Canon ImageCLASS LBP622Cdw Manuel utilisateur

Getting Started

FT6-2592 (000) XXXXXXXXXX Copyright CANON INC. 2020 PRINTED IN XXXXX

Imprimé XXX XXXXX

Quick Operation P.21

Quick Setup NEXT PAGE

Please read "Important Safety Instructions" before operating this product. After you finish

reading this guide, store it in a safe place for future reference.

The information in this document is subject to change without notice.

https://oip.manual.canon/

Getting Started

Please read "Important Safety Instructions" before operating

this product.

P.26

After you nish reading this guide, store it in a safe place for

future reference.

The information in this document is subject to change

without notice.

Mise en route

Prenez connaissance des "Consignes de sécurité importantes"

avant toute utilisation de ce produit.

P. 32

Après en avoir pris connaissance, conservez ce guide dans

un endroit sûr en vue de consultations ultérieures.

Les informations contenues dans ce document peuvent être

modiées sans avis préalable.

Introducción

Lea las "Instrucciones de seguridad importantes" antes de usar

este producto.

página 38

Cuando termine de leer esta guía, guárdela en un lugar

seguro para futuras consultas.

La información de este documento puede ser modicada sin

previo aviso.

Introdução

Leia "Instruções de segurança importantes" antes de operar

este produto.

página 44

Depois de ler este guia, guarde-o em um local seguro para

referência futura.

As informações contidas neste documento estão sujeitas a

alterações sem aviso prévio.

You can access

https://oip.manual.canon/ to read the User's Guide that

describes all functions of this machine.

Le guide de l'utilisateur,

qui décrit toutes les fonctions de cet appareil se trouve sur

https://oip.manual.canon/.

Puede acceder a

https://oip.manual.canon/ para leer la Guía de usuario donde

se describen todas las funciones de este equipo.

Você pode acessar

https://oip.manual.canon/ para ler o Guia do usuário que

descreve todas as funções desta máquina.

Quick Setup

Before starting the installation

•Removeallofthetape.

•DonotremovethestickerthatcoverstheUSB

port.

Sticker

Installation requirements

Provide a space of 4" (100 mm) or more around

the machine.

17"

(430 mm)

14 7/8"

(377 mm)

16 1/2"

(418 mm)

8 1/2"

(216 mm)

11 3/8"

(287 mm)

× 4

Starter toner cartridges are included.

Installing the MachineItems Included with the Machine

Installation of the Machine

Quick Setup

Up to here

Installation of the Machine

Quick Setup

Next, proceed to configure the machine.

Quick Setup

Configuring the Method of

Connecting to a Computer

2. Configure the initial settings, according to the

screen.

•Setthelanguageandcountry/region.

•Setthetimezoneandcurrentdate/time.

•Settheaccesssecuritymeasures.

IMPORTANT

To prevent unauthorized access by third parties,

you need a PIN for login to the remote UI that

has been set on the machine.

Before starting the configuration

•Themachinecannotbeconnectedtoboth

wired and wireless LANs at the same time.

•Ifthemachineisconnectedtoan

unsecured network, your personal

information might be leaked to a third

party. Please be aware and careful of this.

•Themachinedoesnotcomewitha

router. Please have one ready, if necessary.

•Eveninanenvironmentwithoutwireless

LAN router, you can use Access Point

Mode to make a wireless connection to

the machine directly from your mobile

device (Direct Connection).

User's Guide

Specifying the connection method

NoYes

Use wireless LAN to

connect to network?

(Can config. later.)

•ToconnectviawirelessLAN:<Yes>

•ToconnectviawiredLANorUSB:<No>

To connect via wireless LAN

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

NOTE

Parts and functions of the operation panel

P.22 "Start the Operation from the Operation

Panel"

Configuring the Initial Settings of

the Machine

Configuring the Machine Configure the settings in the following order.

Quick Setup

For details

"Setting Up Using the Setup Guide" in the User's Guide

3. Take note of the SSID and network key.

•Checkthelabelontherouter. User's Guide

•Thesettingoperationiseasieriftherouteris

provided with a WPS mark. User's Guide

4. Set the access point and network key

according to the screen below.

For more

information, refer

to the manual.

1. Select <OK>.

2. Select <SSID Settings>.

3. Select <Select Access Point>.

4. Select the access point (SSID).

5. Enteranetworkkey,andselect<Apply>.

6. Select<Yes>.

•Waituntilmessage<Connected.>is

displayed.

7. Select<Close>.

•TheIPaddresswillbeautomatically

configured in a few minutes.

To view a video guide on the process

You can find a video and guide to assist the

process for the Wireless Network connection

from the URL below. Viewing these guides will

ensure a smooth setup of the device into your

existing wireless environment.

https://www.usa.canon.com/WirelessHelp/

"Toner replenishment service" settings

Precautions

•Useofthetonerreplenishmentservice

requires prior registration with select

retailers. This service is only available

in certain countries/regions and for

certain models.

Through the toner replenishment service, new

toner cartridges are automatically delivered to you

before your existing toner cartridge is used up.

•Thisservicecanbesetupthrough<Toner

DeliverySettings>displayedontheHomescreen.

Did you sign up for

toner replenishment

service when you

purchased this

product?

To continue setup

for automatic toner

delivery, press OK,

then press OK again

(if you agree) on

the next screen.

*Network connection

required to complete

registration.

Next Screen:

Press OK

1. Press OK .

2. Press OK .

•Toskip"Tonerreplenishmentservice"(orsetit

later), press and proceed to Step 4.

3. Press OK .

•Ifanerrormessageappears,followtheon-screen

instructions to resolve it.

4. Install the driver and software.

P.9 "Installing the software"

Now you are nished with the

conguration of the initial settings.

Quick Setup

To connect via wired LAN

The machine does not come with a LAN cable.

Please have one ready, if necessary.

1. Make sure that the computer is connected to a

router properly.

2. Check the network settings on the computer.

3. Connect the LAN cable.

•Afterconnectingthecable,waitafewminutes

(until the IP address is set automatically).

•IfastaticIPaddresshasbeensetonthe

computer, set the machine's IP address

manually.

4. Install the driver and software.

P.9 "Installing the software"

Now you are finished with the

configuration of the initial settings.

To connect via USB

•ThemachinedoesnotcomewithaUSBcable.

Please have one ready, if necessary.

•MakesurethattheUSBcableyou

use has the following mark.

•DonotconnecttheUSBcablebeforeinstalling

thedriver.Ifyoudid,disconnecttheUSBcable

from the computer, close the dialog box, and then

perform the following procedure from step 1.

1. Install the driver and software.

P.9 "Installing the software"

•Whenascreenwithinstructionsforconnecting

theUSBcabletothemachineisdisplayed,

removethestickerthatcoverstheUSBport.

Now you are finished with the

configuration of the initial settings.

Configuring the Machine

Quick Setup

Installing the software

•Theproceduredescribedhereisonlyapplicable

when your computer runs on the Windows OS.

For more details on the software installation

procedure, see the driver's manual.

•Fortheinstallationwhenyourcomputerrunson

the macOS, see the driver's manual.

•Yourmachinemaynotcomewiththedriverfor

the macOS , depending on the time of purchase.

New drivers are uploaded to the Canon website,

and you can download and use the latest one.

If the screen is not displayed properly, re-

inserttheCD-ROM/DVD-ROMorsearchfor

"D:\MInst.exe" on the Windows platform (This

descriptionassumesthat"D:"istheCD-ROM/

DVD-ROMdrivename).

Quick Setup

Configuration de la méthode

de connexion à un ordinateur

2. Configurez les réglages initiaux en suivant les

instructions à l'écran.

•Spécifiezlalangueetlepays/région.

•Spécifiezlefuseauhoraireetréglezladateet

l'heure.

•Mettezenplacedesmesuresdesécurisation

des accès.

IMPORTANT

Pour empêcher les accès non autorisés par

des tiers, pour vous connecter à l'interface

utilisateur distante, vous devez utiliser un code

PIN défini sur l'appareil.

Avant de commencer la configuration

•Iln'estpaspossibledeconnecter

l'appareil à la fois à un réseau sans fil et

à un réseau filaire.

•

Faites attention, si l'appareil est connecté à un

réseau non sécurisé, vos données personnelles

peuvent être divulguées à un tiers.

•L'appareiln'estpaslivréavecunrouteur.

Vous devez vous en procurer un.

•

Même dans un environnement sans routeur

de réseau sans fil, vous pouvez utiliser

le mode Point d'accès pour établir une

connexion sans fil entre l'imprimante et

votre appareil mobile (connexion directe).

Guide de l'utilisateur

Spécification de la méthode de connexion

NonOui

Util rés sans fil

pour conn. rés. ?

(Config. ult.)

•Connexionparréseausansfil:<Oui>

•ConnexionparréseaufilaireouUSB:<Non>

Connexion par réseau sans fil

1. Assurez-vous que l'ordinateur est correctement

connecté à un routeur.

2. Vérifiez les réglages réseau sur l'ordinateur.

REMARQUE

Sections et fonctions du panneau de commande

P.28 "Lancez l'opération depuis le panneau

de commande"

Configuration des réglages

initiaux de l'appareil

Configuration de l'appareil

Configurez les réglages dans l'ordre suivant.

Configuration rapide

Autres manuels pour imageCLASS LBP622Cdw

Ce manuel convient aux modèles suivants

Table des matières

Langues :

Autres manuels Canon Imprimante

Canon

Canon imageCLASS D300 Series Manuel utilisateur

Canon

Canon imageRUNNER C475iFZ III Guide d'installation

Canon

Canon Saddle Finisher-AF2 Manuel utilisateur

Canon

Canon imagePROGRAF iPF6400S Series Manuel utilisateur

Canon

Canon S 200 Manuel utilisateur

Canon

Canon imagePROGRAF iPF9400 Manuel utilisateur

Canon

Canon Pixma G2030 Series Guide de configuration

Canon

Canon PIXMA PRO-1 Series Manuel

Canon

Canon PIXMA TR4500 Series Manuel utilisateur

Canon

Canon PIXMA MP970 Manuel utilisateur

Canon

Canon imagePROGRAF iPF771 Manuel utilisateur

Canon

Canon iP3500 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon CX 350 Manuel utilisateur

Canon

Canon PIXMA G1411 Guide de configuration

Canon

Canon SELPHY CP1500 Manuel utilisateur

Canon

Canon CLC5100 Series Manuel utilisateur

Canon

Canon imagePRESS V900 Manuel utilisateur

Canon

Canon Pixma MG2500 Series Manuel utilisateur

Canon

Canon iPF6100 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon iPF710 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon PIXMA MG5220 Series Manuel utilisateur

Canon

Canon PIXMA iP7260 Series Manuel utilisateur

Canon

Canon Pixma iP110 series Manuel utilisateur

Canon

Canon iP100 - PIXMA Color Inkjet Printer Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien

Canon imageCLASS LBP622Cdw Manuel utilisateur

Manuels Imprimante populaires d'autres marques
