CDA hc9625 Manuel de référence
Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
hc9625 Ceramic Hob
Manual for Installation, Use and Maintenance
2
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity:
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
2006/95/EC and Electromagnetic interference compatibility (EMC)
2004/108/EC. Parts intended to come into contact with food conform
to 89/109/EC.
3
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
4
User Information
Please note:
• Ceramic hobs become hot and remain hot during and immediately
after use. Do not touch the hob until it has been allowed to cool.
• Keep children away from the appliance when in use.
• Never put cooking foil or plastic materials on the ceramic surface
when the hob is hot. These materials could melt and cause damage
to the hob.
• Never use the hob top for storage.
• Pan handles should never stand out beyond the edge of the
worktop. This will help ensure children cannot reach them.
• Do not use pans with rough bases (e.g. cast iron) as these may
scratch the hob surface.
• Do not switch on the zones without cookware in place.
• Do not lean over the hob when it is in use.
• Follow the cleaning instructions carefully.
• Ensure the base of the saucepan is clean and dry before placing it
on the hob to prevent damage to the surface of the hob.
• After use, please ensure that the control knobs are in the ‘O”
position.
• This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use (e.g. heating rooms) should be
considered incorrect and therefore dangerous.
• The appliance is not intended to be operated by any means of an
external timer or separate remote-control system.
Important
• Do not use the hob if the glass surface is cracked or damaged, to
prevent risk of electric shock. Disconnect it from the power supply.
5
Using Your Hob
Zones:
1. Front left: 1/2.2kW - 140/210mm dual
2. Centre left: 1.2kW - 140mm
3. Centre right: 0.7/1.7kW - 120/180mm dual
4. Front right: 1.2kW - 140mm
5. Touch control panel
Fig. 1
2
1
3
4
5
6
Touch control
1. Zone indicator key
2. Zone display
3. Zone indicator
4. Dual zone indicator
5. Dual zone key
6. Increase key
7. Decrease key
8. Timer display
9. Timer key
10. Timer zone indicator
11. Minute minder indicator
12. Childlock key
13. Childlock indicator
14. Power key
Fig. 2 3
11
97 14
42 1 5 6 8 10 12 13
7
Fig. 3
Hi-light cooking
zone Ø 140mm
Second element
Hi-light double zone
Fig. 4
How to Use the Hob
The ceramic surface of the hob allows
fast transmission of heat vertically from
the heating elements under the glass to
the pans on the hob top.
The heat does not spread horizontally,
so the hob top remains relatively cool
only a few centimetres from the zone in
use.
Please note:
The heating elements are equipped
with a temperature limiter that will
switch the element o to prevent
damage to the hob.
The temperature limiter may also operate when incorrect pans
are used or pans are poorly positioned. This will aect cooking
performance.
The temperature limiter can be seen in the zone as the straight line
out from the centre of the element. This is not a fault with the hob.
To switch the hob on:
Touch and hold until the zone displays show “0”.
Please note:
If a zone is not selected or the timer set within approximately 10
seconds, the hob will automatically switch o.
8
To switch on a zone:
Once the hob is switched on, touch for the zone required. The
zone indicator will switch on to confirm the zone is active.
EITHER: Touch and hold to select the power level from 1 (minimum)
to 9 (maximum). The power level selected will show on the
zone display.
OR: Touch and hold to select the power level from 9 to 1. The
zone will remain active for approximately ten seconds to
allow for adjustment.
To adjust the power level once set:
Touch for the zone required. The zone indicator will switch on to
confirm the zone is active.
Touch and hold or until the required power level shows on the
zone display.
To use the dual zone:
The dual zones are formed from two separate coils.
Touch at any time to switch the dual zone on or o when the zone is
switched on for either of the dual zones.
The dual zone indicator will switch on when the dual zone is on.
To switch o a zone:
Touch for the zone required.
Touch and hold until the zone display shows “0.”
The zone display will show “0” for 10 seconds, then H to indicate the
residual heat.
9
To switch the hob o:
Touch and hold at any time.
Zone Settings:
Booster:
The hob is equipped with a booster function, which allows a zone to
run at maximum power for a preset period of time before returning to
the required power level. These times are shown in the table.
To set the booster:
Once the hob is switched on, touch for the zone required. The zone
indicator will switch on to confirm the zone is active.
Touch so the zone display shows “9”.
Touch so the zone display shows “A”.
Touch and hold to set the required power level.
Power Level Type of Cooking
0 Switched o
1/2 For melting (butter/chocolate) or keeping food warm
2/3 Keeping food hot or to heat small quantites of liquid
3/4 Heating large quantities of liguid (sauces etc.)
4/5 Slow boiling e.g. spaghetti, soups, stews, potatoes
6/7 Gentle frying
7/8 Browning meats, frying fish. omelettes
9 Fast frying steaks
Cooking Zone Power
Level 1 2 3 4 5 6 7 8 9
Fast Heating Time 1 min. 3 min. 5 min. 6min.
30sec.
8 min.
30sec.
2 min.
30 sec.
3 min.
30 sec.
4 min.
30 sec. N/A
10
To adjust the power level when the booster is set:
Touch for the zone required.
Touch and hold or until the required power level shows on the
zone display.
To cancel the booster:
Touch for the zone required.
Touch and hold until the zone display shows “0”.
Then touch and hold or until the required power level shows on
the zone display. “A” will no longer show on the zone display.
The Timer/ Minute Minder:
The timer allows you to preset the length of time any of the zones
will be on, between a minimum of one minute and a maximum of 99
minutes. The timer can be used on each zone separately and can
also be used as a minute minder, to countdown the time without using
any of the zones.
To set the timer:
Switch on the zone and set the power level.
Whilst the dot is showing on the zone display, touch . The timer
display will show “00” and the timer zone indicator will switch on to
show which zone timer is being set.
To set the time from zero, touch and hold until the required cooking
time shows on the display.
To go straight to 30 minutes, touch .
Then touch either or to adjust the time further.
