HVN91 Induction Hob
Manual for Installation, Use and Maintenance
2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note that
CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance or
use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Electrical safety (LVD)
2006/95/EC and Electromagnetic interference compatibility (EMC)
3
2004/108/EC. Parts intended to come into contact with food conform
to 89/109/EC.
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin.
Please note:
•Induction hobs become hot and remain hot during and immediately
after use. Do not touch the hob until it has been allowed to cool.
•Keep children away from the appliance when in use.
•Never use the hob top for storage.
•Pan handles should never stand out beyond the edge of the
worktop. This will ensure children cannot reach them.
•Do not lean over the hob when it is in use.
•Follow the cleaning instructions carefully.
•Ensure the base of the saucepan is clean and dry before placing it
on the hob.
•Avoid hard shocks from cookware – the vitroceramic glass surface
is highly resistant but not unbreakable.
4
•Do not place hot lids flat on the hob top. A “suction” eect could
cause damage to the hob.
•Do not drag cookware across the hob top: in the long term, this
could cause damage to the hob.
•Do not store cleaning or flammable products in the unit below the
hob.
•Always use appropriate cookware.
•Do not cook unopened tins of food directly on the hob.
•Never put cooking foil or plastic materials on the ceramic surface
when the hob is hot. These materials could melt and cause
damage to the hob.
•This hob (Class 3) has been designed for use only as a cooking
appliance. Any other use should be considered incorrect and
therefore dangerous.
FOR THOSE WITH HEART PACEMAKERS OR ACTIVE IMPLANTS:
The function of this hob conforms to current electromagnetic
interference standards and thus is in total compliance with legal
requirements (2004/108/CE directives).
To avoid interference between your hob and a pacemaker, your
pacemaker must be designed and programmed in compliance with
the regulations that apply to it. As such, CDA guarantee only that our
product is compliant.
With regard to the compliance of the pacemaker or any potential
incompatibility, you should obtain information from the manufacturer
or your attending physician.
5
Important
•Do not use the hob if the glass surface is cracked or damaged to
prevent the risk of electric shock. Disconnect it from the power
supply.
•Ensure that the power cable of a connected electrical appliance
near the hob is not in contact with the cooking zones.
Important: Please refer to page 13 for information on conguring
the power consumption mode correctly. The hob must be
congured at rst switch on.
6
Cooking on Induction
The principle of induction cooking is based on magnetic eect.
When you put your cookware on an induction zone and switch it on,
the electronic boards in the hob produce induced currents in the base
of the cookware and instantly raise its temperature. This heat is then
transferred to the food inside the cookware.
The best cookware to use with induction cooking has thick flat bases,
as the heat will be better distributed so cooking more evenly.
Most cookware is compatible with induction cooking. There are three
ways to check the suitability of your cookware:
1. Using a magnet to see if the base of the pan is magnetic: if three
magnet sticks, then the cookware is compatible.
2.Place the pan on one of the cooking zones switched on to power
level 4: if the display remains on, then the cookware is
compatible. If the display flashes, the cookware cannot be used on
an induction hob.
3.Check the instructions or packaging of the pans for the symbols
indicating suitability for use with induction.
7
Power level Type of cooking
0 Switched o
1/2 For melting (butter/chocolate) or keeping food warm
3/4 Keeping food hot or to heat small quantities of liquid
5/6 Heat larger quantities of liquid (sauces etc.)
7/8 Slow boiling, e.g spaghetti, soups, stews, potatoes
9/10 Gentle frying
11 Browning meats, frying fish, omelettes
P Fast frying steaks
Fig.1
2
14
3
5
Zones:
1. Front left 2.8 kW 180 mm
2. Rear left 2.8 kW 180 mm
3. Rear centre 3.1 kW 210 mm
4. Front right 2.2 kW 160 mm
5. Right 3.6 kW 280 mm
6 7 8 9 10 11 12 13 14
Using your Hob
Control panel:
9. Power key
10. Power level keys
11. Direct power key
12. Zone indicator
13. Boost
14. Direct power key 2
15. Tempo function
16. Timer keys
17. Childlock
The table below oers guidance as to what each power level is for.
8
Using your Hob
To switch the zone on
•Touch the key for the zone required. The zone display will flash 0
and the hob will beep to confirm the hob is on.
Please note: If a power level is not set within five seconds, the zone
will switch o automatically.
To set the power level
•Touch the keys to increase the power level from 1 (lowest) to P
(maximum), and the key to reduce it.
•To go straight to P, touch the key when the zone is switched on.
To turn the power o
•Touch the key for the zone used or reduce the power level on the
zone by touching the key until the zone display switches o.
Direct power key
•The hob is equipped with a direct power key to allow access to a
specific power level for ease of use, with a factory preset of
power level 8.
•After turning the power on for the zone required, touch the direct
power key. To change to any other power level, touch either or
keys until the required power level is shown on the zone display.
•It is possible to adjust the power level on the direct power key if
necessary. To do so, when the hob is switched o, touch the
direct power key for approximately five seconds until the hob beeps
and the display shows the current power level. Touch the or
9
keys until the zone display shows the required power level and then
touch the direct power key to set the powernlevel. The hob will
beep to confirm the power level has been set.
Boost
•The hob is equipped with a boost function, allowing a higher
power level than power level 12 for an unspecified length of time.
This allows maximum temperature to be reached quickly. To turn
on the boost function once the zone is switched on, touch the
key. bo will show on the zone display. When the pan has reached
the temperature required, then select the required power level by
touching or .
Please note:
•The boost function does not switch o automatically. You must set a
power level when boost is no longer required.
Total
•The hob is equipped with a total function, allowing you to set a new
power level for a total period of time before the zone returns to the
first power level.
1. Switch the zone on and set the required power level.
2. Touch the key.
3. Set the new power level using the power keys and total time
required at that level using the timer keys.
4. Confirm the selection by touching the key
10
•The zone display will show the total programme power level
and a. (dot) and the timer will start to countdown. Once the total
programme is complete, the zone will return to the original power
level.
Auto
•The hob is equipped with an automatic programme function, allowing
you to specify both the power level and time a zone will switch on and
o.
1. Switch the zone on
2. Touch the key – the display will show the current time, with the
hours in the zone display and the minutes in the timer display. If
the time is not correct, set the hour using the power keys and the
minutes using the timer keys.
3. Touch the key to confirm the time – the displays will flash.
4. Set the time when the zone is to switch o, using the power keys
for the hours and using the timer keys for the minutes and confirm
it by touching the key.
5. Set the length of time the zone is to be on up to a maximum of 99
minutes using the timer keys and confirm it by touching the key.
6. Set the power level using the power keys up to a maximum of
power level 10 and confirm it by touching the key. The displays
will show Auto and then switch o. A red LED will show to signify
the Automatic programme has been set.
Please note:
•Automatic programming can only be set on one zone for each section.
