Chamberlain 412HMC Manuel utilisateur

PREPARATION

SET POWER SUPPLY VOLTAGE

The receiver can be powered with either 24V ac/dc or with 12Vdc. The

jumper must be in the 24V position for use with 24V, and in 12V position

for use with 12Vdc. The jumper must be set to the proper voltage to

avoid damage to the receiver.

The receiver is factory set at 24V Figure 1.

SET SECURITY MODE

The Universal Receiver can be used with up to 15 rolling code

transmitters or passwords in HIGH security mode. Alternately, it can be

used with up to 31 of any type transmitter in NORMAL security mode,

including any combination of rolling code, billion code, or dip switch

remotes.

The jumper must be set at the HIGH position for the receiver to operate in

HIGH security mode. It must be set at NORMAL position to operate at the

NORMAL mode Figure 2.

When changing from NORMAL to HIGH security mode, any previous

transmitter codes must be erased. Repeat Steps 2 and 3 on Side 2 to

reprogram the receiver for each remote control transmitter in use.

The receiver is factory set at HIGH.

The use of 24V with the jumper in 12V position will cause permanent

damage to the receiver.

FIGURE 1

FIGURE 2

FIGURE 3

To prevent possible SERIOUS INJURY or DEATH from electrocution:

• Be sure power is not connected BEFORE installing the receiver.

To prevent possible SERIOUS INJURY or DEATH from a moving

gate or garage door:

• ALWAYS keep remote controls out of reach of children. NEVER

permit children to operate, or play with remote control transmitters.

• Activate gate or door ONLY when it can be seen clearly, is properly

adjusted, and there are no obstructions to door travel.

• ALWAYS keep gate or garage door in sight until completely closed.

NEVER permit anyone to cross path of moving gate or door.

SET OUTPUT DURATION (COMMERCIAL APPLICATIONS ONLY)

For commercial applications, the receiver can be set for either constant or

momentary closure on the output contacts. Use of constant closure is

prohibited on residential garage door openers because it overrides the

safety reversal devices.

With the jumper in the “M” (Momentary) position, the contacts will close

for 1/4 second regardless of the length of radio transmission. With the

jumper in “C” (Constant) position, the contacts will stay closed as long as

the radio continues transmitting Figure 3.

The receiver is factory set at M.

To prevent possible SERIOUS INJURY or DEATH, the use of

CONSTANT OPERATION on residential openers is PROHIBITED.

NOTICE: To comply with FCC and or Industry Canada (IC) rules, adjustment or modifications of this

receiver and/or transmitter are prohibited, except for changing the code setting or replacing the

battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.

Tested to Comply with FCC Standards FOR HOME OR OFFICE USE. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and (2) this device

must accept any interference received, including interference that may cause undesired operation.

UNIVERSAL RADIO CONTROL

MODELS 312HMC & 312HM (315 MHz)

MODELS 412HMC & 412HM (390 MHz)

Circuit Board

Power Supply

Terminals Jumper Circuit Board

Power Supply

Terminals Jumper

24V POSITION 12V POSITION

Security Mode

Terminals

Jumper

HIGH

SECURITY MODE

NORMAL

SECURITY MODE

Security Mode

Terminals

Jumper

Output Duration

Terminals

Jumper

CONSTANT

OPERATION

Output Duration

Terminals

Jumper

MOMENTARY

OPERATION
