Canon EO-1Ds Mode d’emploi

EOS-1Ds

REF.NO.C12-6021

CANON Ni-MH PACK NP-E3 C50-8041,2

CANON NECK STRAP L4 C56-1731

CANON INTERFACE CABLE C50-8081

IFC-450D6

CANON DC COUPLER KIT C50-8051

DCK-E1

PARTS

CATALOG

CANON DIGITAL CAMERA EOS-1Ds

REF. NO. C12-6021

(See Pg. 7)

(See Pg. 2)

XA1-7170-207 x2

XA1-7170-207 x4

XA1-7170-707

CB4-0038 x4

XA1-7170-457 x2

XA1-7170-707

XA1-7170-457

XA1-7170-307

CB3-0108

CB3-0203

CY3-1425

CB3-0109

CB3-0184

CB3-0146

CB3-0168

CB3-0171

CB3-0172

CB3-0167

CB3-0147

CB3-0188

CB3-0210

CB3-0110

CB3-0102

CB3-0123

CG2-0732

REF.NO.C12-6021

PARTS LIST

PG1

NEW PARTS No. CLAS

QTY DESCRIPTION

CB3-0102-000 B1

COVERING, BACK

CB3-0108-000 B1

TAPE, DOUBLE SIDED 1

(

BACK

)

CB3-0109-000 B1

TAPE, DOUBLE SIDED 2

(

BACK

)

CB3-0110-000

B1TAPE, DOUBLE SIDED 3 (BACK)

CB3-0123-000 B1

COVERING, CF

CB3-0146-000 A1 SEAL, BACK BOTTOM-TR

CB3-0147-000 A1 SEAL, BACK BOTTOM-GR

CB3-0167-000 B1

COVERING, FRONT

CB3-0168-000 B1

TAPE, DOUBLE SIDED

(

FRONT

)

CB3-0171-000 C1

CAP, TERMINAL

CB3-0172-000 C1

CAP, PC-REMOTE

CB3-0184-000 A1SEAL, O RING TRIPOD

CB3-0188-000 B1

COVERING, BOTTOM

CB3-0203-000 C 1 CAP, BATTERY

CB3-0210-000

C2TAPE, DOUBLE SIDED (TRIPOD)

CB4-0038-000 C4

SCREW, CROSS-RECESS, PH

CG2-0732-000 B1 B-CONT HOLDER UNIT

*CY3-1425-000

NAME, PLATE

XA1-7170-207 F 6 SCREW, CROSS-RECESS, PH

XA1-7170-307

F1SCREW, CROSS-RECESS, PH

XA1-7170-457 F 3 SCREW, CROSS-RECESS, PH

XA1-7170-707 F 2 SCREW, CROSS-RECESS, PH

CANON DIGITAL CAMERA EOS-1Ds

REF. NO. C12-6021

A 0.015 SIZE

0.03mm (003)

CB3-0060-000(XXX) detail

0.05mm (005)

0.08mm (008)

0.10mm (010)

0.12mm (012)

0.15mm (015)

0.18mm (018)

0.20mm (020)

(See detail)

(See Pg. 3)

CB3-0164 CB3-0165

CB3-0166

CB3-0073

CB3-0677

CY3-1426

CG2-0899

N.S

CB3-0060-000 x3

XA1-7170-357 x3

REF.NO.C12-6021

PARTS LIST

PG2

NEW PARTS No. CLAS

QTY DESCRIPTION

CB3-0060-000

(

XXX

)

WASHER, FLANGE BACK

CB3-0073-000 C 2 SCREW, CROSS-RECESS, PH

CB3-0164-000 B 1 COVERING, GRIP

CB3-0165-000

B1TAPE, DOUBLE SIDED1 GRIP

CB3-0166-000

B1TAPE, DOUBLE SIDED2 GRIP

*CB3-0677-000 C2

SPRING, LOW PASS FILTER

*CG2-0899-000 B 1 PCB ASS'Y, IMAGE

*CY3-1426-000 B 1 FILTER ASS'Y, LOW PASS

XA1-7170-357 F 3 SCREW, CROSS-RECESS, PH

CANON DIGITAL CAMERA EOS-1Ds

REF. NO. C12-6021

(See Pg. 9)

(See Pg. 4)

(See Pg. 8)

CB1-9282

CB1-9367

CB1-9168

CB1-9367

CB1-9373

CB1-9195

CB1-9196

CB1-9373

CB3-0038

CB1-4255

CB3-0143

CB4-0038 x3

CB1-8581

CG2-0898

CA1-9402 x2

CB1-7982 x2

XA1-7170-507 x2

CB1-7982 x2

CB3-0130 x2

REF.NO.C12-6021

PARTS LIST

PG3

NEW PARTS No. CLAS

QTY DESCRIPTION

CA1-9402-000 C2

SCREW, CROSS-RECESS, PH

CB1-4255-000 C1

SCREW, CROSS-RECESS, PH

CB1-7982-000 C6

SCREW, CROSS-RECESS, PH

CB1-8581-000 C 1 SCREW, CROSS-RECESS, PH

CB1-9168-000 C1

EYEPIECE SH LEVER

CB1-9195-000 C1

MASK, OLC

CB1-9196-000 C1

WINDOW, OLC

CB1-9282-000 C1

SCREW, CROSS-RECESS, PH

CB1-9367-000 B2

DIAL O-RING

CB1-9373-000 C2

EYEPIECE SLIDER

CB3-0038-000 C1

DIAL, EYEPIECE　

DJUSTING

CB3-0130-000 B 2 SHIELD, LIGHT (OLC)

CB3-0143-000 A1 SEAL, TOP-CAP

CB4-0038-000 C 3 SCREW, CROSS-RECESS, PH

*CG2-0898-000 C 1 EYEPIECE COVER UNIT

XA1-7170-507 F 4 SCREW, CROSS-RECESS, PH

CANON DIGITAL CAMERA EOS-1Ds

REF. NO. C12-6021

(See Pg. 5)

CB1-2678 x2

CB4-0038 x2

XA1-7170-257 x4

XA1-7170-257 x2

XA1-7170-407 x2

XA1-7170-407 x4

XA1-7170-257 x2

XA1-7170-357 x2

XA1-7170-167 x2

N.S

CG2-0748

CG2-0889

CG2-0891

CG2-0888

CG2-0890

CG2-0892

CG2-0725

N.S

REF.NO.C12-6021

PARTS LIST

PG4

NEW PARTS No. CLAS

QTY DESCRIPTION

CB1-2678-000 C 4 SCREW, CROSS-RECESS, PH

CB3-0211-000 C 1 SEAL, INSULATING DC/DC

CB4-0038-000 C 2 SCREW, CROSS-RECESS, PH

CB4-0423-000 C 1 COVER, BATTERY

*CG2-0888-000 B1

PCB ASS'Y, D1

*CG2-0889-000 B1

PCB ASS'Y, D2

*CG2-0890-000 B 1 PCB ASS'Y, D3

*CG2-0891-000 B 1 PCB ASS'Y, D4

*CG2-0892-000 B1

PCB ASS'Y, DC/DC

CG2-0725-000 C1

BATTERY PLATE UNIT

CG2-0748-000 C1

PCB ASS'Y, ＣF

*CH1-8075-000 C 1 FPC, A-D2

XA1-7170-167 F 2 SCREW, CROSS-RECESS, PH

XA1-7170-257 F 8 SCREW, CROSS-RECESS, PH

XA1-7170-357 F 2 SCREW, CROSS-RECESS, PH

XA1-7170-407 F 10 SCREW, CROSS-RECESS, PH

CANON DIGITAL CAMERA EOS-1Ds

REF. NO. C12-6021

CB3-0228 x2

CB1-8592

CB3-0223 x2

CA1-7531 x2

XA1-1200-959 x2

XA1-7170-507 XA1-7170-307

XA1-7170-507 x2

XA1-7170-357

XA1-7200-507 x2

XA1-7140-307 N.S

N.S

CG2-0878

CG2-0897

CG2-0872

CG2-0723

N.S

(See Pg. 6)

(MAIN PCB)

(See Pg. 12)

(See Pg. 10)

(See Pg. 11)
