Caple Tela TEL900 Manuel utilisateur
Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Tela Island Hood
Instruction Manual
TEL900
2Instruction manual TEL900 Please keep this instruction manual for future reference
CONTENTS
Safety Instructions 3
Environmental Protection 7
Installation 9
TEL900/SHELF 20
Maximum Load 37
Control Panel 38
Timing 39
Lighting 40
Cleaning and Maintenance 41
After Sales 44
Caple Contact Details 48
3Instruction manual TEL900Please keep this instruction manual for future reference
SAFETY INSTRUCTIONS
WARNING
-The cooking surface and the inferior part of the cooker
hood must be at a minimum distance of 65 cm.
-The appliance is not intended for use by young children
or infirm persons without supervision. Young children
should be supervised to ensure they do not play with
the appliance.
-The cooker hood, when evacuating the extracted air,
could generate negative pressure in the room, which
can’t exceed the limit of 0.04 mbar, in order to avoid
the suck of exhausts deriving from the heat-source.
Therefore the room should be provided with air-intakes
to allow a constant flow of fresh air.
-When performing the electrical connections on the
appliance, please make sure that the current tap is
provided with earth connection and that voltage values
correspond to those indicated on the rating label
placed inside the appliance itself.
-Please disconnect the appliance from power mains,
before carrying out any cleaning or maintenance
operation. If the appliance is not equipped with a
nonseparable flexible cable and plug, or with another
device ensuring omnipolar disconnection from the
mains, with an opening distance between the contacts
of at least 3 mm, then such disconnecting devices must
be provided in the fixed installation.
4Instruction manual TEL900 Please keep this instruction manual for future reference
-If the appliance is equipped with a power cord and a
plug, it shall be placed in such a way that the plug can
be reached easily.
-The use of materials which can burst into flames
should be avoided in close proximity of the appliance.
When frying, please pay particular attention to fire
risk due to oil and grease. Being highly inflammable,
fried oil is especially dangerous. Do not use uncovered
electric grills. In order to avoid possible fire risk, all
instructions for grease-filter cleaning and for removing
eventual grease deposits should be strictly followed.
-Two persons are needed for the installation of
this product.
-This appliance complies with all relevant local and
national safety requirements. Inappropriate use can,
however, lead to personal injury and damage
to property.
-The cooker hood is not intended for outdoor use.
-It must only be used as a domestic appliance to extract
vapours and remove odours from cooking. Any other
usage is not supported by the manufacturer and could
be dangerous.
-Where a recirculation cooker hood is fitted above a gas
hob, please ensure that there is an adequate supply of
fresh air into the room in which it is installed. Please
seek the advice of a qualified gas fitter (e.g. GasSafe in
the UK) if necessary.
5Instruction manual TEL900Please keep this instruction manual for future reference
-Children under 8 years of age must be kept away from
the cooker hood unless they are constantly supervised.
-Children 8 years and older may only use the cooker
hood unsupervised if they have been shown how
to use it safely and recognise and understand the
consequences of incorrect operation.
-The electrical safety of this appliance can only be
guaranteed when correctly earthed. It is essential
that this standard safety requirement is met. If in any
doubt please have the electrical installation tested by a
qualified electrician.
-Do not connect the appliance to the mains electricity
supply by a multi-socket unit or an extension lead.
These are a fire hazard and do not guarantee the
required safety of the appliance.
-The cooker hood can get very hot during cooking due
to heat rising from the hob.
-Do not touch the housing or the grease filters until the
cooker hood has cooled down.
6Instruction manual TEL900 Please keep this instruction manual for future reference
APPROPRIATE USE:
-This appliance is intended to be used in household and
similar applications such as:
› Staff kitchen areas in shops, offices and other
working environments.
› Farm Houses.
› By clients in hotels, motels and other residential
type environments.
› Bed and breakfast type environments.
7Instruction manual TEL900Please keep this instruction manual for future reference
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please recycle where
facilities exist. Check with your Local Authority or retailer for recycling advice. This appliance is
marked according to the European directive on Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be caused by
inappropriate waste handling of this product. The symbol on the product indicates that this
product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. Disposal must be carried
out in accordance with local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this product, please
contact your local council, your household waste disposal service or the retailer where you
purchased the product.
WARRANTY
Your new appliance is covered by warranty. The warranty card is enclosed - if it is missing, you
must provide the following information to your retailer in order to receive a replacement: date of
purchase, model and serial number. Registration can also be completed online by visiting
www.caple.co.uk.
Ensure you keep your warranty card safe, you may need to show it to Caple Service together with
proof of purchase. If you fail to show your warranty card you will incur all repair charges.
Spare parts are only available from Caple Service and spare parts authorised centres.
CE DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all applicable
legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC).
8Instruction manual TEL900 Please keep this instruction manual for future reference
UKCA DECLARATIONS OF CONFORMITY
This appliance has been manufactured to the strictest standards and complies with all
applicable legislation.
TECHNICAL FICHE
This appliance conforms to all current and applicable energy regulations. To view the Technical
Fiche that supports the energy labelling data, please visit the product page on our
website www.caple.co.uk.
9Instruction manual TEL900Please keep this instruction manual for future reference
INSTALLATION
This appliance can be used in recirculation mode only. In recirculation mode the air and fumes
conveyed by the appliance are cleaned by both a grease filter and an active charcoal filter, and
then released back into the room.
Prior to installation, make sure that the packaging is intact and all the parts are unbroken,
otherwise stop the installation and contact your retailer. The manufacturer is not responsible for
damages caused by material handling or product installation.
Before installing the appliance read all these instructions carefully.
WARNING:
This product must be installed by at least 2 people.
Start by removing the parts from the packaging and lay it on a suitable surface such as a soft
material such as sponge or fabric to protect the surface of the hood.
NOTE:
The following instructions are for installing the appliance only. If installing the appliance with
the TEL900/SHELF unit (sold separately), follow the installation instructions in ‘TEL900/SHELF’.
10 Instruction manual TEL900 Please keep this instruction manual for future reference
WHAT’S IN THE BOX
WHAT’S IN THE BOX
4.8 x 38 (x10) = BM4 x 25 (x4) = EØ8 (x10) = AM4 (x4) = F3.5 x 6.4 (x10) = DØ12 x 18 (x6) = G (x8) = O(x4) = L(x2) = M(x2) = N(x4) = Q(x2) = R(x2) = S
(
x1) = PM4 x 10 (x24) = H(x1) = X4 x 16 (x12) = I
