Casio EXILIM EX-Z70 Guide d'installation

K817CUG2PKC

EGFSISwD

Digital Camera

Digitalkamera

Appareil photo numérique

Cámara digital

Fotocamera digitale

Digital kamera

Digitale Camera

EX-Z70

Basic Reference

Grundlegende Referenz

Référence de base

Referencia básica

Guida di consultazione rapida

Grundreferens

Basisreferentie

Bij dit produkt zijn batterijen geleverd.

Wanneer deze leeg zijn, moet u ze niet

weggooien maar inleveren als KCA.

This mark applies in EU countries only.

Este símbolo es válido sólo en países de la UE.

CASIO Europe GmbH

Bornbarch 10, 22848 Norderstedt,

Germany

For Customers in the U.S.A. and Canada

This lithium ion battery, which provides power

for your digital camera, can be recycled.

Please do your part to protect the environment

and recycle this battery.

For information on how to recycle the battery,

please call 1-800-822-8837 or visit http://www.rbrc.org.

Para los clientes de EE.UU. y Canadá

La pila de ión de litio, que proporciona energía a su cámara

digital, puede ser reciclada.

Usted puede proteger el medio ambiente reciclando esta pila.

Para la información sobre cómo reciclar la pila, llame por favor

este numero 1-800-822-8837 o visite http://www.rbrc.org.

Pour la clientèle aux États-Unis et au Canada

La batterie au lithium qui alimente votre appareil photo

numérique peut être recyclée.

Contribuez à la protection de l’environnement en reclyclant

votre batterie.

Pour le détail sur le recyclage de la batterie, veuillez appeler le

1-800-822-8837 ou consulter le site http://www.rbrc.org.

E-1

ENGLISH

Basic Reference

EX-Z70

Congratulations on your selection of the CASIO EX-Z70

Digital Camera! This Basic Reference provides you with the

general information you need to start using the EX-Z70. For

more detailed information, see the EX-Z70 User’s Guide,

which is in digital form as a PDF file on the CD-ROM that

comes bundled with the EX-Z70. Note that to view the EX-

Z70 User’s Guide, you will have to install AdobeRReader.

Consult your dealer or CASIO distributor if you are unable

to open to display the PDF format User’s Guide on the CD-

ROM.

•Be sure to keep all user documentation handy for future

reference.

CONTENTS

Unpacking ......................................................... E-2

Quick Start Guide ............................................. E-3

General Guide ................................................... E-7

Monitor Screen Contents .............................. E-10

Menu Reference ............................................. E-14

Troubleshooting ............................................. E-16

Precautions ..................................................... E-17

E-2

Unpacking

Check to make sure that all of the items shown below are included with your camera. If something is missing, contact your

dealer as soon as possible.

Rechargeable Lithium

Ion Battery (NP-20)

CD-ROM USB Cable Basic Reference

Camera Strap

AV Cable

Lithium Ion Battery

Charger

(BC-11L)

AC Power Cord

*The shape of the AC power

cord plug varies according to

country or geographic area.

E-3

Quick Start Guide

First, charge the battery!

[CHARGE] lamp lights red

during charging.

[CHARGE] lamp goes out

when charging is complete.

Charge the rechargeable litium

ion battery (NP-20) that comes

with the camera.

•It takes about 90 minutes to achieve

a full charge.

Load the battery into the camera.

Stopper

E-4

To configure display language and clock settings

[왖]

[왔]

[왗][왘]

[SET]

2, 3, 4, 5, 6, 7, 8, 9

Press the power button to turn on the camera.

Use [왖], [왔], [왗], and [왘] to select the language

you want.

Press [SET] to register the language setting.

Use [왖], [왔], [왗], and [왘] to select the geographical

area you want, and then press [SET].

Use [왖] and [왔] to select the city you want, and

then press [SET].

Use [왖] and [왔] to select the summer time (DST)

setting you want, and then press [SET].

Use [왖] and [왔] to select the date format setting

you want, and then press [SET].

Set the date and the time.

Press [SET] to register the clock settings and exit

the setting screen.

•Be sure to configure the following settings before

using the camera to record images.

•If you make a mistake when setting the language or

clock with the following procedure, you will need to

use the camera’s menu to individually change the

language or clock settings.

E-5

To record an image

Press [ ] (REC).

•This enters the REC (recording) mode.

Point the camera at the subject, use the monitor

screen to compose the image, and then press

the shutter button half way.

•When the camera finishes its Auto Focus operation, the

focus frame will turn green and the operation lamp lights

green.

Holding the camera still, gently press the shutter

button all the way down.

Before using a commercially available memory

card, be sure to first format it using the camera’s

formatting procedure.

:38

Operation lamp

Focus frame

Auto recording icon

E-6

Press [ ] (PLAY).

Press [왔] ( ).

Use [왗] and [왘] to display the image you want to

delete.

Use [왖] and [왔] to select “Delete”.

•To exit the image delete operation without deleting anything,

select “Cancel”.

Press [SET] to delete the image.

To delete an image

Press [ ] (PLAY).

•This enters the PLAY (playback) mode.

Use [왗] and [왘] to scroll through the

images.

To view a recorded image

2, 3, 4, 5

E-7

3Self-timer lamp

There are two lamp flash patterns.

Pattern 1 flashes once per second and Pattern 2 flashes

twice per second.

4Microphone

5Lens

6Flash

■Front

General Guide

The following illustrations show the names of each

component, button, and switch on the camera.

Camera

1Shutter button

2Power button

Meaning

Self-timer countdown (10 to 3 seconds)

Self-timer countdown (3 to 0 seconds)

Self-timer Lamp

Red

Pattern 1

Pattern 2

E-8

■Back

7Operation lamp

8Zoom button

REC mode : Selects the zoom factor.

PLAY mode : Switches between the actual-size image

screen, 9-image screen, calendar screen,

and enlarged screen.

9Strap ring

0[] (PLAY mode) button

A[] (REC mode) button

B[왖][왔][왗][왘]

•[왔] ( ) (Delete/Flash) button

REC mode: Cycles through the flash mode settings.

: Auto Flash

: Flash Off

: Flash On

: Soft Flash

: Red-eye reduction

PLAY mode: Displays the delete menu.

•[왖] (DISP) button

Cycles through available display settings.

C[SET] button

D[BS] (BEST SHOT) button

Enters the BEST SHOT mode and displays a sample

scene in the REC mode. Use this mode to select a

sample scene for automatic camera setup.

E[MENU] button

Displays the REC mode menu or PLAY mode menu.

FMonitor Screen

EDC

[왖]

[왔]

[왗][왘]

[SET]
