Bushnell 23-2811 Manuel utilisateur

Lit. #: 98-1535101-10

Binocular inSTrucTion Manual

TABLE OF CONTENTS

A New Take on What Hard-Core Hunters Demand

Eye Adjustments

Eyecup Adjustment

Focusing

Neckstrap Attachment

Tripod Socket

Waterproof/Fogproof

Instructions for Care

Cleaning

Une Nouveau Point de Vue de Ce Que Les Fervents de la Chasse Exigent

Reglages des Yeux

Ajustement des œilletons

Mise Au Point

Fixation de la Bandoulière

Articulation Du Trepied

Impermeabilite Et Etancheite Au Brouillard

Conseils D’Entretien

Nettoyage

Nueva Opción Para las Demandas de Cazadores Más Exigentes

Ajustes a los Ojos

Ajuste del Ocular

PAGE #

6-7

12-13

13-14

18-19

English

Spanish

French

24-25

25-26

26-27

30-31

31-32

Enfoque

Colocación de la Correa

Receptáculo del Trípode

Resistente Al Agua / Resistenta a la Niebla

Instrucciones Para el Mantenimiento

Limpieza

Eine Neue Lösung Für Das, Was Eingeﬂeischte Jäger Fordern

Augenpassung

Einstellen Der Augenmuscheln

Fokussieren

Anbringen Des Tragegurts

Stativöffnung

Wasserdicht / Nebeldicht

Handhabungshinweise

Reinigung

Una Prospettiva Nuova Per Le Esigenze Dei Cacciatori Piu’ Intransigenti

Regolazioni Per Gli Occhi

Registrazione Della Conchiglia Oculare

Messa a Fuoco

Attacco Della Tracolla

Zoccolo Per Treppiede

Impermeabile / Antiappannante

Istruzioni Per La Manutenzione Del Binocolo

Pulizia

German

Portugese

A NEW TAKE ON WHAT HARD-CORE

HUNTERS DEMAND. Enviro-Friendly. From the lead

& arsenic free EF glass to the

new Dura-Grip rubber, all Trophy

XLT binoculars are made with

environmentally friendly materials.

Fast Focus. Because every

second counts when you’re

tracking wild game, the focus

wheel moves from near to far with

increased speed, while retaining

the accurate precision you need.

Flip Objective Covers. Attached,

hinged protective lens caps keep

you ready to glass an area quickly

without fumbling with removable

caps that can get left in the mud.

World-Class Optics and Heightened Durability.

With light transmission, clarity and ruggedness

as top priorities, we set out to build the ultimate

hunting binoculars. The XLT series was born, with a new

housing material that’s both durable and comfortable

to use — and environmentally responsible. Fully multi-

coated optics and BaK-4 prisms work together

to deliver ultra-bright, razor-sharp images through

the most critical periods of game movement. And

the tough, streamlined Dura-Grip rubber armored

housing is O-ring sealed and nitrogen purged for

100% waterproof/fogproof dependability. Soft-touch

thumbgrips further improve handling ease, and the

objective lenses are well protected from the elements

by ﬂip covers.

English

Thank you for purchasing your new Bushnell Trophy® XLT Binoculars.

This manual will help you optimize your viewing experience by explaining how you can adjust the

binocular to your eyes, and how to care for this instrument.

Read these instructions carefully before using your binocular.

EYE ADJUSTMENTS

How to Adjust for Distance Between Your Eyes

The distance between the eyes, called “interpupillary distance,” varies from person to person.

To achieve perfect alignment of lens to eyes, follow these simple steps:

1. Hold your binocular in the normal viewing position.

2. Grasp each barrel ﬁrmly. Move the barrels closer together or further apart until you see a

single circular ﬁeld. Always re-set your binocular to this position before using it.

How to Adjust for Individual Eye Strength

As individual eyesight varies from one person to another, your Bushnell Trophy XLT binocular has a

diopter setting feature which allows you to ﬁne-tune the binocular to your vision. Follow the focusing

instructions on the next page.

EYECUP ADJUSTMENT

Your Bushnell Trophy XLT binocular is ﬁtted with twist-up eyecups designed for your comfort and to

exclude extraneous light. For users without eyeglasses, twist the eyecups up, rotating the eyecups

counter-clockwise until they lock into the fully “up” position.

If you wear glasses, make sure the eyecups are in the down position — this will bring your eyes closer

to the binocular lens, allowing you to see the full ﬁeld of view. To lower the eyecups from the full “up”

position, rotate them clockwise. The eyecups may also be left at positions “in between” fully up and fully

down, which may suit some individuals better.

FOCUSING

1. Adjust the interpupillary distance by adjusting the center hinge until you see a single circular

image.

2. The diopter adjustment ring is located directly below the right eyecup. Make sure the diopter

adjustment is set to “zero” for now (raised index tab on the diopter ring is lined up with center mark

on the binocular). Keep both eyes open at all times.

3. Using the attached lens cap or your hand, cover the objective (front) lens on the right side of the

binocular as you look into the eyepieces.

4. Using the center focus knob, focus on a distant object with ﬁne detail (e.g., brick wall, tree

branches, etc) until it appears as sharp as possible on the left side.

5. Uncover the objective lens on the right side, and cover the left objective lens while continuing to

view the same object.

6. Rotate the diopter adjustment ring to bring the object into focus in the right side of the binocular.

Avoid over-turning or forcing the diopter mechanism. If you are unable to bring the object into

focus in the right side by adjusting the diopter ring, make sure the left side is still focused and

that the center focus knob was not moved from its original setting. The diopter adjustment only

affects the right side.

7. Your binocular should now be adjusted for your eyes. Focusing for any distance can now be done

simply by turning the center focus knob. Make a note of the diopter setting you made (index tab

position relative to the +/- scale) for future reference.

NECKSTRAP ATTACHMENT

Thread the ends of the neckstrap through the strap lugs on each side of the binocular, then back

through the plastic buckle. Adjust the position of the binoculars on your chest as they hang around

your neck to your preference by changing the length of the strap portion which passes through the lug

and buckle (by an equal amount on each side).

TRIPOD SOCKET

To attach the Trophy XLT to a tripod or monopod, unscrew (counter-clockwise)

the “B” logo cap which covers the threaded socket inside the center hinge,

and set it aside in a safe place. Use a compatible binocular tripod adapter,

such as the Bushnell model #161001CM, (an accessory bracket, shown here,

which attaches between the binocular and tripod) to attach your Trophy XLT

to any standard tripod in a horizontal position to provide a stable image during

prolonged viewing.

WATERPROOF / FOGPROOF

Your Bushnell Trophy XLT binocular has been designed and built utilizing the latest waterproof and

fogproof technology. The binoculars are O-ring sealed for complete moisture protection. Fogproof

protection is achieved from dry nitrogen purging that removes all internal moisture.

Binocular Tripod

Adapter (optional)

(Bushnell#161001CM)

NEVER LOOK DIRECTLY AT THE SUN WITH YOUR BINOCULAR

AS IT MAY CAUSE SERIOUS DAMAGE TO YOUR EYES

INSTRUCTIONS FOR CARE

Your Bushnell Trophy XLT binocular will provide years of trouble-free service if it receives the normal

care you would give any ﬁne optical instrument.

1. Avoid sharp impacts. Set the binocular down gently on hard surfaces.

2. Tug on the strap after attaching it to make sure it is securely fastened to the binocular before

placing it around your neck.

3. Store your binocular in a cool, dry place whenever possible.

CLEANING

1. Blow away any dust or debris on the lens (or use a soft lens brush).

2. To remove dirt or ﬁnger prints, clean with the supplied micro-ﬁber cloth rubbing in a circular

motion. Use of a coarse cloth or unnecessary rubbing may scratch the lens surface and

eventually cause permanent damage. The included, washable “microﬁber” cleaning cloth is

ideal for the routine cleaning of your optics. Simply breathe lightly on the lens to provide a slight

amount of moisture, then gently rub the lens with the microﬁber cloth.

3. For a more thorough cleaning, photographic lens tissue and photographic-type lens cleaning

ﬂuid or isopropyl alcohol may be used. Always apply the ﬂuid to the cleaning cloth – never

directly on the lens.

WARRANTY/REPAIR

LIFETIME LIMITED WARRANTY

We are so proud of our Bushnell Trophy® XLT Binoculars that their materials and workmanship are warranted to be free of defects for the life

of the binocular. The warranty is available to any owner of the Trophy® XLT Binocular. This warranty does not cover damages caused by misuse

or improper handling, installation or maintenance of the binoculars. At our option, we will repair or replace any defective Trophy® XLT binocular,

which shall be your sole remedy under this warranty. In no event shall we be liable for transportation costs to us, costs of removal or reinstallation

of the binocular, or incidental or consequential damages. Some states do not allow the exclusion of limitation of incidental or consequential

damages, so the above limitation or exclusion may not apply to you.

Any return in the U.S. or Canada made under this warranty must be accompanied by the items listed below:

1) A check/money order in the amount of $10.00 to cover the cost of postage and handling

2) Name and address for product return

3) An explanation of the defect

4) Proof of Purchase

5) Product should be well packed in a sturdy outside shipping carton, to prevent damage in transit, with return postage prepaid to the

address listed below:

IN U.S.A. Send To: IN CANADA Send To:

Bushnell Outdoor Products Bushnell Outdoor Products

Attn.: Repairs Attn.: Repairs

8500 Marshall Drive 25A East Pearce Street, Unit 1

Lenexa, Kansas 66214 Richmond Hill, Ontario L4B 2M9

For products purchased outside the United States or Canada please contact your local dealer for applicable warranty information. In Europe you

may also contact Bushnell at: Bushnell Germany GmbH

European Service Centre

Mathias-Brüggen-Str. 80

D-50827 Köln

GERMANY

Tel: +49 221 995568-0

Fax: +49 221 995568-20

This warranty gives you speciﬁc legal rights. You may have other rights which vary from country to country.
