Ordering Information
Barebone
PEAK980(P/N:93710980Q370)
Intel®8th/9thCoffeelakeCore™ITDP95W,Q370,LGA1151,
2xDDR4upto64GB,DVI‐I,DP,2xUSB3.1(Gen1),6xUSB2.0,
2xGbELAN,4xSATAIII,
3xRS232,1xRS232/422/485,1x60pinconnector ,
1xM.2.
PEAK980‐H(P/N:93710980H310)
Intel®8th/9thCoffeelakeCore™ITDP95W,H310,LGA1151,
2xDDR4upto64GB,DVI‐I,DP,2xUSB3.1(Gen1),6xUSB2.0,
2xGbE LAN,4xSATAIII,
3xRS232,1xRS232/422/485.
PowerRequirement
•PowersourcefromBackplanethroughGoldenFinger
andAUX+12V2x2connector
Dimensions
•PICMG1.3FormFactor,8.9”x4.9”(228mmx126mm)
Environment
•Boardleveloperationtemperature:‐0°Cto60°C
•Storagetemperature:‐40˚Cto85˚C
•Relativehumidity:
– 10%to95%(operating,non‐condensing)
–5%to95%(non‐operating,non‐condensing)
Certifications
•MeetCE/FCCClassA
www.cadmus.com.tw
PEAK980
Black Diagram
Packing
•7P+15PSATAcable*1
•2COMports+bracket*1
•2USB2.0ports+bracket*1
•3PinPowercable
OptionalAccessories
•DVI‐IYcable(P/N:343230280003)
•TPM2.0modulekit(P/N:8850TPM20001)
•DPcable(P/N:343420000010)
BackplaneSupportList:
•NBP1468(P/N:8850NBP14681)
•NBP1257(P/N:8850NBP12570)
•NBP1052(P/N:8850NBP10521)
•NBP05P2(P/N:8850NBP05P20)
•NBP06E5(P/N:8850NBP06E50)
•NBP06P2(P/N:8850NBP06P20)
PICMG1.3
PEAK980
