CHIEF PSMH2482 Manuel utilisateur

INSTALLATION INSTRUCTIONS

Instrucciones de instalación

Installationsanleitung

Instruções de Instalação

Istruzioni di installazione

Installatie-instructies

Instructions d´installation

Large Flat Panel Static Wall Mount

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

PSMH2482

PSMH2482 Installation Instructions

DISCLAIMER

Milestone AV Technologies and its affiliated corporations and

subsidiaries (collectively "Milestone"), intend to make this

manual accurate and complete. However, Milestone makes no

claim that the information contained herein covers all details,

conditions or variations, nor does it provide for every possible

contingency in connection with the installation or use of this

product. The information contained in this document is subject

to change without notice or obligation of any kind. Milestone

makes no representation of warranty, expressed or implied,

regarding the information contained herein. Milestone assumes

no responsibility for accuracy, completeness or sufficiency of

the information contained in this document.

Chief® is a registered trademark of Milestone AV Technologies.

IMPORTANT WARNINGS AND

CAUTIONS!

WARNING:

A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION:

A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING:

Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all components are

properly assembled and installed using the instructions

provided.

WARNING:

Failure to provide adequate structural strength

for this component can result in serious personal injury or

damage to equipment! It is the installer’s responsibility to

make sure the structure to which this component is attached

can support a minimum of 2,000lbs (907.185kg). Reinforce

the structure as required before installing the component.

WARNING:

Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components attached to the PSMH-2482 mount does not

exceed 300 lbs (136.08 kg).

DIMENSIONS

1.89

47.9

35.27

895.8

29.50

749.3

62.00

1574.8

55.12

1400

31.50

800

4.00

OFFSET FROM WALL

101.5

Installation Instructions PSMH2482

LEGEND

TOOLS FOR INSTALLATION/PARTS

Tighten Fastener

Apretar elemento de fijación

Befestigungsteil festziehen

Apertar fixador

Serrare il fissaggio

Bevestiging vastdraaien

Serrez les fixations

Loosen Fastener

Aflojar elemento de fijación

Befestigungsteil lösen

Desapertar fixador

Allentare il fissaggio

Bevestiging losdraaien

Desserrez les fixations

Open-Ended Wrench

Destornillador Phillips

Kreuzschlitzschraubendreher

Chave de fendas Phillips

Cacciavite a stella

Kruiskopschroevendraaier

Tournevis à pointe cruciforme

Pencil Mark

Marcar con lápiz

Stiftmarkierung

Marcar com lápis

Segno a matita

Potloodmerkteken

Marquage au crayon

Drill Hole

Perforar

Bohrloch

Fazer furo

Praticare un foro

Gat boren

Percez un trou

Hex-Head Wrench

Ajustar

Einstellen

Ajustar

Regolare

Afstellen

Ajuster

C(2)

G(4)

5/16-18 x 5/8" M8 x 45mm

F(18)

5/16-18"

E(4)

A(2) B(2)

1/4" 9/16" M5 (included)

D(4)

[Vertical Bracket] [Horizontal Bracket]

[Locking Flag] H(8)

3/8" J(2)

5/16" K(1)

M5 L(1)

3/16"

3/16"(included)

PSMH2482 Installation Instructions

ASSEMBLY AND INSTALLATION

Mount Assembly

1. Attach locking flags (G) to vertical brackets (A) by installing

two 5/16-18 x 5/8" button head cap screws though lower

hole on locking flags, upper hole on vertical brackets, 5/16"

washers (J) and into two 5/16-18" lug nuts (F). (See Figure

Figure 1

2. Attach two vertical brackets (A) to two horizontal brackets

(B) using remaining sixteen 5/16-18 nylon lock nuts (F).

(See Figure 2)

Figure 2

Mount Installation

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

MOUNT FALLING CAUSING SERIOUS PERSONAL

INJURY OR DAMAGE TO EQUIPMENT! The mount weighs

in excess of 75 lbs (34.02 kg). ALWAYS use appropriate

lifting device and follow all safety practices when moving and

installing this mount.

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

DISPLAY FALLING CAUSING SERIOUS PERSONAL

INJURY OR DAMAGE TO EQUIPMENT! It is the installer’s

responsibility to make sure the structure to which this mount

is being attached can support a minimum of 2,000 lbs

(907.18kg). Reinforce the structure as required before

installing this mount.

WARNING:

Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components attached to the PSMH-2482 mount does not

exceed 300 lbs (136.08 kg).

1. Using appropriate lifting device, raise assembled mount

and place mount against wall in desired installation

location. (See Figure 3)

2. Level and adjust horizontal position making certain slots in

upper and lower horizontal brackets on mount are properly

positioned over studs.

3. Using a pencil, or similar marking tool, mark the location of

mounting holes in base onto surface. (See Figure 3)

4. Drill eight 1/4" pilot holes at marked locations. (See Figure

(A) x 2

(G) x 2

(J) x 2

(F) x 2

(F) x 16

(B)

(A)

Installation Instructions PSMH2482

Figure 3

CAUTION:

IMPROPER INSTALLATION CAN LEAD TO

MOUNT FALLING CAUSING SERIOUS PERSONAL INJURY

OR DAMAGE TO EQUIPMENT! DO NOT overtighten

hardware!

5. Secure mount to studs using appropriate hardware for

mountingsurfaceandeight3/8" washers(H). (SeeFigure 4)

Figure 4

Display Installation

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

MOUNT FALLING CAUSING SERIOUS PERSONAL INJURY

OR DAMAGE TO EQUIPMENT! DO NOT substitute

hardware.

1. Move locking flags (G) on mount to the OPEN position. (See

Figure 5)

Figure 5

(H) x 8

OPEN

(G) X 2

PSMH2482 Installation Instructions

Figure 6

(E) x 4

(D) x 4

2. Install four mounting buttons (E) onto display using four M8

x 45 button head cap screws (D). (See Figure 6)

3. Lift display following lifting instructions provided by display

manufacturer.

4. Align mounting buttons on display with teardrop mounting

holes in mount. (See Figure 7)

Figure 7

5. Move display forward until recessed area of mounting

buttons is positioned over lower area of teardrop mounting

holes. (See Figure 7)

6. Lower display until recess area of mounting buttons is

seated in lower area of teardrop mounting holes. (See

Figure 7)

7. Move locking flags (G) to CLOSED position and lock if

desired. (See Figure 8)

Figure 8

8. Route wires and cables to display.

padlock here

(G) X 2

Installation Instructions PSMH2482

PSMH2482 Installation Instructions

Chief Manufacturing, a products division

of Milestone AV Technologies

8831-002000 Rev00

Duchossois Group Company

www.chiefmfg.com

03/09

USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378

P800.582.6480 / 952.894.6280

F877.894.6918 / 952.894.6918

Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands

P+31 (0)40 2668620

F+31 (0)40 2668615

Asia Pacific A Room 24F, Block D, Lily YinDu International Building

LuoGang, BuJi Town, Shenzhen, CHINA.

P+86-755-8996 9226

F+86-755-8996 9217
