CHIEF PNRIW Series Manuel utilisateur

INSTALLATION INSTRUCTIONS

Instrucciones de instalación

Installationsanleitung

Instruções de Instalação

Istruzioni di installazione

Installatie-instructies

Instructions d´installation

Large Flat Panel In-Wall Swing Arm Mount

Spanish Product Description

German Product Description

Portuguese Product Description

Italian Product Description

Dutch Product Description

French Product Description

PNRIW / PNRIWU

PNRIW / PNRIWU Installation Instructions

DISCLAIMER

CSAV, Inc., and its affiliated corporations and subsidiaries

(collectively, "CSAV"), intend to make this manual accurate and

complete. However, CSAV makes no claim that the information

contained herein covers all details, conditions or variations, nor

does it provide for every possible contingency in connection

with the installation or use of this product. The information

contained in this document is subject to change without notice

or obligation of any kind. CSAV makes no representation of

warranty, expressed or implied, regarding the information

contained herein. CSAV assumes no responsibility for

accuracy, completeness or sufficiency of the information

contained in this document.

IMPORTANT WARNINGS AND

CAUTIONS!

WARNING:

A WARNING alerts you to the possibility of

serious injury or death if you do not follow the instructions.

CAUTION:

A CAUTION alerts you to the possibility of

damage or destruction of equipment if you do not follow the

corresponding instructions.

WARNING:

Failure to read, thoroughly understand, and

follow all instructions can result in serious personal injury,

damage to equipment, or voiding of factory warranty! It is the

installer’s responsibility to make sure all components are

properly assembled and installed using the instructions

provided.

WARNING:

Failure to provide adequate structural strength

for the installation of this kit can result in serious personal

injury or damage to equipment! It is the installer’s

responsibility to make sure the structure to which this kit is

attached can support five times the combined weight of all

equipment.

WARNING:

Exceeding the weight capacity can result in

serious personal injury or damage to equipment! It is the

installer’s responsibility to make sure the combined weight of

all components attached to this accessory does not exceed

200 lbs (90.72 kg).

LEGEND

Tighten Fastener

Apretar elemento de fijación

Befestigungsteil festziehen

Apertar fixador

Serrare il fissaggio

Bevestiging vastdraaien

Serrez les fixations

Loosen Fastener

Aflojar elemento de fijación

Befestigungsteil lösen

Desapertar fixador

Allentare il fissaggio

Bevestiging losdraaien

Desserrez les fixations

Hex-Head Wrench

Llave de cabeza hexagonal

Sechskantschlüssel

Chave de cabeça sextavada

Chiave esagonale

Zeskantsleutel

Clé à tête hexagonale

Phillips Screwdriver

Destornillador Phillips

Kreuzschlitzschraubendreher

Chave de fendas Phillips

Cacciavite a stella

Kruiskopschroevendraaier

Tournevis à pointe cruciforme

Installation Instructions PNRIW / PNRIWU

TOOLS REQUIRED FOR INSTALLATION AND PARTS

Figure 1

I/M

(3/16")

K (1)

3/16"

A (1)

G (4)

F (16) H (1)

M(4)

L (4)

J (1)

B (4)

2 short (SIDES)

2 long

D (4)

5/16"

C (4)

5/16-18 x 5/8"

E (4)

5/16"

PNRIW / PNRIWU Installation Instructions

Installation

The following procedure assumes that a Chief Model PAC501

In-Wall accessory has previously been installed following the

installation instructions provided with the PAC501. If a PAC501

is not installed or there are any other questions regarding the

installation of this accessory, immediately contact a Chief

Customer Service representative by calling 800-582-6480 or by

visiting www.chiefmfg.com.

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

MOUNT FALLING CAUSING SEVERE PERSONAL INJURY

OR DAMAGE TO EQUIPMENT! DO NOT deviate from

installation instructions provided. DO NOT substitute

hardware.

1. Align mounting holes in swing arm UPPER and LOWER

mounting brackets with four mounting holes in PAC501.

(See Figure 2)

Figure 2

2. Secure swing arm to PAC501 using four button head cap

screws (C), four lock washers (D) and four flat washers (E).

(See Figure 3)

Figure 3

Trim Installation

To install optional trim;

1. Remove paper covering adhesive and affix three tape

squares (F) to inside lower flange of each trim piece (B).

(See Figure 4)

2. Orient trim pieces (B) as shown in figure below.

(See Figure 4)

3. Remove paper covering adhesive back from tape squares

(F) on trim and press trim (B) against inner wall of box.

(See Figure 4)

Figure 4

Upper Mounting Bracket

Lower Mounting Bracket

(E) x4

(D) x4

(F) x 12

(B) x 4

Installation Instructions PNRIW / PNRIWU

Display Installation

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

MOUNT FALLING CAUSING SEVERE PERSONAL INJURY

OR DAMAGE TO EQUIPMENT! DO NOT install display in a

manner other than that specified by the manufacturer. Certain

displays may require the use of an interface bracket for

proper installation of the display. If an interface bracket is not

installed or there are any other questions regarding the

installation of the display, immediately contact a Chief

Customer Service representative by calling 800-582-6480 or

by visiting www.chiefmfg.com.

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

MOUNT FALLING CAUSING SEVERE PERSONAL INJURY

OR DAMAGE TO EQUIPMENT. Displays can weigh in

excess of 40 lbs (18.1kg). ALWAYS use two people and

proper lifting techniques when installing display.

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

MOUNT FALLING CAUSING SEVERE PERSONAL INJURY

OR DAMAGE TO EQUIPMENT. Make sure mounting buttons

on display are properly seated in mounting holes in faceplate.

To install display:

1. Move mount faceplate to extended position by grasping

faceplate and pulling outward away from wall.

(See Figure 5)

2. While supporting both sides of display, align four mounting

buttons on display or interface bracket with four mounting

holes in faceplate. (See Figure 5)

3. Lower display into place listening for audible "click" to

ensure recessed area of mounting buttons are properly

seated in lower area of mounting holes and "click lock"

mechanism has engaged. (See Figure 5) and

(See Figure 6)

Figure 5

NOTE:

Holes are provided in the faceplate for use with a

padlock orsimilarlockingdevice,ifdesired.Inaddition,

the pin and nut may be removed from the upper holes

and moved to the lower holes for use as a more

permanent locking device. (See Figure 6)

Figure 6

Cable Management

CABLE MANAGEMENT

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

SERIOUS PERSONAL INJURY OR DAMAGE TO

EQUIPMENT! Make sure cables do not run through pinch

points.

1. Loosen front and rear cable clamps on top arm.

(See Figure 7)

2. Thread cable ties (M) under cable clamps and secure

clamps to top arm. (See Figure 7)

3. Route power/audio/video cables through the cable channel

in top arm (See Figure 7), allowing sufficient slack in cables

for left/Right movement of display and swing arm and also

swing arm extension and retraction.

4. Secure cables to top arm using two cable ties (M).

5. Repeat steps 1 through 4 for lower arm.

WARNING:

IMPROPER INSTALLATION CAN LEAD TO

SERIOUS PERSONAL INJURY OR DAMAGE TO

EQUIPMENT! DO NOT route cables through holes in

faceplate.

Remove pin

and nuts and

move to lower holes.

A padlock or bolt may

be placed through latch

holes

PNRIW / PNRIWU Installation Instructions

Figure 7

(M) x 4

x 4

From Display

(A) x 1

From Display

Adjustments

TENSION ADJUSTMENTS

Pitch Tension Adjustment

1. With display mounted, check for desired Pitch tension.

2. If required, adjust the Centris Select

knob right or left until

desired Pitch tension is obtained. (See Figure 8)

3. To lock the mount at the desired position, tighten the Pitch

locking screw. (See Figure 9)

Figure 8

Figure 9

Roll Tension Adjustment

CAUTION:

IMPROPER INSTALLATION CAN LEAD TO

SERIOUS PERSONAL INJURY OR DAMAGE TO

EQUIPMENT!Overtightening lateral adjustment will cause

excessive wear and may distort adjustment components.

1. Using a 9/16” wrench (not provided), slightly tighten or

loosen lateral Roll tension adjustment nut. (See Figure 10)

2. Mount the display and check for desired roll tension.

3. Repeat Steps 1 and 2 until desired Roll tension is obtained.

Centris Select

Pitch Adjustment Knob

Pitch

Locking Screw

Installation Instructions PNRIW / PNRIWU

Figure 10

Swing Arm Tension Adjustment

Swing arm tension is pre-set at the factory and is adjusted to

accommodate displays with weights near the top of the mounts

capacity.

If smaller displays are used it may be difficult to reposition the

display after mounting. Swing arm tension can be adjusted to

compensate for smaller display by:

The display must be mounted prior to adjusting swing arm

tension.

1. Locate the adjustment bar (K) and adjustment wrench (L).

2. Place adjustment bar (K) into socket head cap screw

located at swing arm pivot point. (See Figure 11)

NOTE: The display may need to be repositioned in order

to gain access to the tension adjustment

screw(s).

3. Check swing arm tension. If desired tension is present,

tension adjustment is complete. If additional tension

adjustment is required, repeat steps 2 thru 4 until desired

tension is achieved.

NOTE: If changing from a smaller display to a larger

display may be necessary to increase swing arm

tension.

Figure 11

4. Using the adjustment wrench (L), turn adjustment bar (K)

clockwise to increase swing arm tension or

counterclockwise to reduce swing arm tension. (Small

adjustments of 1/8 turn or less are typically all that is

required to achieve desired tension.) (See Figure 12) and

(See Figure 13)

Figure 12

Figure 13

Roll

Adjustment Nut

Socket Head

Capscrew

(K) x 1

(L) x 1

DECREASE

INCREASE

PNRIW / PNRIWU Installation Instructions

USA/International A 8401 Eagle Creek Parkway, Savage, MN 55378

P800.582.6480 / 952.894.6280

F877.894.6918 / 952.894.6918

Europe A Fellenoord 130 5611 ZB EINDHOVEN, The Netherlands

P+31 40 2668620

F+31 (0) 40 2668615

Asia Pacific A Room 30I, Block D, Lily YinDu International Building

LuoGang, BuJi Town, Shenzhen, CHINA. Post Code: 518112

P+86-755-8996 9226 ; 8996 9236 ; 8996 9220

F+86-755-8996 9217

8805-000242

www.chiefmfg.com

10/07

Autres manuels pour PNRIW Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels CHIEF Support et étagère

CHIEF

CHIEF Flexlink KXC Series Manuel utilisateur

CHIEF

CHIEF Security SLM Series Mount RPMA1 Manuel utilisateur

CHIEF

CHIEF UPM-2401 Manuel utilisateur

CHIEF

CHIEF K1C100 Manuel utilisateur

CHIEF

CHIEF FCA4U Manuel utilisateur

CHIEF

CHIEF KRA300 Manuel utilisateur

CHIEF

CHIEF Universal Slat Wall Multi Arm Mount KSY220 Manuel utilisateur

CHIEF

CHIEF K0W1I2TB Manuel utilisateur

CHIEF

CHIEF Single Ceiling Mount PCS Series Manuel utilisateur

CHIEF

CHIEF SL-150 Manuel utilisateur

CHIEF

CHIEF K1C1KRA204 Manuel utilisateur

CHIEF

CHIEF KWT110 Manuel utilisateur

CHIEF

CHIEF Direct Attach Ceiling Mount JHS Series Manuel utilisateur

CHIEF

CHIEF PAC717 Manuel utilisateur

CHIEF

CHIEF ER Rack Series Manuel utilisateur

CHIEF

CHIEF PSB-2064 Manuel utilisateur

CHIEF

CHIEF JSB2090 Manuel utilisateur

CHIEF

CHIEF Fusion Series Manuel utilisateur

CHIEF

CHIEF MSPDCCS4 Manuel utilisateur

CHIEF

CHIEF PAC-101 Manuel utilisateur

CHIEF

CHIEF SSB-1150 Manuel utilisateur

CHIEF

CHIEF CM6DHXX-T Guide de l'utilisateur

CHIEF

CHIEF PSM-2124 Manuel utilisateur

CHIEF

CHIEF FCAC Series Manuel utilisateur

Manuels Support et étagère populaires d'autres marques

Salamander

Salamander Acadia AC/W/L400/WH Manuel utilisateur

Fohhn

Fohhn VAT-09 Guide de l'utilisateur

ricoo

ricoo FS0522 Manuel utilisateur

AMSOIL

AMSOIL BMK-22 Guide rapide

Kargo Master

Kargo Master 48220 Manuel utilisateur

Milestone AV Technologies

Milestone AV Technologies SIMPLICITY SLF2 Manuel utilisateur

ricoo

ricoo S1222 Manuel utilisateur

Ready-Set-Mount

Ready-Set-Mount RSMCM602 Manuel utilisateur

VidaBox

VidaBox VB MNT FFS2 Manuel utilisateur

Welch Allyn

Welch Allyn 48960 Manuel utilisateur

Arkon

Arkon CM035-ST-2 Manuel utilisateur

PROEL

PROEL PLWIN60C Manuel utilisateur

Agilent Technologies

Agilent Technologies E2609B Manuel utilisateur

Mustang

Mustang MV-ARM4 Manuel utilisateur

Mounting Solutions

Mounting Solutions WRM-320 Manuel utilisateur

Pyle

Pyle PMKSPAD1 Manuel utilisateur

ShelterIt

ShelterIt 21208 Manuel utilisateur

SPL

SPL RackPack?4 1040 Manuel utilisateur
