Canon MX360 Seires Manuel utilisateur

How to Use This Manual

Printing This Manual

MC-5320-V1.00

Basic Guide

Describes the summary of

this product.

Advanced Guide

Describes the detailed

function of this product.

Troubleshooting

Seite 1 von 922 SeitenCanon MX360 series On-screen Manual

How to Use This Manual

Printing This Manual

MP-5287-V1.00

Advanced Guide

Contents

Overview of the Machine

Main Components

How to Navigate Menus on the LCD

Preparing for Faxing

Confirming the Telephone Line Connection

Specifying the Basic Settings for Faxing

Setting the Receive Mode

Faxing

Sending Faxes

Using Various Sending Functions

Receiving Faxes

Using Various Receiving Functions

Using Useful Fax Functions

Copying

Making Copies

Using Various Copy Functions

Scanning

Saving Scanned Data to the Computer

Using Various Scan Functions

Printing from Your Computer

Printing Photos (Easy-PhotoPrint EX)

Printing Documents

Printing Web Pages (Easy-WebPrint EX)

Starting Various Software Applications

Other Usages

Printing the Template Forms such as Notebook

Paper

Printing Photos Directly from Your Digital

Camera or Mobile Phone

Machine Settings

Loading Paper / Originals

Loading Paper

Loading Originals

Routine Maintenance

When Printing Becomes Faint or Colors Are

Incorrect

Replacing a FINE Cartridge

Cleaning the Paper Feed Roller

Appendix

Legal Limitations on Use of Your Product and

Use of Images

Tips on How to Use Your Machine

Seite 2 von 922 SeitenMX360 series Basic Guide

Advanced Guide

Troubleshooting

Contents

> Overview of the Machine

Overview of the Machine

This section shows the component names of the machine and describes the basic operations you need

to know before using it.

Main Components

Front View

Rear View

Inside View

Operation Panel

How to Navigate Menus on the LCD

Basic Operation in Each Mode

Selecting Mode

Selecting Menu Item from Specified Mode

Basic Operation on the Setting Options

Page top

Seite 3 von 922 SeitenOverview of the Machine

Advanced Guide

Troubleshooting

Contents >

Overview of the Machine

> Main Components

C001

Main Components

Front View

Rear View

Inside View

Operation Panel

Front View

(1)

ADF (Auto Document Feeder)

Load a document to copy, scan, or fax. The documents loaded in the Document Tray are scanned

automatically one sheet at a time.

See

Loading Originals in the ADF

(2)

Document Feeder Cover

Open when clearing jammed documents.

(3)

Document Guides

Adjust these guides to match the width of document in the ADF.

(4)

Document Tray

Open to load a document in the ADF. You can load two or more sheets of document of the same size and

thickness. Load the document with the side you want to scan facing up.

(5)

Document Output Slot

Documents scanned from the ADF are delivered here.

(6)

Paper Support

Supports paper loaded in the Rear Tray. Open it to load paper.

(7)

Rear Tray

Load various sizes or types of paper which you can use on the machine. Two or more sheets of the same

size and type of paper can be loaded at the same time, and fed automatically one sheet at a time.

See

Loading Paper

(8)

Paper Guides

Slide to align with both sides of the paper stack.

(9)

Document Cover

Open to load an original on the Platen Glass.

(10)

Paper Output Tray

Seite von 922 SeitenMain Components

Opens automatically when printing or copying starts and printed paper is ejected.

(11)

Operation Panel

Use to change the settings of the machine or to operate it.

See

Operation Panel

(12) Scanning Unit Detection Button

Locks the Scanning Unit (Cover) while the Document Cover is open. This button is pressed down when the

Document Cover is closed, so that you can open the Scanning Unit (Cover). (You do not need to touch this

button.)

For information on the Scanning Unit (Cover), see Scanning Unit (Cover) .

(13)

Direct Print Port

Connect a PictBridge compliant device such as a digital camera or the optional Bluetooth Unit BU-30* to print

directly.

See

Printing Photos Directly from Your Digital Camera or Mobile Phone

You can also insert a USB flash drive to this port.

Refer to the on-screen manual:

Advanced Guide

* The Bluetooth Unit is not available in some countries or regions depending on the local laws and

regulations. For details, contact the service center.

Warning

Do not connect any equipment other than PictBridge compliant devices, the optional

Bluetooth Unit BU-30, and USB flash drives to the Direct Print Port of the machine. This

may cause fire, electric shock, or damage to the machine.

Important

Do not touch the metal casing.

(14) Platen Glass

Load an original to copy, scan, or fax.

Rear View

Seite 5 von 922 SeitenMain Components

(15)

External Device Jack

Connect an external device such as telephone or answering machine.

(16)

Telephone Line Jack

Connect the telephone line.

(17)

USB Port

Plug in the USB cable to connect the machine with a computer.

Important

Do not plug in or unplug the USB cable while the machine is printing or scanning originals

with the computer.

(18)

Power Cord Connector

Plug in the supplied power cord.

Important

Do not touch the metal casing.

Inside View

(19)

Ink Cartridge Locking Covers

Lock the FINE Cartridges into place.

(20)

FINE Cartridge Holder

Install the FINE Cartridges.

The Color FINE Cartridge should be installed into the left slot ( ) and the Black FINE Cartridge should be

Seite 6 von 922 SeitenMain Components

installed into the right slot (

(21)

FINE Cartridges (Ink Cartridges)

A replaceable cartridge that is integrated with Print Head and ink tank.

Note

For details on installing the FINE Cartridges, refer to the printed manual:

Getting Started

(22)

Scanning Unit (Cover)

Scans originals. Open it to replace the FINE Cartridges or remove jammed paper inside the machine. When

opening the Scanning Unit (Cover), lift it with the Document Cover closed.

(23) Scanning Unit Support

Holds the Scanning Unit (Cover) while it is open.

Important

The area (A) indicated in the figure below may be splattered with ink. It does not affect the

performance of the machine.

Do not touch the area (A). The machine may not print properly if you touch it.

Operation Panel

(1)

ON button (POWER lamp)

Turns the power on or off. Lights or flashes green to indicate the power status. Before turning on the

power, make sure that the Document Cover is closed.

Important

Disconnecting the power plug

When disconnecting the power plug after turning off the power, be sure to confirm that

the

POWER

lamp is not lit. If the power plug is disconnected from the wall outlet before the

POWER

lamp is turned off, the machine may become unable to print properly since the

Print Head is not protected.

If the power plug is disconnected, the date/time settings will be reset and all documents

stored in the machine's memory will be lost. Send or print a necessary document, or save

it on the USB flash drive before disconnecting the power plug.

Note

The machine cannot receive faxes when the power is turned off.

The power cannot be turned off while the machine is sending or receiving a fax, or when

there are unsent faxes in the machine's memory.

Seite 7 von 922 SeitenMain Components

(2)

FAX button

Switches the machine to the fax mode.

See

Selecting Mode

(3)

COPY button

Switches the machine to the copy mode.

See

Selecting Mode

(4)

SCAN button

Switches the machine to the scan mode.

See

Selecting Mode

(5)

Menu button

Displays the menu screen.

See

Selecting Menu Item from Specified Mode

(6)

Settings button

Used to change settings on the paper used for printing in the copy or fax mode, or scanning options for

saving scanned data on a computer or a USB flash drive in the scan mode.

See

Basic Operation on the Setting Options .

(7)

LCD (Liquid Crystal Display)

Displays messages, menu items, and the operational status.

Note

The LCD will turn off if the machine is not operated for about 5 minutes. To restore the

display, press any button except the

button or perform the print operation. The display

will be also restored when receiving faxes.

(8)

Numeric buttons

Used to enter numerical values such as the number of copies, as well as fax/telephone numbers and

characters.

(9)

Redial/Pause button

Used to select a number from those recently dialed with the Numeric buttons to redial. You can also use

this button to enter pause time between or after numbers when dialing or registering numbers for example

international calls.

(10) Coded Dial button

Used when sending a fax with a coded speed dial. Pressing this button displays the search coded speed

dial screen or the search telephone number screen.

You can switch screens by pressing the

button.

In the search coded speed dial screen, enter a two-digit code. The recipient with that code will appear for

selection. You can also use the

(-) or

(+) button to select a desired recipient.

In the search telephone number screen, enter the first letter of a registered name. The first recipient with a

name beginning with that letter will appear for selection. Use the

(-) or

(+) button to select the

desired recipient from the search results.

(11) Black button

Starts to make black & white copy, scan, fax transmission, etc.

(12) Color button

Starts to make color copy, scan, fax transmission, etc.

(13) Stop button

Cancels operation when copy, print, scan, or fax transmission/reception job is in progress.

(14) Hook button

Enables you to dial using the Numeric buttons on the machine without picking up the handset. This button is

also used when using an information service, etc.

(15)

Tone button

Switches to tone dialing temporarily if your machine is connected to a rotary pulse line. This button is also

used to change the input mode when entering characters.

(16)

OK button

Finalizes the selection of a menu or setting item.

Resolves an error when printing is in progress or resumes the machine's normal operation after removing

Seite 8 von 922 SeitenMain Components

jammed paper or to eject documents remaining in the ADF.

(17)

(-)

(+) buttons

Used to increase/decrease a setting value such as the number of copies, and select a menu item or setting

option.

When entering the recipient's fax/telephone number for dialing, the

(-) button cancels the entered

character, and the

(+) button inserts a space between characters.

When entering characters such as a name or a fax/telephone number for registration, the

(-) or

(+)

button moves the cursor.

(18)

Back button

Returns the LCD to the previous screen. This button is also used to delete a character under the cursor

when entering characters such as a name for registration.

(19)

FAX Quality button

Selects the scan contrast and resolution of the fax you are sending.

(20)

Alarm lamp

Lights or flashes orange when an error occurs, such as paper-out or ink-out.

(21)

FAX Memory lamp

Lights when there are received or unsent documents stored in the machine's memory.

Note

The machine makes the beep sound when pressing buttons on the Operation Panel.

To change the beep volume, see Machine Settings

Page top

Seite 9 von 922 SeitenMain Components

Advanced Guide

Troubleshooting

Contents >

Overview of the Machine

> How to Navigate Menus on the LCD

C002

How to Navigate Menus on the LCD

You can use the machine to make copies, send/receive faxes, or scan originals without a computer. You

can also make good use of the various functions of the machine with menus and setting items displayed

on the LCD.

This section describes the basic operation to change settings with menus displayed differently for each

mode and the

Settings button.

Basic Operation in Each Mode

Selecting Mode

Selecting Menu Item from Specified Mode

Basic Operation on the Setting Options

Basic Operation in Each Mode

Press the appropriate mode button (A) to switch the screen to the desired mode.

Then, use the

button (B) to select functions available in each mode.

To change settings on the paper used for printing in the copy or fax mode, or scanning options for saving

scanned data on a computer or a USB flash drive in the scan mode, press the

Settings button (C).

Note

Press the

button repeatedly until the desired menu appears. Use the

(-) or

(+) button

to select an item, and press the

button to finalize it.

Press the

Back

button to return the LCD to the previous screen.

For the listing of available menu items, see Selecting Menu Item from Specified Mode

To display Device settings, Maintenance, or Template print, press the

button repeatedly in

any mode.

Press the

Stop

button while any menu or setting item is being displayed to return to the standby

screen for the current mode.

Selecting Mode

Press the appropriate mode button to switch to the desired mode.

Switch to the copy mode.

You can select options such as Frame erase, 2-on-1 copy, and Collated copy in

the Special copy menu.

Switch to the fax mode.

You can perform operations such as printing a report/list, printing faxes saved on

the memory, and registering numbers as well as specify the receive mode in the

Fax settings menu.

Switch to the scan mode.

You can specify the place to save the scanned data in the Save to menu.

Selecting Menu Item from Specified Mode

Pressing the

button while in the copy standby screen cycles through the available menus in the

order shown below. You can use the (+) button to scroll through the menu selections.

The following lists of menu items will help you find an appropriate menu item for a specific function you

Seite 10 von 922 SeitenHow to Navigate Menus on the LCD

Table des matières

Autres manuels Canon Imprimante

Canon

Canon Selphy CP910 Manuel utilisateur

Canon

Canon Pixma TS8700 Series Guide de configuration

Canon

Canon TS3300 Series Guide de configuration

Canon

Canon PIXMA MP240 Manuel utilisateur

Canon

Canon iPF5000 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon BJC-3000 Series Manuel utilisateur

Canon

Canon imageClass LPB7100Cn Manuel utilisateur

Canon

Canon imagePROGRAF iPF6300S Manuel utilisateur

Canon

Canon PIXMA mini320 Series Manuel utilisateur

Canon

Canon PIXMA iX4000 Manuel utilisateur

Canon

Canon iX6500 Series Manuel utilisateur

Canon

Canon iPF8400SE imagePROGRAF Manuel utilisateur

Canon

Canon imageRUNNER 2630 Manuel utilisateur

Canon

Canon MP490 series Manuel utilisateur

Canon

Canon G1020 Series Guide de configuration

Canon

Canon Color Bubble Jet BJC-8200 Manuel utilisateur

Canon

Canon TS8200 Series Guide de configuration

Canon

Canon i850 Manuel utilisateur

Canon

Canon imagePROGRAF iPF770 Manuel utilisateur

Canon

Canon IX-R7000 Manuel utilisateur

Canon

Canon iPF655 - imagePROGRAF Color Inkjet Printer Manuel de référence

Canon

Canon GX7050 Manuel utilisateur

Canon

Canon Color Bubble Jet BJC-2000 Series Manuel utilisateur

Canon

Canon imageCLASS MF6500 Series Guide de sécurité

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
