Canon Pixma Pro9500 Series Manuel utilisateur

Install Easy-PhotoPrint Pro 3

Digital Photo Professional 4

Adobe Photoshop CS/CS2 8

Easy-PhotoPrint Pro 9–10

11–12

Print RAW images after transferring them directly to Easy-PhotoPrint Pro 5

Convert RAW images to TIFF or JPEG and save them to transfer directly to Adobe®Photoshop®CS/CS2 6

Print faithfully to the characteristics of "portrait" or "landscape" in the Picture Style

Accurately print Adobe®RGB (1998) color space

Create your favorite picture while adjusting the image for printing

Print images according to your preference for a photograph, based on memory colors. 14

Print color data in highly expressive black and white gradations without color shift

Print data in your desired colors using Grayscale mode in the Picture Style (Toning effect(None)).

Print data using a filter effect in your desired colors,

using Grayscale mode in the Picture Style (Toning effect(None)).

15–16

Printing 24-26

Sheet Printing Paper Dimensions 28-29

Use Grayscale mode in the Picture Style to print image data using preferred tones,

such as with sepia, with the colors as they are (Toning effect(On)).

RAW Image Adjustment and Picture Style settings

Scan film, then open scanned data using Adobe Photoshop CS/CS2

Add further retouches, then print (Transfer image data directly to Easy-PhotoPrint Pro)

Freely customize colors in PIXMA Pro9500/Pro9000

Monochrome mode

Enable ICC Profile

Linear Tone

Photo Color

Printing B/W photographs as beautiful artworks 19-22

Getting the right margin

for your photographs

Check "Grayscale Photo"

Print with the Color Mode

Contents

Photo printing work-flow using Easy-PhotoPrint Pro

Overview of the Easy-PhotoPrint Pro 1

35 mm film single-lens reflex

+ scanner

Canon Inc.

Digital Photo Professional Ver.2.1

Easy-PhotoPrint Pro

Adobe®Photoshop®CS/CS2

Easy-PhotoPrint Pro Version 1.0

English Version 0.922005

Tutorial

Color mode

Overview

of the Easy-PhotoPrint Pro

Comfortable, and Easy Photograph Production using the Easy-PhotoPrint Pro

Easy-PhotoPrint Pro is plug-in software for Professional Print.

This powerful software application will satisfy the needs of both professionals and

high-level amateurs by providing effective printing solutions.

PIXUS Pro9500 and Pro9000 professional photo printers support paper sizes larger than A3. These two printers, made

specifically to create photographic works of art, not only enable distinct expressiveness in the final printout, with long shelf-

life, but they also maximize that performance. This dedicated print software "Easy-PhotoPrint Pro" is bundled to make it easy

for anyone to use these products. That is the essence of the Easy-PhotoPrint Pro. Professionals and high-level amateurs,

including users of the EOS DIGITAL, alike will quickly recognize that the Easy-PhotoPrint Pro eliminates the troublesome and

complicated tasks associated with printing, and that they can easily print out photographs as beautiful as one can imagine.

Startup as plug-in software

Easy-PhotoPrint Pro starts up as a plug-in software program in a version later than Digital Photo Professional Ver.2.1 and in

Adobe®Photoshop®CS/CS2. It can directly hand-over image data. Then, after developing and retouching images, this

software application allows you to shift seamlessly and directly to the print work.

Solves problems associated with printing for users of Adobe Photoshop CS/CS2

Specifically, problems like "troublesome print size settings," "can't batch print multiple images," and "color management

settings are complex" are now in the past. Easy-PhotoPrint Pro solves these problems that users of the Adobe Photoshop

CS/CS2 often face when printing.

Faithfully reproduces the original colors found in EOS DIGITAL

Easy-PhotoPrint Pro correctly recognizes the color space information set by Digital Photo Professional or Adobe

Photoshop CS/CS2 and reflects that in the final print, to faithfully reproduce images captured by EOS DIGITAL on the PIXUS

Pro9500/Pro9000.

This not only faithfully reproduces the coloring of the picture style set by Digital Photo Professional, but it also prints with

the wide color space available in Adobe®RGB(1998).

New features perfect for creating photographs

Easy-PhotoPrint Pro is provided a whole range of new features developed based on EOS DIGITAL and Adobe Photoshop

CS/CS2 user work-flows. Specifically, this software offers users print modes to satisfy any user need. Users will

immediately find use for features like the "Linear Tone" mode that linearly applies adjustments made to images, or the

"Grayscale Photo" mode that prints authentic looking B/W photographs. Other features include independently setting the

color balance, brightness and contrast of the printer, and registering and calling these settings up.

Easy-PhotoPrint Pro makes it fun and easy to produce beautiful, high-quality photographs.

Shooting Retouch Images Set Printing Features Done

Can't Get Your Desired Results

Image Adjustments

on the Easy-PhotoPrint Pro

Color Balance

Brightness

Contrast

Printer Settings are Troublesome

If You Use the Easy-PhotoPrint Pro

Paper Sizes and Layouts are

Easy to Set

Color Management Settings are Easy

Settings for Beautiful B/W Output

are Easy

Batch Printing of Multiple Images

Adobe, Adobe Photoshop and Adobe RGB (1998) are either registered trademarks or trademarks of Adobe Systems Incorporated in the United States and/or other countries.

Photo printing work-flow

using Easy-PhotoPrint Pro

Digital single-lens reflex

RAW

photographs

JPEG

photographs

Monochrome Mode

Customize printing colors:

color balance, brightness, contrast

Adobe Photoshop CS/CS2

Retouching/image transfer

RAW Image Adjustment / Picture Style settings

Digital Photo Professional

Color data Monochrome

data

Printing

Color Mode

Image transfer

Customize printing colors:

color balance, brightness, contrast

P23

P15

P17

P18

P24

Registration and call up of settings

P27

35 mm film single-lens reflex

Scanner

Easy-PhotoPrint Pro

Plug-in

Seamless linked printing

Create your favorite picture

while adjusting

the image for printing

Enable ICC Profile

Linear Tone Photo Color

Color Management

P11

P13

P14

P15

Convert/Save

RAW images to TIFF or JPEG

Print color data

in highly expressive

black and white

gradations

without color shift

Print images according to

your preference

for a photograph,

based on memory colors.

Print faithfully to the

characteristics of "portrait" or

"landscape" in the Picture Style

Accurately print Adobe

RGB

color space

P19

Print data

in your desired colors

using Grayscale mode

in the Picture Style.

Use Grayscale mode

in the Picture Style

to print image data

using preferred tones,

such as with sepia,

with the colors as they are.

Print data

using a filter effect

in your desired colors,

using Grayscale mode

in the Picture Style.

Printing

B/W photographs as

beautiful artworks

With only four easy clicks, you can plug in to and install Digital Photo

Professional and Adobe Photoshop CS/CS2.

After installation, Easy-PhotoPrint Pro is started from the screen below of Digital Photo Professional Ver.2.1

or Adobe Photoshop CS/CS2.

Install Easy-PhotoPrint Pro

Digital Photo Professional Ver.2.1 Adobe Photoshop CS/CS2

Select[File] [Link printing with Canon printer]

[Print with Easy-PhotoPrint Pro].

Select[File] [Automate]

[Easy-PhotoPrint Pro].

Image adjustment

Picture Style

Adjust RAW images

Digital Photo Professional (bundled with the EOS Digital cameras) is

software that is provided a high-speed RAW developing process, and image

adjusting function that realize a working environment suitable for a

professional work-flow. This includes an editing screen that allows high-

speed previews and multiple image display, and a comparison function

allowing the photographer to compare images before and after adjustments

have been made.

Digital Photo Professional

RAW Image Adjustment and Picture Style settings

Picture Style

Digital Photo Professional Ver.2.1 uses Picture Style to adjust RAW images.

This allows the photographer to reset Picture Styles for RAW images of EOS-

1D Mark II N/EOS 5D/EOS 30D, and to reflect preferred Picture Styles onto

RAW images captured by an EOS DIGITAL that is not provided with the Picture

Style function. This also allows making adjustments of hue, saturation etc.

Digital Photo Professional adjusts RAW

images and saves them as recipes in

separate files.

Digital

Photo Professional

Ver.2.1

RAW

RAW photographs

Set to "Monochrome" in Picture Style

While this can set images to general monochrome, it also enables the user

to apply filter effects of yellow, orange, red and green to the images.

Additionally, using the toning effect allows you to change images into a

monotone in such as sepia and blue.

RAW image print

Digital Photo Professional

Print RAW images after transferring them directly to Easy-PhotoPrint Pro

Digital

Photo Professional

Ver.2.1

Easy-PhotoPrint Pro

Digital Photo Professional Ver.2.1

RAW

Digital Photo Professional and Easy-PhotoPrint Pro,

Linking these enables printing of RAW images.

To print data of images photographed in RAW format, I have to develop the

images, and then convert them to TIFF or JPEG. So, it takes a lot of effort, and is

quite a bother." Digital Photo Professional and Easy-PhotoPrint Pro will change

all that. By linking these two applications together, you can print RAW images

using PIXMA. This takes away the trouble of converting original data to TIFF or

JPEG images and saving them to print by another application. Furthermore,

RAW images can be transferred directly from Digital Photo Professional Ver.2.1

to Easy-PhotoPrint Pro with one click, without having to be saved.

RAW image

transfer

RAW image transfer

Easy-PhotoPrint Pro

RAW

Digital Photo Professional

Convert RAW images to TIFF or JPEG and save them to

transfer directly to Adobe Photoshop CS/CS2

Adobe Photoshop

CS/CS2

JPEG 8/16bit

TIFF

JPEG 8/16bit

TIFF

Image data

transfer

Digital

Photo Professional

Ver.2.1

Adobe Photoshop CS2

Digital Photo Professional Ver.2.1

RAW

Convert/Save

Retouch using Adobe Photoshop CS/CS2,

then convert RAW images to TIFF or JPEG and save them.

Photographers that want to make further, more detailed retouches using

Adobe Photoshop CS/CS2, use Digital PhotoProfessional to adjust the RAW

images, then convert them to JPEG or 8/16 bit TIFF format for saving. Select

[Convert and save...] from the [File] to develop images one at a time, or select

[Batch process...] to develop a number of images all at once.

Transfer converted and saved RAW images to

Adobe Photoshop CS/CS2

Digital Photo Professional enables transferring files converted to JPEG or

8/16 bit TIFF format to Adobe Photoshop CS/CS2. Select the image, then

simply click [Transfer to Photoshop] in the [Tools] menu. This offers a simple

way to automatically transfer images.

Film photographs

When printing images captured by a standard film camera, use a scanner to

load image data to Easy-PhotoPrint Pro via Adobe Photoshop CS/CS2.

If using CanoScan9950F, ScanGear CS starts up by selecting [CanoScan9950F]

from [Import] in the [File] menu of Adobe Photoshop CS/CS2. Select source

(negative or positive film), and click the preview button to check the image.

Then, click the scan button to scan the image. The scanned image will open in

Adobe Photoshop CS/CS2.

(See the following page for details on how to transfer images from Adobe

Photoshop CS/CS2 to Easy-PhotoPrint Pro.)

35 mm film single-lens reflex + scanner

Scan film, then open scanned data using Adobe Photoshop CS/CS2

Scan

EPS PSDJPEG 8/16bit

TIFF

Adobe Photoshop

CS/CS2

EPS PSDJPEG 8/16bit

TIFF

Adobe Photoshop CS2

ScanGear CS

Other

RGB

formats

Other

RGB

formats

Adobe Photoshop CS/CS2

Add further retouches, then print

(Transfer image data directly to Easy-PhotoPrint Pro)

Photoshop®

CS/CS2

EPS PSDJPEG 8/16bit

TIFF

EPS PSDJPEG 8/16bit

TIFF

Images are displayed in the order in which the images were created

using Adobe Photoshop CS/CS2.

All images are set to print one-at-a-time in default.

Start Easy-PhotoPrint Pro plug-ins

from Adobe Photoshop CS/CS2

Transfer images retouched using Adobe

Photoshop CS/CS2 to Easy-PhotoPrint Pro.

This offers seamless transfers simply by

clicking [Automate] in the [File] menu in

Adobe Photoshop CS/CS2, then [Easy-

PhotoPrint Pro]. Then, shift to your print

work. This easy-to-use application is like

Adobe Photoshop CS/CS2's printing

function has been upgraded.

Batch transfer images opened

using Adobe Photoshop CS/CS2 to Easy-PhotoPrint Pro

You can batch-transfer up to 400 images for display. Furthermore, it handles all file

formats (PSD, EPS etc.) supported by Adobe Photoshop CS/CS2 in the RGB format.

Plug-in

startup

Other

RGB

formats

Other

RGB

formats

Easy print settings for simple, carefree printing work

When printing from Adobe Photoshop, there were many complicated tasks like

making complex settings for print layouts and color management. Another problem

was that multiple printings could not be performed at one time. Easy-PhotoPrint

Pro solves all those issues. All print-related tasks for Adobe Photoshop CS/CS2

users are now uniformly controllable with Easy-PhotoPrint Pro, a unified

management solution.

Easy-PhotoPrint Pro

Freely customize colors in PIXMA Pro9500/Pro9000

Independently set and register color settings

in the printer driver

With Easy-PhotoPrint Pro, colors can be freely adjusted in the PIXMA

Pro9500/Pro9000. Adjustments include Color Balance, Brightness and

Contrast. This new system reflects the user's intended coloring, by allowing

color settings for specific types of art paper, or creating colors finely-tuned

for each object of shooting.

Color Balance Adjustment

Prints samples where yellow, red, magenta,

blue, cyan and green are varied based on the

original image (shown in the red frame). This

allows users to select their most preferred

coloring by checking the actual printout,

including slight color differences.

Users that want to make even more detailed

changes to the color balance can use the

function that prints samples where yellow,

red, magenta, blue, cyan and green can be

individually varied. When wanting to

increase red, choose to print in Direction R

and up to 48 simulated images are output.

Original image is at the bottom left.

Print All Directions Single Hue

(Example: print in Direction R)

The cyan, magenta and yellow parameter values are

printed out right below each image. That way, users

can simply type in those values to return the color

balance to their preferred one.

InputInput

Color Balance Adjustment

1. Slide bars

For users who have specific target/intented colors in mind, slide bars are

provided to make fine adjustments to cyan, magenta and yellow values.

2. Pattern Print

For users that are not quite sure which color value to increase or decrease,

or would like to preview the changes first on the actual printout, "Pattern

Print" function is offered. This automatically creates simulated images with

varying color balance as specified by the user, and prints out the results on a

sheet of paper. Users can then determine color balance after previewing

that printout. Users can also keep the printed sheet for another print

opportunity, so that they can reproduce the same settings as a basis for a

new color adjustment.

Easy-PhotoPrint Pro

Autres manuels pour Pixma Pro9500 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Logiciel

Canon

Canon ImageWare Manuel utilisateur

Canon

Canon VIXIA HR10 Manuel utilisateur

Canon

Canon ELURA 100 - Camcorder - 1.3 MP Manuel utilisateur

Canon

Canon EOS 5D Mark II Manuel utilisateur

Canon

Canon UFR II Driver Manuel d'installation et d'exploitation

Canon

Canon CanoScan D646U Manuel utilisateur

Canon

Canon DC22 - 2.2MP DVD Camcorder Manuel utilisateur

Canon

Canon PowerShot A460 Mode d’emploi

Canon

Canon Vixia HG21 Manuel utilisateur

Canon

Canon PowerShot A410 Instructions de montage

Canon

Canon VIXIA HF M32 Manuel utilisateur

Canon

Canon 40D - EOS 40D DSLR Guide de sécurité

Canon

Canon WebView LivescopeMV Manuel utilisateur

Canon

Canon FAXPHONE L80 Guide de sécurité

Canon

Canon EOS Rebel T3 18-55mm IS II Kit Manuel utilisateur

Canon

Canon Powershot S2 IS - Powershot S2 IS 5MP Digital... Manuel utilisateur

Canon

Canon Powershot A3100 IS Guide de démarrage rapide

Canon

Canon HV10 - Camcorder - 1080i Manuel utilisateur

Canon

Canon HV10 - Camcorder - 1080i Manuel utilisateur

Canon

Canon CanoScan D646U Manuel utilisateur

Canon

Canon EOS 7D Mark II (G) Manuel utilisateur

Canon

Canon FS10 Manuel utilisateur

Canon

Canon REALIS WUX10 MARK II D Manuel utilisateur

Canon

Canon 3421B001 - FS200 32GB Flash Memory Camcorder Manuel utilisateur

Manuels Logiciel populaires d'autres marques

COMPRO

COMPRO COMPROFM Manuel utilisateur

Muratec

Muratec OFFICEBRIDGE ONLINE Manuel utilisateur

Oracle

Oracle Contact Center Anywhere 8.1 Manuel utilisateur

Adobe

Adobe 65007312 - Photoshop Lightroom Manuel

Avaya

Avaya NULL One-X for RIM Blackberry Manuel utilisateur

HP ProLiant BL420c Manuel utilisateur

PS Audio

PS Audio PowerPlay Manuel du propriétaire

Brady

Brady LOCKOUT PRO 3.0 Manuel de service

Avaya

Avaya Interaction Center Manuel utilisateur

Texas Instruments

Texas Instruments TI-83 Plus Silver Edition Manuel

Novell

Novell GROUPWISE 8 - INTERNET AGENT Manuel utilisateur

Oracle

Oracle Application 9i Manuel utilisateur

Acer

Acer RDM Manuel utilisateur

Samsung

Samsung Auto Backup Manuel utilisateur

Polycom

Polycom Vortex EF2201 Instructions d'installation et d'utilisation

Brocade Communications Systems

Brocade Communications Systems Brocade 8/12c Manuel utilisateur

Novell

Novell SP2 - S Mode d’emploi

Lexmark

Lexmark Apps Manuel de service
