Crestron Driver User Manual
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 2
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Table of Contents
Statement 4
Safety Precaution 4
Introduction 5
Installation 5
Inputs 6
Outputs 8
Tech Support 10
Warranty 10
Mission Statement 10
Copyright 10
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 3
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Statement
Please read these instructions carefully before connecting, operating, or configuring this
product. Please save this manual for future reference.
Safety Precaution
●To prevent damaging this product, avoid heavy pressure, strong vibration, or immersion
during transportation, storage, and installation.
●The housing of this product is made of organic materials. Do not expose to any liquid,
gas, or solids which may corrode the shell.
●Do not expose the product to rain or moisture.
●Unplug this device during lightning storms
●Clean only with a soft dry microfiber cloth.
●To prevent the risk of electric shock, do not open the case. Installation and maintenance
should only be carried out by qualified technicians.
●Do not use the product beyond the specified temperature, humidity, or power supply
specifications.
●This product does not contain parts that can be maintained or repaired by users.
Damage caused by dismantling the product without authorization from BZBGEAR is not
covered under the warranty policy.
●Installation and use of this product must strictly comply with local electrical safety
standards.
●Only use accessories specified by the manufacture
●Product specifications may be subject to technical upgrades without further notice
●Do not hot plug when it is working.
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 4
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Introduction
This driver has been designed to provide control for the BZBGEAR BG-UMV-HA41 via
RS-232.
Installation
●You will need to copy all of the files in the folder to your project directory to allow
Simpl Windows to recognize the driver module.
●To utilize the RS-232 link use the following settings:
○Baud Rate: 9600
○Data Bits: 8
○Parity: None
○Stop Bits: 1
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 5
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Inputs
The module has the following commands available as inputs:
Command
Type
Description
Rx$
STRING
Product information feedback input.
Reboot
DIGITAL
Reboot the system, trigger on rising edge.
Factory Reset
DIGITAL
Factory reset the system, trigger on rising
edge.
Set_Video_Routing_A
ANALOG
Switch an input [1 ~ 4] AV signal to A
window.
1 ~ 4
1 - HDMI 1
2 - HDMI 2
3 - HDMI 3
4 - HDMI 4
Set_Video_Routing_B
ANALOG
Switch an input [1 ~ 4] AV signal to B
window.
1 ~ 4
1 - HDMI 1
2 - HDMI 2
3 - HDMI 3
4 - HDMI 4
Set_Video_Routing_C
ANALOG
Switch an input [1 ~ 4] AV signal to C
window.
1 ~ 4
1 - HDMI 1
2 - HDMI 2
3 - HDMI 3
4 - HDMI 4
Set_Video_Routing_D
ANALOG
Switch an input [1 ~ 4] AV signal to D
window.
1 ~ 4
1 - HDMI 1
2 - HDMI 2
3 - HDMI 3
4 - HDMI 4
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 6
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Set_Layout
ANALOG
Set multiview mode. [PARAM]=1 ~ 20
1 - 1 WINDOWS Full
2 - 2 WINDOWS PBP
3 - 3 WINDOWS 2U1D
4 - 4 WINDOWS SAME SIZE
5 - 2 WINDOWS PIP LU
6 - 2 WINDOWS PIP LD
7 - 2 WINDOWS PIP RU
8 - 2 WINDOWS PIP RD
9 - 4 WINDOWS PBP 3L1R
10 - 4 WINDOWS PBP 1L3R
11 - 4 WINDOWS PBP 3U1D
12 - 4 WINDOWS PBP 1U3D
13 - 4 WINDOWS PIP 1F3L
14 - 4 WINDOWS PIP 1F3R
15 - 4 WINDOWS PIP 1F3U
16 - 4 WINDOWS PIP 1F3D
Set_Audio_Mix
ANALOG
Enable/Disable audio mix. 0-Disable
1-Enable
Set_Audio_Mute
ANALOG
Mute/Unmute audio. 0-Disable
1-Enable
Set_Audio_Src
ANALOG
Set the audio output source.
1- HDMI 1
2 - HDMI 2
3 - HDMI 3
4 - HDMI 4
5 - Line in
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 7
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Outputs
The module has the following commands available to be used as feedback outputs:
Command
Type
Description
Tx$
STRING
High to indicate the last preset selected.
FB_Input_[InputParam]_Scr
een_ [OutputParam]
DIGITAL
The current AV switching status of
input and output channel.
[InputParam]=1 ~ 4.
[OutputParam]=A ~ D.
FB_LAYOUT [PARAM]
DIGITAL
The current multiview mode
status. [PARAM]=1 ~ 20
1-1 WINDOWS Full
2-2 WINDOWS PBP
3-3 WINDOWS 2U1D
4-4 WINDOWS SAME SIZE
5-2 WINDOWS PIP LU
6-2 WINDOWS PIP LD
7-2 WINDOWS PIP RU
8-2 WINDOWS PIP RD
9-4 WINDOWS PBP 3L1R
10-4 WINDOWS PBP 1L3R
11-4 WINDOWS PBP 3U1D
12-4 WINDOWS PBP 1U3D
13-4 WINDOWS PIP 1F3L
14-4 WINDOWS PIP 1F3R
15-4 WINDOWS PIP 1F3U
16-4 WINDOWS PIP 1F3D
FB_Audio_Mix [PARAM]
DIGITAL
The audio Mix status [PARAM]=0 ~ 1
0-Disable 1-Enable
FB_Audio_Mute [PARAM]
DIGITAL
The audio mute status [PARAM]=0 ~ 1
0-Disable 1-Enable
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 8
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
FB_Audio_Out [PARAM]
DIGITAL
The current audio output source.
[PARAM]=1 ~ 5
1- HDMI 1
2- HDMI 2
3- HDMI 3
4- HDMI 4
5- LINE IN
Address: 830 National Drive #140, Sacramento, CA 95834, USA ·Tel: +1(888)499-9906 ·Email: support@bzbgear.com 9
BZBGEAR BG-UMV-HA41 Crestron Driver User Manual
Tech Support
Have technical questions? We may have answered them already!
Please visit BZBGEAR’s support page (bzbgear.com/support) for helpful information and
tips regarding our products. Here you will find our Knowledge Base
(bzbgear.com/knowledge-base) with detailed tutorials, quick start guides, and step-by-step
troubleshooting instructions. Or explore our YouTube channel, BZB TV
(youtube.com/c/BZBTVchannel), for help setting up, configuring, and other helpful how-to
videos about our gear.
Need more in-depth support? Connect with one of our technical specialists directly:
Phone
1.888.499.9906
Email
support@bzbgear.com
Live Chat
bzbgear.com
Warranty
BZBGEAR Pro AV products and cameras come with a three-year warranty. An extended
two-year warranty is available for our cameras upon registration for a total of five years.
For complete warranty information, please visit bzbgear.com/warranty.
For questions, please call 1.888.499.9906 or email support@bzbgear.com.
Mission Statement
BZBGEAR is a breakthrough manufacturer of high-quality, innovative audiovisual equipment
ranging from AVoIP, professional broadcasting, conferencing, home theater, to live
streaming solutions. We pride ourselves on unparalleled customer support and services.
Our team offers system design consultation, and highly reviewed technical support for all
the products in our catalog. BZBGEAR delivers quality products designed with users in
mind.
Copyright
All the contents in this manual and its copyright are owned by BZBGEAR. No one is allowed
to imitate, copy, or translate this manual without BZBGEAR’s permission. This manual
contains no guarantee, standpoint expression or other implies in any form. Product
specification and information in this manual is for reference only and subject to change
without notice.
All rights reserved. No reproducing is allowed without acknowledgement.
