HE6051FR
Electric Hob
Installation, Use and Maintenance
2
Contents:
3 Important
5 Important Notes
6 Using Your Hob
8 Ecient Use Of Your Hob
9 Care And Maintenance
11 Fitting The Hob
12 How To Install The Hob
14 Mains Electricity Connection
3
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note that
CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance or
use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate to assist CDA
Customer Care in the event of a fault with your appliance and to
register your appliance for guarantee purposes.
Appliance Model
Serial Number
4
EU Declarations of Conformity:
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety
(2014/35/EU - LVD) and Electromagnetic interference compatibility
(2014/30/EU - EMC). Parts intended to come into contact with food
conform to 1935/2004/EC..
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
5
Important Notes
• Please note:
• Electric hobs become hot and remain hot during and immediately after
use. We strongly advise that you do not touch the hob until it has been
allowed to cool. If wiping away a spillage, please take every care not
to burn yourself.
• Keep children away from the appliance when in use.
• Never use the hob top for storage.
• Pan handles should never stand out beyond the edge of the worktop.
This will help to ensure children cannot reach them.
• Do not switch on the hotplates without cookware in place (unless
following step 5 on page 9).
• Do not lean over the hob when it is in use.
• Follow the cleaning instructions carefully.
• Ensure the base of the saucepan is clean and dry before placing it on
the hob.
• After use, please ensure that the control knobs are in the ‘O”
position.
• This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use (e.g. heating rooms) should be considered
incorrect and therefore dangerous.
• The appliance is not intended to be operated by any means of an
external timer or separate remote-control system.
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
0
1
2
3
4
5
6
Using Your Hob
Electric hotplates:
1. 180mm (FL) 2.0kW
2. 145mm (BL) 1.5kW
3. 180mm (BR) 1.5kW
4. 145mm (FR) 1.0kW
Control knobs:
5. Back right
6. Back left
7. Front left
8. Front right
Fig.1
1
23
45
Fig.2
0
1
2
3
4
5
6
6
7
8
7
HOTPLATE SWITCHES:
The power of each hotplate can be varied using the control knob to
select the required heat.
The table below shows the heat at each of the 6 settings:
The ‘OFF’ position is indicated by the symbol ‘0’.
The indicator will light when the hotplate is in use.
When you have finished cooking, check to ensure that the hotplates
are o and the indicator is not lit.
Before using your hob for the first time, switch the hotplates on
for a FEW SECONDS to burn o any grease left over from the
manufacturing process.
Heat setting Description Recommended use
1 Very gentle Stewing vegetables
2 Gentle Boiling potatoes
3 Slow Cooking soups or casseroles
4 Medium Slow roasting or frying
5 High Frying meat or fish
6 Very high Boiling, quick heating, intense frying
8
Ecient Use Of Your Hob
The hob is equipped with hotplates of dierent sizes, designed to
accommodate most shapes and sizes of pan. For best results, only
use pans with flat bottoms and choose an appropriate hotplate
depending on the size of the pan. The most ecient use of the hob is
shown below, where the pan and hotplate are correctly chosen.
Use pan lids where possible to minimize the energy usage of your
appliance.
Turn o each hotplate a few minutes before the end of cooking time.
The residual heat in the hotplate will continue to cook the food for the
remaining cooking time. This will also help preserve the look of your
appliance.
The table below shows the sizes of pan that should be used with each
hotplate:
Hotplate Size
145mm
180mm
Maximum Pan Size (cm)
16
20
Minimum Pan Size (cm)
12
16
Fig.3
9
Care and Maintenance
The hob has a stainless steel surface. Due to this you should use a
non-abrasive cleaner. Any abrasive cleaner (including Cif) will scratch
the surface and could erase the control panel markings. Stainless steel
can be eectively cleaned by simply using a dilute solution of water and
washing up liquid and drying to a shine with a clean cloth.
Over time with use, the stainless steel surface may discolour; this is
normal and does not constitute a fault with this appliance. Proprietary
stainless steel cleaners are available.
IMPORTANT:
Steam cleaners must not be used when cleaning this appliances.
HOTPLATE CARE:
The finish of the cast iron hotplates is designed to be durable in use. The
following tips should be observed to get the best from your hob:
1. Do not use decorative covers; these can cause damage to the surface
and lead to rust.
2. Use a special hotplate surface cleaner to protect and restore the
surface of the hotplates.
3. Do not use soap and water on the hotplates. Wipe up spills and
splashes immediately but take extreme care not to burn yourself.
4. Never operate the hob without a pan, unless it is for a few seconds (as
below).
5. Deposits of fat can be burned o by turning the hotplate on for a few
seconds. The fat will brush o when the appliance has cooled down.
10
IF YOUR HOB IS NOT WORKING:
1. Check that the mains supply has not been switched o.
2. Check that the fuse or circuit breaker has not blown/tripped.
If one or more plates continue to malfunction, please contact CDA
Customer Care. Contact details can be found below.
A: Customer Care Department, The CDA Group Ltd, Harby Road,
Langar, Nottinghamshire, NG13 9HY
T: 01949 862 012 F: 01949 862 003
