The copier is a multi-function copier capable of serving as a copier, fax, and printer.

This Service Manual provides information needed to service the copier in the field. For

information on technologies used in common with the existing copiers, refer to the "Copier

Basic Series" as necessary.

This Service Manual consists of the following chapters:

Chapter 1 General Description introduces the copier's features and

specifications, shows how to operate the copier, and explains how

copies are made.

Chapter 2 Basic Operation provides outlines of the copier's various mechanical

workings.

Chapter 3 Exposure System discusses the principles of operation used for the

copier's lens drive unit and scanner drive unit. It also explains the

timing at which these drive units are operated, and shows how they

may be disassembled/assembled and adjusted.

Chapter 4 Image Formation System discusses the principles of operation used

for the copier's image processing units. It also explains the timing at

which the various units involved in image processing are operated,

and shows how they may be disassembled/assembled and adjusted.

Chapter 5 Laser Exposure System discusses the principles of operation used for

the copier's laser unit. It also explains the timing at which the unit is

operated, and shows how they may be disassembled/assembled and

adjusted.

Chapter 6 Image Formation System discusses the principles of how images are

formed. It also explains the timing at which the various units involved in

image formation are operated, and show how they may be

disassembled/assembled and adjusted.

Chapter 7 Pick-Up/Feeding System explains the principles of picking up and

feeding copy paper in view of the functions of electrical and

mechanical units used to move copy paper and in relation to their

timing of operation. It also shows how these units may be

disassembled/assembled and adjusted.

Chapter 8 Side Paper Deck explains the principles of operation used from when

paper is picked up to when copies are delivered. It also explains the

timing at which various drive units are operated, and shows how they

may be disassembled/assembled and adjusted.

Chapter 9 Fixing System explains the principles used to fuse toner images to

transfer media in view of the functions of electrical and mechanical

units and in relation to their timing of operation. It also shows how

these units may be disassembled/assembled and adjusted.

Chapter 10 Externals/Auxiliary Mechanisms shows the copier's external parts, and

explains the principles used for the copier's various control

mechanisms in view of the functions of electrical and mechanical units

and in relation to their timing of operation. It also shows how these

units may be disassembled/assembled and adjusted.

Chapter 11 Systems explains connections and specifications related to systems

and shows how to disassemble and assemble them.

Chapter 12 Installation introduces requirements for the site of installation, and

shows how the copier may be installed using step-by-step instructions.

INTRODUCTION

1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

Chapter 13 Maintenance and Servicing provides tables of periodically replaced

parts and consumables/durables and scheduled servicing charts.

Chapter 14 Troubleshooting provides tables of maintenance/inspection,

standards/adjustments, and problem identification (image fault/

malfunction).

Appendix contains a general timing chart and general circuit diagrams.

The descriptions in this Service Manual are subject to change without notice for

product improvement or other purposes, and major changes will be communicated in the

form of Service Information bulletins.

All service persons are expected to have a good understanding of the contents of this

Service Manual and all relevant Service Information bulletins, and be able to identify and

isolate faults in the machine.

For a full understanding of the copier, this Service Manual should be used side by side

with the separately available "Copier Basic Series." Refer to the descriptions in each of

the following volumes:

Volume 1

Volume 2

Volume 3

Volume 4

Volume 5

Volume 6

Volume 7

1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

iii

System Configuration

The copier may be configured with its accessories as follows:

nPick-Up/Delivery Accessories

[1] DADF-A1

[2] Finisher-C1

[3] Multi Output Tray C1

[4] Saddle Finisher C2

[5] Finisher-E1

[6] Cassette Feeding Unit-S1

[7] Cassette Feeding Unit-R1

[8] Paper Deck-B1

[3]

[2]

[5]

[8]

[4]

[6]

[7]

[1]

1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

nSystem Accessories

[1] Handset-C1 [120V ONLY]

[2] Expansion Board Base Unit-C1

[3] SCSI Interface Board-D1

[4] Printer Board

[5] Super G3 FAX Board

[6] Battery Board-A1

* PDL I/F Board.

[1]

[5]

[4]

[3]

[2] [6]

1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

When Turning Off the Main Power Switch

Be sure always to turn off the main power switch and disconnect the power plug before starting

disassembly work. In addition,

1. When expanding the fax functions, the secondary battery used to retain fax memory images

will start to operate as soon as the main power switch is turned off. Be sure to complete any

work within one hour if the main power switch must be kept off. (Be sure also to keep the

machine powered at least for one week after installation.)

2. The communication memory lamp on the control panel indicates the presence/absence of fax

memory images. If it is on (indicating the presence of images), be sure to print out the images

before turning off the main power switch and disconnecting the power plug.

3. Turing off the control panel power switch will not remove power from some units. Be sure

always to turn off the main power switch before starting disassembly/assembly work.

4. The power will not be removed even when the front door is opened as long as the control panel

power switch and the main power switch are both on.

COPY

FAX

OPTIONS

Communication memory lamp

Control panel power switch

Main power lamp

Main power

switch

Cassette heater

switch

1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

Connectors for the Pick-Up/Delivery Accessories

When connecting accessories, be sure to use the connectors indicates in the diagram. If, for

example, you connect the paper deck to the cassette pedestal connector and turn on the paper, the

fuse on the paper deck PCB will blow, at times requiring replacement with a new PCB.

For the Feeder

For the Paper deck

For the Cassette Feeding Unit

For the Finisher

Figure. Rear View of the Body

1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

vii

CONTENTS

CHAPTER 1 GENERAL DESCRIPTION

I. FEATURES..................................1-1

II. SPECIFICATIONS.......................1-2

A. Type........................................1-2

B. Method ...................................1-2

C. Performance...........................1-3

D. Paper Deck-B1.......................1-4

E. Others ....................................1-5

F. Default Ratios.........................1-6

G. Copying Speed ......................1-7

III. NAMES OF PARTS.....................1-9

A. External view..........................1-9

B. Cross Section...................... 1-11

IV. OPERATION............................. 1-13

A. Turning On the Power ......... 1-13

B. Control Panel ...................... 1-14

C. Special Features Modes ..... 1-15

D. Additional Functions ........... 1-16

V. ROUTINE MAINTENANCE BY

THE USER ............................... 1-19

VI. SAFETY ................................... 1-20

A. Safety of Laser Light (CLASS 1

LASER PRODUCT) ............ 1-20

B. CDRH Regulations ............. 1-21

C. Handling the Laser Unit ...... 1-22

D. Safety of Toner .................... 1-24

VII. IMAGE FORMATION................ 1-25

A. Outline................................. 1-25

CHAPTER 2 BASIC OPERATION PROVIDES

I. BASIC OPERATION....................2-1

A. Functional Construction .........2-1

B. Outline of the Electrical

Circuitry..................................2-2

C. Sequence of Operations ........2-4

D. Main Motor (M1) Control

Circuit .....................................2-8

E. Inputs to and Outputs from

the Major PCBs................... 2-10

viii

1999 CANON INC. CANON 405/335 REV.0 JAN. 1999 PRINTED IN JAPAN (IMPRIME AU JAPON)

CHAPTER 4

IMAGE FORMATION SYSTEM

I. OUTLINE.....................................4-1

II.

ANALOG IMAGE PROCESSING..

4-3

A. Outline....................................4-3

B. CCD .......................................4-3

C. AE Processing

(ABC processing)...................4-4

D. A/D Conversion ......................4-5

E. Analog Signal Processing

Block ......................................4-6

III.

DIGITAL IMAGE PROCESSING ...

4-7

A. Outline....................................4-7

CHAPTER 5 LASER EXPOSURE SYSTEM

I. OUTLINE.....................................5-1

II.

GENERATING THE BD SIGNAL ..

5-3

III. LASER DRIVER PCB .................5-5

A. Outline....................................5-5

B. Stabilizing the Laser Output...5-6

C. Switching the Laser Activation

Mode ......................................5-7

D. Switching the Laser Output....5-7

B. Shading Correction ................4-8

C. Total Processing.....................4-9

D. Density Processing ............. 4-12

E. Binary Processing............... 4-16

F. Image Memory .................... 4-19

G. Overlay Copying.................. 4-21

IV. DISASSEMBLY/ASSEMBLY .... 4-22

A. CCD Unit............................. 4-23

B. IP PCB ................................ 4-24

Replacing the ROM DIMM

(on the image processor PCB)..

4-25

IV. CONTROLLING THE LASER

SCANNER MOTOR ....................5-8

A. Outline of Operations.............5-8

B. Turning On and Off the Laser

Scanner Motor .......................5-9

V. DISASSEMBLY/ASSEMBLY .... 5-10

A. Laser Scanner Assembly.... 5-11

CHAPTER 3 EXPOSURE SYSTEM

I. OUTLINE OF OPERATIONS ......3-1

A. Outline....................................3-1

B. Sequence of Operations

(original exposure system).....3-2

II. SCANNER DRIVE SYSTEM.......3-3

III. CONTROLLING THE SCANNING

LAMP...........................................3-4

A. Outline....................................3-4

B. Controlling the Pre-Heating

Mechanism.............................3-5

C. Turning On and Off the

Scanning Lamp ......................3-5

D. Controlling the Intensity .........3-5

E. Detecting Errors .....................3-6

IV. IDENTIFYING THE SIZE OF AN

ORIGINAL ...................................3-7

A. Outline....................................3-7

B. Identifying the Size by the

Paper Sensors (1)..................3-7

C. Identifying the Size by the

Paper Sensors (2)..................3-9

D. Identifying the Size by the

Original Width/Length Sensor

of the Feeder....................... 3-10

V. DISASSEMBLY/ASSEMBLY .... 3-11

A. Scanning System ................ 3-12

B. Scanner Drive Assembly..... 3-13

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Imprimante

Canon

Canon Folder Professional 6011 Manuel utilisateur

Canon

Canon imagePRESS C165 Manuel utilisateur

Canon

Canon imagePROGRAF iPF6400S Series Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE DX C3730i Guide d'installation

Canon

Canon Color Bubble Jet BJC-8200 Manuel utilisateur

Canon

Canon PIXMA E3300 Series Guide de configuration

Canon

Canon I450 - i 450 Color Inkjet Printer Manuel

Canon

Canon imageRUNNER ADVANCE 500i Guide de l'administrateur

Canon

Canon MP980 series Manuel utilisateur

Canon

Canon MultiPASS C530 Manuel utilisateur

Canon

Canon imagePROGRAF iPF760 Guide de l'utilisateur

Canon

Canon Pixma MG3500 Series Manuel utilisateur

Canon

Canon SELPHY CP770 Manuel utilisateur

Canon

Canon Laser Shot LBP5970 Manuel utilisateur

Canon

Canon i455 Series Manuel utilisateur

Canon

Canon iP6600D - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon imageCLASS LBP6780dn Manuel utilisateur

Canon

Canon PIXMA MP950 Manuel utilisateur

Canon

Canon C1333iF Manuel utilisateur

Canon

Canon PowerShot S400 Digital Elph Manuel utilisateur

Canon

Canon Mk1500 Manuel utilisateur

Canon

Canon PIXMA G2060 Series Manuel utilisateur

Canon

Canon imageCLASS MF269dw Manuel utilisateur

Canon

Canon LBP-3200 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
