Cateye Stealth EVO+ CC-GL51 Manuel d'instructions
Click the button and follow the
instructions.
CC-GL51
Quick Start
START
Thank you for purchasing our cyclocomputer CATEYE STEALTH evo+.
This Quick Start Manual explains how to set up the STEALTH evo+ and how to install the
unit on your bicycle.
Please set up the unit according to the specified procedure, then it will be ready for use as a
cyclocomputer.
Before use, read the instruction manual that comes with the product thoroughly to the
end to understand the functions of this unit, and to use it safely in a correct manner.
Next
This PDF contains a movie file.
When you click on the movie screen, a message regarding security appears. Click the
“Trust in the text” or “Play” button to close the message.
Click the screen again to play the movie.
Next
Quick Start Manual Contents
Click on the item to view.
Return to a Cover
Setting up the STEALTH evo+
Set up the STEALTH evo+ from a PC
How to install the bracket (movie format)
Optional: How to install the speed sensor (movie format)
Optional: How to wear the heart rate sensor (movie format)
Perform measurement
Operation of buttons
Set up the STEALTH evo+ by operating the buttons as follows.
Check the button position before you start setting up.
AC
MENU
MODE
(Power)
Next
Quick Start Manual Setting up the STEALTH evo+
Formatting operation
Setting the speed unit
Pairing
Setting the tire circumference
Power ON
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Power ON
Pressing and holding the button on the back of the
STEALTH evo+ for 2 seconds turns on the power, and the
screen lights up.
Power ON
(Press and hold)
Power ON
Return to Contents
Next
Return
Quick Start Manual Setting up the STEALTH evo+
Setting the speed unit
Pairing
Setting the tire circumference
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Formatting operation
Press the
MENU
button on the back of the STEALTH evo+
and the AC button simultaneously.
After all screen items light up, the display will be changed
to the speed unit setting screen, and setup will start.
MENU
MENU
AC
AC
MENUAC MENUAC MENUAC
123
Press and hold the* MENU button for 3 seconds
after releasing the AC button.
All screen items light up
Formatting operation
Power ON
Return to Contents
Next
Return
Formatting
operation
Quick Start Manual Setting up the STEALTH evo+
Pairing
Setting the tire circumference
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Setting the speed unit
Setting the speed unit
When the MODE button is pressed, either “km/h” or “m/h
(mile)”
is selected for the speed unit display.
Select the display of your choice.
Press the MENU button to go to the next step “Selecting
the time zone”.
To the next stepkm/h ↔m/h
MENU
MODE
Formatting operation
Setting the speed unit
Power ON
Return to Contents
Next
Return
Quick Start Manual
Setting the tire circumference
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
Setting up the STEALTH evo+
Pairing
Pairing (Searching the sensor ID)
When using the ANT+ sensor, it is necessary to perform
pairing with the STEALTH evo+. When not using, pairing
is not required.
Click on either button and follow the steps below.
Pairing can be performed also after setting is complet-*
ed. When you perform pairing later, click on “I do not
have an ANT+ sensor”.
Formatting operation
Setting the speed unit
Pairing
Power ON
Return to Contents
Return
I do not have an ANT+ sensor
I have an ANT+ sensor
Quick Start Manual Setting up the STEALTH evo+
Setting the tire circumference
Setting the time zone
GPS search screen
(Setup completed)
Setting the daylight saving time
Setting the clock display format
I do not have an ANT+ sensor
Pairing is not required. Press the MENU button 5 times to jump to the next
step “Setting the time zone”.
MENU MENU MENU MENU MENU
Pairing To “Setting the
time zone”.
1 2 3 4 5
Formatting operation
Setting the speed unit
Pairing
Power ON
Return to Contents
Next
Return
