HN6732FR

Induction hob

Installation, use and maintenance

Contents:

3 Important information

4 Important safety warnings/notes

4 Important notes for safety, use and care

5 Pacemaker and active implants information

6 Important safety warnings

6 Saving energy

7 Cooking on induction (and pan compatibility)

8 Hob layout

9 Using your hob

10 Booster function

11 Operating time limiter

12 Timer/minute minder

14 Pause function

14 Keep warm function

16 Bridge function

17 Auto-heat function

18 Safety key lock

18 Residual heat indicators

19 Ecient use of your hob

20 Care and maintenance

21 Cleaning guide

21 Troubleshooting

24 Fitting the hob (ventilation, furniture requirements etc.)

26 Hob cut-out etc.

28 Power conﬁguration

29 Mains electrical connection

31 Energy eciency information

Important

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance

or use in a commercial environment.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by someone

who is responsible for their safety.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety

(LVD) 2006/95/EC and Electromagnetic interference compatibility

(EMC) 2004/108/EC. Parts intended to come into contact with food

conform to 89/109/EC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both energy

and resources. As a reminder of the need to dispose of household

appliances separately, the product is marked with a crossed-out

wheeled dustbin.

Please note:

•Induction hobs become hot and remain hot during and immediately

after use. Do not touch the hob until it has been allowed to cool.

•Keep children away from the appliance when in use.

•Never use the hob top for storage.

•Pan handles should never stand out beyond the edge of the

worktop. This will help to avoid children reaching them.

•Do not lean over the hob when it is in use.

•Follow the cleaning instructions carefully.

•Ensure the base of the saucepan is clean and dry before placing it

on the hob.

•Avoid hard shocks from cookware – the vitroceramic glass surface

is highly resistant but not unbreakable.

•Do not place hot lids ﬂat on the hob top. A “suction” eect could

cause damage to the hob.

•Do not drag cookware across the hob top: in the long term, this

could cause damage to the hob.

•Do not store cleaning or ﬂammable products in the unit below the

hob.

•Always use appropriate cookware.

•Do not cook unopened tins of food directly on the hob.

•Never put cooking foil or plastic materials on the ceramic surface

when the hob is hot. These materials could melt and cause

damage to the hob.

•This hob (Class 3) has been designed for use only as a cooking

appliance. Any other use should be considered incorrect and

therefore dangerous.

FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:

The function of this hob conforms to current electromagnetic

interference standards and thus is in total compliance with legal

requirements (2004/108/CE directives).

To avoid interference between your hob and a pacemaker, your

pacemaker must be designed and programmed in compliance with

the regulations that apply to it. As such, CDA guarantee only that our

product is compliant.

With regard to the compliance of the pacemaker or any potential

incompatibility, you should obtain information from the manufacturer

or your attending physician.

Important

•Do not use the hob if the glass surface is cracked or damaged to

prevent the risk of electric shock. Disconnect it from the power

supply.

•Ensure that the power cable of a connected electrical appliance

near the hob is not in contact with the cooking zones.

Saving energy

Using energy in a responsible way not only saves money but also

helps the environment. The following will help you to save energy:

•Use proper pans for cooking. A saucepan should never be smaller

than a zone. Always remember to cover any pans.

•Ensure pans and the hob are kept clean. Soils can prevent heat

transfer and repeatedly burnt-on spillages can often only be

removed by products which cause damage to the environment.

•Do not uncover the pan too often (a watched pot never boils!).

Be sure to recycle all of the packaging. All packaging materials

used are 100% recyclable.

Cooking on Induction

The principle of induction cooking is based on magnetic eect.

When you put your cookware on an induction zone and switch it on,

the electronic boards in the hob produce induced currents in the base

of the cookware and instantly raise its temperature. This heat is then

transferred to the food inside the cookware.

The best cookware to use with induction cooking has thick ﬂat bases,

as the heat will be better distributed meaning cooking is more even.

Most cookware is compatible with induction cooking.

There are three ways to check the suitability of your cookware:

1. Using a magnet to see if the base of the pan is magnetic: If the

magnet sticks, then the cookware is compatible.

2. Place the pan on one of the cooking zones and switch the

zone on. If the display continues to show the selected power

level then the cookware is compatible. If the display shows “ ”,

the cookware cannot be used on an induction hob.

3. Check the instructions or packaging of the pans for the

symbols indicating suitability for use with induction.

Using your hob

Zones:

1. Front left 2 - 3kW 210 mm

2. Back left 1.2 - 1.4kW 160 mm

3. Front right 1.6 - 2.5kW 180mm

4. Back right 1.6 - 2.5kW 180 mm

Control panel:

1. On/o sensor 6. Timer indicator

2. Pause function sensor 7. Timer sensor

3. Booster function sensor 8. Keep warm sensor

4. ‘+’ and ‘-’ adjustment sensors 9. Keep warm indicator

5. Cooking zone indicators 10. Safety key lock indicator

11. Safety key lock sensor

Fig. 2

Fig. 1

910

Using Your Hob

To switch the hob on

•To switch the power on, touch and hold the "On/o sensor" (1) for

approximately two seconds. The hob will beep, all four cooking

zone indicators will illuminate with either the symbols shown in part

5 of Fig. 2 or a capital or lower case 'H'.

Please note: If a power level is not set within ten seconds, the hob

will switch o automatically.

To activate a zone and set a power level

•Simply set the desired power level using the ‘+’ and ‘-’ adjustment

sensors for the required zone. The standard power levels range

from 1 (minimum) to 9 (maximum). The hob will then begin heating

providing that the correct cookware is being used.

To deactivate a zone

•Touch the relevant zone's ‘+’ and ‘-’ adjustment sensors simultane-

ously for approximately 1 second.

• If switching o multiple zones, the above steps need to be taken

for each zone. When all the zones are at "0", the hob will switch o

automatically after approximately ten seconds.

•Alternatively, to switch o the hob immediately, touch and hold the

"On/o sensor" (1) for approximately two seconds.

Please note: Any zones that are still hot to the touch will display an

" " provided the mains power supply is not interrupted.

Booster

The hob is equipped with a booster function on all zones, allowing a

higher power level than the maximum for approximately ten minutes.

To activate the booster on a zone

•Touch the desired zone's booster function sensor (3). "P" will show

in the cooking zone indicator to show that the booster is on.

• The booster function automatically deactivates after 10 minutes of

usage. The cooking zone will continue to operate at its nominal

power at this point. The booster can be reactivated after this time

provided the hob's internal components have not overheated.

To deactivate the booster on a zone

• To cancel the booster at any time, touch the desired zone's booster

function sensor (3) or use the ‘+’ and ‘-’ adjustment sensors to return

the heat a dierent setting.

Please note: The booster function cannot be used on all cooking

zones at the same time. This is to prevent damage to the internal

modules caused by overheating.

If the appliance's electronic circuits or induction coils overheat

whilst the booster function is in operation then the function will be

automatically deactivated and the zone will continue to operate at its

nominal power. The booster function will be available again once the

internal components have been cooled suciently.

It is normal for a high pitched whirring noise to begin whilst the

booster function is in use. This is the cooling fan(s) inside the hob
