HC9606FR
Ceramic hob
Installation, use and maintenance
2
Contents:
3 Important
5 Important information
6 Hob layout
7 Using your hob
8 Operating time limiter
9 Triple zone function
9 Dual zone function
10 Auto-heat function
11 Timer/Minute minder
13 Safety key lock
14 Residual heat indicators
14 Ecient use of your hob
16 Care and maintenance
17 Cleaning guide
18 Troubleshooting
20 - 24 Installation
20 Installation - preparation
22 How to install the hob
24 Mains electrical connection
27 Energy eciency information
3
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
EU Declarations of Conformity
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety
(LVD) 2014/35/EU and Electromagnetic interference compatibility
4
(EMC) 2014/30/EU. Parts intended to come into contact with food
conform to 1935/2004/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EU DIRECTIVE 2012/19/EU.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
Please note:
• Ceramic hobs become hot and remain hot during and immediately
after use. Do not touch the hob until it has been allowed to cool.
•Keep children away from the appliance when in use.
•Never use the hob top for storage.
•Pan handles should never stand out beyond the edge of the
worktop. This will help to avoid children reaching them.
•Do not lean over the hob when it is in use.
•Follow the cleaning instructions carefully.
•Ensure the base of the saucepan is clean and dry before placing it
on the hob.
•Avoid hard shocks from cookware – the vitroceramic glass surface
is highly resistant but not unbreakable.
5
•Do not place hot lids flat on the hob top. A “suction” eect could
cause damage to the hob.
•Do not drag cookware across the hob top: in the long term, this
could cause damage to the hob.
•Do not store cleaning or flammable products in the unit below the
hob.
•Always use appropriate cookware.
•Do not cook unopened tins of food directly on the hob.
•Never put cooking foil or plastic materials on the ceramic surface
when the hob is hot. These materials could melt and cause
damage to the hob.
•This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use should be considered incorrect and
therefore dangerous.
Important
•Do not use the hob if the glass surface is cracked or damaged
to prevent the risk of electric shock. Disconnect it from the
power supply.
•Ensure that the power cable of a connected electrical appliance
near the hob is not in contact with the cooking zones.
•When connecting the hob to the power and switching it on for
the first time the cooking zone displays may show the code
A F 4 and 3, or 1, followed by a flashing ' ' on one or more
zones. This is not a fault and the ' ' should disappear after
approximately one hour.
•The safety key lock may be active. Simply press and hold the
safety key lock sensor (2) for three seconds to deactivate it.
6
Hob layout
Zones:
1. 2.3kW Ø210/175/120 mm 3. 0.7kW/1.7kW Ø 120/180 mm
2. 1.2kW Ø145 mm 4. 1.2kW Ø145 mm
Control panel:
1. On/o sensor 5. Dual and triple zone sensor
2. Safety key lock sensor with LED 6. Cooking zone display
3. Cooking zone sensor 7. Timer display with LEDs
4. Power level slider 8. Timer sensor with ‘+’ and ‘-’
sensors
Fig. 1
1
23
4
123
4
6
75
Fig. 2
3
6
8
7
Using your hob
To switch the hob on
• To switch the power on, touch and hold the "On/o sensor" (1)
for approximately two seconds. The hob will beep and all displays
will show “0”.
Please note: If a power level is not set within ten seconds, the hob
will switch o automatically.
After switching the mains supply on to the hob, or if the mains supply
is interrupted and then restored, the safety key lock may be activated.
The safety key lock LED will be on to indicate this. Simply press and
hold the safety key lock sensor (2) for approximately two seconds to
deactivate the satey key lock and proceed to use the hob as normal.
The safety key lock also activates after 60 seconds if the appliance
is switched o via the on/o sensor (1). This is to help to prevent
accidental use. Simply follow the same step as above to deactivate
the safety key lock.
To set the power level
• Simply select the desired zone using the relevant cooking zone
sensor (3) and then use the power level slider to set the required
power level. The power level ranges from the 1 (minimum) to the 9
(maximum). The hob will then begin heating.
To turn the power o to a zone
•To switch o a zone you can touch the relevant cooking zone
8
sensor (3) and then use the power level slider to return the power
level to 0. The cooking zone indicator will display a "0" to confirm
that the zone is now inactive. Alternatively you can press the on/o
sensor (1).
•If switching o multiple zones, the above steps need to be taken
for each zone. When all the zones are at "0", the hob will switch o
automatically after approximately ten seconds.
•To switch o the hob immediately, touch and hold the "On/o
sensor" (1) for approximately two seconds.
Please note: Any zones that are still hot to the touch will display an
" " provided the mains power supply is not interrupted.
Operating time limiter
Each zone has an operating time limiter to increase overall eciency
and to prevent the hob from being left on indefinitely. If a zone's heat
setting is not changed for a specific duration then the associated zone
is automatically switched o and residual heat indicator activated.
Zones can still be used as normal in accordance with the operating
instructions. The operating time limiter is set according to the last
selected heat setting. The maximum operating times for each setting
can be found below.
10
1
Zone Power Level
Maximum
Operating Time
(hours)
234 5 6 7 8 9
6 5 5 4 1.5 1.5 1.5 1.5
9
Triple zone function
The front-left zone is equipped with a triple zone function that allows
you to extend the heating area for the zone. In normal use, the zone
functions with just the smaller inner ring until the triple zone function is
activated.
To activate the triple zone function
•Simply set a power level on the front-left zone and then press the
dual and triple zone sensor (5) once to activate the middle zone
and press it again to also activate the outer zone. The LEDs above
the zone display will show you when one or both of the zone
extensions are in use (one LED indicates that the middle zone
extension is active, two LEDs indicate that both zone extensions are
active).
To deactivate the triple zone function
•Simply activate zone adjustment by pressing the relevant zone
sensor and then press the dual and triple zone sensor (5) until no
LEDs above the display are lit.
Dual zone function
The centre (or rear)-right zone is equipped with a dual zone function
that allows you to extend the heating area for the zone. In normal use,
the zone functions with just the smaller circular ring until the dual zone
function is activated.
To activate the dual zone function
• Simply set a power level on the centre (or rear)-right zone and then
10
press the dual and triple zone sensor (5) once to extend the zone.
The LED above the zone's display will illuminate to show you that
the dual zone is active.
To deactivate the dual zone function
•Simply activate zone adjustment by pressing the relevant zone
sensor and then press the dual and triple zone sensor (5). The
above the zone's display should extinguish and the zone will
return to operating on the inner zone only.
Auto-heat function
Each zone is equipped with an auto-heat function which shortens
the warm-up time for that zone before reverting the set power level.
•To activate the auto-heat function, touch position '9' of the power
level slider twice. The relevant zone's display will alternate
between power level '9' and the letter 'A' for approximately 10
seconds. Within this time, set the desired power level by touching
the power level slider. The relevant zone display will alternate
between the set power level and the letter 'A' for the duration that
the auto-heat function is active.
•To disengage the auto-heat function simply use the power level
slider to return the zone's power level to '0'. Alternatively, if you
have finished using the hob, you can use the on/o sensor (1).
