Canon BJC-2100 Series Manuel utilisateur

Simplified Manual

BJC-2100/2100SP

Part number: QY8-1372-000

1 Product / Option / Comsumable list

2 Specifications

3 Error code list

4 Service mode

(Test print, EEPROM reset....)

5 External view / Parts list

6 H/W troubleshooting flowchart

7 Special Service Information

Service Test Print

Rev 01 2000.3/22

(QE-12E-0231)

Attachment

for

1. Product / Option / Comsumable lists

1.1 Products

Product Name Product Code Sales territory Remarks

Canon Bubble Jet Printer Q30-3330-720 CCSI

BJC-2100 Q30-3330-721 CANADA

Q30-3330-722 LATIN(LV)

Q30-3330-723 LATIN(HV)

Q30-3330-724 ARG

Q30-3330-730 EUROPE

Q30-3330-731 GERMAN

Q30-3330-732 FRANCE

Q30-3330-780 U.K.

Canon Bubble Jet Printer Q30-3331-710 JAPAN

BJ F210

Canon Bubble Jet Printer Q30-3340-740 AUSTRALIA

BJC-2100SP Q30-3340-733 ASIA(HV)

Q30-3340-734 CHN

Q30-3340-750 HK

Q30-3340-760 KRN

Q30-3340-723 TWN

1.2 Options

Product Name Product Code Remarks

Canon BJ Cartridge Container Q70-3130

SB-21 Q70-3530

IS-22

Canon BJ Scanning Holder Q70-3640 Scanning Holder for IS-22 (A4)

SH-101 A4/LTR

Canon BJ Scanning Holder Q70-3650 Scanning Holder for IS-22 (A3)

SH-101 A3/LDR

1.3 Consumables

Product Name Product Code Remarks

Canon BJ Cartridge F45-0561 BJ Cartridge (BK)

BC-20

Canon Color BJ Cartridge F45-1301 BJ Cartridge (Regular Color)

BC-21e

Canon Color BJ Cartridge F45-1311 BJ Cartridge (Photo Color)

BC-22e Photo

Canon Color BJ Cartridge F45-1101 BJ Cartridge (Fluorescent Color)

BC-29F

Canon Ink Cartridge F47-0731 Ink tank for BC-21e (BK)

BCI-21 Black

Canon Ink Cartridge F47-0741 Ink Tank for BC-21e (Color)

BCI-21 Color

Canon Color Image Scanner Cartridge

2. Specifications

2.1 Specifications

(

Note

)

Difference from the based BJ

-2000

2000

P is written in RED

DeskTop serial color bubble jet printer

Paper feeding method Auto Sheed Feeding

Resolution 720 dpi X 360 dpi

Printing Speed

HQ Color 1.5ppm (Color throughput pattern)

Mono. 4ppm (Monochrome throughput pattern)

HS Color 2ppm (Color throughput pattern)

Mono. 5ppm (Monochrome throughput pattern)

Printing Direction Switching unidirectional

( Printing direction automatically changes according to

the print data/ print mode/ installed cartridged type. )

Print width 203.2mm (8inch)

Interface IEEE1284 compatible 8-bit parallel / USB

Stacking Capacity of sheet feeder

Plain paper Max. 5mm stac

pprox. 5

eets w

75g

LGL size Max. 10 sheets

Envelopes Max. 5 sheets

Transparencies Max. 20 sheets

Back Print Film Max. 10 sheets

Glossy photo paper Max. 1 sheet

Glossy film Max. 1 sheet

Fabric Max. 1 sheet

T-shirt transfer Max. 1 sheet

Banner paper Max. 1 sheet

Scanning document Max. 1 sheet

Detection functiones

Paper out Available

Paper width None

Waste ink amount Available

Available

Distinction of cartridge Available

Ink out None

Distinction of scanner Available

Mismatch BJ/scanner Available

Noise 45 dB (Sound pressure level ISO9296)

Environmental requirement

During operation Temp. 5 to 35 deg. C (41 to 95 deg. F)

Humidity 10% to 90%RH (no condensation)

Non operation Temp. 0 to 35 deg. C (32 to 95 deg. F)

Humidity 5% to 90%RH (no condensation)

Power supply AC100V/120V 50/60H

(LV) Japan,USA,Canada

AC220/240V 50Hz (HV) Europe,Asia

Power consumption 18W

Stand-by status 2W

External dimension

W/O paper tray/suppor

370(W) X 191(D) X 164(H)

W paper tray/support 370(W) X 461(D) X 241(H)

Weight 2.4kg (W/O BJ cartridge and option)

Applicable safety standards

Printer FCC,IC,CE Mark,TWN-EMC,C-Tick,VCCI

Safety

2.2 Product life

Whichever of the following comes first

-5 years

-Color printing 3000 pages

-Black printing 10000 pages

UL,CUL,CB Report,GS,CE Mark,FIMKO,DENTORI,AS,PSB,CCIB,KRN-DENTORI

Input voltage/Frequency

Presence of BJ cartridge

3. Error Code List

Error will be displayed on the host computer monitor.

The host computer should be set to ECP or Nibble mode and use the BJ Status Monitor on Win95.

Error indication Error condition

1000 The printer is out of paper. Push the RESET botton to paper feed.

1200 Front cover is opened. Close the front cover.

1300 Paper JAM occurrs. Pull up the paper.

1400 BJ cartridge is not installed. Install the BJ cartridge and close the front cover.

1440 Incorrect cartridge is installed.

5000 Home position error H/W fail Replace the printer.

5100 Carriage control error H/W fail Replace the printer.

5200 Head temperature error H/W fail Replace the BJ cartridge.

5400 Printer temperature error H/W fail Replace the printer.

5600 No cartridge while printing H/W fail Replace the printer.

5B00 Waste ink full H/W fail Replace the printer.

5C00 Purging operation error H/W fail Replace the printer.

6100 ROM error H/W fail Replace the printer.

6300 RAM error H/W fail Replace the printer.

5210 Scanner cartridge error H/W fail Replace the scanner cartridge.

6800 EEPROM error H/W fail Replace the printer.

Error Code

Install the correct BJ cartridge and close the front cover.

4. Service Mode

Function Procedure Remarks

Cleaninng the BJ cartridge Cleaning time

( while the AC plug is plugged in) :Approx.20seconds.)

Test print Print nozzle check pattern

1) Nozzle pattern Double click the RESET button. BC-20/21e/22e/29F

( while the AC plug is plugged in)

2) Service test print

Control ROM Version See *1 service test print' Needs BC-20

Pages of each Cartridge Print sample : See *3

Waste ink Amount

Destination setting

EEPROM Reset See *2 EEPROM reset / Destination setting

(Reset waste ink amount)

Destination setting See *2 EEPROM reset / Destination setting

(Japan/SP/Others)

*1 Service test print

-1 Without the cartridge installed, connect the plug of the AC adapter to the AC outlet

while holding down the RESET button.

-2 Release the RESET button, press it down again within 5 seconds and release it.

-3

pen t

ront cover an

nsta

-20

(bl

cartr

)

-4 Hold down the RESET button for 2 seconds or more and release it.

-5 Close the front cover.

-6 The printer starts service test printing.

*2 EEPROM reset / Destination setting

-1 Without the cartridge installed, connect the plug of the AC adapter to the AC outlet

while holding down the RESET button.

-2 Release the RESET button, press it down again within 5 seconds and release it.

-3 Hold down the RESET button for 2 seconds or more and release it.

-4 < EEPROM Reset > < Destination setting >

Hold down the RESET button for 2 secs or more. -Japan Press the RESET button once.

-Others Press the RESET button twice

-SP Press the RESET button 3 times

After the button is pressed, the carriage will move same time

as the number of times the RESET button is pressed.

*3 Print sample of 'Service test print'

You can check the EEPROM setting by 'Service test print'.

Control ROM Version Amount of waste ink

Destination setting Page counts of

Japan BJ F210 SC IS-22(Scanner)

SP BJC-2100SP VL BC-22e

Others BJC-2100 VC BC-21e

BK BC-20

Press and hold the RESET botton for 2 seconds or more

ROM Ver X.XX BC-20 Lost Ink XX.X% Page count-->BK XXXX PB XXXX CL XXXX VC XXXX LD XXXX VL XXXX SC

XXXX

CG ROM Ver X.XX BJYYYYY Wiping yyyy Manual purge yyyy Dry time : OFF Purge Flag : yyy Door :

5. External View / Parts List

••••

Parts List

Key Part Number Rank Q'ty Description Remarks

A Q10-1001-710 N 1 WHOLE UNIT, W/O CARTRIDGE CONTAINER

B QH3-3397 1 AC Adapter 100/120V 50/60HZ LV(USA,CANADA,JAPAN)

QH3-3400 1 AC Adapter 100/120V 50/60HZ HV(Europe)

QH3-3403 1 HV(CHN,ASIA,AUS)

QH3-3404 1 LV(KRN)

QH3-3406 1 HV(TWN)

6. H/W Troubleshooting Flowchart

(Confirmation of the printer when refurbishing)

Yes

Print the "Service Test Print"

Yes

No Yes

Yes

Normal Defective

print ?

Possible to

Open the front cover

Is the waste ink capacit

10% or hi

her ?

print ?

Install the print head

Close the front cover

Connect the computer

with the PARALLEL I/F

Connect the computer

with the USB I/F

performed?

(

Auditoril

Is pur

operation

Possible to

Insert the AC adapter

Replace the print-head and

re-print the "service test print".

* Refer to "4.Service Mode"

regarding printing method.

Doe the CR/LF motor ˝move noisely?

Does the CRG move to the

head replacement position?

Correct?

Correct ?

(Refer to the attached sample)

1) Non ejection of ink

Yes ----------------------------> NG

2) Top margin:

Outside of paper -------------> NG

3) Line

Not connexted ----------------> NG

4) Gray part

If there is black/white line ---> NG

7. Service Information

7.1 Replacement using whole unit

Whole Unit (WHOLE UNIT, W/O CARTRIDGE CONTAINER : Q10-1001-710)

1 Remove the AC adapter from the printer returned from the user.

2 Install the removed AC adapter in the whole unit.

3 Affix the product name label. (The label has been packaged with whole unit)

4 Do 'destination setting'. (See "4.Service Mode" for detail)

< Composition of WHOLE UNIT, W/O CARTRIDGE CONTAINER>

Enclosure

•••• Printer unit (No product name label / No AC adapter)

Paper pick-up tray

Paper output tray

Product name labels

Packing material

7.2 Difference from the BJC-2000/2000SP

BJC-2000/2000SP BJC-2100/2100SP

I/F Parallel I/F Only Parallel and USB I/F

External Color One color Two-toned color

Bottom case, Paper output tray :Gray

Others :Current color

Paper output tray Composed of 3 parts Composed of 2 parts

Elastic Folding

2 flaps No flaps

Spur 13 pcs 7 pcs

Power Supply 30W 18W

Product Life Whichever of the following comes first

Color :6,000 sheets Color :3,000 sheets

Monochro

:20,000 sheets Monochrome :10,000 sheets

Auto cleaning

(Auto purge) Yes No

Yes <--

Yes (By internal timer) Yes (By internal timer or time data from P.C.)

Yes <--

es <--

Power consumption Max Whichever of the following comes first

Turned On

Replace cartridge

By RESET button

Replace Ink tank

Timer(72Hr)

Print dot count

Cover open 10min

Attached Sample (Service Test Print)

tem 1

on e

ect

on o

All

area o

e samp

e as

Check item 2 (Top margin)

Check item 3

(Line)

Check item 4 Check item 4

(Gray part) (Gray part)

ROM Ver x.xx BC-20 LostInk xx.x% PageCount -> BK xxxxx PB xxxxx CL xxxxx VC xxxxx LD xxxxx VL xxxxx SC xxxxx

CG Ver 1.00 BJxxxxx Wiping xxxxxxk ManualPurge xxxxx DryTime : OFF PurgeFlag : xxx Door : CLOSE USBSerialNo. Xxxxxx

Paper size :

XX XX XX XX XX XX XX XX XX XX

Autres manuels pour BJC-2100 Series

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Imprimante

Canon

Canon imageCLASS LBP122dw Manuel utilisateur

Canon

Canon iPF830 Series Manuel utilisateur

Canon

Canon iP90v - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon imageRUNNER ADVANCE DX 8905 Manuel utilisateur

Canon

Canon Color Bubble Jet BJC-5000 Series Manuel utilisateur

Canon

Canon PIXMA iX7000 Manuel utilisateur

Canon

Canon imageCLASS MF5950dw Manuel de service

Canon

Canon S9000 Manuel utilisateur

Canon

Canon PIXMA iX6550 Manuel utilisateur

Canon

Canon imagePROGRAF TM-305 Manuel utilisateur

Canon

Canon iPF710 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon Pixma TR150 Manuel utilisateur

Canon

Canon i-SENSYS MF6180dw Guide d'installation et d'utilisation

Canon

Canon imageRUNNER ADVANCE C5500 Series Manuel utilisateur

Canon

Canon IMAGERUNNER ADVANCE SERIES Guide d'installation

Canon

Canon CP-200 Manuel utilisateur

Canon

Canon 900D - i Color Inkjet Printer Guide de configuration

Canon

Canon LBP-860 Manuel utilisateur

Canon

Canon CP-220 Manuel d'installation et d'exploitation

Canon

Canon imageCLASS MF6500 Series Guide de sécurité

Canon

Canon CR-206 Manuel d'utilisation et d'entretien

Canon

Canon LBP5050 Series Manuel utilisateur

Canon

Canon MG6600 Series Manuel utilisateur

Canon

Canon imagePROGRAF TX-3100 Guide de configuration

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
