Campbell CRS451 Manuel utilisateur

CRS451/CRS456

Submersible Water-Level

Recording Sensor

Issued: 3.3.14

Printed under licence by Campbell Scientific Ltd.

CSL 996

USER MANUAL

Guarantee

This equipment is guaranteed against defects in materials and workmanship.

This guarantee applies for twelve months from date of delivery. We will

repair or replace products which prove to be defective during the guarantee

period provided they are returned to us prepaid. The guarantee will not apply

to:

•Equipment which has been modified or altered in any way without the

written permission of Campbell Scientific

•Batteries

•Any product which has been subjected to misuse, neglect, acts of God or

damage in transit.

Campbell Scientific will return guaranteed equipment by surface carrier

prepaid. Campbell Scientific will not reimburse the claimant for costs incurred

in removing and/or reinstalling equipment. This guarantee and the Company’s

obligation thereunder is in lieu of all other guarantees, expressed or implied,

including those of suitability and fitness for a particular purpose. Campbell

Scientific is not liable for consequential damage.

Please inform us before returning equipment and obtain a Repair Reference

Number whether the repair is under guarantee or not. Please state the faults as

clearly as possible, and if the product is out of the guarantee period it should

be accompanied by a purchase order. Quotations for repairs can be given on

request. It is the policy of Campbell Scientific to protect the health of its

employees and provide a safe working environment, in support of this policy a

“Declaration of Hazardous Material and Decontamination” form will be

issued for completion.

When returning equipment, the Repair Reference Number must be clearly

marked on the outside of the package. Complete the “Declaration of

Hazardous Material and Decontamination” form and ensure a completed copy

is returned with your goods. Please note your Repair may not be processed if

you do not include a copy of this form and Campbell Scientific Ltd reserves

the right to return goods at the customers’ expense.

Note that goods sent air freight are subject to Customs clearance fees which

Campbell Scientific will charge to customers. In many cases, these charges are

greater than the cost of the repair.

Campbell Scientific Ltd,

Campbell Park, 80 Hathern Road,

Shepshed, Loughborough, LE12 9GX, UK

Tel: +44 (0) 1509 601141

Fax: +44 (0) 1509 601091

Email: [email protected]

www.campbellsci.co.uk

PLEASE READ FIRST

About this manual

Please note that this manual was originally produced by Campbell Scientific Inc. primarily for the

North American market. Some spellings, weights and measures may reflect this origin.

Some useful conversion factors:

Area: 1 in2(square inch) = 645 mm2

Length: 1 in. (inch) = 25.4 mm

1 ft (foot) = 304.8 mm

1 yard = 0.914 m

1 mile = 1.609 km

Mass: 1 oz. (ounce) = 28.35 g

1 lb (pound weight) = 0.454 kg

Pressure: 1 psi (lb/in2) = 68.95 mb

Volume: 1 UK pint = 568.3 ml

1 UK gallon = 4.546 litres

1 US gallon = 3.785 litres

In addition, while most of the information in the manual is correct for all countries, certain information

is specific to the North American market and so may not be applicable to European users.

Differences include the U.S standard external power supply details where some information (for

example the AC transformer input voltage) will not be applicable for British/European use. Please

note, however, that when a power supply adapter is ordered it will be suitable for use in your country.

Reference to some radio transmitters, digital cell phones and aerials may also not be applicable

according to your locality.

Some brackets, shields and enclosure options, including wiring, are not sold as standard items in the

European market; in some cases alternatives are offered. Details of the alternatives will be covered in

separate manuals.

Part numbers prefixed with a “#” symbol are special order parts for use with non-EU variants or for

special installations. Please quote the full part number with the # when ordering.

Recycling information

At the end of this product’s life it should not be put in commercial or domestic refuse

but sent for recycling. Any batteries contained within the product or used during the

products life should be removed from the product and also be sent to an appropriate

recycling facility.

Campbell Scientific Ltd can advise on the recycling of the equipment and in some cases

arrange collection and the correct disposal of it, although charges may apply for some

items or territories.

For further advice or support, please contact Campbell Scientific Ltd, or your local agent.

Campbell Scientific Ltd, Campbell Park, 80 Hathern Road, Shepshed, Loughborough, LE12 9GX, UK

Tel: +44 (0) 1509 601141 Fax: +44 (0) 1509 601091

Email: [email protected]

www.campbellsci.co.uk

Contents

PDF viewers: These page numbers refer to the printed version of this document. Use the

PDF reader bookmarks tab for links to specific sections.

1. Introduction.......................................................1

2. Cautionary Statements .....................................1

3. Initial Inspection and Handling Guidelines .....1

3.1 Ships With..............................................................................................2

4. Overview............................................................2

5. Specifications....................................................2

6. Installation.........................................................4

6.1 Appropriate Depth..................................................................................4

6.2 Avoiding Freezing Conditions................................................................4

6.3 Dislodge Bubbles ...................................................................................5

6.4 Well Installation .....................................................................................5

6.5 Other Installations ..................................................................................5

6.6 Battery Voltage Reading ........................................................................5

6.7 Attaching Suspension Cable to CRS451/CRS456..................................6

7. Programming.....................................................7

7.1 Settings...................................................................................................7

7.2 Connect to the CRS451/CR456..............................................................8

7.3 Configure CRS45X for Measurements...................................................8

7.4 Compensating Measurements for Barometric Pressure........................14

7.4.1 Using an Additional CRS45X.....................................................15

7.4.2 Using a Barometer......................................................................15

8. Maintenance ....................................................19

8.1 Every Visit............................................................................................19

8.2 Every Two to Three Years or on a Rotating Schedule .........................20

8.3 Battery Replacement ............................................................................20

9. Troubleshooting..............................................25

Appendices

Appendix A. Calibration Certificate ...................................................................A-1

Appendix B. Conversion to Units of Measurement............................................B-1

Table

B-1. Conversion Factors ..........................................................................B-1

CRS451/CRS456 Submersible

Water-Level Recording Sensor

1. Introduction

The CRS451 consists of a water-level and water-temperature sensor that has its

own time clock and memory to store the collected data, in a compact stainless-

steel case. This frees users to place the sensor in remote sites and let it collect data

for long periods of time. The CRS451/CRS456 supports standard time-based

scanning and recording along with event-based recording based on water level

change (Delta) or logarithmic time sequence for pump and slug tests. HydroSci

software is included and supports test set up, data retrieval, and data display.

The CRS451 has a 316L stainless-steel case that can be submerged in most canals,

wells, ponds, lakes, and streams. The CRS456 has a rugged titanium case that

allows it to be used in saltwater or other harsh environments.

Before using the CRS451/CRS456, please study:

Section 2, Cautionary Statements

Section 3, Initial Inspection

Section 6, Installation

2. Cautionary Statements

The CRS451/CRS456 will be damaged if encased in frozen liquid (see

Section 6.2, Avoiding Freezing Conditions, for more information).

Although the CRS451/CRS456 is a rugged and reliable device, it is also a

highly precise scientific instrument and should be handled as such.

Dropping the instrument or allowing it to “free fall” down a well may damage

the transducer.

Confirm the compatibility of the instrument to non-water environments before

installation.

The CRS456 should be used in harsh water applications, including salt water.

3. Initial Inspection and Handling Guidelines

Upon receipt of the CRS451/CRS456, inspect the packaging for any signs of

shipping damage. File damage claims with the shipping company.

Immediately check package contents against the shipping documentation (see

Section 3.1, Ships With). Contact Campbell Scientific with any discrepancies.

The model number and pressure range are etched on the housing.

Check this information against the shipping documentation to

ensure that the expected product was received.

CRS451/CRS456 Submersible Water-Level Recording Sensor

3.1 Ships With

#27555 USB 2.0 Cable Type A Male to Micro B Male, 6ft

#29225 HydroSci Software on CD

4. Overview

The CRS451/CRS456, Submersible Water-Level Recording Sensor, provides

reliable, accurate pressure/level measurements that are fully temperature

compensated.

The 24 bit A/D has simultaneous 50/60 Hz rejection and automatic calibration for

each measurement. A number of additional advanced measurement techniques are

employed to harness the best possible performance available from today’s state of

the art pressure sensor technology. The CRS451/CRS456 reverts to a low power

sleep state between measurements. A series of measurements are performed

yielding a temperature and pressure value. This measurement cycle can be as fast

as 1 second.

The design features a piezoresistive sensor housed in a 316L stainless steel

(CRS451) or titanium (CRS456) package to enhance reliability. The rugged

construction makes the CRS451/CRS456 suitable for water level measurement in

irrigation applications, water wells, lakes, streams, and tanks. The titanium

package of the CRS456 makes it ideal for salt water or other harsh environments.

The CRS451/CRS456 has three nose cone options. The weighted nose cone

makes the transducer easier to submerge to depth. The NPT option allows the

sensor to be mounted to a 1/4 inch fitting. The nose cones can be exchanged at a

later time.

Communicating with the CRS451/CRS456 requires a micro USB cable and

HydroSci software running on a computer with Windows XP or later.

Configurable settings can be changed using Campbell Scientific’s HydroSci

software utility.

5. Specifications

Features:

Field replaceable batteries

Campbell Scientific quality

No additional datalogger, enclosure, and power supply; reduces system

costs and simplifies installation

Free customer-friendly software for communication, configuration, data

collection

Fast scan rate

Large data storage capacity

High accuracy

Long battery life

Autres manuels pour CRS451

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Campbell Instrument de mesure

Campbell

Campbell TEMPERATURE PROBE 109SS Manuel utilisateur

Campbell

Campbell CR-PVS1 Manuel utilisateur

Campbell

Campbell SoilVUE 10 Manuel utilisateur

Campbell

Campbell LI200R Manuel utilisateur

Campbell

Campbell CR10XTCR Manuel utilisateur

Campbell

Campbell CS300 Manuel utilisateur

Campbell

Campbell SR05 Manuel utilisateur

Campbell

Campbell CS320 Manuel utilisateur

Campbell

Campbell HMP35C Manuel utilisateur

Campbell

Campbell Wind Monitor Series Manuel utilisateur

Campbell

Campbell IRGASON Manuel utilisateur

Campbell

Campbell CS616 Manuel utilisateur

Campbell

Campbell CS140 Manuel utilisateur

Campbell

Campbell LI200S-LC Manuel utilisateur

Campbell

Campbell TE525 Manuel utilisateur

Campbell

Campbell Met One 034A-L Manuel utilisateur

Campbell

Campbell TDR Guide de l'utilisateur

Campbell

Campbell CRS451 Manuel utilisateur

Campbell

Campbell SR11 Manuel utilisateur

Campbell

Campbell CS500-LC Manuel utilisateur

Campbell

Campbell MMW-005 Manuel utilisateur

Campbell

Campbell EC150 Manuel utilisateur

Campbell

Campbell CS800-L Manuel utilisateur

Campbell

Campbell CSAT3BH Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
