Camera User Guide

Please Read This First

This guide explains how to prepare the camera and use its basic features.

ENGLISH

Basic

The following guides are available. Refer to them as necessary according to the

flowchart below.

Flowchart and Reference Guides

System Map

Basic Camera User

Guide (This Guide)

• Read this first.

Advanced Camera

User Guide

Direct Print User

Guide

Basic Camera User

Guide (This Guide)

Software Starter Guide

ZoomBrowser EX/

ImageBrowser Software

User Guide

• PDF manuals available on

the Canon website.

http://web.canon.jp/Imaging/

information-e.html

For information on included items and

items sold separately

The Components Guide

Preparations

• Charging the battery

• Installing the battery and memory card

• Setting the date, time and language

Shooting

Playback/Erasing

Menus and Settings

Handling precautions, references to the

various shooting and playback functions

Printing

• Installing the software

• Downloading images to a computer

• Using the software

In this guide, the Basic Camera User Guide is called the Basic Guide, and the Advanced

Camera User Guide is called the Advanced Guide. Also, "battery" refers to the battery pack.

You may not be able to achieve the full

performance of this camera with the

included memory card.

Front View

Wrist Strap Mount

Microphone (Advanced Guide pp. 41, 90, 91)

AF-assist Beam (Advanced Guide p. 24)

Red-Eye Reduction Lamp (Advanced Guide p. 35)

Self-Timer Lamp (p. 17)

Flash (p. 15)

Speaker

Lens

The Components Guide

In order to avoid dropping the camera, wear the wrist strap

when using the camera.

cde g

Attaching the Wrist Strap How to Open the Terminal Cover

Toggle

The toggle's position on

the strap can be

changed. It can also be

used to open the

DIGITAL terminal cover

and when inserting or

removing a memory

card.

The Components Guide

Back View

LCD Monitor (Advanced Guide pp. 12, 15)

DIGITAL Terminal (p. 28)

A/V OUT (Audio/Video output) Terminal (Advanced Guide p. 101)

Terminal Cover

Tripod Socket

DC Coupler Terminal Cover (Advanced Guide p. 131)

Memory Card Slot/Battery Cover (p. 7)

The interface cable and AV cable cannot be connected

simultaneously.

The LCD monitor may be covered with a thin plastic film

for protection against scratches during shipment. If so,

remove the film before using the camera.

Controls

Mode Switch (pp. 11, 12)

Power Button (p. 11)

Zoom Lever (p. 15, Advanced Guide p. 76)

Shooting: (Wide Angle)/ (Telephoto)

Playback: (Index)/ (Magnify)

Shutter Button (p. 11)

(Print/Share) Button (pp. 23, 31, Advanced Guide pp. 66, 67)

Playback Button (pp. 10, 19, Advanced Guide pp. 76, 100)

FUNC./SET (Function/Set) Button (p. 21, Advanced Guide p. 22)

Touch Control Dial (p. 4)

Indicator (p. 5)

MENU Button (p. 22, Advanced Guide p. 23)

DISP. (Display) Button (Advanced Guide p. 12)

(Macro)/ (Infinity)/ Button (p. 16)

(ISO Speed)/ (Jump)/ Button (Advanced Guide pp. 65, 79)

(Flash)/ Button (p. 15)

(Continuous)/ (Self-timer)/ (Single Image Erase)

/ Button (pp. 17, 20, Advanced Guide p. 36)

b d

i j

The Components Guide

Using the Touch Control Dial

Touching the Dial

A magnified image of the touch control dial displays on the LCD

monitor when you place your finger on the dial. Circling your finger on

the dial allows you to configure the functions assigned to each button.

Circling Your Finger on the Dial

You can select categories or images by circling your finger on the dial.

Circling counterclockwise works the same as the button and

circling clockwise the same as the button. (It may also work as the

/ buttons with some functions.)

• Functions that cannot be configured are shown in gray.

• The dial display (Touch Icons) can be turned On/Off in

the (Set up) menu (Advanced Guide p. 26).

• When Touch Icons is set to [Off], the icon of the function

being touched appears in green on the LCD monitor.

Touch Icons

Sample in shooting mode

Screen shot of selecting

a shooting mode

The following functions can be operated using the touch control dial.

Please note that some of the options for some functions cannot be

operated with it.

Indicator

The camera indicator lights or blinks under the following circumstances.

Operable Functions

Reference Page

Basic Advanced

Shooting

Selecting a shooting mode

p. 12 –

Selecting / / / / /

pp. 15,

16, 17

pp. 36, 65

Selecting options in the FUNC. menu

p. 21 p. 22

Playback

Selecting images

p. 19 pp. 76, 77,

78, 79, 98,

102

Operations for playing/editing movies

– pp. 80, 82

Operations for sound memos and the

Sound Recorder

–pp. 90, 91

Operations for DPOF print settings and

direct transfer settings. –pp. 104,

108

Shooting

and

Playback

Selecting options in menus

p. 22 p. 23

Selecting time zones for the world clock – p. 20

Selecting options for the My Camera settings

–p.110

Never do the following while the indicator is blinking green.

These actions may corrupt image data.

• Shake or jolt the camera

• Shut off the power, or open the memory card slot/battery cover

Green: Ready to shoot (camera beeps twice)*/

connected to computer/display off (Advanced

p. 26)

Blinking Green:

Camera starting up/Time Lapse (movie) recording/

Image recording/reading/erasing/transferring (when

connected to a computer/printer)

Orange: Ready to shoot (flash on)

Blinking Orange: Ready to shoot (camera shake warning)

* Camera beeps once if difficult to focus.

The Components Guide

Charging the Battery.

Charge the battery before use under the following circumstances.

• When using the battery for the first time.

• When the "Change the battery pack." message displays.

1. Insert the battery into the battery charger.

2. Plug the battery charger (CB-2LV) into a power outlet, or

attach the power cord to the battery charger (CB-2LVE) and

plug it into a power outlet.

Battery charger model names and types vary by region.

The charge indicator will light orange while the battery is

charging. It will change to green when the charge is complete.

Charging takes approximately 1 hour 30 minutes.

Preparations

To protect the battery and prolong its life, do not charge it for

longer than 24 hours continuously.

See the Advanced Guide: Battery Handling (p. 127).

Charge Indicator

Align these symbols For CB-2LV For CB-2LVE

Installing the Battery.

1. Slide the memory card slot/battery cover and open it (

2. Push the battery lock in the direction of the arrow (

) and

insert the battery until it locks.

To remove the battery, push the battery lock in the direction of

the arrow (

) and hold it while pulling the battery out.

Inserting the Memory Card.

1. Insert the memory card until it clicks into place.

2. Close the memory card slot/battery cover (

Ensure that the memory card is correctly oriented before

inserting it in the camera. Inserting it backward may cause

the camera to fail to recognize the memory card or to

malfunction.

See the Advanced Guide: Handling the Memory Card (p. 129).

See the Advanced Guide: Formatting Memory Cards (p. 29).

Battery Lock

Front

Preparations

To Remove the Memory Card

Push the memory card with your finger or the toggle on the wrist strap

until the memory card clicks and then release it.

First Time Settings

Setting the Date/Time

1. Press the power button (

2. Use the or button to select an item and the or

button to change its value (

To set the daylight saving option, select the icon and use the

or button to configure the setting.

3. Confirm that the correct time is displayed and press the

FUNC./SET button (

The date and time can also be set in the Set up menu (p. 22).

You can use SD memory cards, SDHC memory cards and

MultiMediaCards with this camera. These cards are collectively

called memory cards in this guide.
