User's Guide

Laser Beam Printer

Contents

Turning the Printer ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Tu r ning the Printer ON . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Tu r ning the Printer OFF. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Online and Ofﬂine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Placing the Printer Online . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Placing the Printer Ofﬂine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Paper Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Usable Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Paper Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Paper Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Abbreviations of Paper Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Printable Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Unusable Paper. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Paper Capacity of Paper Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Paper Capacity of the Output Trays. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Loading Paper in the Paper Cassette . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

When Loading Standard Size Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

When Loading Custom Size Paper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Loading Paper in the Multi-purpose Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29

Loading Paper (Other than Postcards and Envelopes) . . . . . . . . . . . . . . . . . 29

Loading Postcards and Envelopes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Paper Jam Area. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Procedure for Clearing Paper Jams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

Replacing the Toner Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

When < トト

トトナナ

ナナーー

ーー

ヨヨ

ヨヨウウ

ウウイイ

イイ／／

／／カカ

カカクク

ククニニ

ニニンン

ンン > Appears . . . . . . . . . . . . . . . . . . . . . 60

Replacing the Toner Cartridge. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Canceling a Job . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Conﬁrming the Printer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Service Call Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Message List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Turning the Printer ON/OFF

The printer can be turned ON/OFF using the power switch on the right side of the

printer body. Be sure to observe the following instructions in order to prevent

unexpected problems.

Turning the Printer ON

To use this printer, press " " of the power switch to turn the printer ON. After running

a self-diagnostic test on the printer unit and optional accessories, the printer will be

ready to print.

IMPORTANT

•

Do not turn the power ON immediately after turning it OFF. If you want to turn the printer

ON again after turning it OFF, wait at least 10 seconds after turning the printer OFF

before turning it ON again.

•

Be sure to set the paper cassette in the printer before you turn the power ON for the ﬁrst

time after you install the printer.

•

Although a sheet of blank paper is output when you turn the power ON for the ﬁrst time

after you install the printer, this is not an error.

Press " " of the power switch on the printer.

The indicators and display on the control panel come on, and the printer initiates a

self-diagnostic test on the printer unit and optional accessories.

If no abnormality is found during the self-diagnostic test, the オンライン indicator, 印

刷可 indicator and Paper Source indicator for the currently selected paper source

come on, <00 インサツカノウ

>, <00 LIPS>, or <00 ESC/P> appears in the

display, and the printer is ready to print.

The following information is displayed in the display.

Turning the Printer OFF

Turn the printer OFF using the following procedure.

IMPORTANT

•

If the printer is used on a network, make sure that it is not printing data from another

computer before turning the power OFF.

•

If you turn the printer OFF when the

ジョブ

indicator is on, all the print data remaining in

the printer memory will be erased. If there is any necessary print data remaining in the

printer, wait until it is output, or press [

リセット

] in the offline state and then select <

ハイ

シュツ

> to output the data before turning the printer OFF.

•

Do not turn the power OFF when the printer is in any of the following status:

-While the printer is in the middle of printing

-While the printer is running a self-diagnostic test immediately after turning the power

-While a message informing you that the NVRAM is being initialized or being written is

displayed

-While <

02 キドウチュウ

> is displayed

Paper Source Indicators

オンライン Indicator

印刷可 Indicator



ｲﾝｻﾂ



ｶﾉｳ



Printable and not

processing print data

Size of paper in the currently

selected paper source

Make sure that the ジジ

ジジョョ

ョョブブ

ブブ

indicator is off.

Press " " of the power switch on the printer.

Off

Online and Ofﬂine

When the printer can receive data from the computer and print the data, the printer

is in the state of "Online", and when the printer is disconnected with the computer

and cannot receive data, the printer is in the state of "Ofﬂine".

To perform the settings for each menu using the control panel, switch the printer

status as follows:

O: The status that you can enter the menu

X: The status that you cannot enter the menu

*You cannot specify the settings in the ユーザメンテナンス

options when the printer is in the online status.

Placing the Printer Online

When printing from the computer, the printer has to be online. Before printing, make

sure that the printer is online. If not, place the printer online using the following

procedure. The printer comes online automatically after you turn it ON.

Press [ オオ

オオンン

ンンララ

ラライイ

イインン

ンン ].

The オンライン

indicator comes on, and the printer is ready to print.

IMPORTANT

When an error is occurring in the printer (when the

メッセージ

indicator is on, or the

number in the message blinks), the printer does not come online. Eliminate the

cause of the error before you place the printer online.

When the printer is online When the printer is ofﬂine

セットアップ

Menu O* O

給紙選択

Menu O O

リセット

Menu O O

ジョブ

Menu O X

ユーティリティ

Menu O X

オンライン

NOTE

If the printer has entered the sleep mode 1, the

オンライン

indicator is off even

when the printer is online, and only the

印刷可

indicator and

主電源

indicator are on.

If the printer has entered the sleep mode 2, only the

主電源

indicator is on. If the

printer receives data while it is in the sleep mode, the mode is released, the

オンラ

イン

indicator comes on, and the printer is ready to print.

Placing the Printer Ofﬂine

To conﬁgure the printer so that it does not receive data from the computer or

specify the settings for all the options in the セットアップ

menu, place the printer

ofﬂine using the following procedure.

Press [ オオ

オオンン

ンンララ

ラライイ

イインン

ンン ].

The オンライン

indicator goes off, allowing you to specify the settings on the control

panel.

IMPORTANT

This printer comes online automatically if left in the ofﬂine state for ﬁve minutes or

longer. However, when an error is occurring in the printer (when the

メッセージ

indicator is on, or the number in the message blinks), or while you are performing

any setting, such as selecting the menu functions or a paper source, or when

specifying the paper size, the printer does not come online automatically.

オンライン

Paper Requirements

Usable Paper

To ensure optimum performance, use only paper that falls within the speciﬁcations

in the following lists. Using inappropriate paper may result in deterioration in print

quality or paper jams.

IMPORTANT

When continuously printing the paper of 200 mm wide or less, the safety function that

prevents damages caused by heat may slow the print speed down in stages. (The print

speed may be as slow as approximately 2 ppm.)

Paper Size

The following shows the paper sizes that can be used with this printer. The symbol

indicates the paper that can be used for 1-sided printing and automatic 2-sided

printing, the symbol O indicates the paper that can be used for only 1-sided

printing, and the symbol X indicates the paper that cannot be used.

Paper Size

Paper Source

Multi-purpose Tray Cassette 1 Cassette 2

(Optional)

B5 O O O

A5 O O O

Legal

Letter

Executive O O O

Custom paper size O*

Postcard

100.0 mm x 148.0 mm OXX

Reply postcard

148.0 mm x 200.0 mm OXX

4 on 1 postcard

200.0 mm x 296.0 mm OXX

You can load paper of the following custom paper sizes.

- When loading paper in portrait orientation: Width 76.2 to 215.9 mm; Length 127.0 to 355.6 mm

- When loading paper in landscape orientation (only when LIPS LX Printer Driver is used): Width 127.0 to 215.9

mm; Length 127.0 to 215.9 mm

You can load paper of the following custom paper sizes.

- When loading paper in portrait orientation: Width 148.0 to 215.9 mm; Length 210.0 to 355.6 mm

- When loading paper in landscape orientation (only when LIPS LX Printer Driver is used): Width 210.0 to 215.9

mm; Length 210.0 to 215.9 mm

Paper Type

The following shows the paper types that can be used with this printer. The symbol

indicates the paper that can be used for 1-sided printing and automatic 2-sided

printing, the symbol O indicates the paper that can be used for only 1-sided

printing, and the symbol X indicates the paper that cannot be used.

■

Plain Paper

This printer can print plain paper that is 76.2 to 215.9 mm wide, 127.0 to 355.6 mm long,

and that weighs between 64 and 80 g/m2, including the standard paper sizes: A4, B5, A5,

Legal, Letter, Executive, Postcard, Reply postcard, and 4 on 1 postcard.

Plain paper can be loaded in the paper cassettes and multi-purpose tray. Additionally,

paper at sizes of A4, Letter, and Legal is available for automatic 2-sided printing.

Envelope

YOUGATA No. 4

105.0 mm x 235.0 mm OXX

YOUGATA No. 2

114.0 mm x 162.0 mm OXX

Paper Type

Paper Source

Multi-purpose Tray Cassette 1 Cassette 2

(Optional)

Plain paper (64 - 80 g/

m2)

Heavy paper (90 - 120 g/

m2)

Heavy paper (121 - 163

g/m2)OXX

Heavy paper (199 g/m2)O X X

Transparency O X X

Label O X X

Postcard O X X

Envelope O X X

Paper Size

Paper Source

Multi-purpose Tray Cassette 1 Cassette 2

(Optional)

■Heavy Paper

This printer can print heavy paper that is 76.2 to 215.9 mm wide, 127.0 to 355.6 mm long,

and that weighs between 90 and 199 g/m2, including the standard paper sizes: A4, B5,

A5, Legal, Letter, Executive, Postcard, Reply postcard, and 4 on 1 postcard. Heavy paper

that weighs between 90 and 120 g/m2can be loaded in the paper cassettes and

multi-purpose tray. Heavy paper that weighs between 121 and 199 g/m2can be loaded in

the multi-purpose tray. Additionally, paper that weighs between 90 and 120 g/m2of A4,

Legal, and Letter sizes is available for automatic 2-sided printing.

■Transparency

This printer can print A4 and Letter size transparencies. Transparencies can be loaded in

the multi-purpose tray.

IMPORTANT

•

Use "A4 size transparencies for LBP recommended by Canon". "A4 size transparencies

for LBP recommended by Canon" weighs 8.7 g per sheet.

•

Thoroughly fan the transparencies before loading them as they may stick to each other.

■Label

This printer can print A4 and Letter size labels. Labels can be loaded in the multi-purpose

tray.

IMPORTANT

•

Use "A4 size labels recommended by Canon". "A4 size labels recommended by Canon"

weighs 7.8 g per sheet.

•

Do not use the labels in the following conditions. Using inappropriate labels may result in

paper jams that are difﬁcult to clear or may result in damage to the printer.

-Peeled labels or partly used labels

- Coated labels that are easily peeled off from the backing sheet

- Labels with uneven adhesive

■Postcard/Reply postcard/4 on 1 postcard

This printer can print postcards, reply postcards, 4 on 1 postcards, and 4 on 1 postcards

recommended by Canon. Load postcards, reply postcards, and 4 on 1 postcards in the

multi-purpose tray with the printing side facing up.

IMPORTANT

•

Printing inappropriate size postcards (other than Postcard, Reply postcard, 4 on 1

postcard, and 4 on 1 postcard recommended by Canon) may result in deterioration in

print quality or paper jams.

•

You cannot print reply postcards with folds.

•

If the postcards are curled, ﬂatten the curls by warping them in the opposite direction

before loading them.

•

Postcards and reply postcards for ink jet printers cannot be printed.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Imprimante

Canon

Canon imagePRESS C1+ Manuel utilisateur

Canon

Canon imagePROGRAF iPF6400SE Manuel utilisateur

Canon

Canon iP5000 - PIXMA Color Inkjet Printer Mode d’emploi

Canon

Canon imageCLASS MPC190 Guide de l'utilisateur

Canon

Canon imagePROGRAF iPF6350 Guide de l'utilisateur

Canon

Canon Oce Arizona 1200 Series Manuel utilisateur

Canon

Canon 2909B002 Manuel utilisateur

Canon

Canon imagePROGRAF TA-30 Manuel utilisateur

Canon

Canon iRC3380 Mode d’emploi

Canon

Canon Color imageRUNNER LBP5970 Manuel utilisateur

Canon

Canon imagePROGRAF iPF8400 Manuel utilisateur

Canon

Canon iP4680 Instructions d'utilisation

Canon

Canon PIXMA PRO-200 Manuel utilisateur

Canon

Canon imageRUNNER 1019j Manuel utilisateur

Canon

Canon iPF655 - imagePROGRAF Color Inkjet Printer Manuel utilisateur

Canon

Canon Laser Shot LBP-1910 Manuel utilisateur

Canon

Canon iP8500 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon BJ-W3000 Manuel utilisateur

Canon

Canon PIXMA E3300 Series Manuel utilisateur

Canon

Canon S820MG Manuel utilisateur

Canon

Canon imagePROGRAF iPF765 Guide de l'utilisateur

Canon

Canon imagePROGRAF W7200 Instructions d'installation et d'entretien

Canon

Canon CP-200 Manuel utilisateur

Canon

Canon PIXMA MP470 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
