Canon EOS 70D (W) Manuel utilisateur

In this booklet, basic procedures for easy-to-use “Transferring

Images between Cameras” and “Connecting to a smartphone”

functions are explained.

For detailed explanation about Wi-Fi functions, refer to “Wi-Fi

Function Instruction Manual” included in the Camera Instruction

Manual CD-ROM.

Wi-Fi Function

Basic Instruction Manual

EOS 70D (W)

INSTRUCTION

MANUAL

This camera’s wireless LAN functions let you perform a range of tasks

wirelessly, from sending images to Web services and other cameras to

controlling the camera remotely, simply by connecting to a Wi-Fi

network or other device supporting this camera’s wireless LAN functions.

* Instructions for (3) to(6) and for (2) toconnect via an access point are explained

in the “Wi-Fi Function Instruction Manual” (PDF) in the CD-ROM.

What You Can Do Using the Wireless LAN Functions

(1)Transfer images

between cameras

Exchange images

(6)View images using

a media player

View images

(5)Send images to

a Web service

Save and share images

(4)Operate the camera

remotely using EOS Utility

Remotely control the camera

(3) Print images using

a Wi-Fi printer

Print images

(2) Connect to a

smartphone

Make images

viewable on a

smartphone

Shoot remotely

with a smartphone

(Canon Image Gateway)

What You Can Do Using the Wireless LAN Functions

(1)z Transfer images between cameras (p.15)

Transfer images between this camera and other Canon cameras

with built-in wireless LAN functions.

(2)q Connect to a smartphone (p.23)

View saved images or operate the camera from your smartphone.

Install the dedicated application “EOS Remote” on your smartphone

to use these functions.

(3)l Print images using a Wi-Fi printer (CD-ROM)

Connect the camera to a wireless LAN compatible printer supporting

PictBridge (Wireless LAN) to print images wirelessly.

(4)DOperate the camera remotely using EOS Utility (CD-ROM)

Connect the camera and a computer wirelessly and operate your

camera remotely using the provided software EOS Utility.

(5)wSend images to a Web service (CD-ROM)

Upload your images to CANON iMAGE GATEWAY, an online photo

service for Canon users (free registration required), to share them

with family and friends.

(6) View images using a media player (CD-ROM)

Display images on the camera’s memory card on your TV set, by

using a media player supporting DLNA* via a wireless LAN.

* Digital Living Network Alliance

In this manual, the term “wireless LAN” is used as a general term for

Wi-Fi and Canon’s original wireless communication functions.

The ** (numbers) for “(p.**)” in this manual indicate reference page

numbers for more information.

Sections of this manual labeled with the following symbols contain

particular types of information as described below.

Warnings to prevent potential problems during operation.

Additional information provided to supplement the content about

basic operations.

Conventions Used in This Manual

Microsoft and Windows are trademarks or registered trademarks of

Microsoft Corporation in the United States and/or other countries.

Macintosh and Mac OS are trademarks of Apple Inc., registered in the U.S.

and other countries.

Wi-Fi is a registered trademark of the Wi-Fi Alliance.

Wi-Fi Certified, WPA, WPA2, and the Wi-Fi Certified logo are trademarks of

the Wi-Fi Alliance.

WPS used on camera settings screens and in this manual stands for Wi-Fi

Protected Setup.

UPnP is a trademark of the UPnP Implementers Corporation.

All other trademarks are the property of their respective owners.

Note that Canon cannot be held liable for any loss or damage from erroneous

wireless LAN settings for using the camera. In addition, Canon cannot be held

liable for any other loss or damage caused by use of the camera.

Introduction 2

What You Can Do Using the Wireless LAN Functions .....................2

Conventions Used in This Manual....................................................4

Basic Settings for Wireless LAN Functions 7

Registering a Nickname....................................................................8

Basic Operation and Settings .........................................................11

Transferring Images Between Cameras 15

Selecting the Connection Destination.............................................16

Sending Images..............................................................................18

Reconnecting..................................................................................21

Connecting to a Smartphone 23

Preparation .....................................................................................24

Using Camera Access Point Mode to Establish a Connection .......25

Operating the Camera Using a Smartphone...................................28

Reconnecting..................................................................................30

Wireless LAN (Wi-Fi) ......................................................................31

Contents

MEMO

Basic Settings for

Wireless LAN Functions

This chapter describes settings necessary for using the

camera’s wireless LAN functions.

First, set the camera’s nickname.

When the camera is connected to another device via a wireless LAN,

the nickname will be displayed on the device. Be sure to set a nickname

for your camera.

1Select [Wi-Fi].

Under the [53] tab, select [Wi-Fi],

then press <0>.

2Select [Enable].

Press the <V> key to select

[Enable], then press <0>.

X[Wi-Fi function] is now selectable.

3 Select [Wi-Fi function].

Under the [53] tab, select [Wi-Fi

function], then press <0>.

XWhen this setting is selected for the

first time, a screen to register a

nickname is displayed. Select [OK]

and proceed on to step 4.

Registering a Nickname

4Enter a nickname.

For instructions on entering

characters, see “Virtual Keyboard

Operation” on the next page.

Up to 16 characters can be entered.

5Finish.

When you are finished, press the

<M> button.

Select [OK] on the confirmation

screen, then press <0>. The

nickname is registered, and the [Wi-

Fi function] screen will appear.

To change the nickname, press the

<B> button on the screen above,

then select [Edit nickname] on the

screen displayed.

Registering a Nickname

Switching to other input areas

To switch between top and bottom

input areas, press the <Q> button.

Moving the cursor

To move the cursor, press the <U>

key in the top area.

Entering text

In the bottom input area, press the <V> or <U> key to select

characters and press <0> to enter them.

You can check how many characters you have entered, and how

many more can be entered, by referring to [*/*] on the upper right of

the screen.

Switching to other input modes*

Select [ ] at the lower right of the bottom area. Each time you

press <0>, the input mode changes. The input mode changes in

the following order: lower-case characters9numbers/symbols 1

9numbers/symbols 29upper-case characters.

* When [Touch control: Disable] is set, you can enter all characters on one

screen.

Deleting text

Press the <L> button to erase one character.

Finishing text entry

Press the <M> button to confirm what you have entered and

exit. If a confirmation screen is displayed, select [OK] to exit.

Canceling text entry

Press the <B> button to cancel text entry and exit. If a

confirmation screen is displayed, select [OK] to exit.

Virtual Keyboard Operation
