BYD AUTO S6, S6A, S6K Owner's Manual

BYD S6, S6A, S6K

Owner’s Manual

BYD AUTO S6, S6A, S6K Owner's Manual

BYD Auto Sincere Service Commitment

Dear Users:

Thanks for your choice. Thanks to your concern, some of our services are superior to the industry standard; thanks to your

suggestions, we continue to pursue better service. In order to provide you with excellent service, we are committed to:

1. Keep smile and enthusiastic whenever and wherever;

2. Provide you with a clean environment for rest;

3. Provide you with warm reception the first time you enter into the shop;

4. Valuate the machine repair items before servicing; give the final price of maintenance items; new items will subject to your

confirmation; before settlement, we will check with you item by item again;

5. Estimate the servicing time and follow up; notify you immediately if there is any delay. If you want to check the servicing

process, I will reply in 10 minutes;

6. In the servicing process, I use the six-piece suit interior protection and three-piece exterior protection for your car.

7. Only use genuine parts;

8. Whatever question or need, I will reply immediately until solved;

9. I will pay a return visit within three days to ensure that your car drives normally;

10. Any opinion and suggestion are appreciated.

Version 201211

Without the written permission of BYD, it is prohibited to reproduce or photocopy any part of

this manual.

BYD AUTO S6, S6A, S6K Owner's Manual

Foreword

Thank you for choosinga BYDAUTO.To help you use and maintain your BYDAUTO, please read the Instruction Manual carefully.

If you have any doubts about the instructions, please contact the BYD auto sales service station for help. For more detailed car

information, please visit http://www.bydauto.com.cn/service/manual/index.php

As BYD AUTO adopts the EFI (electronic fuel injection) engine and as its electric wiring structure is complicated, do not install

additional electric appliances yourself, such as anti-theft systems, multi-media systems, and xenon headlights. Please use

original spare parts from BYD. Otherwise, any faults caused will not be covered by BYD's warranty (guarantee of repair,

replacement and return). To prevent loss caused by vehicle accidents, it is suggested that vehicle insurances including the

"self-ignition loss insurance" and the "theft & robbery insurance", etc be purchased. In addition, please do not leave valuables

in your car so as protect your car better and protect your valuables from being stolen.

The manual aims to help you use the car correctly, but does not include all instructions about its configuration. For the

configuration, please consult the contract related to the product (if any), or consult the dealer selling the product to you.

Figures in the manual are for reference only. If any figure in the manual is inconsistent with the actual object, the actual

product will prevail.

BYD Auto Industry Company Limited reserves the right for revising the technical characteristics and contents and the spare

part status alteration in this manual without prior notice.

BYD AUTO S6, S6A, S6K Owner's Manual

Please follow the instructions where "Tips" and "Warning" are indicated in this manual to avoid the possibility of injuries or

damage.

The notice types and their details of use are as follows:

Tips

Precautions to be followed to make

maintenance easier

Thank you for choosing a BYD Auto. Your opinions and suggestions are welcome. To provide better service to you, please

provide accurate contact details, and contact a BYD Sales service station for your information updates. Please obtain the

number plate for your vehicle as soon as possible and pay attention to relevant state laws and regulations.

For car usage communication, please visit BYD Auto Club BBS: http://club.bydauto.com/bbs/

WARNING

Precautions to avoid vehicle

damage or personal injury

BYD AUTO S6, S6A, S6K Owner's Manual

Table of Contents

Vehicle Performance Parameters of BYD AUTO.......................................................................................................................1

Chapter 1 Operation of Instruments and Controls..................................................................................................................1-1

Chapter 2 Driving Guidelines .................................................................................................................................................2-1

Chapter 3 Starting and Driving...............................................................................................................................................3-1

Chapter 4 Emergency Treatment...........................................................................................................................................4-1

Chapter 5 Vehicle Exterior Maintenance................................................................................................................................5-1

Chapter 6 Maintenance Instructions.......................................................................................................................................6-1

Chapter 7 Self-maintenance...................................................................................................................................................7-1

BYD AUTO S6, S6A, S6K Owner's Manual

Vehicle Performance Parameters of BYD AUTO

Product Model S6 S6A S6K

Basic Type Load-type vehicle body structure, 5 doors/1 lid/2 carriages

Drive Mode Front transverse engine, front-wheel drive

Dimensions L×W×H mm 4810×1855×1725 (1680, excluding the luggage rack) (no load)

Wheelbase mm 2720

Tread Front mm (Front/rear) 1580/1555

Wheel

Alignment

Front wheel chamber -0º40´±45´

Front wheel toe-in 0±2mm

Kingpin inclination angle 10º40´±45´′

Kingpin caster angle 2º35´±45´

Rear wheel chamber -0º45´±45´

Rear wheel toe-in 3±2 mm

Curb Weight kg

1620 1665 1695

Gross Weight kg

1995 2040 2070

Front/Rear Axle Load (Gross Weight) kg

1050/945 1055/985 1085/985

Maximum Design Speed

km/h

180 185 185

Tyre Size (Spare) 225/65R17

Tyre Pressure

kPa

210

Approach Angle °(degree)

23.5

BYD AUTO S6, S6A, S6K Owner's Manual

Departure Angle °(degree)

Front Overhang mm

1010

Rear Overhang mm

1080

Minimum Ground Clearance mm

≥190

Minimum Turning Radius m

≤11.8

Passenger Capacity persons

Boot Capacity L

Maximum Grade %

≥30

Brake Pedal Free Travel mm

1-5

Engine Model BYD483QB BYD488QA BYD488QA

Engine Type

In-line four

cylinders/16valves, MPI

fuel injection, dual

overhead camshaft

DOHC

In-line four cylinders/16

valves, MPI fuel injection,

single overhead camshaft

SOHC

In-line four cylinders,

forced circulation water

cooling, dual overhead

camshaft, four strokes

Displacement ml 1991 2362 2362

Max. Torque Nm/rpm 172/4750 229/4000 229/4000

Max. Output Power kw/rpm 95/5800 118/5800 118/5800

Fuel Consumption K/100km

9.2 9.8 9.8

Tyre Balancing Requirement The imbalance amount measured after counterbalance is clamped on each

side of the wheel assembly should be less than 10g

˄1084L/ lay down the second row seats 2398L ˅±5L

BYD AUTO S6, S6A, S6K Owner's Manual

Anti-theft system 1-1

Chapter 1

Section 1

Operation of Instruments and Controls

Anti-theft System

Keys.............................................................................................1-4

Wireless Remote Control Function...............................................1-6

Intelligent Key Access and Starting Function...............................1-8

Steering Lock Function...............................................................1-10

The Battery in the Tntelligent Key Runs out of Power................1-10

Anti-theft System........................................................................1-12

Power Windows .........................................................................1-13

Power Door Lock........................................................................1-13

Back Door ..................................................................................1-15

Sunroof.......................................................................................1-15

BYD AUTO S6, S6A, S6K Owner's Manual

Anti-theft system1-2

BYD Passenger Car Identification

Identification Number of Engine

and Transmission

Your car has several identification

numbers located at different positions.

1. Engine model and engine number

are printed on the engine block.

2. The transmission number is located

on the label on the top of the

transmission.

Do not confuse the transmission

number with the engine number.

Emission system identification

The pollutant emission system of the

car has two identifications:

1. Front three-way catalyst

The other emission system

identification is on the rear three-way

catalyst, in the bottom of the car, as

shown below

Tips

When the engine is started or

just flames out, do not touch it

because it is still hot.

For S6 models in the sale, the

emission identification depends on the

power assembly:

Vehicle Identification Number

The vehicle identification number is

marked on the upper left of the

instrument panel and the floor beam

of the front passenger seat

respectively as shown below. The

vehicle identification number is used

Engine

model

Manual

transmission

number

Engine

model

Auto transmission

number

Front three-way

catalyst

identification

Emission system

identification

BYD AUTO S6, S6A, S6K Owner's Manual

Anti-theft system 1-3

for owner registration.

As shown in the figure below, the

manufacture nameplate in the bottom

of the right side wall B pillar is also

marked with the vehicle identification

number.

The figure below is the fuel grade

nameplate, which is attached to the

inside of the filler cap.

Warning & Tips

The cooling fan warning label and

engine coolant replacement signage

are attached to the inside of the

engine room.

Airbag warning label is attached to the

right sun visor.

Vehicle identification number

Vehicle nameplate

Fuel tank

code

Coolant signage

Cooling fan signage
