SK320

Single oven

Installation, use and maintenance

Contents:

3 Important information

5 Safety instructions

6 First use of the oven

7 Oven controls, functions and use

10 Electronic programmer/timer

11 Setting the current time

11 Minute minder function

12 Semi-automatic cooking

13 Automatic cooking

14 Cleaning and maintenance

16 Removing the appliance door

17 Replacing the appliance door

18 Removing the inner door glass

19 Changing the oven light bulb

20 Installation

22 Mains electrical connection

24 Troubleshooting

25 Energy Eciency Information

IMPORTANT: Please read the user instructions carefully before

using the appliance for the ﬁrst time and before installing it.

Failure to install the oven, or to have it installed, as per the user

manual could invalidate the warranty. Any service calls relating to

misuse or incorrect installation could incur a service charge.

Important

This appliance must only be used for the purpose for which it is

intended, i.e. domestic cooking. Any other use could be dangerous

and may lead to premature failure of the appliance.

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note that

CDA reserve the right to invalidate the guarantee supplied with this

product following incorrect installation or misuse of the appliance.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

User information:

• Ovens become hot during and immediately after use.

•The oven door can become very hot during operation.

•After use, please ensure that the oven switches are in the ‘O’

position.

•Keep children away from the appliance when in use, and

immediately after use.

•Do not allow children to play with or on the appliance.

•Keep the oven door closed whilst grilling.

Appliance information:

Please enter the details from the appliance rating plate on to the

following page for reference, to assist CDA Customer Care in the

event of a fault with your appliance and to register your appliance for

guarantee purposes.

Appliance Model

Serial Number

EU Declarations of Conformity:

This oven has been designed, constructed and marketed in

compliance with safety requirements of EU Directive 2014/35/EU (Low

voltage) and requirements of EU Directive 2014/30/EU.

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety (LVD)

and Electromagnetic interference compatibility (EMC). Parts intended

to come into contact with food conform to 1935/2004/EC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2012/19/EU.

At the end of its working life, the product must not be disposed

of as urban waste. It must be taken to a special local authority

dierentiated waste collection centre or to a dealer providing this

service.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health deriving from

inappropriate disposal and enables the constituent materials to be

recovered to obtain signiﬁcant savings in energy and resources. As a

reminder of the need to dispose of household appliances separately,

the product is marked with a crossed-out wheeled dustbin.

Important

• Read the user instructions carefully before using the oven

for the ﬁrst time.

• Follow the instructions for ﬁrst use of the oven.

•Clean the oven regularly.

•Remove spills as soon as they occur.

•Always use oven gloves when removing shelves and trays

from the ovens.

•Do not allow children near the oven when in use.

•Do not allow fat or oils to build up on the oven shelves, grill

pan or oven base.

•Do not place any cooking utensils or plates directly on the

oven base.

•Always grill with the oven door closed.

•Do not grill food containing fat without using the grill pan

grid.

•Do not cover the grill pan grid, the oven walls or the base

with aluminium foil.

•Do not use the oven tray for roasting.

•Do not perform maintenance or cleaning of the oven

without ﬁrst switching o the electricity supply. If the oven

has recently been used, allow to cool.

•Do not place hot enamel parts in water. Leave them to

cool ﬁrst.

•Do not allow vinegar, coee, milk, saltwater, lemon or

tomato juice to remain in contact with enamel parts.

•Do not use abrasive cleaners or powders that will scratch

the surface of the enamel.

•Do not attempt to repair the internal workings of your oven.

• Do not dismantle any parts without disconnecting the oven

from the mains power supply.

•Do not use the appliance if any part is broken (e.g. door

glass). Disconnect it from the mains power supply and

contact CDA Customer Care.

•The cooling fan may run even long after the oven has

ﬁnished cooking.

•During use the appliance becomes very hot; do not touch

the heating elements inside the oven or the interior.

•Do not allow children near the oven when in use, nor to play

with it.

•This appliance is not intended for use by persons (including

children over the age of 8) with reduced physical, sensory

or mental capabilities, or lack of experience or knowledge,

unless they have been given supervision or instruction

concerning use of the appliance by a person responsible for

their safety.

•Children may not perform cleaning and maintenance

unsupervised.

•Do not harsh abrasive cleaners or sharp metal scrapers to

clean the oven door glass since they can scratch the

surface, which may result in shattering of the glass.

•Abrasive detergents and steam cleaning equipment should

not be used for cleaning.

•The oven may require increased ventilation on the before

ﬁrst use steps. This can be achieved either from an open

window or the use of an extractor.

•Clean up any major spills to avoid the risk of ﬁre or

excessive smoke.

•Do not hang towels or cloths on the oven handle at any

time.

•Ensure that the oven is cool and power to the appliance

has been turned o before carrying out any cleaning or

maintenance including door removal.

•Always wear adequate PPE (Personal Protective Equipment)

when carrying out any handling, maintenance or cleaning.

First use of the oven

First use

•The metal casing of this appliance has been coated with a

preservative to protect it during transport and storage. This should

be removed during installation by using a non-abrasive stainless

steel cleaner. Always follow the instructions given with the cleaner

being used.

•Before using the oven for the ﬁrst time we recommend that you

clean the oven with soapy water, rinse carefully. Set the current

time on the programmer as per page 13. Heat on each of the

below programmes at maximum temperature for the speciﬁed time.

A slightly unpleasant smell may be produced, caused by grease

remaining on the oven elements from the production process.

15 minutes full grill 60 minutes fan oven

60 minutes conventional oven

Please note:

•This oven has been ﬁtted with a cooling fan to achieve maximum

eciency and to maintain low surface temperatures. The cooling fan

will switch on automatically when the oven switches on. It is normal

for the cooling fan to run for an hour or more after use, depending

on the duration, temperature and type of cooking programme used.

IMPORTANT - Always operate within the temperature ranges

stated for each function on pages 9 - 11.

Oven controls and use

IMPORTANT: You must set the current time on the oven

programmer, as per page 13, for the oven to operate properly.

Cooking function knob (B in Fig. 1)

To set the function, turn the cooking function knob (B in Fig. 1) to

the required function. You will need to set a temperature on all

functions except the defrost function. The neon indicator next to

the temperature knob will extinguish when the temperature has been

reached.

below and on the following two pages:

Fan oven

This function uses the circular heating element with a

temperature between 50°C and 250°C. The fan then

circulates the hot air which helps to achieve uniform

heat distribution.

Defrost

This function uses the fan to circulate air, at ambient

Fig. 1 A B

BCD

temperature, within the oven which helps to accelerate

the defrosting process. 1 kg takes approximately 1 hour

to defrost, depending on the type of food.

Fanned Grill

This function radiates the heat from the grill element but

also uses the fan to circulate the hot air. The hot air is

distributed over and under the food that you are grilling.

This fully temperature variable grill is ideal for grilling

ﬁsh or other items whose appearance can be spoiled by

a normal grill function.

It can be set between 50°C and 250°C.

When fan grilling, please note:

• Always grill with the oven door closed.

• The grill pan does not need to be as close to the

grill as possible.

• Do not grill for more than 30 minutes at a time.

• Preheat the grill for up to ﬁve minutes with the

oven door closed.

Full Grill

This function radiates the heat from the grill element

and the top element.

This fully temperature variable grill is ideal for grilling a

full family meal. It can be set between 50°C and

250°C.
