Canon Image CLASS Manuel utilisateur

Setup Guide

3User's Guide / FAQ

1Important Safety Instructions

Be sure to read these manuals before using

the machine.

• After finish reading this guide, store it in a safe place

for future reference.

• The information in this guide is subject to change

without notice.

2Setup Guide (this document)

for Asia for Korea

https://oip.manual.canon/

123456 87 9

Checking the Items

Included

× 4

Removing the Packing

Material

1. Install the machine in the location where it

will be used.

2. Remove all the packing material.

Remove all of the tape.

Loading Paper

A4 A5/A4

1 2 3 4 5 6 87 9

Ensure that the amount

of paper loaded is not

above this line

Installing the Optional

Product

If you are not using optional product,

proceed to step .

Before Installing the Optional Product

When installing the optional product after the machine

has been installed, perform the following before starting

work:

1. Shut down the machine and your computer.

2. Unplug the machine from the mains power outlet.

3. Disconnect all cords and cables from the machine.

Paper Feeder/Cassette Pedestal

1. Install the paper feeder in the location

where it will be used.

123456 87 9

• You can stack up to three paper feeders.

When Using the Cassette Pedestal

1. Install the cassette pedestal in the location

where it will be used.

Lock the four casters.

1 2 3 4 5 6 87 9

• You can stack up to two paper feeders and the

cassette pedestal with the machine.

Connecting the Power Cord

Specifying the Basic

Settings

When you turn on the machine for the first time, the

Setup Guide starts up on the operation panel. Perform

the initial machine setup by following the on-screen

instructions.

Operation panel

1. Select the language.

2. Select the country/region.

3. Select the time zone.

4. Set the current date/time.

Specifying the Security

Settings

Set an Administrator password to increase machine

security.

1. Check the message and press .

2. Select <Yes>.

To continue without setting a password, select

<No> and proceed to "Specifying the Network

Settings".

3. Enter a password and select <Apply>.

Enter the same password again and select <Apply>.

4. Check the message and press .

Specifying the Network

Settings

Specify the settings for connecting the machine to a

network. Before proceeding, check that the computer and

router are correctly connected to the network.

Wired LAN

1. Select <Wired LAN>.

2. Connect the LAN cable.

Wait a few minutes while the machine's IP address

is automatically set.

123456 87 9123456 87 9

1 2 3 4 5 6 87 9

2 3 4 5 6 87 91

Wireless LAN

The example described in this document is for the <SSID

Settings>. See the User's Guide for information on other

configuration procedures.

1. Check the router's "SSID" and "Network

key".

SSID : XXXXXXXXXXXX

Network key : XXXXXXXXXXXX

2. Select <Wireless LAN>.

3. Check the message and press .

4. Select <SSID Settings>.

5. Select <Select Access Point>.

6. Select the router with the matching SSID.

If the <Apply settings of IEEE 802.1X Settings to the

connection?> message appears, select <Yes> and

proceed to step 8below.

7. Enter the network key you checked above

and select <Apply>.

8. Select <Yes>.

Once a connection is established, the home screen

appears.

Installing the Software/

Drivers

Install the software and drivers from the CD/DVD-ROM

included, or visit the URL below and download them from

the Canon website for your country/region.

https://global.canon/en/support/

Example: LBP722Cx download

XXXXXXX download

설정 가이드

3사용자 안내서 / FAQ

1중요 안전 지침

본 기기를 사용하기 전에 반드시 다음

설명서를 읽으십시오.

• 본 가이드를 다 읽은 후에는 향후 참조할 수

있도록 안전한 장소에 보관하십시오.

• 본 가이드의 정보는 통지 없이 변경될 수

있습니다.

2설정 가이드 (본 문서)

아시아 한국

https://oip.manual.canon/

1 2 3 4 5 6 87 9

포함된 항목 확인

× 4

포장재 제거

1. 사용할 위치에 기기를 설치합니다 .

2. 포장재를 모두 제거합니다 .

테이프를 모두 제거

합니다 .

용지 적재

A4 A5/A4

1 2 3 4 5 6 87 9

적재된 용지의 양이 이

선 위로 올라가지 않도

록 해야 합니다

옵션 제품 설치

 옵션제품을사용하지않는경우

단계로진행합니다 .

옵션 제품을 설치하기 전

기기를 설치한 후 옵션 제품을 설치할 때는 작업을

시작하기 전에 다음을 수행합니다 :

1. 기기와 컴퓨터를 종료합니다 .

2. 주전원 콘센트에서 기기의 플러그를 뽑습니다 .

3. 코드와 케이블을 기기에서 모두 분리합니다 .

용지 피더 / 카세트 받침대

1. 사용할 위치에 용지 피더를 설치합니다 .

1 2 3 4 5 6 87 9

123456 87 9

• 용지 피더를 최대 3 개까지 쌓아둘 수

있습니다 .

카세트 받침대를 사용할 경우

1. 사용할 위치에 카세트 받침대를

설치합니다 .

캐스터 4 개를 잠

급니다 .
