Calculated Industries ConcreteCalc Manuel utilisateur

For Today’s Concrete Professional

User’s Guide

ONSTRUCTION

ASTER

M–R/C

Tape

ONCRETE

ALC

™

CALCULATED INDUSTRIES

–

Area

Wt/Vol

Ft-In

M–

Per

xAreaArc

Size

M+

456

Rcl

%•

On/C

–

Off

Conv

Inch

Feet

Yds

Cu Sq

Width Vol

Length

√__

Sq–Up

Stair

Weight

Block

Circ

Height

Drop Ftg

FEET INCH

CONCRETECALC™

Introducing ConcreteCalc . . . . . . . . . . .3

Key Definitions . . . . . . . . . . . . . . . . . . .4

Operating Basics . . . . . . . . . . . . . . . .15

Linear Dimensions . . . . . . . . . . .15

Square and Cubic Dimensions . .16

Dimension Conversions . . . . . . .17

Math Operations . . . . . . . . . . . .20

Memory Operation . . . . . . . . . . .23

Fractional Settings . . . . . . . . . . .25

Paperless Tape Function . . . . . . .27

Using the ConcreteCalc . . . . . . . . . . . .29

Linear Division . . . . . . . . . . . . . .29

Linear Addition . . . . . . . . . . . . .31

Circle Calculations . . . . . . . . . . .32

Area Calculations . . . . . . . . . . . .33

Volume Calculations . . . . . . . . . .34

Square-up Concrete . . . . . . . . . .41

Blocks, Bricks, Walls & Footings .42

Computing Drop . . . . . . . . . . . .48

Stair Problems (Risers/Treads) . .50

Appendix A . . . . . . . . . . . . . . . . . . . .54

Accuracy/Display . . . . . . . . . . . .54

Error . . . . . . . . . . . . . . . . . . . . .54

Auto-Range . . . . . . . . . . . . . . . .54

Battery & Auto Shut-Off . . . . . . .55

Full Reset/All Clear . . . . . . . . . . .55

Default Settings . . . . . . . . . . . . .55

Surface Area and Volume Formulas .56

Area Formulas . . . . . . . . . . . . . .57

TABLE OF CONTENTS

2– ConcreteCalc™

Designed for today’s concrete profes-

sional, the all-new ConcreteCalc™ adds

even more power to the already pow-

erful Construction Master line-up. Like

earlier models, this calculator is so sim-

ple to use, even the novice user can

easily solve dimension-related prob-

lems. Features include:

wwSolve Dimensional Math with Ease

wwInstant Dimensional Conversions

wwEnglish/Metric Conversions

wwWeight/Volume Conversions

wwRectangular Area/Volume Calculations

wwInstant Block Quantity Solutions

wwInstant Footing Volume Calculations

wwInstant Square-Up (Diagonal) Solutions

wwDrop Distance Calculations

wwInstant Circular Area and Perimeter

wwInstant Arc Length Calculations

wwCalculate Stair Risers and Treads

wwMaterial Estimations

wwPaperless Tape

INTRODUCING

CONCRETECALC™

User’s Guide – 3

Basic Functions

[+] [–] [x] [÷] [=]

Arithmetic Operation Keys —Used to

perform arithmetic functions.

[%]

Percent — Four-function percent key.

[0] – [9] and [ • ]

Numeric Keys —Used to key numeric

values.

[Off]

Power Off — Turns all power off. Resets

the display and all non-permanent reg-

isters.

[On/C]

Power On/Clear — Turns on power.

Pressing once clears the last entry and

the display. Pressing twice in succes-

sion clears all temporary registers.

[Conv]

Convert —Used with the dimensional

keys to convert between dimensions.

Dimensions can only be converted with-

in the same convention (i.e., linear,

square or cubic). Also used to access spe-

cial functions when used in combination

with other keys as defined herein.

KEY DEFINITIONS

4– ConcreteCalc™

[ ]

Square Root —Used to find the square

root of a number.

Note: Attempts to find

the square root of a linear or volume

dimension will cause an “Error”.

[Conv] [ ]

x2 — Finds the square of the displayed

value.

Note: Attempts to find the square of

an area or volume dimension will cause an

“Error”

[M+]

Memory Add —Adds the displayed num-

ber to the value stored within the semi-

permanent Memory.

[Conv] [M+]

Memory Minus —Subtracts the dis-

played value from Memory.

[Rcl]

Recall —Recalls values stored in any

Memory.

[Rcl] [Rcl]

Memory Display/Clear —Displays the

value in Memory and clears the register.

[Conv] [Rcl]

Memory Clear —Clears the Memory

without changing the current display.

User’s Guide – 5

Dimension Keys

[Yds]

Yards —This is an entry and conver-

sion key. The entry can be a whole

number or a decimal number. Used with

the [Conv] key converts any other dis-

played dimensioned number to yards.

[Feet]

This is an entry and conversion key.

The entry can be a whole number or

decimal number. This key can also be

used in conjunction with the [Inch] and

[/] keys for entering values in Feet-

Inch format. For example, 6 feet 9-1/2

inches is entered as follows:

6 [Feet] 9 [Inch] 1 [/] 2

Repeated presses of this key during

conversions will toggle between Feet-

Inch and Decimal Feet formats.

[Inch]

This is an entry and conversion key.

The entry can be in whole or decimal

numbers. This key can also be used in

conjunction with the [/] key for enter-

ing values in Fractional Inch format.

Repeated presses of this key during

conversions will toggle between Fractional

Inch and Decimal Inch formats.

6– ConcreteCalc™

[/]

Fraction Bar —This key is used to

enter fractions. Fractions can be

entered as proper (1 or less — 1/2, 1/8,

1/16) or improper (greater than 1 —

3/2, 65/64). For example, to enter 1/2,

the key sequence would be: 1 [/] 2. If

the denominator (the bottom number)

is not entered, then the set fractional

level (1/16, 1/2, etc.) is used. [Rcl] [/]

displays the current fractional setting.

[Cu]

Cubic —This key is used with a dimen-

sion key (feet, inches, yards, meters,

etc.) to identify a value as being a vol-

ume. Example: 5 [Cu] [Yds].

[Sq]

Square —This key is used with a

dimension key (feet, inches, yards,

meters, etc.) to identify a value as being

an area. Example: 10 [Sq] [Feet].

[m]

Meters —This is an entry and conver-

sion key used to enter decimal meters

or to convert decimal meters from some

other dimensional format (when used

in conjunction with the [Conv] key).

User’s Guide – 7

[mm]

Millimeters —This is an entry and con-

version key used to enter or to convert

to decimal millimeters (when used in

conjunction with the [Conv] key).

[Weight]

This key is used to convert a dimen-

sioned cubic value or volume, to a

weight value using the [Conv] key and

the stored Weight per Volume (see

below). For example, 5 [Cu] [Yds]

[Conv] [Weight] equals 7.5 tons, or 10

[Weight] (tons) [Conv] [Cu] [Yds] equals

6.666667 cubic yards. Repeated press-

es of this key, after a cubic entry or

conversion, will toggle between tons,

pounds and kilograms.

[Conv] [%]

Weight per Volume—Used to set the

Weight per Volume. Can be programmed

as Tons per Cubic Yard, Pounds per

Cubic Yard, or Kilograms per Cubic Meter.

Default is 1.5 Tons/Cu. Yd. To set a dif-

ferent weight per volume, for example, 2

Tons/Cu. Yd, press 2 [Conv] [%]. Value

will be permanently stored. To recall

stored value, press [Rcl] [%].

8– ConcreteCalc™

Area/Volume Keys

[Length]

Enters the value for Length in dimen-

sion problems (e.g., for calculating area

or volume).

Note: This key is also used to

enter the length for “Square-ups” and the

“Run” for stair problems.

[Width]

Enters the value for Width in dimension

problems (e.g., calculating area or vol-

ume).

Note: This key is also used to enter

the width for “Square-ups.”

[Height]

Enters the value for Height in dimen-

sion problems (e.g., for calculating vol-

ume).

Note: This key is also used to enter

the “Rise” for stair problems.

[Vol]

Volume —Computes the volume

(Length x Width x Height) in Cubic

Yards based on entered Length, Width

and Height values. A second press will

display the area (in square feet) based

on entered Length and Width. Successive

presses will toggle the display between

the calculated area and volume.

[Conv] [Vol]

Area —Computes the area in Square

Feet based on entered Length and Width.

User’s Guide – 9

Square-Up & Drop Keys

[Sq-Up]

Square-up —Enters or computes the

“Square-Up” (or Diagonal) length based

on entered Length and Width values.

[Drop]

Computes the total drop (or fall) over

an entered Length, given an entered

percentage drop or inch drop per foot

value. Successive presses will act as a

“constant add,” for displaying succes-

sive drops.

Block/Footing Keys

[Block]

Number of Blocks —Computes the num-

ber of blocks or bricks needed after enter-

ing a wall area, or values entered in

Length and Height.

[Conv] [Block]

Block Size —Used to permanently set

the size of a single block or brick. The

default size is 128 square inches for an

8” x 16” block. To recall the stored

block area, press [Rcl] [Block].

[Ftg]

Footing —Used to compute concrete

volume of footings, walls, curbs, etc.

10 – ConcreteCalc™

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Calculated Industries Calculatrice

Calculated Industries

Calculated Industries 3442 Manuel utilisateur

Calculated Industries

Calculated Industries 6260 Manuel utilisateur

Calculated Industries

Calculated Industries Construction Master plus EZ 4067 Manuel utilisateur

Calculated Industries

Calculated Industries Construction Master IV Manuel utilisateur

Calculated Industries

Calculated Industries 8015 Manuel utilisateur

Calculated Industries

Calculated Industries 8515 Manuel utilisateur

Calculated Industries

Calculated Industries ElectriCalc Pro 5060 Manuel utilisateur

Calculated Industries

Calculated Industries ElectriCalc Pro Manuel utilisateur

Calculated Industries

Calculated Industries PROJECTCALC CLASSIC 8503 Manuel utilisateur

Calculated Industries

Calculated Industries 4020 Manuel utilisateur

Calculated Industries

Calculated Industries 4054 Manuel utilisateur

Calculated Industries

Calculated Industries TimeCard Tabulator II Manuel utilisateur

Calculated Industries

Calculated Industries Tradesman Calc 4400 Manuel utilisateur

Calculated Industries

Calculated Industries Construction Master 5 Manuel utilisateur

Calculated Industries

Calculated Industries 9430 Manuel utilisateur

Calculated Industries

Calculated Industries ULTRA MEASURE MASTER 8025 Manuel utilisateur

Calculated Industries

Calculated Industries CONVERSIONCALC PLUS Manuel utilisateur

Calculated Industries

Calculated Industries Measure Master 4018 Manuel utilisateur

Calculated Industries

Calculated Industries Pocker Real Estate Master 3400 Manuel utilisateur

Calculated Industries

Calculated Industries 4225 Manuel utilisateur

Calculated Industries

Calculated Industries PIPE TRADES PRO 4095 Manuel utilisateur

Calculated Industries

Calculated Industries Construction Master IV Manuel utilisateur

Calculated Industries

Calculated Industries 4325 Manuel utilisateur

Calculated Industries

Calculated Industries 3420 Manuel utilisateur

Manuels Calculatrice populaires d'autres marques

HP 35s Manuel

Casio

Casio CFX-9970G Manuel utilisateur

LEXIBOOK

LEXIBOOK EL350 Manuel utilisateur

HP HP-97 Manuel utilisateur

Citizen

Citizen SDC-414N Manuel utilisateur

Casio

Casio fx-3800P Manuel utilisateur

Canon

Canon P26-DHIII Manuel utilisateur

Citizen

Citizen 520DPA Manuel utilisateur

Sharp

Sharp EL-9900 Manuel utilisateur

Casio

Casio FX-9860GII - SOFTWARE VERSION 2-00 Manuel utilisateur

Casio

Casio MS-7UC Manuel utilisateur

Sharp

Sharp WriteView EL-W506 Manuel technique

Casio

Casio FC-200 Manuel utilisateur

Casio

Casio fx-CG50 Manuel utilisateur

HP HP-67 Guide de l'utilisateur

Royal

Royal CBC2000 Manuel utilisateur

Heathkit

Heathkit IC-2009 Manuel utilisateur

Universal

Universal UNV-15907 Manuel utilisateur
