ATS

Convenience &

Personalization Guide

2017

cadillac.com

Electric

Parking Brake

Switch♦

Power Mirrors

Control

Turn Signal Lever/

Exterior Lamps

Control

Instrument

Cluster/Driver

Information

Center

Cruise Control/

Voice

Recognition

Buttons

Tilt/Telescope

Steering Column

Adjuster

Windshield

Wipers

Lever

Audio Steering

Wheel

Controls/

5-way Control

Head-Up

Display

Controls♦

Trunk

Release

Review this guide for an overview of some important features in your Cadillac ATS. Some optional equipment described in this guide

(denoted by ♦) may not be included in your vehicle. More detailed information can be found in your Owner Manual.

Cadillac

CUE

Touch

Screen♦

Traction Control

and StabiliTrak/

Auto Stop-Start

Disable♦/Driver

Mode Butttons

Heated Seat

Buttons♦/

Climate

Controls

Storage

Compartment

Access♦

(behind control

panel)

Engine Start/

Stop Button

Audio System

Controls♦

Hazard

Warning

Flashers

Lane Keep

Assist with

Lane Departure

Warning♦/Park

Assist Buttons♦

INSTRUMENT PANEL

REMOTE KEYLESS ENTRY

TRANSMITTER KEYLESS ACCESS SYSTEM

Lock

Press to lock all doors.

Unlock

Press to unlock the driver's door.

Press again to unlock all doors.

Press and hold to open all windows.

Note: To change the Remote Lock and

Unlock settings, go to Remote Lock,

Unlock, Start in the Vehicle Settings

menu.

Remote Vehicle Start

♦

Use to start the engine from outside

the vehicle. See Adaptive Remote Start on page 17.

Vehicle Locator/Panic Alarm

Press and release to locate your vehicle. e exterior lamps ash

and the horn sounds.

Press and hold for 3 seconds to activate the alarm. e turn

signal lamps ash and the horn sounds for 30 seconds, or until the

buon is pressed again or the vehicle is started.

Trunk Release

Press twice to open the trunk.

See Keys, Doors and Windows in your Owner Manual.

e Keyless Access System enables operation of the doors, ignition

and trunk without removing the Remote Keyless Entry transmier

from your pocket or purse. e transmier must be within 3 feet

of the door being unlocked or the trunk.

KEYLESS UNLOCKING

With the transmier within range:

Press the lock buon on the driver’s door handle to unlock the

driver’s door; press it again within 5 seconds to unlock alldoors.

Press the lock buon

on a passenger door

handle to unlock all

doors.

Press the touch

padabove the

licenseplate to open

the trunk.

KEYLESS LOCKING

With the ignition o, the transmier removed from the vehicle,

and all doors closed:

Press the lock buon on any door handle to lock all doors

immediately.

If Passive Locking is turned on, all doors will lock automat ically

aer a short delay once all doors are closed.

Note: To change the door lock and unlock settings, go to Remote Lock,

Unlock, Start in the Vehicle Settings menu.

See Keys, Doors and Windows in your Owner Manual.

♦Optional equipment

KEYLESS START

START

With the vehicle in Park or

Neutral, press the brake pedal

(and clutch pedal, if equipped)

and then press the ENGINE

START/STOP buon to start

theengine. e green indicator

on the buon will illuminate.

ENGINE START/STOP will

illuminate on the buon when the headlamps are on.

Note: The transmitter must be in the vehicle to turn on the ignition. If the

transmitter battery is weak, place the transmitter in the pocket at the front

of the center console storage area to enable the engine to start.

Cell phone chargers may interfere with the operation of the Pushbutton

Start System and should not be plugged in when starting or turning o the

engine.

STOP/OFF

Shi to Park (automatic transmission), or 1st or Reverse

(manual transmission), and press the ENGINE START/STOP

buon to turn o theengine.

Power is available to operate the audio system for 10 minutes or

until the driver’s door is opened.

ACCESSORY

With the engine o and the brake pedal NOT depressed,

pressthe ENGINE START/STOP buon to place the vehicle

inAccessory mode. e yellow indicator on the buon will

illuminate.

See Driving and Operating in your Owner Manual.

AUTO ENGINE STOP/START

(IF EQUIPPED)

e Auto Engine Stop/Start system is included on 2.0L L4 turbo-

charged engine and 3.6L V6 engine vehicles with an automatic

transmission.

When the brakes are applied and the vehicle is at a complete stop,

the engine may turn o, depending on operating conditions, to

conserve fuel. When the engine stops, the tachometer displays

AUTO STOP. When the brake pedal is released or the accelerator

pedal is pushed, the engine will restart.

Auto Stop may automatically deactivate if:

• A minimum vehicle speed is not reached.

• e engine or transmission is not at the required operating

temperature.

• e outside temperature is not in the required operating range.

• e shi lever is in any gear other than D (Drive).

• e baery charge is low.

• e current seings for the climate control or defog system

have not been reached.

• e Auto Stop time is greater than 2 minutes.

AUTO ENGINE STOP/START DISABLE

Press the

buon on the center console when the engine is

running to disable the Auto Engine Stop/Start system.

When the system is disabled, the buon indicator will not be illu-

minated and the

symbol on the instrument cluster will change

from green to white with a slash through it.

See Driving and Operating in your Owner Manual.

VOICE RECOGNITION

Push to Talk

Press to answer an incoming call or interact with the OnStar,

Bluetooth or Cadillac CUE system.♦

End Call/Mute

Press to end/decline a call or mute/unmute the audio system.

See Instruments and Controls in your Owner Manual.

5-WAY CONTROL

Moves le/right, up/down, and in.

Left/Right

Press to navigate to the le or

right cluster display. Press the le

to exit a center display menu.

Up/Down

Press the control bar up or down

to scroll through a menu.

SEL Select

Press to select a highlighted menu item.

AUDIO CONTROLS

+ –Volume

Press +or –to increase or decrease the volume.

Next/Previous

Press or to select the next or previous favorite radio station

or track.

See Instruments and Controls in your Owner Manual.

CRUISE CONTROL

On/O

SET Set Speed

With Cruise Control on, press

the control bar down fully to

set the cruise speed.

RES Resume Speed

With Cruise Control on, press the control bar up fully to resume the

previous set speed.

+ – Adjust Speed

When active, press the control bar up (+) or down (–) lightly to

increase or decrease the set speed by 1-mph increments; press up or

down fully to increase or decrease the set speed to the next 5-mph

interval on the speedometer.

Cancel

Press to cancel cruise control without erasing the set speed from

memory.

Following Gap

♦

Press repeatedly to select a gap seing of Far, Medium, or Near.

See Driving and Operating in your Owner Manual.

HEATED STEERING WHEEL

♦

On/O

See Instruments and Controls in your Owner Manual.

STEERING WHEEL CONTROLS

♦Optional equipment

INSTRUMENT CLUSTER

Refer to your Owner Manual to learn about the information being relayed

by the lights, gauges and indicators of the instrument cluster.

StabiliTrak O

Low Tire Pressure

Service Electric Parking Brake

Antilock Brake System Warning

Airbag Readiness

Brake System Warning

High Beam Headlamps

Lane Keep Assist/

Lane Departure Warning

Forward Collision Alert

StabiliTrak/Traction Control

Engaged

Engine Oil Pressure Warning

Security Notiﬁcation

Lights On Reminder

Charging System Warning

Low Fuel Warning

Engine Coolant Temperature

Safety Belt Reminder

Adaptive Forward Lighting Activated

PARK Electric Parking Brake Set

Check Engine Warning

Traction Control O

Cruise Control Activated

Adaptive Cruise Control Activated

AutoStop

Symbols

See Instruments and Controls in your Owner Manual.

DRIVER INFORMATION CENTER

e Driver Information Center displays a variety of vehicle

information on three display zones. Zones can be personalized to

display: digital speedometer, trip odometer, fuel range, average fuel

economy, compass, oil life, tire pressure, navigation, phone or other

vehicle information.

Use the 5-way control on the right side of the steering wheel to nav-

igate and select between the available menus. To select the desired

display information:

1. Press the le or right side of the control bar to select one

of the three display zones.

2. Press the control bar up or down to scroll through

amenu.

3. Press SEL (Select) to select a menu item. Press and hold to reset

values on certain screens.

4. Press the le or right side of the control bar to retain the

information view and to exit the display zone.

See Instruments and Controls in your Owner Manual.

HEAD-UP DISPLAY♦

e Head-Up Display (HUD) projects some operating information

onto the windshield, reducing the need to look away from the road.

e HUD controls are located on the le side of the instrument panel.

HUD

Li up or press down to adjust the position of the image. It cannot

be adjusted side-to-side.

INFO

Press to select from four displays: Speed View; Audio/Phone View;

Navigation View; and Performance View.

Li up or press down to brighten or dim the display.

Hold down to turn o the display.

ROTATION OPTION

Adjust the angle of the HUD image to compensate for windshield

variations.

To adjust the angle of the HUD, use the 5-way control to view

the Options menu on the instrument cluster and select HUD

Rotation.

See Instruments and Controls in your Owner Manual.

♦Optional equipment

TOUCH SCREEN AND CONTROLS♦

Applications:

Touch the screen icon to

access the application

Wi-Fi

Indicator

See your Cadillac CUE Infotainment System Manual.

Power/Mute:

Press and hold to turn

Cadillac CUE On/O; press to

mute/unmute audio

Climate Control Fan Speed

Defrost Mode

Driver’s Temperature

Control

Additional Pages:

Touch to view additional

pages of applications

Interaction Selector:

Touch to display the

favorites list

Passenger’s Temperature

Control

Passenger’s Heated

Seat Control♦

Driver’s Heated

Seat Control♦

The controls use capacitive technology – simply touch the icon/text

to access a feature or adjust a function.

VOLUME:

Touch arrows or swipe

ﬁnger above chrome bar

AUTO:

Automatic Climate

Control Operation

Rear Window Defog

Recirculation Mode

Home Page

Storage Compartment

(with USB port and

Wireless Charging♦):

Press and hold the bright

bar to open/close

CADILLAC CUE MENUS♦

CUE oers a variety of entertainment, communication and vehicle system options. Touch an application icon on the touch screen to access

the following items.

See your Cadillac CUE Infotainment System Manual.

Audio

• Radio Band

• Media

• Seek Up/Down

• Tune/Play

• Browse

• Menu

Navigation

♦

• Zoom Out

• Zoom In

• Overview

• Destination

• Map Menu

• Seek Up/Down

• Mute/Unmute

• Cancel Destination

Phone

• Voice Recognition

• Contacts

• Recent

• Keypad

• Voice Mail

• Phones

Note: Press and hold

the Push to Talk

steering wheel button to

activate Voice Pass-Thru.

See page 12.

Climate

• Driver/Vehicle

Set Temperature

• Passenger

Set Temperature

• Sync Temperature

Seings

• A/C Mode

• Automatic Climate

On/O

• Air Delivery Seings

• Fan Speed

Settings

• Time and Date

• Rear Seat Reminder

• Language

• Valet Mode

• Teen Driver

• Radio

• Vehicle

• Bluetooth

• Apple CarPlay

• Android Auto

• Voice

• Display

• Rear Camera

• Return to Factory

Seings

• Soware Information

♦Optional equipment

CADILLAC CUE FEATURES♦

Refer to your Owner Manual for important safety information about using the infotainment system while driving.

Cadillac CUE uses a Bluetooth or USB connection to link a compatible smartphone, cell phone, USB ash drive or portable audio player/iPod®

to the touch screen infotainment display. It oers a variety of entertainment options and features enhanced hands-free voice control.

For assistance, call 1-855-4-CUE-NOW (1-855-428-3669) or visit my.cadillac.com/learn.

Tap

Touch and Hold

Drag

Spread

Pinch

SETTING THE TIME

1. Touch Seings on the Home page.

2. Touch Time and Date.

3. Touch Set Time.

4. Touch +or – to adjust the hours, minutes, and AM or PM.

5. Touch Back to exit the menu.

If the Auto Set feature is enabled, the time will be updated

automatically as the system obtains time information from the

cellular network.

PORTABLE AUDIO DEVICES

USB ports and an auxiliary audio input jack are located in the center

console storage compartment.

Connect an iPod®, iPhone®, MP3 player, a USB ash drive or a

USB mass storage device to the USB port.

Touch Audio, and then touch Media until the connected

device is shown. Cadillac CUE will read the device and build a

list of voice commands. Search for music on-screen or by voice

commands.

INTERACTING WITH THE CADILLAC CUE SYSTEM

You can use simple gestures on the touch screen just as you would

on a smartphone to interact with the Cadillac CUE system.

Autres manuels pour ATS 2017

Table des matières

Autres manuels Cadillac Automobile

Cadillac

Cadillac 2014 Escalade Manuel utilisateur

Cadillac

Cadillac 2008 DTS Manuel utilisateur

Cadillac

Cadillac 1995 sedan deville Manuel utilisateur

Cadillac

Cadillac XT6 2020 Manuel utilisateur

Cadillac

Cadillac 2014 XTS Manuel utilisateur

Cadillac

Cadillac 1995 Fleetwood Manuel utilisateur

Cadillac

Cadillac CTS-V SEDAN 2013 Manuel utilisateur

Cadillac

Cadillac 2004 XLR Manuel utilisateur

Cadillac

Cadillac 2009 SRX Manuel utilisateur

Cadillac

Cadillac ATS 2013 Manuel utilisateur

Cadillac

Cadillac ESCALADE ESV 2004 Manuel utilisateur

Cadillac

Cadillac XT5 2017 Manuel utilisateur

Cadillac

Cadillac 60 Series 1963 Guide d'installation

Cadillac

Cadillac 2011 Escalade Hybrid Manuel utilisateur

Cadillac

Cadillac CT4 2022 Manuel utilisateur

Cadillac

Cadillac XT4 2020 Manuel utilisateur

Cadillac

Cadillac 1967 VVI Guide produit

Cadillac

Cadillac 2006 DTS Manuel utilisateur

Cadillac

Cadillac SRX 2011 Manuel utilisateur

Cadillac

Cadillac CTS SEDAN - BROCHURE 2010 Manuel utilisateur

Cadillac

Cadillac 2016 ELR Manuel utilisateur

Cadillac

Cadillac 2010 Escalade Manuel utilisateur

Cadillac

Cadillac ATS 2018 Manuel utilisateur

Cadillac

Cadillac 2006 CTS-V Manuel utilisateur

Manuels Automobile populaires d'autres marques

Toyota

Toyota 2000 Tundra Manuel utilisateur

CITROËN

CITROËN DS4 DSign Manuel utilisateur

Lexus

Lexus 2015 CT 200h Manuel utilisateur

Mercedes-Benz

Mercedes-Benz M-class ML 55 AMG Manuel utilisateur

Porsche

Porsche Boxster S Manuel utilisateur

GMC

GMC 2010 Savana 1500 Cargo Manuel utilisateur

KIAM

KIAM SPORTAGE 2014 Manuel de la liste des pièces

GMC

GMC 2013 Terrain Instructions de montage

GMC

GMC T-Series 1999 Manuel utilisateur

Mercury

Mercury 1998 Mystique Manuel utilisateur

Mercury

Mercury 2007 Mariner Manuel utilisateur

Mazda

Mazda 2007 Mazdaspeed 3 Mode d’emploi

Mazda

Mazda 2014 CX-5 Manuel utilisateur

GMC

GMC Chevrolet Express 2022 Manuel utilisateur

GMC

GMC 1997 Jimmy Manuel utilisateur

Chevrolet

Chevrolet 2012 Malibu Manuel utilisateur

Skoda

Skoda FABIA RS - ANNEXE 118 Manuel utilisateur

Seat

Seat toledo Manuel utilisateur
