Chuango H4 Manuel utilisateur

Printed in China

PA: H4-UM-EN-V1.0

H4 GSM/WiFi

Smart Home System

User Manual

Gentle Reminder:

Please read through this manual carefully before use.

Please keep this manual for further reference.

Please ensure proper usage based on a full understanding of this manual.

Contents

Characteristics of Smart Home System------------------------------------------------01

Packaging List -------------------------------------------------------------------------02

Operating Principle --------------------------------------------------------------- 03-04

Categories of Detector Zones ------------------------------------------------------03

Operate Together with Multiple Smart Switch --------------------------------------04

Introduction of Panel-------------------------------------------------------------- 05-07

Powering on the Panel -------------------------------------------------------------06

Positioning of Panel -----------------------------------------------------------------07

Use of Accessories ---------------------------------------------------------------- 08-11

Remote Control---------------------------------------------------------------------08

Door/Window Contact--------------------------------------------------------------09

PIR motion detector ----------------------------------------------------------------09

Smart Switch------------------------------------------------------------------------ 11

Accessory Pairing /Removal------------------------------------------------------- 11-12

Pairing Wireless Accessories --------------------------------------------------------11

Pairing Wireless siren (requires separate purchase) ---------------------------------12

Removal of Wireless Accessories----------------------------------------------------12

Removal of Wireless Siren (requires separate purchase) ----------------------------12

Installation of Accessories --------------------------------------------------------- 13-14

Installation of Door/Window Contact -----------------------------------------------13

Installation of PIR Motion Detector -------------------------------------------------14

App Setting and Operation ------------------------------------------------------- 15-20

Step 1: Download App--------------------------------------------------------------15

Step 2: WiFi Network Setting -------------------------------------------------------16

Step 3: Registration ----------------------------------------------------------------16

Step 4: App Operation--------------------------------------------------------------17

APN Settings --------------------------------------------------------------------------22

Remote Control by Phone ------------------------------------------------------------23

Restore Default Settings---------------------------------------------------------------23

FAQs ------------------------------------------------------------------------------ 24-25

Specication ---------------------------------------------------------------------- 26-28

Safety Reminder ----------------------------------------------------------------------29

Maintenance and Repair --------------------------------------------------------------30

Disclaimer-----------------------------------------------------------------------------31

01 02

Characteristics of Smart Home System

1. Stable Transmission

Stable transmission at 315MHz or 433MHz direction frequency and at 868 MHz or

915 MHz bidirectional frequency

2. Powerful Functions

Security system and home automation 2 in 1

Supports WiFi and SIM card

Supports 5 alarm notication numbers

Supports 50 wireless accessories (10 remote controls, 40 detectors/smart switches)

3. High Level of Security

Hidden tamper switch to prevent malicious damage

Built-in 1,000,000 RF codes

105-dB siren deterrence

4. User-friendliness

Addition and removal of accessories by category

App remote control alarm system and home appliance switch control

Packaging List

Please check if the following items are contained in the package. In case of any missing

parts, please contact the distributor/retailer.

H4 panel ×1 H4-PW smart switch ×1 RC-86 bidirectional

remote control ×2

PIR-860 bidirectional

PIR motion detector ×1

DWC-86 bidirectional

door/window contact ×1

AC adapter ×1

H4 stand ×1 Double-sided adhesive

tape (Two for PIR

detector and two for

door contact)

User manual ×1PIR stand ×1

03 04

Operating Principle

PIR motion detector after pairing

Door/window contact after pairing

Intrusion

detected

Panel alarm/

App notication/

phone call

Manage through remote

control/mobile phone

User

Operating Principle of Panel Alarm

Categories of Detector Zones

Normal Zone: If panel is set to Arm or Home arm, normal zone detector will enter

operating mode. Any detection of intruders or an emergency situation will trigger the

panel alarm.

Home Zone: If panel is set to Arm, home zone detector will enter operating mode.

Any detection of intruders will trigger the panel alarm. If panel is set to Home Arm, no

alarm signal sent from the home zone detector will be processed.

Delay Zone: This is the alarm delay zone. If panel is set to Arm, delay zone detector

will turn the alarm on after the designated period of time once triggered. This usually

applies to the door/window contact of the entrance door. For example, if door/window

contact of entrance door is set as delay zone and the delay time is 30 seconds, the

user will be reminded with a warning sound from the panel to set the system to Disarm

mode after entering the home under the Arm condition. If panel has not been set to

Disarm after 30 seconds, it will sound the alarm.

24-Hour Zone: 24-hour zone operates independently of the setting of Arm or Disarm.

Once the zone is triggered, the alarm will be immediately activated.

Categories Factory Default Zone

PIR-860 PIR Motion Detectorr Home Zone (Modiable via App)

DWC-86 Door/Window Contact Normal Zone (Modiable via App)

Operating together with Multiple Smart Switches

Lamp

Fan

Microwave oven

Coffee machine

H4 Panel

Home appliance

switches can be

freely controlled

through App.

Operating Principle of Home Appliance Control

05 06

Introduction of Panel

WiFi

Indicator

Light

GSM Indicator Light

Status Indicator Light

Front Side

SOS button

Top Side

Description of Indicator Light

Indicator Light Status Meaning

WiFi Indicator

Light

Flash slowly (once every 3 seconds) WiFi network searching

Flash quickly(once every second) Conguration status

Steady on WiFi network connected

Status Indicator

Light

Blue light is steady on Home arm

Green light is steady on Disarm

Red light is steady on Arm

Flashing Panel alarm

Red, green and blue lights ash

simultaneously

Panel is in low battery condition.

Please connect with AC power.

Off Panel is not powered on, or not

powered with adapter

GSM Indicator

Light

Flash quickly (once per second) GPRS network searching

Flash slowly (once every 3 seconds) GPRS network connected

Off No SIM card

Note: After pressing the SOS button, the panel will immediately sound the alarm.

Tamper Switch

SIM Card Slot AC Adapter Port

Power Switch

Pairing Button

Back Side

Note: After pressing the Tamper Switch, the panel will immediately sound the alarm.

Powering on the Panel

Connect AC adapter to power outlet → When the power is OFF, insert your own SIM

card → Turn power switch from OFF to ON → When GSM indicator light ashes slowly

(once every three seconds), GPRS network has been connected.

Note: The SIM card should allow you to make and receive calls, with function of GPRS, SMS

and caller ID activated. If the user only chooses WiFi control system, insertion of SIM card is

not required. Then there will be push messages sent from the APP instead of alarm phone

calls upon sounding of alarm.

07 08

Positioning of Panel

Place on the table. For best reception of the wireless signal, it is recommended that

you place the panel in an open area that is located centrally to the whole alarm system.

Avoid placing the panel on a load-bearing wall or beside any electrical appliances.

Set on the Table

After closing the back cover of the panel and tightening the screws, it can be placed

on the table for use.

Use of Accessories

Remote Control

Arm button Disarm button

SOS button

Home Arm button

Description of Indicator Light

Buttons Status

Press Arm button and the panel will make a “Di” sound once, setting the

system to Arm.

Press Arm button for at least 3 seconds, the indicator light goes on.

The system will be set to Mute Arm.

Press Disarm button and the panel will make a ““Di” sound twice, setting

the system to Disarm.

Press Disarm button for at least 3 seconds, the indicator light goes on.

The system will be set to Mute Disarm.

Press Home Arm button and the panel will make a “Di” sound once,

setting the system to Home Arm. Under this condition, home zone

accessories will be set to Disarm to enable home activities of the owner.

Press Home Arm button for at least 3 seconds, the indicator light goes

on. The system will be set to Mute Home Arm.

Press SOS button, the indicator light goes on. The panel will immediately

sound the alarm.

Note: If, upon pressing a button, the LED light flickers twice and then goes out, then the

remote control battery is low. Please replace the battery as soon as possible.

09 10

Door/Window Contact

Door/window contact is for detection of the opening-closing state. If the system is set

to Arm and the transmitter is more than 2cm apart from the magnet, the panel will

receive an alarm signal from door/window contact and then sound the alarm.

AAA 1.5V

2.5m

Transmitter Magnet

Indicator Light

Tamper Switch

Note: Indicator light ashes once: Door/window contact is triggered.

Flashes once after 2 seconds when triggered: The battery is running low. Please replace the

battery as soon as possible.

After pressing the Tamper Switch, the system will immediately sound the alarm.

Important!

Door/window Status Alert: When arm/ home arm the system without door/window

closed, the panel will sound “DiDi” to remind you for 15s. If press the Arm button

again, the sound will stop and system arm immediately.

PIR Motion Detector

PIR motion detector adopts digital dual-core fuzzy logic control processing technology

and an intelligent analysis algorithm. Upon detection of human body movement, the

panel will receive an alarm signal and then sound the alarm.

AAA 1.5V

2.5m

Detection Window

Indicator Light

Note: Indicator light ashes once: Motion is detected.

Flashes three times per second: The battery is running low. Please replace the battery as soon

as possible.

Working Mode

Testing Mode

After removing the insulating strip, the PIR motion detector will conduct a

self-inspection for around 1 minute and then enter testing mode. The detector carries

out detection every 10 seconds. After 3 minutes, the status indicator blinks twice, and

the detector switches to power saving mode.

Note: Equipped with the batteries with pressing and holding the test button, the motion

detector will remain in the testing mode eternally. That is detecting every 10 seconds.

Reloading the batteries can exit this mode.

Power Saving Mode (Default Setting)

This product is designed with an intelligent power-saving mode. If human body

movements are detected twice within 3 minutes, it will be automatically switched to

sleeping mode to save power. Any movement within the detection zone will not turn

the light on or send an alarm signal. If no human body movements have been detected

after 3 minutes, the PIR motion detector automatically returns to the alert mode.

After self-inspection and a 3-minute testing

mode, detector enters power saving mode

If human body movements are detected twice within

3 minutes, the detector will automatically be switched

to sleeping mode.

No detection of human body movement for 3 minutes

Exit sleeping mode and enter

operating mode.

Tamper Switch

Test Button

11 12

Detection Area

AAA 1.5V

2.5m

Top View

Side View

Smart Switch

The H4 panel can be matched with multiple smart switches. You can control home

appliances remotely using these switches.

Status Indicator Light Pairing button/

On-off button

Electrical Socket

Note: When the power is on, the status indicator light will glow steadily; when power is off,

the status indicator light will turn off.

Accessory Pairing/Removal

Accessories in this kit was paired before the products left the factory. New accessories

have to be paired with the panel successfully before installation for use.

Pairing Wireless Accessories

Press the Pairing button once on the panel (see g.). The panel will make a “Di” sound

once, before entering pairing mode. If you trigger the wireless accessory once, the

panel will make a “Di” sound once; this completes pairing with the panel. The detector

of the rst paired is Zone 1; the detector of the second paired is Zone 2, and so on.

Names of the detectors can be customized via App.

Note: If the panel makes a “Di”sound once, that means successful pairing; if the panel makes

a “Di”sound twice, that means repeated pairing.

Press any button on the remote

control

Separate the transmitter from the

magnet by at least 2 cm

Place the PIR motion detector in a

high position and then walk within

the detection area to trigger the

PIR alarm once (the indicator light

ashes once).

Press and hold the Pairing button

and the switch will make a “Di”

sound once

Pairing Wireless Siren (requires separate purchase)

Press the Pairing button of the wireless siren once; it will make a “Di” sound once,

before entering pairing mode. Then press the Pairing button of the panel twice; the

wireless siren will make a “Di” sound once, that means repeated pairing.

Removal of Wireless Accessories

Press and hold the Pairing button of the panel for 5 seconds until it makes a “Di”

sound once and then release. All wireless accessories have been removed. Wireless

accessories can also be removed by category through the App.

Removal of Wireless Siren (Requires Separate Purchase)

Press the Pairing button of the alarm for 8 seconds and it will make a “Di” sound once,

successfully disconnecting the wireless siren from the panel.

13 14

Installation of Accessories

Upon conrmation of successful pairing, enter installation processes.

Installation of Door/Window Contact

Step 1: Choose a Suitable Place

The contact can be mounted on objects that can be opened/closed like doors,

windows, and cabinets. To mount on a metal door, please block up the contact.

Step 2: Use Double-sided Adhesive Tape on the Back of Door/Window Contact

When attaching the contact, ensure the distance between the transmitter and the

magnet is less than 1 cm. When the distance exceeds 2 cm and the transmitter ashes,

this means the door/window contact is functioning properly.

Step 3: Testing

Set the panel to arm and then trigger the door/window contact (open the door

or window) to ensure proper functioning of the panel in receiving signals from the

accessory.

2.2-2.5m

Installation of PIR Motion Detector

Insatallation notice: Should not face glass doors/windows; should not face objects

that easily swing; should not face any source of cold or heat, such as a heater, air-

conditioner, refrigerator or microwave oven; avoid installing two PIR motion detectors

within the same detection area to prevent mutual interference.

2.2-2.5m

Step 1: Choose a Suitable Place

For best detection, it is recommended that you use a piece of 3M double-sided

adhesive tape inside the package to mount the PIR motion detector on a clean wall at

the corner of a major passageway (e.g. living room and corridor) at 2.2-2.5 m above

the ground.

2.2-2.5m

Ground

Step Two: Test the PIR Motion Detector

After mounting the detector, move within the detection area and observe the status

indicator light. If any human body movement is detected, the status indicator light will

ash once.

2.2-2.5m

Note: You may also use an accessory stand and

screws to mount the product in a special position and

then achieve best detection through the walking test

and manual adjustment of angles.

Step 3: Testing

Set the panel to Arm and then trigger the detector to ensure proper functioning of the

panel in receiving signals from the accessory.

15 16

App Setting and Operation

H4 has WiFi and GPRS dual-network function. During the use of WiFi, the GPRS

network will be disconnected. If the WiFi connection fails (e.g. the Internet connection

is unstable or there is no power supply from the adapter), it will be automatically

disconnected and the search for the GPRS network will begin.

Step 1: Download App

iPhone Mobile: Enter App Store, type the search keyword “H4 Smarthome” and then

download for installation. Android Mobile: Enter Google Play mobile app store, type

the search keyword “H4 Smarthome” and then download for installation.

H4 Smarthome

Step 2: WiFi Network Setting

1. Press the pairing button of the panel three times. The panel will make a “Di” sound

once and the WiFi indicator light will ash quickly (once per second), means it enters

network conguration mode.

2. Open App, tap [Network Conguration] and then follow the instruction in the app.

When the WiFi indicator light is steady on means wi network connected.

H4 Smarthome

Note: In case of any change of the router name or password, please set up the network

conguration again. User may choose GPRS network control system without conguration of WiFi

network. After insertion of a SIM card and a slow ash (once every three seconds) of the GSM

indicator light, you can proceed with registration and login on the App and then start to use it.

Step 3: Registration

Enter the user name, password, panel ID No. and SN code in the registration interface

to complete registration.

H4 Smarthome

Note: Each panel has its own ID and SN code shown at the bottom of the panel. Please keep it

properly. You may tap [Forgot User Information] to retrieve a forgotten username or password.

Table des matières

Manuels Unité de contrôle populaires d'autres marques

Festo

Festo Compact Performance CP-FB6-E Manuel de la liste des pièces

Elo TouchSystems

Elo TouchSystems DMS-SA19P-EXTME Manuel utilisateur

JS Automation

JS Automation MPC3034A Manuel utilisateur

JAUDT

JAUDT SW GII 6406 Series Guide rapide

Spektrum

Spektrum Air Module System Manuel utilisateur

BOC Edwards

BOC Edwards Q Series Manuel utilisateur

KHADAS

KHADAS BT Magic Manuel utilisateur

Etherma

Etherma eNEXHO-IL Manuel utilisateur

PMFoundations

PMFoundations Attenuverter Manuel utilisateur

GEA

GEA VARIVENT Manuel utilisateur

Walther Systemtechnik

Walther Systemtechnik VMS-05 Manuel utilisateur

Altronix

Altronix LINQ8PD Instructions de montage

Eaton

Eaton Powerware Series Manuel utilisateur

WAGO

WAGO 750-407/040-000 Manuel utilisateur

Sony

Sony CCU-590 Manuel utilisateur

Graco

Graco 25D614 Manuel utilisateur

Task Force Tips

Task Force Tips YE-RF-900 Manuel de programmation

Shini

Shini SPV-U Series Manuel utilisateur
