Portable Hot Water Boilers
Instruction Manual
Model: CS113 and CS115
www.cecilware.com
Since 1911
®
Cecilware Corporation 43-05 20th. Av nu , LIC NY 11105
T l: 800.935.2211 / 718.932.1414 • Fax: 718.932.7860
Email: custom r.s rvic @c cilwar .com
Special Features:
CAUTION:
Do Not Run The Unit Dry ( ithout ater)
T rn thermostat knob all the way co nterclockwise to OFF position. Fill with fresh water, pl g into electric o tlet, t rn thermostat knob
clockwise to the maxim m setting of “10”, then t rn to the desired temperat re (between 5 and 8).
• Precision Thermostat For Accurate Temperature
Control.
• Portable, Easily Moved To Any Convenient
ocation.
• Sight Glass Indicates Water evel.
2
Portable Hot Water Boilers CS113 and CS115
Very Important Setup Instructions:
Do Not Run The Unit Dry ( ithout ater)
Turn thermostat knob all the way counterclockwise to OFF position. Fill with fresh water, plug into electric
outlet, turn thermostat knob clockwise to the maximum setting of “10”, then turn to the desired temperature
(between 5 and 8).
Cleaning Instructions:
1 Wipe exterior with a soft, damp cloth.
2 Clean urn inside with mild soap and water. Rinse thoroughly.
Electrical: Cord & plug s t includ d, N ma plug 5-15P. Export voltag 2.4KW 220V availabl . Bod Construction: Stainl ss st l.
Model Description
Dimensions
Diameter x H Electrical
Ship
Weight
CS113 3 gal. Holding Urn/Wat r Boil r 11" diam t r x 21½" 120V,1.4KW,11.6A 15 lbs.
CS115 5 gal. Holding Urn/Wat r Boil r 11" diam t r x 27½" 120V,1.4KW,11.6A 18 lbs.
NEMA 5-15R
Specifications
3
Portable Hot Water Boilers CS113 and CS115
Parts ist
CS113 & CS115
ITEM DESCRIPTION PART #
1.... URNCOVERKNOB ....................... M027A
2 ... COVER,URN ............................ Q004A
3 . . . SCREW, PAN HD PHI S.S. 10-24 X ½" . . . . . . . P264A
4 . . . GAUGE G ASS SHIE D 8" (CS113) . . . . . . . . . . D023A
5 . . . GAUGE G ASS SHIE D 10 ¾" (CS115) . . . . . . . D018A
6 ... GAUGESHANK .......................... D021A
7 ... FAUCET ............................... D064A
8 . . . SCREW, THERMOSTAT . . . . . . . . . . . . . . . . . . . . P018A
9 ... THERMOSTATKNOB ..................... M008A
10 ... THERMOSTAT ........................... 005A
11 . . . SCREW, 8-32 X 3∕8"SE FTAP .............. P140A
12 ... HO EP UG(1.250DIA) ................... P300A
13 ... BOTTOMCOVER ......................... Q186A
14 ... HI- IMIT ............................... 573A
15 ... STRAINRE IEF ......................... B012A
ITEM DESCRIPTION PART #
16 .. INECORD ............................. C032A
17 .. CAUTION ABE ......................... N001A
18 . . BOTTOM, WATER COMPARTMENT . . . . . . . . . . . Q187A
19 .. URNBODY(CS113) ...................... R045A
20 .. URNBODY(CS115) ...................... R046A
21 .. HAND E ............................... M007A
22 .. P UGINCO AR ........................ Q012A
23 . . HEATER E EMENT 120 V . . . . . . . . . . . . . . . . . . G193A
24 . . HEATER E EMENT 220 V . . . . . . . . . . . . . . . . . . G359A
25 . . SCREW, PAN HD PHI S.S. 6-32 X ¼" . . . . . . . P688A
26 . . SCREW, PAN HD PHI S.S. w/O-RING 10-32 X 3∕8" . N001A
27 . . SIGHT G ASS RETAINER . . . . . . . . . . . . . . . . . . UB17A
28 . . RETAINER MOUNTING B OCK . . . . . . . . . . . . . . K808A
29 .. PI OT IGHT............................ C002A
