PJ Camera Software 1.1

Multi PJ Camera System

Controller Software for Windows

User’s Guide

Keep this manual in a safe place for future reference.

• Microsoft, PowerPoint, Windows, Windows NT, Windows XP, and the Windows

logo are registered trademarks or trademarks of Microsoft Corporation of the

United States in the United States and other countries.

• Other company and product names may be registered trademarks or trademarks

of their respective owners.

• The contents of this User’s Guide are subject to change without notice.

• Copying of this manual, either in part or its entirety, is forbidden. You are

allowed to use this manual for your own personal use. Any other use is

forbidden without the permission of CASIO COMPUTER CO., LTD.

• CASIO COMPUTER CO., LTD. shall not be held liable for any lost profits or

claims from third parties arising out of the use of this product or this

manual.

• CASIO COMPUTER CO., LTD. shall not be held liable for any loss or lost

profits due to loss of data caused by malfunction or maintenance of this

product, or any other reason.

• The sample screens shown in this manual are for illustrative purposes only,

and may not be exactly the same as the screens actually produced by the

product.

MA0505-C

Contents

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Using This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Startup Modes and this Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Precautions when Using the PJ Camera Software . . . . . . . . . 7

Chapter 1

PJ Camera Software Overview . . . . . . . . . . . . . . . . . . 12

Starting Up PJ Camera Software . . . . . . . . . . . . . . . . . . . . . . 13

PJ Camera Software Startup Modes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Starting Up PJ Camera Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

PJ Camera Software Modes and Basic Operations . . . . . . . . . . . . 16

Using PJ Camera Software Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Operation Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

PJ Camera Software Window . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Using the Guide Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Selecting a Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Using Projection Area Capture and Board Area Capture . . . . . . . 25

Projection Area Capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Board Area Capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Quitting PJ Camera Software . . . . . . . . . . . . . . . . . . . . . . . . . 27

Chapter 2

Using PJ Camera Software . . . . . . . . . . . . . . . . . . . . . 28

Using the PJ System Like an OHP Projector

(Document Camera Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Document Camera Mode Overview . . . . . . . . . . . . . . . . . . . . . . . . 29

Projecting Images in the Document Camera Mode . . . . . . . . . . . . 33

Operations Available During Projection in the

Document Camera Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

Scanning Images (Scanner Mode) . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Scanner Mode Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Using Auto Scanning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Using Manual Scanning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

Contents

Using Image Files Stored on the Computer’s Hard Disk in a

Presentation (PC Image Mode). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

PC Image Mode Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

Using the Preview List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Using Playlists. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Using Projection Area Capture and Board Area Capture . . . . . . . . . . . . . 79

Using Image Files Stored in PJ Camera Memory in a

Presentation (Camera Image Mode) . . . . . . . . . . . . . . . . . . . . . . . . 80

Camera Image Mode Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Using the Preview List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Camera Image Mode Playlist Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Using Projection Area Capture and Board Area Capture . . . . . . . . . . . . . 84

Using PJ Camera Software with PowerPoint or Other

Presentation Software (Presentation Mode) . . . . . . . . . . . . . . . . . . 85

Entering the Presentation Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Presentation Mode Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Using Projection Area Capture and Board Area Capture . . . . . . . . . . . . . 86

Using Projection Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Zooming and Scrolling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

Editing the Projected Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89

Viewing the Recorded Image of the Currently Projected Image . . . . . . . . 92

Saving the Projected Image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

Viewing the Image Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95

Projection Area Capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97

Using Projection Area Capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Board Area Capture. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Using Board Area Capture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104

Contents

Chapter 3

Configuring PJ Camera Software Settings . . . 108

PJ Camera Software Operating Environment. . . . . . . . . . . . . . . . 109

Operating Environment Dialog Box. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Configuring Operating Environment Settings . . . . . . . . . . . . . . . . 110

Operating Environment Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

Operation Bar Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Configuring Operation Bar Properties . . . . . . . . . . . . . . . . . . . . . . . . . . . 117

Chapter 4

Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120

Menus and Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

[File] Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

[Edit] Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

[View] Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123

[Camera] Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

[Tools] Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

[Image] Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125

[Playlist] Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

[Help] Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Shortcut Menu Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127

Document Camera Mode Shortcut Menu Commands . . . . . . . . . 127

PC Image Mode and Scanner Mode Shortcut Menus. . . . . . . . . . . . . . . 128

Camera Image Mode Shortcut Menus . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Toolbar Button Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Standard Toolbar Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132

Playlist Toolbar Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

Function Keys and Shortcut Key Operations . . . . . . . . . . . . . . . . 134

Guide Icon Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135

Image File Properties Dialog Box Contents . . . . . . . . . . . . . . . . . 136

PJ Camera Software Folder Structure. . . . . . . . . . . . . . . . . . . . . . 138

Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140

Introduction

This User’s Guide describes how to use PJ Camera Software, which is special

controller software for the Multi PJ Camera System.

Using This Manual

The contents of this manual are written assuming that you have read the “MULTI PJ

CAMERA/Multifunctional Camera System YC-400 User’s Guide” and have already set up the

Multi PJ Camera System.

Be sure to read the “MULTI PJ CAMERA/Multifunctional Camera System YC-400 User’s

Guide” before reading this manual.

zMost of the operations presented in this manual are performed using the menus and

toolbar. Some examples also include information about using keyboard shortcut keys.

zAs a general rule, operations using the shortcut menu that appears when you right-click

with the mouse are not included. For information about the shortcut menu, see “Chapter 4

Reference”.

■MULTI PJ Camera

The term “PJ Camera” in this manual refers to the camera unit of the Multi PJ Camera

System.

■Projection

PJ Camera Software is basically software for projecting images from a projector. Because of

this, the term “projection” is used in this manual to refer to operations that actually cause the

image to fill the computer screen (without actually projecting it).

PJ Camera Software has two startup modes: a Multi PJ startup mode and a Business

Document startup mode (“PJ Camera Software Startup Modes” page 13). The startup mode

you select determines the PJ Camera Software functions that are available to you.

zAll of the explanations in this manual apply when you start up PJ Camera Software in the

Multi PJ startup mode.

zOnly functions and explanations with next to their title apply when you start up PJ

Camera Software in the Business Document startup mode.

zDescriptions of items that explain particular differences between the Multi PJ and the

Business Document startup modes are presented as shown below.

Startup Modes and this Manual

z(Text describing difference)

Precautions when Using the PJ

Camera Software

PJ Document Stage

zNever write on the document stage and take care to guard against scratching or otherwise

damaging it. Writing or other marks on the document stage can interfere with projection in

the Document Camera Mode and scanning in the Scanner Mode.

zExternal Light

Room illumination, sunlight, or light from some other source shining onto the document

stage during a Document Camera Mode or Scanner Mode image recording operation can

cause white out and other image abnormalities.

Document Camera Mode

The Multi PJ Camera System automatically monitors the status of the document stage in

order to optimize contour extraction and automatic image recording operations under a variety

of different conditions. Because of this, you should adjust the camera position whenever

recording conditions change or when you move the camera due to a mode change, etc.

■Automatic Image Recording

The automatic image recording function detects changes in brightness and contrast. Though

the Multi PJ Camera System can adapt to a wide range of conditions, automatic image

recording may not be possible under the following conditions.

zIn a room where there is insufficient lighting to detect contours

zIn a room where there are large fluctuations in the lighting level

zA document that is smaller than the specified size

In the above cases, use manual recording.

Tip

If the shutter releases even though there is nothing on the document stage, check the

following.

zIf the document stage is badly damaged, have it repaired.

zIf the document stage is very dirty, clean it.

zIf there has recently been a change in the camera recording conditions, perform camera

position adjustment.

Precautions when Using the PJ Camera Software

■Contour Extraction

Contour extraction uses brightness contrast to extract the rectangular shapes in an image.

Though the Multi PJ Camera System can adapt to a wide range of conditions, certain types

of documents may not be compatible with automatic contour detection. The following are the

conditions that promote successful automatic contour detection.

zMake sure the room is lit sufficiently.

zPlace the document in the center of the document stage, and make sure that no part of it

is extending off of the stage.

zMake sure the document is free of creases and curls, and is either rectangular or square.

zMake sure the document is free of creases and wrinkles.

zUse only documents that are within the stipulated range of sizes (from business card size

to A4 (210 ×297mm)(8.3 ×11.7inch)/Letter size).

zUse documents whose color provides sufficient contrast with the document stage color. Also,

the color surface of the table where the PJ Camera Stand is located should be a different

color from the document stage.

zPlace the PJ Camera Stand on a surface that does not reflect light.

zWhen placing a document onto the document stage, make sure the document is relatively

straight (tilted no more than about 30 degrees).

Tip

Check for the following if you experience occasional contour detection problems.

zIn the case of a color document, is there sufficient color contrast around the contours?

If not, use a setting that does not perform contour extraction.

zIs room lighting too dim to allow adequate contour contrast detection?

Increase the level of room lighting or use a setting that does not perform contour extraction.

zIs part of the document outside of the document stage area?

Re-position the document taking care to ensure that no part of the document extends past

the edges of the document stage. Make sure that the entire document is within the area of

the document stage.

zThe document is curled or bent.

Flatten the document so it forms a rectangle or square.

Tip

Check the following points if contour detection does not work at all.

zIs the document smaller than the specified size?

If it is, extraction cannot be performed.

zIs the document in the center of the document stage with no part of the document

extending off the sides of the stage?

Position the document in the center of document stage and ensure that no part of it extends

off the sides.

Precautions when Using the PJ Camera Software

Tip

Check the following points if you suddenly start to have problems with contour detection.

zHas there been a change in the conditions under which you are using the camera?

Perform camera position adjustment.

zHave you changed to a different type of document?

Check to make sure that the document contents conform to contour extraction requirements.

zIs an edge of the document running along a joint of the document stage?

Reposition the document so its edges do not run along any document stage joint.

zIs the document positioned in the center of the document stage?

Make sure that the document is positioned so one part of it is located on the cross mark

in the center of the document stage.

zIs the document too small?

Use the “Small Document” setting.

Projection Area Capture

When capturing the image area, compose the image so the entire projection area fits within it.

Adjust the position of the projector to make sure that the projected image is rectangular or

square.

zThe PJ Camera Software corrects for distorion of the projection image. This can cause

written text or graphics in the combined Projection Area Capture image to appear somewhat

different from the original.

zFor best results, make sure to check for the following when composing an image for

Projection Area Capture.

• Make sure that the projection area is included within the image.

• Make sure that the projection area fills the entire image.

• Make sure that the center of the image is located within the projection area on the

whiteboard.

• Make sure that all of the projection area is on the whiteboard, and that it forms a

rectangular or square shape.

• Make sure there is sufficient contrast around the periphery of the projection area.

• Make sure there is no light from a fluorescent or incandescent light source shining into

the projection area.

zA slow shutter speed setting is used in order to produce high-resolution images. Avoid

shaking or moving the camera while recording images.

Precautions when Using the PJ Camera Software

Board Area Capture

When capturing the board area, compose the image so the entire board area fits within it.

For best results, make sure to check for the following when composing an image for Board

Area Capture.

zMake sure that the whiteboard contour fits within the image.

zMake sure the whiteboard fills the entire image.

zMake sure that the center of the image is located within the whiteboard area.

zMake sure there is sufficient contrast around the periphery of the whiteboard.

zMake sure there is no light from a fluorescent or incandescent light source shining onto the

whiteboard.

zMake sure that the angle between the projector and the whiteboard is no greater than 30

degrees.

A slow shutter speed setting is used in order to produce high-resolution images. Avoid

shaking or moving the camera while recording images.

Scanner Mode

■Contour Extraction

See “Contour Extraction” on page 8 for details.

Scanner resolution is 160dpi at the center of the image if fully zoomed out. Resolution is

lower at the periphery of the image.

PJ Camera Software Precautions

■USB Hub Connection

In rare cases, you may not be able to turn off the camera when it is connected to a USB

hub.

If this happens, do not use a USB hub.

■Recovering after your computer goes into standby

The camera may not operate correctly after you recover from a suspend/standby state on

your computer. After recovering from a suspend/standby state on your computer, press the PJ

Camera stand’s power button to turn power off and then back on again.

Autres manuels pour YC-400 - Document Camera

Table des matières

Autres manuels Casio Projecteur

Casio

Casio XJ-H1750 Manuel d'instructions et de sécurité

Casio

Casio XJ-A245V SERIES Manuel utilisateur

Casio

Casio XJ-450 Manuel utilisateur

Casio

Casio XJ-S37 - XGA DLP Projector Manuel d'instructions et de sécurité

Casio

Casio XJ-A245V SERIES Manuel utilisateur

Casio

Casio XJ-S36 - XGA DLP Projector Manuel d'instructions et de sécurité

Casio

Casio XJ-H1700 Manuel utilisateur

Casio

Casio XJ-S43W - WXGA DLP Projector Manuel utilisateur

Casio

Casio XJ-450 Guide de dépannage

Casio

Casio XJ-A235V SERIES Manuel d'instructions et de sécurité

Casio

Casio XJ-A246 Manuel d'instructions et de sécurité

Casio

Casio SLIM XJ-A251 Manuel d'instructions et de sécurité

Casio

Casio XJ-460 - XGA DLP Projector Manuel utilisateur

Casio

Casio XJ-S31 - XGA DLP Projector Manuel utilisateur

Casio

Casio XJ-H1600 Manuel utilisateur

Casio

Casio XJ-S31 - XGA DLP Projector Manuel utilisateur

Casio

Casio XJ-S33 series Manuel utilisateur

Casio

Casio XJ-UT351WN SERIES Mode d’emploi

Casio

Casio SLIM XJ-A141 Manuel utilisateur

Casio

Casio YC-400 - Document Camera Manuel utilisateur

Casio

Casio XJ-A130V/XJ-A135V* Manuel utilisateur

Casio

Casio XJ-350 Manuel utilisateur

Casio

Casio XJ-V1 Manuel utilisateur

Casio

Casio XJ-A130 Manuel utilisateur

Manuels Projecteur populaires d'autres marques

iEmmet

iEmmet MP-312 Manuel utilisateur

Epson

Epson VS400 Manuel utilisateur

Sony

Sony VPL-HS10 Marketing Specifications & Features Manuel utilisateur

Sony

Sony VPL-HW65ES Manuel de service

Toshiba

Toshiba TLP-791U Manuel utilisateur

Philips

Philips LC1341 Guide de référence

Panasonic

Panasonic PTL735NTU - LCD PROJECTOR-NETWORK IB Manuel utilisateur

NEC

NEC NP600S EDU Manuel utilisateur

BenQ

BenQ SH753P Manuel utilisateur

Eiki

Eiki EK-623U series Manuel utilisateur

Epson

Epson PowerLite Pro Cinema 6020UB Manuel utilisateur

Epson

Epson PowerLite Home Cinema 705HD Manuel utilisateur

Christie

Christie LHD700 Manuel utilisateur

Navitar

Navitar FX Manuel utilisateur

InFocus

InFocus LitePro 560 Manuel utilisateur

Sony

Sony SRX-R815P Manuel utilisateur

Vivitar

Vivitar DP1500 X Manuel utilisateur

Acer

Acer C20 Series Manuel utilisateur
