HN3621FR

Induction Hob

Installation, Use and Maintenance

Important

The CDA Group Ltd cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that CDA reserve the right to invalidate the guarantee supplied with

this product following incorrect installation or misuse of the appliance

or use in a commercial environment.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by someone

who is responsible for their safety.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

EU Declarations of Conformity

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety

(LVD) 2014/35/EU and Electromagnetic interference compatibility

(EMC) 2014/30/EU. Parts intended to come into contact with food

conform to 1935/2004/EC.

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.

At the end of its working life, the product must be taken to a special

local authority waste collection centre or to a dealer providing

appliance recycling services.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health. It also

enables the constituent materials to be recovered, saving both energy

and resources. As a reminder of the need to dispose of household

appliances separately, the product is marked with a crossed-out

wheeled dustbin.

Please note:

•Induction hobs become hot and remain hot during and immediately

after use. Do not touch the hob until it has been allowed to cool.

•Keep children away from the appliance when in use.

•Never use the hob top for storage.

•Pan handles should never stand out beyond the edge of the

worktop. This will help to avoid children reaching them.

•Do not lean over the hob when it is in use.

•Follow the cleaning instructions carefully.

•Ensure the base of the saucepan is clean and dry before placing it

on the hob.

•Avoid hard shocks from cookware – the vitroceramic glass surface

is highly resistant but not unbreakable.

•Do not place hot lids ﬂat on the hob top. A “suction” eect could

cause damage to the hob.

•Do not drag cookware across the hob top: in the long term, this

could cause damage to the hob.

•Do not store cleaning or ﬂammable products in the unit below the

hob.

•Always use appropriate cookware.

•Do not cook unopened tins of food directly on the hob.

•Never put cooking foil or plastic materials on the ceramic surface

when the hob is hot. These materials could melt and cause

damage to the hob.

•This hob (Class 3) has been designed for use only as a cooking

appliance. Any other use should be considered incorrect and

therefore dangerous.

FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:

The function of this hob conforms to current electromagnetic

interference standards and thus is in total compliance with legal

requirements (2004/108/EC directives).

To avoid interference between your hob and a pacemaker, your

pacemaker must be designed and programmed in compliance with

the regulations that apply to it. As such, CDA guarantee only that our

product is compliant.

With regard to the compliance of the pacemaker or any potential

incompatibility, you should obtain information from the manufacturer

or your attending physician.

Important

•Do not use the hob if the glass surface is cracked or damaged to

prevent the risk of electric shock. Disconnect it from the power

supply.

•Ensure that the power cable of a connected electrical appliance

near the hob is not in contact with the cooking zones.

Cooking on Induction

The principle of induction cooking is based on magnetic eect.

When you put your cookware on an induction zone and switch it on,

the electronic boards in the hob produce induced currents in the base

of the cookware and instantly raise its temperature. This heat is then

transferred to the food inside the cookware.

The best cookware to use with induction cooking has thick ﬂat bases,

as the heat will be better distributed meaning cooking is more even.

Most cookware is compatible with induction cooking.

There are three ways to check the suitability of your cookware:

1. Use a magnet to see if the base of the pan is magnetic: If the

magnet sticks, then the cookware is compatible.

2. Place the pan on one of the cooking zones and switch the

zone on. If the display continues to show the selected power

level then the cookware is compatible. If the display shows “ ”,

the cookware cannot be used on an induction hob.

3. Check the instructions or packaging of the pans for the

symbols indicating suitability for use with induction.

Using your hob

Zones:

1. Upper 1.4kW 180 mm

2. Lower 1.4kW 180 mm

Control panel:

1. On/o sensor 4. Minus setting selector

2. Cooking zone display 5. Plus setting selector

3. Cooking zone selector 6. Timer display

ﬁg. 1

ﬁg. 2

12233

Using Your Hob

To switch the hob on

•To switch the power on, touch and hold the "On/o sensor" (1) for

approximately two seconds. The hob will beep and all displays will

show “0”.

Please note: If a zone is not selected nor a power level set within

twenty seconds, the hob will switch o automatically.

To set the power level

•Touch the cooking zone selector (3) for the required zone. The hob

will beep and the zone display will brighten.

•Select the desired heat setting using the "+" or "-" selectors. The

power level ranges from 1 (minimum) to 9 (maximum). The hob will

begin heating and the cooking zone indicator will remain brighter

for approximately ten seconds before dimming.

Please note: After zone selection, zone adjustment will remain active

for approximately ten seconds. Also, if no key is touched within twenty

seconds, the zone will become inactive and the hob will switch o

automatically.

To turn the power o to a zone

•To switch o a zone, touch the cooking zone selector (3) so that the

cooking zone display (2) brightens. Then use the "+" or "-" selectors

to adjust the power level to "0". The cooking zone indicator will

display a "0" to conﬁrm that the zone is now inactive but will display

an " " if the zone is still hot to the touch.

• If switching o both zones, the above step needs to be taken

for each zone. When both the zones are at "0", the hob will switch

o automatically after approximately twenty seconds.

•Alternatively, to switch o the hob immediately, touch and hold the

"On/o sensor" (1) for approximately two seconds. Any zones that

are still hot to the touch will display an " ".

Please note: In case of a cut to the power supply, the residual heat

indicators will not be displayed yet the zones may still be hot to the

touch. It is advisable to refrain from touching the hob top, particularly

with bare hands, for some time after use.

Operating time limiter

In addition to the booster deactivation timer, each zone has an

operating time limiter to increase overall eciency and to prevent

the hob from being left on indeﬁnitely. If a zone's heat setting is

not changed for a speciﬁc duration then the associated zone is

automatically switched o and residual heat indicator activated.

Zones can still be used as normal in accordance with the operating

instructions. The operating time limiter is set according to the last

selected heat setting. The maximum operating times for each setting

can be found on page 10.

Please note: In order to conserve electricity and ensure maximum

eciency of the hob, heat setting "9" will automatically reduce to heat

setting "8" after 30 minutes of continuous usage.

Operating time limiter durations

Zone heat setting Maximum operating time

1 8 hours 36 minutes

2 6 hours 42 minutes

3 5 hours 18 minutes

4 4 hours 18 minutes

5 3 hours 30 minutes

6 2 hours 48 minutes

7 2 hours 18 minutes

8 2 hours

9 1 hour 30 minutes

Timer/Minute Minder

The hob is equipped with a timer that allows a ﬁnish time to be set

for the end of cooking on any zone, between a minimum of 1 minute

and a maximum of 99 minutes. This timer can be used separately for

each zone. Once the timers are set, the timer display will show the

time remaining on the ﬁrst zone to ﬁnish cooking and an LED will ﬂash

next to the zone power level. The timer can also be used as a minute

minder to count down time when the zones are not in use.

To set the timer

•First switch on the hob and set the desired zone to the power level

required.

•Whilst the relevant cooking zone display (2) is bright, touch the “+”

and “-” selectors simultaneously.
