ATS

Convenience &

Personalization Guide

2018

cadillac.com

Review this quick reference guide for an overview of some important features in your Cadillac ATS.

Some optional equipment described in this guide (denoted by

♦

) may not be included in your vehicle.

More information can be found in your Owner's Manual and at my.cadillac.com.

Certain restrictions, precautions and safety

procedures apply to your vehicle. Please read

your Owner’s Manual for complete instructions.

INSTRUMENT PANEL

Power

Mirrors

Control

Turn Signal Lever/

Exterior Lamps

Control

Instrument

Cluster/Driver

Information Center

Windshield

Wipers

Lever

Head-Up

Display

Controls♦

Memory

Seat

Buttons

Cadillac User

Experience

Touch Screen♦

Engine Start/

Stop Button

Audio

System

Controls♦

Hazard

Warning

Flashers

Electric

Parking

Brake

Switch♦

Cruise Control/

Voice

Recognition

Buttons

Tilt/Telescope

Steering

Column

Adjuster

Audio

Steering Wheel

Controls/

5-way Control

Trunk

Release

Traction Control

and StabiliTrak/

Auto Stop-Start Disable♦/

Driver Mode Buttons

Heated Seat

Buttons♦/

Climate

Controls

Storage

Compartment

Access♦(behind

control panel)

Lane Keep Assist

with Lane Departure

Warning♦/Parking

Assist Buttons♦

REMOTE KEYLESS ENTRY

TRANSMITTER KEYLESS ACCESS SYSTEM

Lock

Press to lock all doors.

Unlock

Press to unlock the driver's door.

Press again to unlock all doors.

Press and hold to open all windows.

Note: To change the Remote Lock and

Unlock settings, go to Settings > Vehicle

> Remote Lock, Unlock, Start.

Remote Start

♦

Use to start the engine from outside

the vehicle. See Adaptive Remote

Start on page 17.

Vehicle Locator/Panic Alarm

Press and release to locate your vehicle. e exterior lamps ash

and the horn sounds.

Press and hold for 3 seconds to activate the alarm. e turn

signal lamps ash and the horn sounds for 30 seconds, or until the

buon is pressed again or the vehicle is started.

Trunk Release

Press twice to open the trunk.

See Keys, Doors and Windows in your Owner's Manual.

e Keyless Access System enables operation of the doors, ignition

and trunk without removing the Remote Keyless Entry transmier

from your pocket or purse. e transmier must be within 3 feet

of the door being unlocked or the trunk.

KEYLESS UNLOCKING

With the transmier within range:

Press the lock buon on the driver’s door handle to unlock the

driver’s door; press it again within 5 seconds to unlock alldoors.

Press the lock buon

on a passenger door

handle to unlock all

doors.

Press the touch

padabove the

licenseplate to open

the trunk.

KEYLESS LOCKING

With the ignition o, the transmier removed from the vehicle,

and all doors closed:

Press the lock buon on any door handle to lock all doors

immediately.

If Passive Locking is turned on, all doors will lock automatically

aer a short delay once all doors are closed.

Note: To change the door lock and unlock settings, go to Settings > Vehicle

> Remote Lock, Unlock, Start.

See Keys, Doors and Windows in your Owner's Manual.

♦Optional equipment

KEYLESS START

START

With the vehicle in Park or

Neutral, press the brake pedal

(and clutch pedal, if equipped)

and then press the ENGINE

START/STOP buon to start

theengine. e green indicator

on the buon will illuminate.

ENGINE START/STOP will

illuminate on the buon when the headlamps are on.

Note: The Remote Keyless Entry transmitter must be in the vehicle to turn

on the ignition. If the transmitter battery is weak, place the transmitter in

the pocket at the front of the center console storage area to enable the

engine to start. Replace the transmitter battery as soon as possible.

STOP/OFF

Shi to Park (automatic transmission), or 1st or Reverse

(manual transmission), and press the ENGINE START/STOP

buon to turn o theengine.

Power is available to operate the audio system for 10 minutes or

until the driver’s door is opened.

ACCESSORY

With the engine o and the brake pedal NOT depressed,

pressthe ENGINE START/STOP buon to place the vehicle

inAccessory mode. e amber indicator on the buon will

illuminate.

See Driving and Operating in your Owner’s Manual.

AUTO ENGINE STOP/START OPERATION

(IF EQUIPPED)

A fuel-saving automatic engine stop/start system is included on

vehicles equipped with the 2.0L L4 turbocharged engine and an

automatic transmission and all 3.6L V6 engines.

While driving, when the brake pedal is applied and the vehicle is

at a complete stop, the auto engine stop/start system may turn o

the engine, depending on operating conditions. When the engine

is o, the tachometer gauge will read AUTO STOP. Upon releasing

the brake pedal or applying the accelerator pedal, the engine will

restart. Aer parking the vehicle and turning o the engine, the

tachometer gauge will read OFF.

e engine may remain running or restart when the vehicle is

stopped if:

• A minimum vehicle speed is not reached.

• e engine or transmission is not at the required operating

temperature.

• e outside temperature is not in the required operating range.

• e shi lever is in any gear other than D (Drive).

• e baery charge is low.

• e climate control system requires the engine to run based on

the current seings.

• e Auto Stop time is greater than 2 minutes.

AUTO ENGINE STOP/START DISABLE

Press the

buon on the center console when the engine is

running to disable the auto engine stop/start system.

When the system is disabled, the buon indicator will not be illu-

minated and the

symbol on the instrument cluster will change

from green to white with a slash through it.

See Driving and Operating in your Owner’s Manual.

VOICE RECOGNITION

Push to Talk

Press to answer an incoming call or interact with the OnStar,

Bluetooth or infotainment system.♦

End Call/Mute

Press to end/decline a call or mute/unmute the audio system.

See your Cadillac User Experience Manual.

DRIVER INFORMATION CENTER CONTROL

e 5-way control moves le/right, up/down, and in.

Left/Right

Press to view the le or right clus-

ter display. Press the le to exit

a display menu.

Up/Down

Press the control bar up or down

to scroll through a menu.

SEL Select

Press to select a highlighted menu item.

See Instruments and Controls in your Owner's Manual.

AUDIO CONTROLS

+ –Volume

Press +or –to increase or decrease the volume.

Next/Previous

Press or to select the next or previous favorite radio station

or track.

See your Cadillac User Experience Manual.

CRUISE CONTROL

On/O

SET Set Speed

With Cruise Control on, press

the control bar down fully to

set the cruise speed.

RES Resume Speed

With Cruise Control on, press the control bar up fully to resume the

previous set speed.

+ – Adjust Speed

When active, press the control bar up (+) or down (–) lightly to

increase or decrease the set speed by 1-mph increments; press up or

down fully to increase or decrease the set speed to the next 5-mph

interval on the speedometer.

Cancel

Press to cancel cruise control without erasing the set speed from

memory.

Following Gap (ADAPTIVE CRUISE CONTROL

♦

)

Press repeatedly to select a gap seing (the time between your

vehicle and a detected vehicle) of Far, Medium, or Near.

See Driving and Operating in your Owner's Manual.

HEATED STEERING WHEEL

♦

On/O

See Instruments and Controls in your Owner's Manual.

STEERING WHEEL CONTROLS

♦Optional equipment

INSTRUMENT CLUSTER

Refer to your Owner’s Manual to learn about the information being

relayed by the lights, gauges and indicators of the instrument cluster.

StabiliTrak O

Low Tire Pressure

Service Electric Parking Brake

Antilock Brake System Warning

Airbag Readiness

Brake System Warning

High Beam Headlamps

Lane Keep Assist/

Lane Departure Warning

Forward Collision Alert

StabiliTrak/Traction Control

Engaged

Engine Oil Pressure Warning

Security Notiﬁcation

Lights On Reminder

Charging System Warning

Low Fuel Warning

Engine Coolant Temperature

Safety Belt Reminder

Adaptive Forward Lighting Activated

PARK Electric Parking Brake Set

Check Engine Warning

Traction Control O

Cruise Control Activated

Adaptive Cruise Control Activated

AutoStop

Symbols

See Instruments and Controls in your Owner’s Manual.

DRIVER INFORMATION CENTER

e Driver Information Center displays a variety of vehicle

information on three display zones. Zones can be personalized to

display: digital speedometer, trip odometer, fuel range, average fuel

economy, compass, oil life, tire pressure, navigation, phone or other

vehicle information.

Use the 5-way control on the right side of the steering wheel to nav-

igate and select between the available menus. To select the desired

display information:

1. Press the le or right side of the control bar to select one

of the three display zones.

2. Press the control bar up or down to scroll through

amenu.

3. Press SEL (Select) to select a menu item. Press and hold to reset

values on certain screens.

4. Press the le or right side of the control bar to retain the

information view and to exit the display zone.

See Instruments and Controls in your Owner’s Manual.

HEAD-UP DISPLAY♦

e Head-Up Display (HUD) projects some operating information

onto the windshield.

e HUD controls are located on the le side of

the instrument panel.

HUD

Li up or press down to adjust the position of the image. It cannot

be adjusted side-to-side.

INFO

Press to select from four displays: Speed View; Audio/Phone View;

Navigation View; and Performance View.

Li up or press down to brighten or dim the display.

Hold down to turn o the display.

ROTATION OPTION

Adjust the angle of the HUD image to compensate for windshield

variations.

To adjust the angle of the HUD, use the 5-way control to view

the Options menu on the instrument cluster and select HUD

Rotation.

See Instruments and Controls in your Owner’s Manual.

♦Optional equipment

CADILLAC USER EXPERIENCE CONTROLS

Applications♦:

Touch the screen icon to

access the application

Wi-Fi

Indicator

Power/Mute:

Press and hold to turn

the system On/O; press to

mute/unmute audio

Climate Control Fan

Speed O

Windshield Defrost

Mode

Driver’s Temperature

Control

Passenger’s

Temperature

Control

Passenger’s Heated

Seat Control♦

Driver’s Heated

Seat Control♦

The controls use capacitive technology – simply touch the icon/text

to access a feature or adjust a function.

VOLUME:

Touch arrows or swipe

ﬁnger above chrome bar

AUTO:

Automatic Climate

Control Operation

Rear Window Defog

Recirculation Mode

Home Page

Storage Compartment:

Press and hold the bright

bar to open/close

See your Cadillac User Experience Manual.

♦Optional equipment

CADILLAC USER EXPERIENCE MENUS

Your ATS oers a variety of entertainment, communication and vehicle system options. You can use simple gestures on the touch screen just

as you would on a smartphone, such as tap, drag, pinch and spread, to interact with the infotainment system. Touch an application icon on the

touch screen to access the following items.

Audio

• Most Recent Audio

Sources

• More Audio Sources

• Seek Up/Down

• Tune

• HD Radio

• Browse

• Sound

• Station Favorites

Navigation♦

• Search

• Favorite

• Recent

• Cancel

• Map Menu

• Zoom Out

• Zoom In

• Destination

• Vehicle Icon

Phone

• Favorites

• Keypad

• Recent

• Contacts

• Devices

Note: Press and hold the

Push to Talk steering

wheel button to activate

Bluetooth Speech

Recognition. See page 12.

Climate

• Front/Rear Seings♦

• Driver/Vehicle Set

Temperature

• Passenger Set

Temperature

• Fan Speed

• Air Distribution

Seings

• On/O

• A/C Mode

• Automatic Seing

• Recirculation Seing

• Sync Temperature

Seings

Settings

• System

• Apps

• Vehicle

• Personal

CADILLAC USER EXPERIENCE FEATURES

Refer to your Owner’s Manual for important information about using the infotainment system while driving.

Use a Bluetooth or USB connection to link a compatible smartphone, cell phone, USB ash drive or portable audio player/iPod®to the touch

screen infotainment display. For assistance, call 1-855-428-3669 or visit my.cadillac.com/learn.

Tap

Touch and Hold

Drag

Spread

Pinch

SETTING THE TIME

1. Touch Seings on the Home page, and then touch System.

2. Touch Time/Date.

3. Touch Set Time.

4. Touch or to adjust the hours, minutes, and AM or PM.

5. Touch to exit the menu.

If the Auto Set feature is enabled, the time will be updated

automatically as the system obtains time information from the

cellular network.

STORING STATION FAVORITES

Radio stations from all bands (AM, FM or SiriusXM♦) can be stored

in any order.

1. Display the desired radio station.

2. Touch and hold a favorite screen buon. Favorites also can be

saved by touching the in a station or channel list.

3. Repeat the steps to store another favorite item.

INTERACTING WITH THE TOUCH SCREEN

You can use simple gestures on the touch screen just as you would

on a smartphone.

Autres manuels pour ATS 2018

Table des matières

Autres manuels Cadillac Automobile

Cadillac

Cadillac 2015 Escalade Manuel utilisateur

Cadillac

Cadillac 2003 Escalade Manuel utilisateur

Cadillac

Cadillac STS 2006 Guide de configuration

Cadillac

Cadillac 2006 Escalade Manuel utilisateur

Cadillac

Cadillac Cadillac 1973 Manuel utilisateur

Cadillac

Cadillac CTS COUPE Manuel utilisateur

Cadillac

Cadillac 2011 SRX CROSSOVER Manuel utilisateur

Cadillac

Cadillac 1965 Fleetwood Seventy-Five Manuel utilisateur

Cadillac

Cadillac 2015 Escalade Manuel utilisateur

Cadillac

Cadillac 2012 Cadillac SRX Manuel utilisateur

Cadillac

Cadillac 2000 Manuel de la liste des pièces

Cadillac

Cadillac 2009 DTS Manuel utilisateur

Cadillac

Cadillac 2011 CTS COUPE Manuel utilisateur

Cadillac

Cadillac LYRIQ 2023 Manuel utilisateur

Cadillac

Cadillac 2004 SRX Manuel utilisateur

Cadillac

Cadillac 2000 DeVille Manuel utilisateur

Cadillac

Cadillac 1994 Fleetwood Manuel utilisateur

Cadillac

Cadillac CTS COUPE - SPECIFICATIONS 2011 Manuel utilisateur

Cadillac

Cadillac 2010 Escalade EXT Manuel utilisateur

Cadillac

Cadillac 1995 Fleetwood Manuel utilisateur

Cadillac

Cadillac 2002 Escalade Manuel utilisateur

Cadillac

Cadillac 2012 Cadillac Escalade Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur

Cadillac

Cadillac 2012 Cadillac SRX Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Skoda

Skoda FABIA RS - ANNEXE 118 Manuel utilisateur

Seat

Seat toledo Manuel utilisateur
