sec 4.0 ms 4.0 ms

OFF ON ON 1/500 sec 2.0 ms 2.0 ms

ON OFF OFF 1/1000 sec 1.0 ms 1.0 ms

ON OFF ON 1/2000 sec 488 us 504 us

ON ON OFF 1/4000 sec 236 us 250 us

ON ON ON 1/10000 sec 110 us 120 us

Note: At vertical binning mode and partial scan mode, the shutter speed set by SW will be invalid since the set frame rate

will be its shutter speed. At trigger shutter mode, the shutter speed set by SW will be valid.

Rear Switch for Scanning Mode Change SW4, SW9

Binning Partial Setting Mode

OFF OFF 30 fps Full Frame Scan

ON OFF 60 fps Binning Scan

OFF ON 60 fps 1/2 Partial Scan

ON ON 120 fps 1/4 Partial Scan

Rear Switch for Mode Change SW5, SW6, SW7

Mode2 Mode1 Mode Scanning Mode

5 6 7

OFF OFF OFF Normal Operation

OFF ON ON Long Time Exposure Operation (Restart, Reset)

ON OFF OFF Trigger Operation by Switch Setting (SYNC Rest)

ON OFF ON Trigger Operation by Switch Setting (SYNC Non-reset)

ON ON OFF Trigger Operation by Pulse Width Setting (SYNC Reset)

ON ON ON Trigger Operation by Pulse Width Setting (SYNC Non-reset)

＊ Do not set the mode other than those above.

Rear Switch for Gain Setting SW8

OFF Fixed Gain 0 dB

ON Manual Gain 0～12 dB

Rear Switch for HD/VD Input Output SW10

OFF HD/VD Output Valid at normal operation

ON HD/VD Input Valid at normal operation, long time exposure operation, and

trigger shutter operation (non-reset)

HD Input Trigger shutter operation (reset)

Table des matières

Autres manuels CIS Appareil photo numérique

CIS

CIS VCC-FC60FR19CL Guide de démarrage rapide

CIS

CIS VCC-GC21FR11PCL Guide de démarrage rapide

CIS

CIS VISION:elite VCC-GM60FV11CL Guide de démarrage rapide

CIS

CIS VCC-G20E20B Guide de démarrage rapide

CIS

CIS DCC-4K2 Guide de démarrage rapide

CIS

CIS VCC-G20X30B Guide de démarrage rapide

CIS

CIS VCC-5CL4MHS Guide de démarrage rapide

CIS

CIS VCC-5CXP4M Guide de démarrage rapide

CIS

CIS VCC-SXCXP1SW Guide de démarrage rapide

CIS

CIS VISION:mini VCC-G22S21APCL Guide de démarrage rapide

CIS

CIS VCC-SXCXP5M Guide de démarrage rapide

CIS

CIS VISION:mini VCC-GC20V41CL Guide de démarrage rapide

CIS

CIS VCC-FC21FR19OP Guide de démarrage rapide

CIS

CIS VCC-GC21FR11OP Guide de démarrage rapide

CIS

CIS VCC-SXCXP3R Guide de démarrage rapide

CIS

CIS VISION:mini VCC-F22V39ACL Guide de démarrage rapide

CIS

CIS VISION:elite VCC-FC41SX29CL Guide de démarrage rapide

CIS

CIS VCC-120CXP1M Guide de démarrage rapide

CIS

CIS VCC-12CL1M Guide de démarrage rapide

CIS

CIS DCC-HD3N Guide de démarrage rapide

CIS

CIS VISION:mini VCC-G22U21ACL Guide de démarrage rapide

CIS

CIS Vision:Elite VCC-F32FV19CL Guide de démarrage rapide

CIS

CIS VCC-SXCXP3M Guide de démarrage rapide

CIS

CIS VCC-FC21FR19PCL Guide de démarrage rapide

Manuels Appareil photo numérique populaires d'autres marques

Mercury

Mercury 350K Manuel utilisateur

Pentax

Pentax Optio LS 465 Manuel utilisateur

Sanyo

Sanyo VPC-S1085 Manuel utilisateur

GE SMART A1255 Manuel utilisateur

Point Grey

Point Grey Gazelle Manuel utilisateur

Nikon

Nikon COOLPIX A Manuel utilisateur

Pentax

Pentax P-5 Manuel utilisateur

BlazeVideo

BlazeVideo A280 Manuel utilisateur

Sony

Sony MCA-20 Manuel utilisateur

Sony

Sony Alpha DSLR-A290 Manuel utilisateur

ATIK Cameras

ATIK Cameras One Manuel utilisateur

CohuHD Costar

CohuHD Costar 3930 Series Manuel utilisateur

Leica

Leica M10-R Manuel utilisateur

FujiFilm

FujiFilm FinePix A700 Manuel utilisateur

Lorex

Lorex LNZ81P25 Series Manuel utilisateur

GE J1470S Manuel utilisateur

Sony

Sony A6700 Guide de l'utilisateur

Canon

Canon EOS ELAN7 Manuel utilisateur
