Canon ImageRUNNER C3222L Manuel utilisateur

Getting Started

Quick Operation P.5

Quick Setup P.2

Please read "Important Safety Instructions" before operating this product. After you ﬁnish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

User's Guide / FAQ

https://oip.manual.canon/

Conguring the Method of

Connecting to a Computer

About Application Library

Application Library is an application that

allows you to use useful functions for

routine jobs or other convenient

functions in a one-touch operation

without necessity of making functional

settings every time. You can access each

registered function by simply pressing

the appropriate button displayed in the

Home screen. For the respective

function, see the description displayed in

the Setup Guide.

2. Conﬁgure the initial settings, according to the

screen.

• Set the date and time

• Conﬁgure the Remote UI Access

• Perform color correction

IMPORTANT

To prevent unauthorized access by third parties,

you need a PIN for login to the remote UI that

has been set on the machine.

Before starting the conguration

• The machine cannot be connected to

both wired and wireless LANs at the

same time.

• If the machine is connected to an

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of

this.

• The machine does not come with a

router. Please have one ready, if

necessary.

• Even in an environment without

wireless LAN router, you can use Access

Point Mode to make a wireless

connection to the machine directly

from your mobile device (Direct

Connection).

User's Guide

Specifying the connection method

• To connect via wireless LAN : <Yes>

• To connect via wired LAN or USB : <No>

Conguring the Machine

Conguring the Initial Settings

of the Machine

Congure the settings in the following order.

Quick Setup

For details

"Setting Up Using the Setup Guide" in the User's Guide

To connect via wireless LAN

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Take note of the SSID and network key.

• Check the label on the router. User's Guide

• The setting operation is easier if the router is

provided with a WPS mark. User's Guide

4. Set the access point and network key.

1. Select the access point (SSID).

2. Enter a network key, and select <Apply>.

• Wait until message <Connected.> is

displayed.

3. Select <Close>.

• The IP address will be automatically

conﬁgured in a few minutes.

5. Install the driver and software.

P.4 "Installing the software"

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

• After connecting the cable, wait a few

minutes (until the IP address is set

automatically).

• If a static IP address has been set on the

computer, set the machine's IP address

manually.

4. Install the driver and software.

P.4 "Installing the software"

Now you are finished with the

configuration of the initial settings.

Now you are finished with the

configuration of the initial settings.

Quick Setup

To connect via USB

• The machine does not come with a USB cable.

Please have one ready, if necessary.

• Make sure that the USB cable you

use has the following mark.

• Do not connect the USB cable before installing

the driver. If you did, disconnect the USB cable

from the computer, close the dialog box, and then

perform the following procedure from step 1.

1. Install the driver and software.

P.4 "Installing the software"

Now you are finished with the

configuration of the initial settings.

Installing the software

You can download the latest printer driver from

the Canon website (https://global.canon/en/

support/).

POINT

For details of software installation, see the driver's

manual. The manual can be downloaded from, or

viewed on, the same page of the Canon website

as for the software.

Latest OS support information

See the Canon website (https://global.

canon/en/support/).

For details

"Setting Up Using the Setup Guide" in the User's Guide

Conguring the Machine

Quick Setup

Quick

Operation

Remember before

You Start Operation

Place your original on the platen glass Place your originals into the feeder

Place the original

with the scan side

face down.

Place to ﬁt

inside the

corner. Place the originals

with the scan side

face up.

Adjust

the slide

guides.

Suitable for scanning book

pages, magazine pages and

newspaper clips.

Suitable for continuously

scanning many pages of

literature, quotation, etc.

Place the Original Properly

Start the Operation from the Operation Panel

Machine

Quick Operation

Operation Panel

Display (screen)

([Energy Saver] key)

([Home] key)

Scanning

1. Place the original.

2. Press , and select <Scan>.

3. Select the type of scan, and enter the necessary information.

4. Select <Start>, <B&W Start> or <Color Start>.

Types of scan

■Store in computer

■Store in USB memory device

■Send e-mail/I-Fax

■Send to le server

To scan from a computer

■Use the scanner driver

supplied with the machine For details

"Scanning" in the User's Guide

Copying

1. Place the original.

2. Press , and then select <Copy>.

3. Specify the copy settings, as necessary.

4. Enter the desired number of copies.

5. Select <Start>.

Useful copy functions

■N on 1

■2-Sided or 1-Sided

■Enlarging or reducing

■Copying ID cards

For details

"Copying" in the User's Guide

Printing

1. Open the document to print, and select the print function of the

application.

2. Select the printer driver for the machine, and select [Preferences] or

[Properties].

3. Specify the paper size.

4. Specify the paper source and paper type.

5. Specify the print settings, as necessary.

6. Select [OK].

7. Select [Print] or [OK].

Useful print settings

■2-sided

■N on 1

■Booklet Printing

For details

"Help" on the printer driver

Quick Operation

In the following, the operations that are common

to paper drawers 1 and 2 are described by taking

drawer 2 as example.

2This operation is only applicable to Paper

Drawer 2.

Slide the light blue knobs to adjust the

positions of the paper guides.

Align the protrusion to the

appropriate paper size marking.

3First fan the paper stack well and then load

it.

Make sure that

this line is not

exceeded.

Paper

The print side face up

4Place the paper drawer back into the

machine.

CAUTION!

Be careful not to get your fingers caught

between the paper drawer and the

machine.

If you have changed the paper type, be

sure to change the paper settings.

5Press , and then select <Paper Settings>.

6Specify the size and type of paper, according

to the screen.

Loading in the Paper Drawer

For details

"Loading Paper" in the User's Guide

Loading Paper

Quick Operation

When paper is jammed, a screen, as shown below

appears.

Clear the paper jams, according to the on-screen

instructions.

Check the following.

• Is the power turned ON?

• Is the machine out of sleep mode?

If both the display and are not lit, press the

power switch.

• Is the power cord connected correctly ?

If the problem persists, see the User's Guide.

If a Problem Has Occurred

Replacing Consumables

Toner Cartridge

Canon genuine toner cartridge

• Canon NPG-67 Toner Black

• Canon NPG-67 Toner Cyan

• Canon NPG-67 Toner Magenta

• Canon NPG-67 Toner Yellow

• Canon NPG-67L Toner Cyan

• Canon NPG-67L Toner Magenta

• Canon NPG-67L Toner Yellow

For details

"Troubleshooting" in the User's Guide

The Machine Does Not Seem to

Work Paper Jams Have Occurred

Quick Operation

Black Streaks Appear in Images

Clean the document feed scanning areas.

1. Open the feeder, and clean the lower side

document feed scanning area using a cloth

dampened with water. Then, wipe the area

with a soft, dry cloth.

NOTE

Do not use glass cleaner or an alcohol

solution, etc., as they will strip away the stain-

proof coating.

2. Close the feeder.

If black streaks still appear after the

document feed scanning area has

been cleaned

Perform feeder cleaning.

1. Press , and then select <Menu>.

2. Select <Adjustment/Maintenance>

<Start> on the screen.

NOTE

It takes approximately 20 seconds to clean

the feeder.

Irregularities Appear in Images/Images

Are Faint

Solution 1

The paper may have absorbed moisture.

Turn the Dehumidication switch on. If the

problem is still not resolved, load paper

that is not damp.

Solution 2

Perform gradation adjustment.

1. Press , and then select <Menu>.

2. Select <Adjustment/Maintenance> <Adjust

Image Quality> <Auto Adjust Gradation>

on the screen.

Follow the instructions on the screen to perform

gradation adjustment.

For more information, see the User's Guide.

For details

"Adjusting Gradation" in the User's Guide

Printing Results Are Not

Satisfactory

If a Problem Has Occurred

Quick Operation

Table des matières

Autres manuels Canon Imprimante

Canon

Canon TS5100 series Manuel utilisateur

Canon

Canon imageCLASS X LBP1871 Manuel utilisateur

Canon

Canon PIXMA iP2000 Series Manuel utilisateur

Canon

Canon Laser Shot LBP5000 Manuel utilisateur

Canon

Canon PIXMA MP150 Manuel utilisateur

Canon

Canon Colorado 1650 Manuel utilisateur

Canon

Canon BJC-S200 Manuel utilisateur

Canon

Canon mg6400 series Manuel utilisateur

Canon

Canon iPF8000 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon PIXMA MX922 Instructions d'utilisation

Canon

Canon imagePROGRAF iPF6400S Series Manuel utilisateur

Canon

Canon PIXMA TS5000 Series Manuel utilisateur

Canon

Canon imageclass MF229DW Manuel utilisateur

Canon

Canon BJC-6000 Series Manuel

Canon

Canon PowerShot S500 Digital ELPH Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE DX C357iF Guide d'installation

Canon

Canon PowerShot S5 IS Manuel utilisateur

Canon

Canon LBP3250 Series Manuel utilisateur

Canon

Canon imageCLASS LBP6300dn Manuel utilisateur

Canon

Canon imagePRESS Series Manuel utilisateur

Canon

Canon MX320 Manuel utilisateur

Canon

Canon Color imageCLASS MF8350Cdn Guide de sécurité

Canon

Canon S 530D Manuel utilisateur

Canon

Canon iP6600D - PIXMA Color Inkjet Printer Mode d’emploi

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien

Canon imageRUNNER C3222L Manuel utilisateur

Manuels Imprimante populaires d'autres marques
