Casio V-N500 Series Manuel utilisateur

CASIO

V-T500/V-N500 Series

Quick Start Guide

(Version 1.07)

CASIO Computer Co., Ltd.

June 2013

Table of the Contents

1. Product Overview 4

1.1 Features at a Glance 4

1.2 Library Configuration 6

1.3 Development Manuals 6

2. Prerequisites 7

2.1 Skills Required 7

2.2 Hardware Required 7

2.3 Systems Required 7

2.4 Software Required 8

3. Setting up the Development Environment 9

3.1 Application Development 9

3.2 Installing JDK 10

3.3 Installing Android SDK 13

3.4 Installing Eclipse 17

3.5 Installing ADT 19

3.6 Installing Software Development Kit (“SDK”) 24

4. Connecting V-T500/V-N500 to PC 25

4.1 Installing USB Driver 25

5. Setting Up the Development Environment 28

5.1 Setting JDK 28

5.2 Setting AVD 29

5.3 Setting Android Project 31

5.4 Setting Up the Debugging Environment 33

5.4.1 Setting the Debug Configuration with Terminal 33

5.4.2 Setting the Debug Configuration with the Emulator 34

5.4.3 Debugging Applications 35

6. Emulator 38

6.1 Software Required 38

6.2 Starting Up the Emulator 38

6.2.1 How to Start Up the Emulator 38

6.3 Using the Emulator 41

6.3.1 V- T500/V-N500 Emulator 41

7. Eclipse 42

7.1 Developing with System Library 42

8. Kitting 61

8.1 New Configuration of System 61

8.1.1 Flow of New Configuration 61

8.1.2 Design the system 61

8.1.3 Set Environment 61

8.1.4 Install Application Software 62

8.1.5 Replicate Environment to Other Terminals 63

8.1.6 Set Specific Environment of Each Terminal 66

9. Appendix Default Values of the Setting 68

No part of this reference manual may be produced or transmitted in any form or by any means, electronic or

mechanical, for any purpose, without the express written permission of CASIO Computer Co., Ltd. in Tokyo

Japan. Information in this reference manual is subject to change without advance notice. CASIO Computer Co.,

Ltd. makes no representations or warranties with respect to the contents or use of this manual and specifically

disclaims any express or implied warranties of merchantability or fitness for any particular purpose.

1. Product Overview

This guide clearly and concisely sets out the information developers need to know to get started with CASIO

V-T500/V-N500 series terminals development.

1.1 Features at a Glance

The following is a brief overview of the features available on V-T500/V-N500series terminals. For further

details on the hardware specifications, refer to V-T500/V-N500Series Hardware Manual.

Table 1.1 Features at a Glance

V-T500/V-N500

CPU OMAP 1.5 GHz Dual core

Memory RAM 1 GB

F-ROM 16 GB

Platform Android 4.0

LCD Model IPS mode TFT color LCD

Size 10.1 inch

Pixel 1280 x 800 Wide XGA

Color 16.7

Viewing angle 80°

Backlight LED Backlight

LED Red x 1, Green x 1

(For confirmation of charging/state of operation)

Touch panel Capacitive touch panel with Multi-Touch

Input :Pen-type digitizer

Button Power button/function buttons A and B/

Volume button (UP/DOWN)/

Screen locking button (display rotation locking button)

Bluetooth®

communication

Version Bluetooth® Specification Ver.4.0+EDR

Communication range Approximately 5 meters(Varies depending on conditions of radio wave

and environment.)

Class 2 (Output 2.5 mW Range 10 m)

NFC

Model ISO14443 Type A (Mifare)

ISO14443 Type B

Felica(JIS X 6319)

ISO15693 (Tag)

Antenna Magnetic loop antenna

SIM Standard ISO 7816 IC Card Standard

General specification

SAM Standard ISO 7816 IC Card Standard

General specification

Wireless LAN

Standard specification IEEE 802.11a/b/g/n

Communication system Spread Spectrum Communication System

Modulation method BPSK,QPSK,CCK,16QAM,64QAM

Transfer rate 802.11a/g：up to 54Mbps

802.11b：up to 11Mbps

802.11n：up to 72Mbps

Communication range 802.11b/g/n：50m (in-door), 150 m

(out-door) (2.4GHz band for /n)

802.11a/n ：30m (in-door), 150 m

(out-door) (5GHz band for /n)

Output 802.11a：12.0dBm min. Typical 13.5dBm

(at 54Mbps)

802.11b：17.0dBm mini. Typical 18dBm

(at 11Mbps)

802.11g：12.0dBm mini. Typical 14dBm

(at 54Mbps)

802.11n：11.0dBm min. Typical 12.5dBm

(at 72Mbps)

GPS General specifications 1575.42 MHz, C/A Code

Positioning scheme Self-ephemeris

SD card slot Supporting SDHC/SDIO cards

Micro SD card slot Supporting SDHC card

USB USB host x 1

USB devicex 1

Camera Effective pixels Approx. 2M Pixels (2592×1944 pixels)

Aperture F2.8±5%

Focal length f=3.4mm±5%

Focus distance 10cm to infinity

LED light 21,000mcd()

Speaker Alarm, etc.

Microphone Voice input

Power source Main Battery Lithium Ion Polymer Rechargeable Battery

Sub-battery 1 x Lithium Ion Secondary Battery

Temperature -20 to 50 °C

Humidity 10 to 90% RH

Drop strength 1.0 m

Waterproof and dustproof performance IP54-compliant

Size 269 mm x 190 mm x 14 mm

1.2 Library Configuration

The V-T500/V-N500 Software Development Kit (“BDK”) provides various libraries including those listed

in the table.

Table 1.2

Library Description

System Library Library that is used to control the system.

SAM Library Library that is used to communicate with the SAM Card.

Authentication library Library that is used to set the authentication function such as the password.

Camera scanning library Library that is used to scan symbols with the camera.

The following table shows each file name of the jar files.

Table 1.3

Library jar file

System Library jp_casio_vx_framework_system.jar

SAM Library jp_casio_vx_framework_sam.jar

Authentication library jp_casio_vx_framework_authenticate.jar

Camera scanning library jp_casio_vx_framework_camerascanner.jar

1.3 Development Manuals

The V-T500/V-N500 Software Development Kit (“BDK”) provides various development reference

manuals as described in the table below.

Table 1.4 V-T500/V-N500 manual

Development Manual Description

Quick Start Guide This reference manual.

Hardware Manual Reference manual that describes hardware specifications in detail on each

dedicated option and V-T500/V-N500 handheld terminal.

Software Manual Reference manual that describes software specifications in detail for all the

software integrated in V-T500/V-N500 handheld terminal.

Table 1.5 Library manual

Development Manual Description

System Library Manual Reference manual that describes individual functions in detail for System

Library.

SAM Library Manual Reference manual that describes individual functions in detail for SAM Library.

Authentication Library Manual Reference manual that describes individual functions in detail for

Authentication Library.

Camera Scanning Library Manual Reference manual that describes individual functions in detail for Camera

Scanning Library.

2. Prerequisites

2.1 Skills Required

V-T500/V-N500 application can be developed by the following languages:

•Java

The following skills or experience are also desirable:

•Android OS

•Development of Android applications

•Eclipse integrated development environment

•Some networking experience

2.2 Hardware Required

The following models and dedicated options are available.

Table 2.1 List of available model

Model no. Remark

V-N500

V-T500

2.3 Systems Required

PC Operating System

One of following OS (in case of 32 bit) is required.

•Microsoft Windows Vista Service Pack 2 or later

•Microsoft Windows 7 Service Pack 1 or later (Professional/Ultimate)

One of following OS (in case of 64 bit) is required.

•Microsoft Windows 7 Service Pack 1 or later (Professional/Ultimate)

Main unit of the computer

The personal computer on which the OS above operates

Memory

Secure the necessary and adequate capacity for operating the OS above.

The necessary capacity varies according to the OS used. In either case, a capacity of 1 GB or more is

recommended.

Hard disc capacity

10 GB or more free space is recommended.

2.4 Software Required

The Android development environment is required for developing the V-T500/V-N500 application.

Table 2.2 Development platform

Programming Language Detail

Java Java SE Development Kit (JDK compiler-compliant level 1.6)

Android SDK (API level 15)

Eclipse 3.7 (Indigo)

ADT Plugin for Eclipse

Table 2.3 The URL where each tool is supplied

Tool Manual Version no. Detail

JDK 6 (u31 or later) http://www.oracle.com/technetwork/java/javase/downloads/index.html

Android SDK r18 and r20 (old) http://dl.google.com/android/installer_xxx-windows.exe

(Case of r20) http://dl.google.com/android/installer_r20-windows.exe

(latest) http://developer.android.com/sdk/index.html

Eclipse 3.7 (Indigo) http://www.eclipse.org/downloads/packages/release/indigo/sr2

ADT 15.0.0 or later

20.0.0 or earlier

(old) http://dl.google.com/android/ADT-xx.x.x.zip

(Case of 20.0.0) http://dl.google.com/android/ADT-20.0.0.zip

(latest) https://dl-ssl.google.com/android/eclips

Note: The URLs above are as of April 4, 2013.

3. Setting up the Development Environment

3.1 Application Development

This chapter explains what to set up for the development environment before starting your application

development.

(1) Installing JDK/Android SDK/Eclipse/ADT

Install the development environment for the Android application on the PC.

For details, refer to Chapter 2.4 Software Required.

(2) Installing CASIO SDK to PC

Install CASIO SDK on the PC.

For the installation method, refer to Chapter 3.6 Installing Software Development Kit (“SDK”).

(3) Connecting V-T500/V-N500 to PC

Connect V-T500/V-N500 to PC.

For the connection method, refer to Chapter 4. Connecting V-T500/V-N500 to PC.

(4) Preparing the Device Emulator

Prepare to use the CASIO V-T500/V-N500 device emulator on the PC.

For the operation method, refer to Chapter 6. Emulator.

If no device emulator is required, proceed to (5).

(5) Application Development

Now, the application development environment is set up and your development with the development

platform can be started.

After an application has been developed, transfer it to the Device Emulator or an actual terminal of

V-T500/V-N500 via the tool of (3) to check the operability.

For the application development method and transferring your application, refer to Chapter 7. Eclipse.

3.2 Installing JDK

Java SE JDK can be downloaded from the Java site. Access the Java site, and download the Java SE JDK

package compatible with the Windows platform used.

The URL and the details of the Java site may differ from those given in this document because the site has been

updated.

When downloading Java SE JDK, access the Java site from a search site, and follow the procedures explained

on the site.

http://www.oracle.com/technetwork/java/javase/downloads/index.html

Figure 3.1

jdk-6u31-windows-i586.exe (32 Bit version) is downloaded in the example below.

Download the 64 bit version for the 64 bit version OS.

Autres manuels pour V-N500 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Casio portable

Casio

Casio CASSIOPEIA E-15 Manuel utilisateur

Casio

Casio Cassiopeia EG-800 Manuel utilisateur

Casio

Casio DT-X100 Series Instructions de montage

Casio

Casio Cassiopeia E-125 Manuel utilisateur

Casio

Casio IT-800 Series Instructions de montage

Casio

Casio DC-7800 Manuel utilisateur

Casio

Casio DT-X30G Manuel utilisateur

Casio

Casio Cassiopeia EG-800 Manuel utilisateur

Casio

Casio IT-300-35E Guide de démarrage rapide

Casio

Casio IT-G500 Series Instructions de montage

Casio

Casio DT-970M50E Manuel utilisateur

Casio

Casio DT-X7 Series Instructions de montage

Casio

Casio DT-X200 Series Instructions de montage

Casio

Casio CASSIOPEIA FIVA MPC-701 Series Manuel utilisateur

Casio

Casio IT-600 Series Manuel utilisateur

Casio

Casio Cassiopeia E-200 Manuel utilisateur

Casio

Casio DT-X200 Series Manuel utilisateur

Casio

Casio DT-X7 Series Manuel utilisateur

Casio

Casio Cassiopeia EG-800 Guide de dépannage

Casio

Casio Cassiopeia E-115 Manuel utilisateur

Casio

Casio DT-X8 Series Instructions de montage

Casio

Casio IT-G500-C16E Manuel utilisateur

Casio

Casio IT-G400 Series Manuel utilisateur

Casio

Casio DT-X10 - M30U - Win CE Manuel utilisateur

Manuels portable populaires d'autres marques

Honeywell

Honeywell Dolphin 9900 Manuel utilisateur

Honeywell

Honeywell CN75 Manuel utilisateur

MiTAC

MiTAC Mio 168 Manuel utilisateur

Wasp

Wasp WDT92 Manuel utilisateur

Texas Instruments

Texas Instruments TI-Nspire Manuel utilisateur

AXEM Technology

AXEM Technology MBS Manuel utilisateur

Armstrong

Armstrong Brain Wave Instructions de montage

Unitech

Unitech TB128 Manuel utilisateur

Symbol

Symbol MC9000-G Manuel d'installation et d'exploitation

Unitech

Unitech HT1 1D Batch Manuel utilisateur

Ingenico

Ingenico IWL220 GPRS Manuel utilisateur

Intermec

Intermec CK61 Manuel utilisateur

Symbol

Symbol c2000 Manuel utilisateur

Symbol

Symbol MC18 Manuel d'installation et d'exploitation

Acer

Acer n20 Manuel utilisateur

Intermec

Intermec CK61 Manuel utilisateur

Docomo

Docomo F-04H Manuel utilisateur

Toshiba

Toshiba e350 Series Manuel utilisateur
