Canon PIXMA G4010 Series Manuel utilisateur
Trưc tiên đc Thông tin an ton v quan trng
(ph lc).
Baca Keamanan dan Informasi Penting
(lampiran) terlebih dahulu.
Hưng dn bt đu
Mari Memulai
Read Safety and Important Information
(addendum) rst.
Getting Started
1
2
Lp đt My in .........................................................................................trang 1
Kt ni vi my tnh v smartphone/my tnh bng ................................ trang 4
Memasang Pencetak ......................................................................... halaman 1
Menghubungkan dengan Komputer dan Ponsel Pintar/Tablet .......... halaman 4
Cch gi My in Đon phim gii thch
.....................................................................................
......................................
Cara Memegang Pencetak Video Penjelasan
Installing the Printer ................................................................................. page 1
Connecting with Computer and Smartphone/Tablet ................................ page 4
How to Hold Printer Explanatory Movies
1
ENGLISH
1. Checking Included Items
□ Power cord
□ Safety and Important Information
□ Getting Started (this manual)
□ Setup CD-ROM for
Windows PC
□ Cartridge
□ Ink bottle
□ Modular cable
2. Removing Packing
Materials
1 Remove the packing materials (such as orange
tape) from outside the printer.
2 aOpen the scanning unit / cover.
bRemove the orange tape and the protective
material and discard them.
a
b
3. Installing the Cartridge
1 Open the cartridge locking cover.
2 Take out the C (color) cartridge from the package
and remove the label.
3 Remove the protective tape.
Do not touch.
4 Insert the C (color) cartridge on the left.
Do not bump it against the
surrounding parts.
5 Repeat steps 2 to 4 to insert the B (black)
cartridge on the right.
6 Close the cartridge locking cover and push it
down.
7 Press down both joint buttons.
2
4. Pouring Ink
This product requires careful handling of ink. Ink may
splatter when the ink tanks are lled with ink. If ink gets
on your clothes or belongings, it may not come off.
1 Open the ink tank cover.
2 Grab and remove the tank cap of the ink tank.
3 Hold the ink bottle upright and remove the bottle
cap.
4 Insert the nozzle of the ink bottle into the inlet and
stand the ink bottle upside down.
5 Pour all ink into the ink tank.
Conrm that the ink has been lled to the upper
limit line (A).
(A)
6 Replace the tank cap securely.
7 Close the ink tank cover.
8 Repeat steps 1 to 7 to pour all ink into the
corresponding ink tanks on the right according to
the label.
Conrm that the ink has been lled to the upper
limit line (A).
(A)
3
ENGLISH
9 Close the scanning unit / cover.
5. Turning on Printer
1 Connect the power cord.
Back
Do not connect any cables except the power cord
yet.
2 Press the ON button.
3 When the following screen appears, use the [
and ] buttons to select a language, and then
press the OK button.
4 If the following screen appears, select your country
or region, and then press the OK button.
5 Conrm that all the ink tanks have ink in them.
6 Select Yes with the [ and ] buttons, and then
press the OK button.
4
7-A. Connecting to Computer
macOSWindows
You need a connection setup for each computer. Proceed with the setup from step 1 for each computer.
1 Start the setup le for either method or method .
Downloading from the Internet
aOpen a web browser ( etc.) on your computer.
bInput the following URL and access the Canon
website.
cSelect Set Up.
dInput the model name of your printer and click OK.
You can select a model name from the list.
eClick Setup.
The procedures for Windows and macOS are shown
below. If you are using a computer with an OS other
than Windows or macOS, such as a Chrome OS, do
the setup according to the on-screen instructions.
fClick Download and download the setup le.
gExecute the downloaded le.
Proceed to step on the next page to
continue.
6. Preparing for Connection
1 Press the OK button.
Preparing the ink starts.
This takes about 5 to 6 minutes. Proceed to the next
step.
2 Check that the following screen appears.
From here on, proceed to a step according to how you use
the printer.
• To use the printer by connecting only to a computer
or both to a computer and smartphone
"7-A. Connecting to Computer"
• To use the printer by connecting only to a
smartphone
"7-B. Connecting to Smartphone" on page 6
To use the printer without connecting to
a computer or smartphone
aPress the Stop button on the printer.
bIn the connection method selection screen, use the
[and ] buttons to select Do not connect, and
then press the OK button.
cUse the [ and ] buttons to select Yes, and then
press the OK button.
dWait until the following screen appears.
The setup is now complete.
To continue fax setup, proceed to page
8.
5
ENGLISH
Using Setup CD-ROM (Windows Only)
aLoad the Setup CD-ROM in your computer.
■ When using Windows 10 or Windows 8.1:
bWhen the following message appears on the right
side of your computer screen, click it.
cIf the following screen appears, click Run
Msetup4.exe.
dIf the User Account Control dialog box appears,
click Yes.
When This Message Does Not Appear (or Has
Disappeared)
1. Click File Explorer on the taskbar.
or
2. Click This PC on the left side of the opened window.
3. Double-click the CD-ROM icon on the right side of
the window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
4. Proceed to step d.
■ When using Windows 7:
b When the AutoPlay screen appears, click Run
Msetup4.exe.
c If the User Account Control dialog box appears,
click Continue.
When AutoPlay Screen Does Not Appear
1. Click Computer from the start menu.
2. Double-click the CD-ROM icon on the right side of
the opened window.
If the contents of the CD-ROM appear, double-click
Msetup4.exe.
Proceed to step to continue.
2 Click Start Setup. If the following screen appears, click Exit.
Follow the on-screen
instructions to proceed
with the setup.
The setup is complete when the following screen appears on the printer's screen. You
can print from your computer.
To continue fax setup, proceed to page 8.
6
7-B. Connecting to Smartphone
iOS
Android
You need a connection setup for each smartphone. Proceed with the setup from step 1 for each smartphone.
Preparation
• Turn on Wi-Fi on your smartphone.
• If you have a wireless router, connect your smartphone to the wireless router you want to connect to the printer.
* For operations, refer to manuals of your smartphone and the wireless router or contact those manufacturers.
1 Install the application software Canon PRINT Inkjet/SELPHY in your smartphone.
: Search "Canon PRINT" in App Store.
: Search "Canon PRINT" in Google Play.
Or access the Canon website by scanning the QR code.
* You may not connect your smartphone to the Internet wirelessly during connecting the printer to the smartphone directly.
In that case, you may be charged depending on the contract with your service provider.
* Up to 5 devices can be connected to the printer via wireless LAN connection directly.
2 Check the display on the printer.
The screen turns off when no operation is made for about 10 minutes. Press one of the buttons on the operation
panel (except for the ON button) to display the screen.
a Does the following screen appear?
b Does (the printer is connected to the network) appear on the screen displayed by pressing the
Copy button?
aTap the installed application
software.
bFollow the on-screen instructions to register the
printer.
cMake sure that the right
screen appears.
The connection with your smartphone is
now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading
Paper" on page 8.
To continue fax setup, proceed to page
8.
Yes
No Yes (Proceed to .)
No (Proceed to .)
If appears, the printer cannot communicate by
wireless LAN connection. For details, access "http://ij.start.
canon" to see Frequently Asked Questions.
7
ENGLISH
Troubleshooting
Printer is not found from your smartphone.
aPress the Setup button on the printer. bUse the [ and ] buttons to select Wireless LAN
setup > Easy WL connect, and then press the
OK button.
cReturn to the operation of your smartphone.
Procedures below vary depending on iOS or Android. Select your operating system and proceed to its
procedure.
aTap Settings on your smartphone's home screen,
and tap Canon_ij_XXXX in the Wi-Fi settings.
If Canon_ij_XXXX does not appear on the list, see
"Troubleshooting" below to operate the printer, and
then repeat step a.
bTap the installed application software.
cFollow the on-screen instructions to register the
printer.
Follow the on-screen instructions to proceed
with the setup.
If you select Auto Select Conn. Method
(recommended) on the connection method
selecting screen, the appropriate connection
method is selected automatically depending on
your environment.
dMake sure that the following screen appears.
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
If a message saying "Printer is not registered.
Perform printer setup?" does not appear, see
"Troubleshooting" below to operate the printer, and
then wait for a while until the message appears.
Follow the on-screen instructions to proceed
with the setup.
• The appropriate connection method is selected
depending on your environment.
• If two printer names appear on the Register
Printer screen as shown below, select A.
A) G4010 series (xxx.xxx.xxx.xxx)
B) Direct-xxxx-G4010series
cMake sure that the following screen appears.
The connection with your smartphone is now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading Paper" on page 8.
To continue fax setup, proceed to page 8.
8
1 Open the paper support and the paper support
extension.
2 Slide the right paper guide to the end.
3 Load paper with the print side facing up.
4 Slide the right paper guide to align it with the
side of the paper stack.
5 aPull out the paper output tray.
bOpen the output tray extension.
a
b
Loading Paper
■ Opening from the website
aAccess the Canon website.
bSelect Set Up.
cWhen the screen for selecting a model appears, input
the model name of your printer.
dSelect Making Fax Ready for Use.
■ Opening from the manual installed into your computer
The following is an example using Windows 10.
aClick the Start button.
bClick All apps > Canon G4010 series On-screen
Manual in this order, and then open the Basic
Manual.
cSelect Setting Up the FAX.
Using Fax Function
Before using the fax function, refer to Setting Up the FAX to set up the fax function of your printer. You can refer to
Setting Up the FAX by either of the following methods.
Table des matières
Langues :
Autres manuels Canon Imprimante
Canon
Canon iP90 - PIXMA Color Inkjet Printer Manuel utilisateur
Canon
Canon NP-6020 Manuel utilisateur
Canon
Canon iR2016 Series Manuel utilisateur
Canon
Canon iR3570 Series Manuel utilisateur
Canon
Canon imagePRESS Series Manuel utilisateur
Canon
Canon MAXIFY MB2320 Mode d’emploi
Canon
Canon TS8350 Series Guide de configuration
Canon
Canon Pixma TR7600 Series Guide de configuration
Canon
Canon imageRUNNER 2745i Manuel utilisateur
Canon
Canon imagePROGRAF iPF8400S Manuel utilisateur
Canon
Canon Color Bubble Jet BJC-8200 Manuel utilisateur
Canon
Canon PIXMA G1410 Series Manuel utilisateur
Canon
Canon TR8500 Series Manuel utilisateur
Canon
Canon iP1700 - PIXMA Color Inkjet Printer Manuel utilisateur
Canon
Canon Pixma Pro 9000 Mark II series Manuel utilisateur
Canon
Canon imageRUNNER 2630 Manuel utilisateur
Canon
Canon iR2230 Manuel utilisateur
Canon
Canon CX-G2400 Instructions de montage
Canon
Canon Pixma TR150 Manuel utilisateur
Canon
Canon imagePROGRAF iPF6400 Manuel utilisateur
Manuels Imprimante populaires d'autres marques
Ricoh
Ricoh Aficio AP400 Manuel utilisateur
BIXOLON
BIXOLON SRP-352plusV Manuel utilisateur
Epson
Epson Stylus Photo PX700W Instructions de montage
Ricoh
Ricoh SP204SF Manuel utilisateur
Star Micronics
Star Micronics futurePRNT TSP100 Manuel utilisateur
Epson
Epson TM-TM88V-i Manuel d'utilisation et d'entretien
