Canon PIXMA MX882 Series Manuel utilisateur

<< Previous Next >>

Getting Your Multifunction

Back On Your Network

After A Router Or Network Change

PIXMA MX882

Windows & Mac OS

If any of the following situations exist

•You have replaced your Router or Access Point

•You want to use a different wireless network

•Router settings have been changed.

Please complete the following steps to apply the new

configuration settings to your multifunction.

<< Previous Next >>

Preparing to Connect My Multifunction

To My Network

Network Requirements

Before connecting the machine to the network, make sure that configuration of the computer and access point or router is

complete, and that the computer is connected to the network.

<< Previous Next >>

Preparing to Connect My Multifunction

To My Network

Notes on Network Connection

•The configuration, router functions, setup procedures and security settings of

the network device vary depending on your system environment. For details,

refer to your device's instruction manual or contact its manufacturer.

•In an office setup, consult your network administrator

•If you connect to a network that is not protected with security measures,

there is a risk of disclosing data such as your personal information to a third

party.

•If an error message appears or if you have trouble with the network

connection, refer to the printed manual: Network Setup Troubleshooting.

•Place the machine and computer on the same network segment.

An "Ad-hoc connection," which establishes a direct

connection to the computer over a wireless connection

without using an access point, is not supported.

Be sure to prepare an access point.

<< Previous Next >>

Preparing to Connect My Multifunction

To My Network

<< Previous Next >>

Before you continue, please gather the following information which will be required to

connect your multifunction to your network. This information will be entered on the

machine's operation panel.

•Access Point /Network Name: also referred to as the SSID, an identifier to identify

the specific access point

•Network Key: also referred to as an encryption key, WEP key or WPA/WPA2

passphrase, Per-Shared key. A password required to access the wireless network

If you do not know your Access Point/Network Name or your Network Key, use the

following links for information on using our Canon PIXMA Wireless Setup Assistant.

•Windows Users Click Here

•Mac Users Click Here

Adding Your Multifunction to Your Network

Step One

Press the Setup button (A)

Step Two

Use the or button (B) to select Wireless LAN setup, then

press the OK button

<< Previous Next >>

Adding Your Multifunction to Your Network

Step Four

Select Easy setup, and then press the OK button.

Step Three

Select Yes, then press the OK button.

When wireless connection is enabled, the Wi-Fi lamp (D)

lights blue.

<< Previous Next >>

Step Five

Select the access point name, then press the OK button.

NOTE: If you are living in an apartment, nearby access

points in use may be detected.

Step Six

Make sure that one of the screens, below, is displayed, then press

the OK button..

If the following screen is not displayed, go to step 9

Adding Your Multifunction to Your Network

<< Previous Next >>

Step Eight

Make sure that the network key is correct, then press the left

FUNCTION button. (below End setup)

Adding Your Multifunction to Your Network

Step Seven

Enter the network key you wrote down, then press the

left FUNCTION button (E).

Press the center FUNCTION button (F) to switch

character entry modes.

<< Previous Next >>

Network key entry is case-sensitive. Be sure to enter upper

and lower case letters correctly.

Adding Your Multifunction to Your Network

Step Nine

When the screen below appears, press the OK button.

If Failed to connect to the access point.appears, press the

OK button, make sure that the network key is correct, then

enter it again. If a connection still cannot be established, refer

to the printed manual: Network Setup Troubleshooting.

Your MX882 is now connected to your

network

<<Previous
