Handleiding Technofeed control unit TF1000
Manual
-UK-
Page | 2
MANUAL (UK)
Page | 3
MANUAL (UK)
Index
The Technofeed control unit TF1000 ...................................................................................................... 4
Home screen............................................................................................................................................ 5
Menu ....................................................................................................................................................... 6
Animals................................................................................................................................................ 7
Location box ->......................................................................................................................... 8
Animal ->.................................................................................................................................. 9
Feed -> ............................................................................................................ 10
Feedcurves ........................................................................................................................................ 11
Curve ->.................................................................................................................................. 12
< Check >................................................................................................................................ 12
Adjust ->.......................................................................................................... 13
Locations ........................................................................................................................................... 14
Location ->.............................................................................................................................. 15
Start times ->................................................................................................... 16
Management..................................................................................................................................... 17
Sign in..................................................................................................................................... 18
Service.................................................................................................................................... 19
Backup............................................................................................................. 20
Service............................................................................................................. 21
Monitor........................................................................................................... 22
Sign out .................................................................................................................................. 22
By location and box......................................................................................... 23
By animalnumber ->........................................................................................ 24
Settings -> .............................................................................................................................. 25
Dosing ............................................................................................................. 26
Calibration....................................................................................................... 27
Manual start.................................................................................................... 28
Systemclock .................................................................................................... 29
Page | 4
MANUAL (UK)
The Technofeed control unit TF1000
This is the user manual of the Technofeed Control unit TF1000. The information in this user manual is
the property of Cawi pig farming solutions and may not be multiplied or distributed without the
express permission of the owner.
The user manual contains a triangle with an exclamation mark several times. This is an
important announcement that may affect the functionality of the system. Therefore, read
these announcements with extra attention.
The user manual is written to give instructions for using the Technofeed control unit TF1000.
Therefore, read this user manual carefully before using the system. This is to prevent unforeseen
inconveniences.
The Technofeed control unit TF1000 may only be connected and configured by a certified technician.
The power supply for the complete system must comply with NEN1010, guidelines for electrical
installations.
Warning: Please note that in times of a power failure no feed is given and this must be set
later. Also the feed starts that should have taken place at that time.
Note: Cawi pig farming solutions is not responsible for the data that is entered and also not
for automatic actions that may result. This system does not prevent the user from his / her
responsibility to ensure the healthy living conditions of the animals.
Page | 5
MANUAL (UK)
Home screen
Below is the home screen of the Technofeed Control unit TF1000. Three choices are possible on the
home screen: Menu, code and a flag.
With this function you go directly to the
menu. Here you can install, change or give service
to your Technofeed installation.
This function is for your service engineer
to be able to change settings in the software. The
code is only known by experienced technicians and is built in to ensure that the system cannot be
changed by inexperienced users.
If you push the flag on the home screen for 3 sec. you can change the language of your system.
Once this has been set, you no longer have to change it.
Page | 6
MANUAL (UK)
Menu
In the menu you have the choice of four
different options: Animals, Feed Curves,
Locations and Management. In the top right you
can see the current time and date. If this
information is incorrect, you can change this
information here. The four different options are
classified as follows:
With this function you can change the data of your animals that have been
sign up in the “locations” function. Such as: Curve number, Curve days,
correction percentages on the curve and Pre-days (only for nursery).
With this function you can change the feed curves, check the feed curves,
rename the feed curves and organize the feed curves.
With this function you can change the starting times by location, give the
location a name and set a feeding start at a location.
With this function you can sign up animals, sign out, go to the service menu
and change settings.
Page | 7
MANUAL (UK)
Animals
With this function you can change the data of
your animals that have been sign in in the
“locations” function. Such as: Curve number,
Curve days, correction percentages on the curve
and Pre-days (only for nursery).
At the top of the corner you will find the data in
the order: Location, Box and Animal number.
Linked to the animal number that is entered
under animal number (“1234” below).
In the window (1234) of the animal number you can select the wanted
animal by using the arrow keys next to the screen. You also have the option
of entering the number. Press the number for that. A keyboard appears with
which you can enter the wanted animal number. Then press [ENT] to confirm
the number.
It is also possible to approach the animal by location / box with possibly unknown animal numbers. In
this case, press:
With this function you can search the animal number with the location and box
number.
When the wanted animal is selected, you can click on the “Animal” function.
With this function you can view and change the curve of the selected animal.
You can also change the pre-days and feed percentages from the animal.
Page | 8
MANUAL (UK)
Location box ->
With this function you can search the animal number with the location and box number.
With this function you can select the correct location of the wanted animal
by using the arrow keys next to the screen. You also have the option of
entering the location. Press the number for that. A keyboard appears with
which you can enter the wanted animal number. Then press [ENT] to
confirm the number.
With this function you can select the correct box of the wanted animal by
using the arrow keys next to the screen. You also have the option of
entering the box. Press the number for that. A keyboard appears with which
you can enter the wanted animal number. Then press [ENT] to confirm the
number.
When the wanted animal is selected, you can click on the “Animal” function.
With this function you can view and change the curve of the selected animal.
You can also change the pre-days and feed percentages from the animal.
Page | 9
MANUAL (UK)
Animal ->
With this function you can view and change the curve of the selected animal. You can also change
the pre-days and feed percentages from the animal.
The wanted curve of the animal can be selected by using the arrow keys above and below
the screen. You also have the option of entering the curve number. Press the number for
that. A keyboard appears with which you can enter the wanted curve number. Then press
[ENT] to confirm the number.
This function is only required for nursery.
With this function you enter the number of days that the animal is before the expected
delivery date. The number of pre-days to be set is a maximum of 14 days. Then he counts
back one day every day (at 00:01 am) until day 0, after day 0 the feed curve will start.
If the Pre-day is at 0, the feed curve starts automatically! If the pre-day number
is 1 or higher, feeding is done according to the pre-days, regardless of the number of
the curve days. During the pre-days, a fixed amount of feed is given equal to day 0 of
the feed curve!
In the two windows next to the curve number you can enter the correction on the curve
and the curve day of the animal.
In the upper window you can enter a correction (75-125) percentage on the curve by
animal. This value can deviate a maximum of 25 percent on the curve assigned to the
animal. Press the number for that. A keyboard appears with which you can enter the wanted
deviation in percentages. Then press [ENT] to confirm the number.
Note: This value remains until this value is changed manually again.
In the lower window you can adjust the curve day of the animal. Press the number for that. A
keyboard appears with which you can enter the wanted curve day. Then press [ENT] to confirm the
number.
Page | 10
MANUAL (UK)
You can then see the number of grams of the
calculated daily amount by animal at the number
of grams in the window (see red box on the left).
With this function you can see the current feed calculation for the day. You
will also see the number of grams of food that has already been supplied to
the animal this day.
Feed ->
With this function you can see the current feed calculation for the day. You will also see the number
of grams of food that has already been supplied to the animal this day.
