Canon 0298B002 Manuel utilisateur

PRINTED IN CHINA

CT1-7794-000 © CANON INC. 2008

2008.05

English

INSTRUCTION MANUAL

CANON INC. 30-2, Shimomaruko 3-chome, Ohta-ku, Tokyo 146-8501, Japan

U.S.A. CANON U.S.A. INC.

One Canon Plaza, Lake Success, NY 11042-1198, U.S.A.

For all inquires concerning this product, call toll free in the U.S.

1-800-OK-CANON

CANADA CANON CANADA INC. HEADQUARTERS

6390 Dixie Road, Mississauga, Ontario L5T 1P7, Canada

CANON CANADA INC. MONTREAL BRANCH

5990, Côte-de-Liesse, Montréal Québec H4T 1V7, Canada

CANON CANADA INC. CALGARY OFFICE

2828, 16th Street, N.E. Calgary, Alberta T2E 7K7, Canada

For all inquiries concerning this product, call toll free in Canada

1-800-OK-CANON

EUROPE, CANON EUROPA N.V.

AFRICA & Bovenkerkerweg 59-61, P.O. Box 2262, 1180 EG Amstelveen, The Netherlands

MIDDLE EAST CANON COMMUNICATION & IMAGE FRANCE S.A.S.

12 Rue de l’Industrie 92414 Courbevoie Cedex, France

CANON UK LTD.

Woodhatch Reigate Surrey RH2 8BF, United Kingdom

CANON DEUTSCHLAND GmbH

Europark Fichtenhain A10, 47807 Krefeld, Germany

CANON ITALIA S.p.A.

Via Milano 8 I-20097 San Donato Milanese, Milano, Italy

CANON Schweiz AG

Geschäftsbereich Wiederverkauf, Industriestrasse 12, CH-8305 Dietlikon, Switzerland

CANON GMBH

Zetschegasse 11, A-1230 Wien, Austria

CANON España, S. A.

C/Joaquín Costa, 41, 28002 Madrid, Spain

SEQUE Soc. Nac. de Equip., Lda.,

Praça da Alegria, 58, 2°, 1269-149 Lisboa, Portugal

CENTRAL & CANON LATIN AMERICA, INC.

SOUTH AMERICA 703 Waterford Way, Ste. 400 Miami, FL 33126, U.S.A.

ASIA CANON (China) Co., Ltd.

15F Jinbao Building No.89 Jinbao Street, Dongcheng District, Beijing 100005, China

CANON HONGKONG CO., LTD.

19/F., The Metropolis Tower, 10 Metropolis Drive, Hunghom, Kowloon, Hong Kong

CANON SINGAPORE PTE. LTD.

1 HarbourFront Avenue, #04-01 Keppel Bay Tower, Singapore 098632

CANON KOREA CONSUMER IMAGING INC.

Startower Bldg.17F,737,Yeoksam-Dong, Kangnam-Ku, Seoul, 135-984, Korea

OCEANIA CANON AUSTRALIA PTY. LTD.

1 Thomas Holt Drive, North Ryde, N.S.W. 2113, Australia

CANON NEW ZEALAND LTD.

Akoranga Business Park, Akoranga Drive, Northcote, Auckland, New Zealand

JAPAN CANON MARKETING JAPAN INC.

16-6, Kohnan 2-chome, Minato-ku, Tokyo 108-8011, Japan

COPY

English

A81_00.fm Page 1 Tuesday, February 5, 2008 2:33 PM

COPY

Thank you for purchasing a Canon product.

The Canon Speedlite 430EX II is a multi-feature flash unit for Canon

EOS cameras. It works automatically with E-TTL II, E-TTL, and TTL

autoflash systems. It can be used as an on-camera flash or as part of a

wireless flash system.

Read this instruction manual while also referring to your

camera’s instruction manual.

Before using the Speedlite, read this instruction manual and your camera’s

instruction manual to familiarize yourself with the Speedlite operations.

The basic operation is the same as with normal AE shooting.

When the 430EX II is attached to an EOS camera, almost all automatic

exposure control for flash photography is handled by the camera.

Although the 430EX II is an external flash unit, it works automatically and

seamlessly like the camera’s built-in flash.

It becomes automatically compatible with the camera’s flash

metering mode (E-TTL ll, E-TTL, and TTL).

In accordance with the camera’s flash control system, the Speedlite controls

the flash automatically in the respective flash metering mode:

1. E-TTL II autoflash (evaluative flash metering with preflash reading/lens

distance information)

2. E-TTL autoflash (evaluative flash metering with preflash reading)

3. TTL autoflash (off-the-film metering for real-time flash metering)

Regarding the camera’s available flash metering modes, refer to the

“External Speedlite” specification in the “Specifications” of your

camera’s instruction manual.

In the camera instruction manual, cameras having flash metering

modes 1 or 2 are called Type-A cameras (compatible with E-TTL II or

E-TTL). And cameras having flash metering mode 3(compatible only

with TTL) are Type-B cameras.

* This instruction manual assume that you are using the Speedlite with a Type-A

camera.

For Type-B cameras, see page 37.

A81_00.fm Page 2 Wednesday, February 6, 2008 5:45 PM

COPY

The operation procedures in this instruction manual assume that both

the camera and Speedlite’s power switches are ON.

Icons used in the text to indicate the respective buttons, dials, and

settings match the same icons found on the camera and Speedlite.

The (4) / (0) / (3) icons indicate that the respective function

remains in effect for 4 sec., 6 sec., or 16 sec. after you let go of the

button.

Reference page numbers are indicated by (p.**).

This instruction manual uses the following alert symbols:

: Warning to prevent shooting problems.

: Gives supplemental information.

Contents

Conventions Used in this Manual

The <9> symbol in the text refers to the +/– button.

The <8> symbol in the text refers to the Select/

Setting button.

1Getting Started and Basic Operation................................. 7

2Using Flash ........................................................................ 13

3Wireless Flash ................................................................... 25

Reference ............................................................................ 32

A81_00.fm Page 3 Thursday, February 14, 2008 11:19 AM

COPY

Nomenclature

Built-in wide panel

(retracted) (p.18)

Flash head

Wireless sensor

AF-assist beam emitter

(p.23)

Mounting foot (p.9)

Locking pin Contacts

Bracket mount

cover

Bracket mounting hole

Case Mini stand

Mini stand pocket

Shoe

A81_00.fm Page 4 Wednesday, February 6, 2008 5:48 PM

COPY

LCD panel (p.6)

* <A>

LCD panel illumination/

Custom Function

setting button (p.6/21)

* <8> Select/Setting button

<J>

Pilot lamp/

Test firing button (p.10)

<D>

Flash mode/Slave setting button

(p.11, 19/31)

<z>

Bounce lock release

button (p.17)

Bounce angle index

<G>

Zoom button/Wireless setting

button (p.18/26, 29, 30)

<E>

High-speed

sync (FP flash)/Shutter

curtain synchronization

button (p.16)

Flash exposure

confirmation lamp (p.11)

Battery compartment cover

(p.8)

Lock-release button (p.9)

Power switch (p.10)

Mounting foot’s lock lever

(p.9)

<9> +/– button

Asterisked buttons have functions which remain active for 8 sec. after you

press and let go of the button. The <B> illumination lasts for 12 sec.

A81_00.fm Page 5 Thursday, February 14, 2008 11:31 AM

COPY

LCD Panel

To illuminate the LCD panel, press the <B> button.

The items actually displayed depend on the current settings.

Manual flash output level

Flash exposure compensation

amount

Max. flash range

Aperture

Custom Function

<d> Manual zoom

<c> High-speed

sync (FP flash)

<f>

Flash exposure

compensation

<u> Custom Function

<r> Second-curtain sync

<q> Manual flash

<a/b>

E-TTL (ll)/TTL autoflash

<X> Slave flash

Channel

<s> Auto zoom

for image sensor

size

Indicator (feet)

Indicator (meters)

Slave ID

Zoom focal length

A81_00.fm Page 6 Thursday, February 14, 2008 11:31 AM

COPY

Getting Started and

Basic Operation

Installing the Batteries ............................................ 8

Attaching and Detaching the Flash......................... 9

Turning on the Power Switch................................ 10

Fully Automatic Flash Shooting ............................. 11

Using E-TTL II and E-TTL Autoflash in the

Shooting Modes.................................................... 12

To avoid overheating and degrading the flash

head, do not fire more than 20 continuous

flashes. After 20 continuous flashes, allow a rest

time of at least 10 min.

If you fire more than 20 continuous flashes and

then fire more flashes in short intervals, the

inner overheating prevention function may be

activated to make the recycling time about 8 to

20 sec. If this occurs, allow a rest time of about

15 min. and the flash will then return to normal.

Cautions for firing continuous flashes

A81_01.fm Page 7 Tuesday, February 5, 2008 2:33 PM

COPY

Install four size-AA batteries.

1Open the cover.

Slide the battery compartment cover

as shown by the arrow and open it.

2Install the batteries.

Make sure the + and – battery

contacts are correctly oriented as

shown in the battery compartment.

3Close the cover.

Close the battery compartment cover

and slide it as shown by the arrow.

Recycling Time and Flash Count

Based on new size-AA alkaline batteries and Canon’s testing standards.

Installing the Batteries

Recycling Time (Approx.) Flash Count (Approx.)

0.1 - 3.0 sec. 200 - 1400

Using size-AA batteries other than the alkaline type may cause improper

battery contact due to the irregular shape of the battery contacts.

If you change the batteries after firing many flashes continuously, be

aware that the batteries might be hot.

Use a new set of four batteries of the same brand. When replacing the

batteries, replace all four at one time.

Size-AA Ni-MH or lithium batteries can also be used.

A81_01.fm Page 8 Wednesday, February 6, 2008 5:49 PM

COPY

1Attach the Speedlite.

Slip the Speedlite’s mounting foot into

the camera’s hot shoe all the way.

(The mounting foot will protrude

slightly from the hot shoe.)

2Secure the Speedlite.

On the mounting foot, slide the lock

lever to the right.

XWhen the lock lever clicks in place, it

will be locked.

3Detach the Speedlite.

While pressing the lock-release

button, slide the lock lever to the left

and detach the Speedlite.

Attaching and Detaching the Flash

Before attaching or detaching the Speedlite, be sure to turn off the Speedlite.

A81_01.fm Page 9 Tuesday, February 5, 2008 2:33 PM

COPY

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Canon Flash de l'appareil photo

Canon

Canon MR-14EXl Manuel utilisateur

Canon

Canon Macro Ring Lite MR-14EX Manuel utilisateur

Canon

Canon 580EX - Speedlite II - Hot-shoe clip-on... Manuel utilisateur

Canon

Canon Speedlite 430EX 2 Manuel utilisateur

Canon

Canon SPEEDLIGHT 550EX Manuel utilisateur

Canon

Canon Speedlite 430EX II Manuel utilisateur

Canon

Canon SPEEDLIGHT 420ex Manuel utilisateur

Canon

Canon 600EXII-RT Manuel utilisateur

Canon

Canon 220EX - Speedlite - Hot-shoe clip-on Flash Mode d’emploi

Canon

Canon Speedlite 188A Manuel utilisateur

Canon

Canon Speedlite 133 D Manuel utilisateur

Canon

Canon Speedlite 420EX Manuel utilisateur

Canon

Canon 50/50e Manuel utilisateur

Canon

Canon 220EX - Speedlite - Hot-shoe clip-on Flash Manuel utilisateur

Canon

Canon Speedlite EL-5 Instructions de montage

Canon

Canon Speedlite 244 T Manuel utilisateur

Canon

Canon Speedlite 420 EZ Manuel utilisateur

Canon

Canon 580EX - Speedlite II - Hot-shoe clip-on... Manuel utilisateur

Canon

Canon 540EZ - Speedlite - Hot-shoe clip-on Flash Manuel utilisateur

Canon

Canon Speedlite 420EX Manuel utilisateur

Canon

Canon 220EX - Speedlite - Hot-shoe clip-on Flash Manuel utilisateur

Canon

Canon Speedlite 380EX Manuel utilisateur

Canon

Canon SPEEDLITE 270EX II Manuel utilisateur

Canon

Canon Speedlite 600EX-RT Manuel utilisateur

Manuels Flash de l'appareil photo populaires d'autres marques

Sigma

Sigma EF-610 DG SUPER - Manuel utilisateur

Godox

Godox DP300 Manuel utilisateur

Sony

Sony HVL-FDH4 Manuel utilisateur

Sony

Sony HVL-RLA Manuel utilisateur

Nikon

Nikon SB-28 Manuel utilisateur

Olympus

Olympus FL 36R Manuel utilisateur

Nikon

Nikon BC-7 Manuel utilisateur

Altura Photo

Altura Photo AP-305N Manuel utilisateur

Nikon

Nikon SB-800 Manuel utilisateur

DÖRR

DÖRR DFX-300 Manuel utilisateur

Sunpak

Sunpak 622 Super Pro-System Manuel utilisateur

Polaroid

Polaroid PL108-AF Manuel utilisateur

Godox

Godox Thinklite TT350P Manuel utilisateur

Pentax

Pentax AF240Z Manuel utilisateur

Pixapro

Pixapro Li-ion 350 II N Manuel utilisateur

Opus

Opus OPL-M40 Manuel utilisateur

Nissin

Nissin Mark II Di866 Pofessional Manuel utilisateur

Nikon

Nikon Speedlight SB-700 Manuel utilisateur
