Canon CP-100 Manuel utilisateur

Canon Card Photo Printer

User Guide ENGLISH

Foto-impresora Canon para

tamaño tarjeta

Guía del usuario

ESPAÑOL

Imprimante photo Canon

Guide d'utilisation

FRANÇAIS

Contents

Quick Start Guide .................................................................... 2

Introduction .............................................................................. 4

Features................................................................................... 5

Read This First ........................................................................ 6

Package Contents.............................................................. 6

Safety Precautions............................................................. 8

Proper Usage and Handling ............................................ 11

Components Guide.......................................................... 15

Let’s Print ............................................................................... 16

Checking Your Ink/Paper Sets.......................................... 16

Loading the Ink Cassette ................................................. 18

Placing the Paper into the Paper Cassette ...................... 19

Loading the Paper Cassette ............................................ 20

Connecting the Printer to a Power Source....................... 21

Connecting the Camera to the Printer ............................. 22

Printing ............................................................................ 23

Using the Battery/Charge Adapter Kit BCA-CP100 (Optional) .. 24

Charging the Battery Pack NB-CP1L............................... 24

Installing the Battery Pack NB-CP1L ............................... 26

Using the Car Battery Adapter CBA-CP100 (Optional) ......... 28

Troubleshooting ..................................................................... 29

Error Messages ..................................................................... 31

Specifications ........................................................................ 34

English

This section explains the procedures required to print images on postcard size

paper, using the ink cassette, the paper cassette and the paper included in your kit.

When using the optional Color Ink/Paper (label) set, refer to

Let’s Print

. p. 16

Quick Start Guide

Top Cover

Middle Cover

Paper

(Glossy side up and address/stamp

side last)

Loading the Ink Cassette p. 18

Insert the supplied ink cassette (Postcard size) in the printer.

Placing the Paper into the Paper Cassette p. 19

Place the supplied standard paper (Postcard size, 5 sheets) in

the paper cassette.

Middle Cover closed

Top Cover open

Loading the Paper Cassette p. 20

Push the paper cassette all the way into the paper cassette slot.

Connecting the Printer to a Power Source p. 21

Place the printer on a level surface and connect the compact power

adapter.

Connecting the Camera to the Printer p. 22

Connect the camera to the printer using the direct interface cable

and press the ON/OFF button.

Printing p. 23

Set the camera to replay mode and turn the power on. Display

the image you wish to print and select [Print] or [OK].

Press until the indicator

lights orange.

e.g. PowerShot S200 DIGITAL ELPH/

DIGITAL IXUS v2

Introduction

Thank you for your purchase of the Canon Card Photo Printer CP-100.

This

User Guide

explains the printer’s general flow of operations, from print

settings to printing. For information about how to make prints, refer to the

Camera

User Guide

that came with your camera.

Before using your printer for the first time, please read through the safety precautions.

(p. 8)

Warning Against Copyright Infringement

Please respect all copyrights. Use of images produced by this printer for purposes

other than personal entertainment may be prohibited by law. The taking of photographs

at performances, trade shows, exhibitions, and other such venues may be subject to

restrictions regardless of intended use.

Warranty Limitations

This printer’s warranty is only effective in the country of sale. If a problem arises while

the printer is in use abroad, please convey it back to the country of sale before

proceeding with a warranty claim to a Canon Customer Support Help Desk.

For Canon Customer Support contacts, please see the Canon Limited Warranty

supplied with your printer.

Disclaimer

•While every effort has been made to ensure that the information contained in this

User Guide is accurate and complete, no liability can be accepted for any errors or

omissions. Canon reserves the right to change the specifications of the hardware

and software described herein at any time without prior notice.

•No part of this User Guide may be reproduced, transmitted, transcribed, stored in

a retrieval system, or translated into any language in any form, by any means,

without the prior written permission of Canon.

•Canon makes no warranties for damages resulting from corrupted or lost data due

to a mistaken operation or malfunction of the product, the CompactFlash™cards

(CF cards) or use of non-Canon CF cards.

Trademark Acknowledgements

•Canon is a trademark of Canon, Inc.

•Any other company and product names used herein may be trademarks of

their respective companies.

Connects directly to supporting Canon cameras

Allows easy printing from any Canon camera that supports direct printing. Just

connect the interface cable and you’re ready to go.

Three paper sizes

You can print on standard paper in postcard size, L size or credit-card size.

Two types of labels (credit-card size)

In addition to the standard size paper, you can print full-sized labels or 8-label

stickers with the credit-card size paper.

High-quality prints, fast feeding of the paper

Offers photo-quality prints. Produces up to 18 prints without reloading.

Fast printing

Postcard size images can be printed at the high speed of 81 seconds per sheet.

Coated prints

Applies a protective coating to each print.

Borderless prints

Can produce borderless images that fill the paper completely.

Supports DPOF (Digital Print Order Format)

Supports DPOF settings for print selection, number of copies, and shooting date.

Easy outdoor printing

You can easily print outdoors by attaching the Battery Pack (optional) to the

printer. The Car Battery Adapter (optional) can also be used as a power source.

Features

•If does not display on the camera’s LCD monitor when you connect your

camera to this printer, your camera’s firmware may be incompatible with this

printer. Please check the Canon BeBit website ( http://www.canon.co.jp/

Imaging/BeBit-e.html ) or your regional Canon website, for information or to

download compatible firmware.

Card Photo Printer CP-100 Paper Cassette

(Postcard size)

Direct Interface Cable DIF-100Standard Paper

(Postcard size, 5 sheets)

Compact Power Adapter

CA-CP100

AC Cable

User Guide

(this booklet)

Warranty Card*

Canon Customer Support Leaflet*

* Not included in some regions.

•For information about which direct interface cable** should be used on your camera, refer to the

Camera User Guide

** Direct interface cable is used to connect the camera to the printer.

Direct Interface Cable DIF-200

Read This First

Package Contents

Ink Cassette (Postcard size)

Paper Cassette

(Card size)

Cleaner Stick

The following products are sold separately.

•Paper Cassette PCL-CP100 (L size)*

•Color Ink/Paper Set KP-36IP

(Postcard size, 36 standard sheets)

•Color Ink/Paper Set KL-36IP*

(L size, 36 standard sheets)

•Color Ink/Paper Set KC-36IP

(Card size, 36 standard sheets)

•Color Ink/Full-sized Label Set KC-18IF

(Card size, Full-size, 18 Label sheets)

•Color Ink/Label Set KC-18IL

(Card size, Multiple (8-screen), 18 Label sheets)

•Battery Pack NB-CP1L

•Battery/Charge Adapter Kit BCA-CP100

•Car Battery Adapter CBA-CP100

* Not sold in some regions.

Safety Precautions

•Before using the devices, please ensure that you have read and understood

the safety precautions described below. Always ensure that the devices are

operated correctly.

•The safety precautions noted on the following pages are intended to instruct

you in the safe and correct operation of the devices to prevent injuries or

damage to yourself and other persons.

•“Devices”refers to the “printer, compact power adapter, battery pack

(optional) or charge adapter (optional)”throughout this guide.

WARNINGS

Devices

If the devices emit smoke or a burning odor, or show other signs of significant

malfunction, immediately unplug the AC cable from the electrical outlet. Continued

operation under these conditions poses risk of fire or electric shock. Be sure that

smoke or burning odor subsides, and then contact your dealer or the nearest Canon

Customer Support help desk.

If the devices are dropped or the devices casing becomes damaged, unplug the AC

cable from the electrical outlet. Continued operation poses risk of fire or electric shock.

Contact your dealer or the nearest Canon Customer Support help desk.

Never rest small metallic objects or liquid containers on top of the devices. If liquid

splashes onto the devices, wipe the devices dry using a soft absorbent cloth. If liquid

spills into the devices or an object falls into the devices, immediately unplug the AC

cable from the electrical outlet. Continued operation poses risk of fire or electric shock.

Contact your dealer or the nearest Canon Customer Support help desk.

Do not use flammable solvents such as alcohol, benzene, or paint thinner to clean the

devices. Use of such solvents poses a fire risk.

Do not drop or insert metallic or combustible objects into the devices. Entry of foreign

objects into the devices may result in fire, electric shock, or equipment failure. Store

the devices out of the reach of children.

Do not disassemble or modify the devices. The devices contain high-voltage

components, and there is risk of electric shock. If your devices need internal

adjustment or repair, contact your dealer or a Canon Customer Support help desk.

Do not touch metal parts of the devices or the power plug during thunderstorms.

Lightning strikes may produce lethal voltages within the devices. Keep clear of the

devices while thunderstorms are in progress.

Power

Do not exceed the cable and power outlet ratings when operating this product. Do not

operate this product outside of the specified voltage rating.

Connecting too many lines to the same outlet may result in fire. Check that the voltage

of the outlet is compatible with the devices before them in.

If the AC cable becomes damaged (if internal wiring is exposed, etc.), immediately

unplug the cable from the electrical outlet. Continued use poses risk of fire or electric

shock.

Do not plug in or unplug the AC cable while your hands are wet, as this may result in

electric shock. When unplugging the cable, hold it firmly at the plug area. Do not pull

directly on the cable, as this may damage or expose the cable’s internal wiring,

resulting in risk of fire or electric shock.

Be sure that the AC cable is plugged all the way in. A loose connection may result in

heat buildup, fire, or electric shock.

Do not damage, modify, or rest heavy objects on the AC cable. Damage to the cable

may result in the exposure of live wires, fire, or electric shock.

Keep the AC cable free of dust. The presence of dust or metallic debris on the plug

poses risk of fire or electric shock. If the plug area is not clean, unplug the AC cable

and then wipe the plug area clean using a dry cloth. Check the plug periodically to

make sure it is clean.

Usage Location

Do not place the devices on an unstable or tilted table or desk, as there is risk that the

devices may fall and cause injury.

CAUTIONS

Devices

Do not block the air vents on the printer. Blocking the vents may cause the inside of the

printer to overheat, resulting in damage to internal components and risk of equipment

failure or fire. Use the devices in a well-ventilated area.

Do not rest heavy objects on the devices. Objects may fall off the devices and cause

injury. Weight placed on the devices may deform the casing, resulting in damage to

internal parts and posing risk of fire.

Unplug the devices when you are not using them. If the devices remain plugged in,

there is risk that accidental contact with the device’s internal parts may cause electric

shock. Leaving the devices plugged in during prolonged periods of non-use poses risk

of fire.

Autres manuels pour CP-100

Table des matières

Langues :

Autres manuels Canon Imprimante

Canon

Canon 8996A001 - i 455 Color Inkjet Printer Guide de configuration

Canon

Canon PIXMA MG3120 Manuel utilisateur

Canon

Canon DR-4010C - imageFORMULA - Document Scanner Manuel utilisateur

Canon

Canon PiXMA TR8550 Series Manuel utilisateur

Canon

Canon LASER SHOT LBP-2410 Manuel utilisateur

Canon

Canon PIXMA MX310 series Manuel utilisateur

Canon

Canon i9100 Series Manuel utilisateur

Canon

Canon G550 Manuel utilisateur

Canon

Canon I450 - i 450 Color Inkjet Printer Manuel utilisateur

Canon

Canon PowerShot S330 Digital ELPH Manuel

Canon

Canon imageCLASS LBP161dn+ Manuel utilisateur

Canon

Canon PIXMA MP497 Manuel utilisateur

Canon

Canon Selphy CP730 Guide de configuration

Canon

Canon Selphy CP600 Manuel utilisateur

Canon

Canon SELPHY ES2 Manuel utilisateur

Canon

Canon iPF755 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon LBP-810 Manuel utilisateur

Canon

Canon PIXMA TS5000 Series Manuel utilisateur

Canon

Canon i960 Series Manuel utilisateur

Canon

Canon image Prograf iPF780 Series Manuel utilisateur

Canon

Canon iP3300 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon LBP352 Manuel utilisateur

Canon

Canon PIXMA MG5600 Series Guide de configuration

Canon

Canon 3433B010 Guide de l'utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
