Canon MG8100 series Manuel utilisateur

How to Use This Manual

Printing This Manual

MC-5160-V1.00

Basic Guide

Describes the summary of

this product.

Advanced Guide

Describes the detailed

function of this product.

Troubleshooting

Page 1 of 1135 pagesCanon MG8100 series On-screen Manual

How to Use This Manual

Printing This Manual

About Disc Label Printing

MP-5035-V1.00

Advanced Guide

Contents

Overview of the Machine

Main Components

How to Navigate Menus on the LCD

Printing Photos

Printing Photos Saved on the Memory Card /

USB Flash Drive

Using Various Functions

Inserting the Memory Card

Inserting the USB Flash Drive

Copying

Making Copies

Using Various Copy Functions

Reprinting Photos from Printed Photos

Reprinting Printed Photos

Printing Photos from Films

Loading the Films

Using Various Functions

Scanning

Saving Scanned Data to the Computer

Using Various Scan Functions

Printing from Your Computer

Printing Photos (Easy-PhotoPrint EX)

Printing Documents

Printing Web Pages (Easy-WebPrint EX)

Starting Various Software Applications

Other Usages

Printing PDF Files Saved on the Memory Card /

USB Flash Drive

Printing the Template Forms such as Notebook

Paper

Printing Photos Directly from Your Digital

Camera or Mobile Phone

Machine Settings

Loading Paper / Originals

Loading Paper

Loading Originals

Routine Maintenance

Replacing an Ink Tank

When Printing Becomes Faint or Colors Are

Incorrect

Cleaning the Paper Feed Roller

Cleaning the Pad in the Cassette

Appendix

Legal Limitations on Use of Your Product and

Use of Images

Tips on How to Use Your Machine

Page 2 of 1135 pagesMG8100 series Basic Guide

Advanced Guide Troubleshooting

Contents > Overview of the Machine

Overview of the Machine

This section shows the component names of the machine and describes the basic operations you need

to know before using it.

Main Components

Front View

Rear View

Inside View

Operation Panel

How to Navigate Menus on the LCD

Using the Operation Panel

Selecting Menus on the HOME Screen

Selecting a Menu or Setting Item

Other Operations

Page top

Page 3 of 1135 pagesOverview of t e Mac ine

Advanced Guide Troubleshooting

Contents > Overview of the Machine > Main Components

C001

Main Components

Front View

Rear View

Inside View

Operation Panel

Front View

(1) Document Cover

Open to load an original on the Platen Glass.

(2) Paper Support

Raise and tip back to load paper in the Rear Tray.

(3) Rear Tray

Load photo paper or envelopes which you can use on the machine. Two or more sheets of the same size

and type of paper can be loaded at the same time, and fed automatically one sheet at a time.

See Loading Paper .

(4) Paper Guides

Slide to align with both sides of the paper stack.

(5) Operation Panel

Use to change the settings of the machine or to operate it.

See Operation Panel .

(6) Paper Output Tray

Opens automatically when printing or copying starts and printed paper is ejected.

(7) Output Tray Extension

Open to support the printouts. Open it when printing or copying.

Page 4 of 1135 pagesMain Components

(8) Scanner Lock Switch

Locks the scanner to prevent sliding or damage when transporting the machine. Be sure to unlock it before

turning the power on.

(9) Platen Glass

Load an original to copy or scan.

(10) FAU (Film Adapter Unit) Protective Sheet

Protects the FAU lamp and the Platen Glass. The Film Guide used for scanning film can be stored behind the

FAU Protective Sheet.

See Loading the Films .

(11) FAU (Film Adapter Unit) lamp

Lights up the film when scanning films.

(12) Infrared Port

Use this port to print from a mobile phone with wireless infrared communication.

See Printing Photos from a Wireless Communication Device .

(13) Direct Print Port

Connect a PictBridge compliant device such as a digital camera or the optional Bluetooth Unit BU-30* to print

directly.

See Printing Photos Directly from Your Digital Camera or Mobile Phone.

You can also insert a USB flash drive to this port.

See Inserting the USB Flash Drive .

* The Bluetooth Unit is not available in some countries or regions depending on the local laws and

regulations. For details, contact the service center.

Warning

Do not connect any equipment other than PictBridge compliant devices, the optional

Bluetooth Unit BU-30, and USB flash drives to the Direct Print Port of the machine. This

may cause fire, electric shock, or damage to the machine.

Important

Do not touch the metal casing.

Do not use the USB cable longer than around 10 feet / 3 meters to connect any PictBridge

compliant device to the machine since it may affect the operation of other peripheral

devices.

(14) Cassette

Load A4, B5, A5, or Letter-sized plain paper and insert it into the machine. Two or more sheets of the same

size of plain paper can be loaded at the same time, and fed automatically one sheet at a time.

See Loading Paper .

Page 5 of 1135 pagesMain Components

Rear View

(15) Wired LAN Connector

Plug in the LAN cable to connect the machine to a LAN.

Important

Do not touch the metal casing.

Note

Remove the LAN connector cap before connecting the LAN cable.

(16) USB Port

Plug in the USB cable to connect the machine with a computer.

Important

Do not touch the metal casing.

Do not plug in or unplug the USB cable while the machine is printing or scanning originals

with the computer.

(17) Rear Cover

Detach to remove jammed paper.

(18) Power Cord Connector

Plug in the supplied power cord.

Inside View

(19) Ink lamps

Light or flash red to indicate the ink tank status.

See Checking the Ink Status .

Page 6 of 1135 pagesMain Components

(20) Print Head Holder

Install the Print Head.

(21) Print Head Lock Lever

Locks the Print Head into place.

Important

Do not raise this lever after installing the Print Head.

(22) Scanning Unit (Cover)

Scans originals. Open it to replace ink tanks, to check ink lamps, or to remove jammed paper inside the

machine. When opening the Scanning Unit (Cover), lift it with the Document Cover closed.

(23) Access lamp

Lights or flashes to indicate the memory card status.

See Inserting the Memory Card .

(24) Card Slot

Insert a memory card.

See Inserting the Memory Card .

(25) Card Slot Cover

Open to insert a memory card.

See Inserting the Memory Card .

(26) Inner Cover

Close it when printing on paper.

Note

For details on installing the Print Head and ink tanks, refer to the printed manual: Getting

Started.

Operation Panel

* The illustration below shows all Operation Panel lit for explanatory purposes.

Except for the ON button, only available buttons will be lit.

(1) ON button

Page 7 of 1135 pagesMain Components

Turns the power on or off. Before turning on the power, make sure that the Document Cover is closed.

Important

Disconnecting the power plug

When disconnecting the power plug after turning off the power, be sure to confirm that

the POWER lamp is not lit. If the power plug is disconnected from the wall outlet while the

POWER lamp is lit or flashing, the machine may become unable to print properly since the

Print Head is not protected.

(2) HOME button

Used to display the HOME screen.

See Selecting Menus on the HOME Screen .

(3) Back button

Returns the LCD to the previous screen.

(4) Function buttons

Used to select menus on the HOME screen or select a function menu displayed at the bottom of the LCD.

See Selecting a Menu or Setting Item .

(5) LCD (Liquid Crystal Display)

Displays messages, menu items, and the operational status. You can also preview photos on the LCD

before printing.

Note

The display of the LCD and buttons on the Operation Panel will turn off if the machine is

not operated for about 5 minutes. To restore the display, touch any button except the ON

button. This will let the LCD turn on, and available buttons light. Performing a print operation

from a PC, etc. will also restore the display as it was before the LCD turned off.

(6) LCD open button

Press to raise the LCD.

(7) Black button

Starts black & white copying, scanning, etc.

(8) Color button

Starts color printing, copying, or scanning.

(9) Stop button

Cancels operation when print, copy, or scan job is in progress.

(10) [+] [-] buttons

Specifies the number of copies to copy or print.

(11) Wi-Fi lamp

Lights or flashes blue to indicate the wireless LAN status.

Lights: Wireless LAN active is selected.

Flashes: Printing or scanning over wireless LAN. Also flashes while searching for wireless LAN access

point during setup and when connecting to the access point.

(12) Alarm lamp

Lights or flashes orange when an error occurs, such as paper-out or ink-out.

(13) POWER lamp

Lights blue after flashing when the power is turned on.

(14) OK button

Finalizes the selection of a menu or setting item.

Resolves an error when printing is in progress or resumes the machine's normal operation after removing

jammed paper.

(15) , , , and buttons (Scroll Wheel)

Used to select a menu or setting item.

Page 8 of 1135 pagesMain Components

See Using the Operation Panel .

Note

When Operation panel buttons are touched, the machine generates keypad or alarm sounds as

necessary. For information about setting sound volume, see Machine Settings.

Page top

Page 9 of 1135 pagesMain Components

Advanced Guide Troubleshooting

Contents > Overview of the Machine > How to Navigate Menus on the LCD

C002

How to Navigate Menus on the LCD

You can use the machine to print photos on a memory card or USB flash drive, make copies, or scan

originals without a computer. You can also make good use of the various functions of the machine with

the menu screen and the settings screen on the LCD.

This section describes the basic operation to navigate menus on the HOME screen and to select setting

items necessary for printing.

Using the Operation Panel

Selecting Menus on the HOME Screen

Selecting a Menu or Setting Item

Other Operations

Using the Operation Panel

The buttons lit on the Operation panel depend on the screen being displayed. To aid operation, only

buttons available for the current screen light up.

To select a button, touch it lightly with your finger tip.

Important

Notes on using the Operation Panel

Do not place any object (especially metallic objects or objects containing moisture) on the Operation

Panel. Doing so may cause the machine to malfunction.

Precious metals, such as in rings and bracelets, may cause malfunction of the machine. When

using the Operation Panel, keep such metals at least 0.8 inches / 2 cm away from the Operation

Panel.

Note

The display of the buttons on the Operation Panel will turn off if the machine is not operated for

about 5 minutes. To restore the display, touch any button except the ON button. This will let the LCD

turn on, and available buttons light. Performing a print operation from a PC, etc. will also restore the

display as it was before the LCD turned off.

Using the , , , or button (Scroll Wheel)

(A) Touch the , , , or button to select items.

(B) Trace your finger along the Scroll Wheel to select items.

Page 10 of 1135 pagesHow to Navigate Menus on t e LCD

Table des matières

Autres manuels Canon Imprimante

Canon

Canon PIXMA MX360 Series Manuel utilisateur

Canon

Canon TR8600 Series Manuel utilisateur

Canon

Canon imageFORMULA DR-G2140 Manuel utilisateur

Canon

Canon iP100 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon imagePROGRAF iPF6350 Guide de l'utilisateur

Canon

Canon imageRUNNER ADVANCE DX 8905 Manuel utilisateur

Canon

Canon iPF5100 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon FAX-L900 Mode d’emploi

Canon

Canon DR-4010C - imageFORMULA - Document Scanner Manuel utilisateur

Canon

Canon imageCLASS LBP6780dn Manuel utilisateur

Canon

Canon PIXMA MP520 Manuel utilisateur

Canon

Canon imageCLASS X LBP1238 Manuel utilisateur

Canon

Canon PIXMA G7000 Series Manuel utilisateur

Canon

Canon BJC6500 - BJC 6500 Color Inkjet Printer Manuel utilisateur

Canon

Canon S100SP Manuel utilisateur

Canon

Canon imageRUNNER C3222L Manuel utilisateur

Canon

Canon imageCLASS MF5950dw Manuel de service

Canon

Canon mg6400 series Manuel utilisateur

Canon

Canon iP2600 - PIXMA Color Inkjet Printer Mode d’emploi

Canon

Canon i900D Series Manuel utilisateur

Canon

Canon PIXMA G5020 Guide de configuration

Canon

Canon PR-C151 Manuel utilisateur

Canon

Canon Pixma PRO-100S series Manuel utilisateur

Canon

Canon LBP-800 Mode d’emploi

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
